g-lites Beam 300 User manual


1. Dispacking
Thank you purchasing G-Lites Moving Head Beam 300. For your own safety, please read this
manual before installing the device. This manual covers the important information on
installation and applications. Please install and operate the fixture with following instructions.
Meanwhile, please keep this manual well for future needs.
G-Lites Moving Head Beam 300 is made of a new type of high temperature strength of
engineering plastics and cast aluminum casing with nice outlook. The fixture is designed and
manufactured strictly following CE standards, complying with international standard DMX512
protocol. It’s available independently controlled and linkable with each other for operation.
And it is applicable for large-scale live performances, theater, studio, nightclubs and discos.
The light adopts powerful Philips MSR GOLD 300/2 MINI FAST which features high brightness
and stability. Please carefully dispack it when you receive the fixture and check whether it is
damaged during the transportation. And please check whether the following items are included
inside the box:
Beam 300----------- one Signal Cable----one
Omega Clamp------Two User Manual----one
2. Safety Instructions
This device has left the factory in perfect condition. In order to maintain this condition and to
ensure a safe operation, it is absolutely necessary for the user to follow the safety instructions
and warning notes written in this user manual.
If the device has been exposed to temperature changes due to environmental changes, do not
switch it on immediately. The arising condensation could damage the device. Leave the device
switched off until it has reached room temperature.
This device falls under protection-class I. Therefore it is essential that the device be earthed.
The electric connection must carry out by qualified person.
The device shall only be used with rate voltage and frequency.


Make sure that the available voltage is not higher than stated at the end of this manual.
Make sure the power cord is never crimped or damaged by sharp edges. If this would be the
case, replacement of the cable must be done by an authorized dealer.
Always disconