FXA XCLICK FXAGY1946 User manual

FXAGY1946
Instruction manual (Original instructions) GB pg 6-17
Käyttöohje (Alkuperäisten ohjeiden käännös) FI s. 18-29
Bruksanvisning (Översättning av originalinstruktionerna) SE s. 30-41
Bruksanvisning (Oversettelse av de opprinnelige instruksjonene) NO s. 42-53
Kasutusjuhend (Tõlgitud originaal juhendist) EE l. 54-65
Instrukcijas (Tulkojums no oriģinālvalodas) V l. 66-77
Instaliavimo instrukcijos (Vertimas originali instrukcija) T s. 78-89

2
(1)
11
4
8
12
9
10
12
13
14
3
7
15
6
5

3
(2) (3)
(4) (5)
(6) (7)
(8) (9) 9.2 9.3
9.1

4
(10) (11)
(12) (13)
(14) (15)
(16) (17)
10.1

5
(18) (19)
(20) (21) 21.1
21.2

6
INTRODUCTION
Thank you for purchasing this product which has
passed through our extensive quality assurance
process. very care has been taken to ensure that it
reaches you in perfect condition.
SAFETY FIRST
Before attempting to operate this power tool the
following basic safety precautions should always be
taken to reduce the risk of fire, electric shock and
personal injury. It is important to read the instruction
manual to understand the application, limitations and
potential hazards associated with this tool.
CERTIFICATE OF GUARANTEE
This product is guaranteed for a period of 2 Years,
with effect from the date of purchase and applies only
to the original purchaser. This guarantee only applies
to defects arising from, defective materials and or
faulty workmanship that become evident during the
guarantee period only and does not include
consumable items. The manufacturer will repair or
replace the product at their discretion subject to the
following. That the product has been used in
accordance with the guide lines as detailed in the
product manual and that it has not been
subjected to misuse, abuse or used for a purpose for
which it was not intended. That it has not been taken
apart or tampered with in any way whatsoever or has
been serviced by unauthorised persons or has been
used for hire purposes. Transit damage is excluded
from this guarantee, for such damage the transport
company is responsible. Claims made under this
guarantee must be made in the first instance, directly
to the retailer within the guarantee period. Only under
exceptional circumstances should the product be
returned to the manufacturer. In these case it shall be
the consumer’s responsibility to return the product at
their cost ensuring that the product is adequately
packed to prevent transit damage and must be
accompanied with a brief description of the fault and
a copy of the receipt or other proof of purchase. The
manufacturer shall not be liable for any special,
exemplary, direct, indirect, incidental, or consequential
loss or damage under this guarantee. This guarantee
is in addition to and does not affect any rights, which
the consumer may have by virtue of the Sale of Goods
Act 1973 as amended 1975 and 1999.
The power tool is intended for domestic use only.
The power tool is not suitable and is not intended
for commercial or professional use.
The warranty does not cover defects and damage
to power tools resulting from use for purposes
other than domestic use, in particular as a result of
pushing through and abuse.
”Warranty is voided in case the tool is damaged due
to one of the conditions below:
1. Misuse of product or negligence of proper
maintenance of product,
2. Commercial, professional or rental use of product,
3. Repair done by an unauthorized service company.
4. Damages caused by external objects or
substances.”
STATUTORY RIGHTS
This guarantee is in addition to and in no way affects
your statutory rights.
PRODUCT DISPOSA
When this product reaches the end of it’s life or is
disposed of for any other reason, it must not be
disposed of in household waste. In order to preserve
natural resources, and to minimise adverse
environmental impact, please recycle or dispose of
this product in an environmentally friendly way. It
should be taken to your local waste recycling centre
or other authorised collection and disposal facility.
If in doubt consult your local waste authority for
information regarding available recycling and / or
disposal options.
IMPORTANT INFORMATION ABOUT THIS
PRODUCT
This product is specifically designed to work with the
FXA XCLICK range of batteries and charger.
INTENDED USE
The line trimmer/brush cutter is intended to be used
only by adults who have read and understood the
instructions and warnings in this manual and can be
considered responsible for their actions. This product
is only intended for use outdoors in a well ventilated
area. For safety reasons, the product must be
adequately controlled by using two-handed operation.
When fitted with the line trimmer cutting head, the
product is intended for cutting long grass, pulpy
weed, and similar vegetation at or about ground level.
When fitted with the 3-tooth blade, it can also cut
bushes.
The cutting plane should be approximately parallel to
the ground surface. The product should not be used
to cut or trim hedges, bushes, or other vegetation
where the cutting plane is not parallel to the ground
surface.
SAFETY INSTRUCTIONS
Usage of line trimmer/brush cutter (the tool) always
involves the risk of accidents, therefore please
observe the relevant accident prevention instructions.
The tool has been constructed according to the latest
technology and in accordance with the recognized
technical safety regulations. Nevertheless, use of the
tool can involve risks to the user or the third persons,
and can cause damage to the tool or other objects.
Charger Battery
(Not Included) (Not Included)
FXADL1051 FXAJDB180Li
FXAJD3IN1BCT FXAJDB180Li-II

7
WARNING! This tool is not intended for use by young
children or infirm persons unless they have been
adequately supervised by a responsible person to
ensure that they can use the tool safely. Young
children should be supervised to ensure that they do
not play with the tool.
WARNING! Using battery powered power tools, you
must observe following safety instructions to protect
yourself against electric shock, danger of injuries and
danger of fire.
Read all these instructions before using the grass
trimmer and observe strictly. Keep these safety
instructions at a safe place.
Use the tool in a safety conscious manner and for
suitable applications. Immediately rectify or have
rectified any faults which could adversely affect
safety!
This tool may cause serious injuries. Please read the
instruction manual carefully as to the correct handling,
the preparations, the maintenance and the proper use
of the grass trimmer. Familiarise yourself with the tool
before the first use and also have you introduced to
practical use of the tool.
TRAINING
Never allow children or people unfamiliar with the
instructions to use the product.
Read the instructions carefully. Be familiar with all
controls and the proper use of the product.
Keep the area clear of all bystanders, children and
pets while trimming. Stop the product if anyone enters
the area.
Never operate the product when you are tired, ill or
under the influence of alcohol, drugs, or medicine.
Use the product for cutting grass and light weeds
only. Do not use for any other purpose.
Keep in mind that the operator or user is responsible
for accidents or hazards occurring to other people or
their property.
PREPARATION
Wear full eye and hearing protection while operating
the product. If working in an area where there is a risk
of falling objects, head protection must be worn.
Wear eye protection which is marked to comply with
ANSI Z87.1 when operating this product.
Hearing protection may restrict the operator’s ability
to hear warning sounds
Pay particular attention to potential hazards around
and inside the work area.
Wear heavy long trousers, boots, and gloves. Do not
wear loose fitting clothing, short trousers, jewellery of
any kind, or use with bare feet.
Secure long hair so it is above shoulder level to
prevent entanglement in moving parts.
Before use and after any impact, check that there are
no damaged parts. A defective switch or any part that
is damaged or worn should be properly repaired or
replaced by an authorised service facility.
Make sure the cutting attachment is properly installed
and securely fastened.
Never operate the product unless all guards,
deflectors and handles are properly and securely
attached.
Consider the environment in which you are working.
Keep the working area free from wires, sticks, stones
and debris, which if struck by the cutter, can become
thrown objects.
INE TRIMMER SAFETY WARNINGS
Some regions have regulations that restrict the use of
the product. Check with your local authority for
advice.
Never allow children or people unfamiliar with the
instructions to use the product.
Use the product in daylight or good artificial light.
Avoid using on wet grass.
Do not walk backwards when using the product.
Keep firm footing and balance. Do not overreach.
Overreaching can result in loss of balance. Always be
sure of your footing on slopes. Walk, never run.
Do not operate the product when there is a risk of
lightning.
Do not expose the product to rain or wet conditions.
Water entering an appliance will increase the risk of
electric shock.
Keep bystanders, children and pets 15 m away from
the area of operation, stop the product if anyone
enters the area.
Keep the cutting attachment below waist level.
Never operate the product with damaged guards or
without guards in place.
Never fit a metal replacement line.
Keep hands and feet away from the cutting means at
all times, especially when switching on the motor.
Beware, the cutting elements continue to rotate after
the motor is switched off.
Beware of objects thrown by the cutting means. Clear
debris like small stones, gravel and other foreign
objects from the work area before starting operation.
Wires or string may become entangled with the
cutting means.

Switch off and disconnect from the power supply
before:
•servicing
•leaving the product unattended
•cleaning your product or clearing a blockage
•changing accessories
•checking for any damage after hitting an object
•checking for any damage if the product
•starts to vibrate abnormally
•performing maintenance
•removing blade or line
•installing blade or line
Always ensure that ventilation openings are kept clear
of debris.
Make sure the debris shield is properly installed and
securely fastened.
Make sure all guards, deflectors and handles are
properly and securely attached.
Do not modify the product in any way. This may
increase the risk of injury to yourself or others.
Use only the manufacturer’s replacement cutting line.
Do not use any other cutting attachment.
Immediately switch off and disconnect the battery in
the event of accident or breakdown. Don’t operate the
product again until it has been fully checked by an
authorised service centre.
BRUSH CUTTER SAFETY WARNINGS
In addition to the above rules, these additional
instructions are appropriate when using the product in
brushcutter mode.
Use heavy-duty gloves while installing or removing
blades, they have sharp edges.
Do not attempt to touch or stop the blade when it is
rotating.
A moving blade can cause severe injury. Maintain
proper control of the machine with both hands until
the blade has completely stopped rotating.
Replace any blade that has been damaged. Always
make sure blade is installed correctly and securely
fastened before each use.
Use only the manufacturer’s replacement 3-tooth
blades. Do not use any other cutting attachment.
Never cut any material over 13 mm diameter.
Your brushcutter is fitted with a harness. Carefully
adjust the harness to fit comfortably and help to
support the weight of the machine at your right side.
Never wear additional clothing over the harness or
otherwise that restrict access to the quick release
mechanism.
Store the blade with the cardboard blade protector
before storing the unit, or during transportation.
Always remove the blade protector before using the
unit. If not removed, the blade protector could
become a thrown object as the blade begins to turn.
xercise extreme caution when using the blade with
this product. Blade thrust is the reaction that may
occur when the spinning blade contacts anything it
cannot cut. This contact may cause the blade to stop
for an instant, and suddenly “thrust” the unit away
from the object that was hit. This reaction can be
violent enough to cause the operator to lose control of
the unit. Blade thrust may occur without warning if the
blade snags, stalls, or binds. This is more likely to
occur in areas where it is difficult to see the material
being cut.
For cutting ease and safety, approach the weeds
being cut from the right to the left. In the event that an
unexpected object or woody stock is encountered,
this practice could minimize the blade thrust reaction.
Both hands must be used at all times to control this
product.
ADDITIONA SAFETY RU ES CHARGERS
1. Before using the charger, read all the instructions
and cautionary markings on the charger and battery
pack as well as the instructions on using the battery
pack.
2. Only charge your batteries indoors as the charger is
designed for indoor use only.
3. DANGER! If the battery pack is cracked or
damaged in any other way, do not insert it in the
charger. There is a danger of electric shock or
electrocution.
4. WARNING! Do not allow any liquid to come into
contact with the charger. There is a danger of electric
shock.
5. The charger and battery packs supplied with it are
specifically designed to work together. Do not attempt
to charge the battery pack with any other charger than
the one supplied.
6. Do not pull on the power cord to disconnect it from
the mains supply socket.
7. Do not use the charger if it has been subjected to a
heavy knock, dropped or otherwise damaged in any
way. Take the charger to an authorised service centre
for a check or repair.
8. Do not disassemble the charger. Take it to an
authorised service centre when service or repair is
required. Incorrect re-assembly may result in the risk
of fire, electric shock or electrocution.
9. To reduce the risk of an electric shock, unplug the
charger from the power supply before attempting to
clean it. Removing the battery alone does not reduce
the risk.
8

ADDITIONA SAFETY RU ES FOR THE BATTERY
PACK
1. The battery pack for this tool has been shipped in a
low charge condition. You should charge the battery
pack fully before use.
2. Do not incinerate the battery pack even if it is
seriously damaged or can no longer hold a charge.
The battery pack can explode in a fire.
3. A small leakage of liquid from the battery pack may
occur under extreme usage or temperature conditions.
This does not necessarily indicate a failure of the
battery pack. However, if the outer seal is broken and
this leakage comes into contact with your skin wash
the affected area quickly with soap and water. If the
leakage gets in your eyes flush your eyes with clean
water for a minimum of 10 minutes and seek
immediate medical attention.
Inform the medical staff that the liquid is a 25-35%
solution of potassium hydroxide.
4. Never attempt to open the battery pack for any
reason. If the plastic housing of the battery pack
breaks open or cracks, immediately discontinue its
use and do not recharge it.
5. Do not store or carry a spare battery pack in a
pocket or toolbox or any other place where it may
come into contact with metal objects. The battery
pack may be short- circuited causing damage to the
battery pack, burns or a fire.
BATTERY CHARGING INFORMATION
Charging rates for NiCad and/or Li-Ion NiCad and/or
Li-Ion battery charging rates are determined by the
time taken to fully charge the battery and are
determined by the charge current. The three most
commonly used charging rates are typically:
Fast charge.
Slow charge.
Trickle charge.
FAST CHARGE BATTERIES
The charging rates for fast charge batteries can vary
between 30 minutes and 90 minutes. The charging
rate for the battery supplied with a cordless power
tool is stated in the product manual.
S OW CHARGE BATTERY
The charging rates for slow charge batteries are
between 3 hours and 5 hours.
TRICK E CHARGE BATTERIES
The charging rates for trickle charge batteries are
between 7 hours and 9 hours.
IMPORTANT!
NICAD AND/OR I-ION BATTERY CHARGING
INFORMATION.
AWAYS FU Y DISCHARGE A NiCad and/or i-
Ion BATTERY BEFORE CHARGING AND NEVER
EXCEED THE CHARGING RATE TIME, EXCEPT
WHEN “CONDITIONING” A NEW BATTERY.
CHARGING PROCEDURE
When charging a new NiCad and/or Li-Ion battery it
should be fully discharged followed by a full charge
for the charging rate for the battery as stated in the
product manual plus 30 minutes.
This should then be followed by a full discharge and a
further full charge for the charging rate for the battery
as stated in the product manual plus 30 minutes. This
procedure will condition the battery and equalise the
cell voltages. Following this procedure will ensure the
optimum operation of the battery.
When repeatedly using the charger to charge a
number of batteries always allow the charger to cool
down before charging another battery. It is
recommended that the cooling down period is not
less than 30 to 45 minutes.
When charging a battery that has been discharged
during heavy use allow the battery to cool down
before charging. It is recommended that the cooling
down period is not less than 30 to 45 minutes.
NICAD AND/OR I-ION CHARGING & CHARGERS
NiCad and/or Li-Ion batteries need to be recharged
with a reasonable amount of care, largely because
they can be damaged by overcharging.
Overcharging can result in the battery temperature
and internal pressure to rise rapidly. This can cause
the cells to distort and lose electrolyte, and in extreme
cases where the internal pressure is extremely high
they can even explode.
This situation can also arise when an overcharged
battery is fitted to the product and is being used. In
order to avoid this extreme situation it is of vital
importance that NiCad and/or Li-Ion batteries are fully
discharged before charging and that the charge time
is not exceeded except when “Conditioning” a new
battery. Repeated charging of partially discharged
batteries could cause failure of one or more of the
cells.
SE F DISCHARGE
A lithium battery can self discharge and lose its stored
charge. Typically it can lose approximately 5% of its
charge in the first month after fully charging (when
stored at room temperature), and then loses it by a
further 3% per month. When stored at higher
temperatures the self discharge rate will be
accelerated.
BATTERY CHARGING INDOORS
This charger is designed to be used indoors. We do
not recommend that it is used inside your home.
Ideally batteries should be charged on a bench in a
workshop, garage or shed.
9

If the charging operation is to be carried out in your
home the area must be well ventilated and the charger
must be placed on a non combustible surface
ensuring that the ventilation slots are not blocked.
Never exceed the charging time except when
“Conditioning” a new battery, as this could damage
the battery and charger.
BATTERY DISPOSA
When the battery fails to charge or maintain its
charge, its usable life is exhausted. To preserve
natural resources, please recycle or dispose of the
battery pack properly. This battery pack contains
nickel-cadmium cells. Before disposal ensure that the
battery pack is fully discharged by operating your
cordless product then remove the battery pack from
the drill housing and cover the battery pack
connections with heavy duty tape, to prevent short
circuit and energy discharge which could result in a
fire. Do not attempt to open or remove any of the
components.
Consult your local waste authority for information
regarding available recycling and / or disposal
options.
SPECIFIC SAFETY INSTRUCTIONS
RE-CHARGEAB E BATTERIES.
Batteries may leak or explode if not charged or
handled correctly. Always observe the following
precautions when handling batteries. nsure that the
machine is switched off before removing or fitting
batteries.
Do not use this battery with any other product.
Do not attempt to fit the battery the wrong way round.
Do not short out, or attempt to dismantle the battery.
Do not expose the battery to flames or excessive
heat.
Do not immerse in or expose the battery to water.
Do not store or transport the battery with loose metal
objects such drill and driver bits.
Batteries are prone to leakage when discharged. To
avoid damage to the product, remove or
re-charge the battery when no charge remains. Store
the battery in a cool place when not in use.
After prolonged use the battery may become hot.
Before removing the battery, switch the machine off
and allow the battery to cool down. Do not use the
battery if you notice any discoloration or distortion of
the battery casing.
GENERA SAFETY RU ES
WARNING! Read all instructions Failure to follow all
instructions listed below may result in electric shock,
fire and/or serious injury. The term "power tool" in all
of the warnings listed below refers to your mains
operated (corded) power tool or battery operated
(cordless) power tool.
SAVE THESE INSTRUCTIONS
1) WORK AREA
a) Keep work area clean and well lit. Cluttered and
dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can cause you
to lose control.
2) E ECTRICA SAFETY
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will
reduce risk of electric shock.
b) Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators.
There is an increased risk of electric shock if your
body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords
increase the risk of electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of
electric shock.
3) PERSONA SAFETY
a) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the influence of drugs, alcohol or medication.
A moment of inattention while operating power
tools may result in serious personal injury.
b) Use safety equipment. Always wear eye
protection. Safety equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will
reduce personal injuries.
c) Avoid accidental starting. nsure the switch is in
the off position before plugging in. Carrying power
tools with your finger on the switch or plugging in
power tools that have the switch on invites
accidents.
10
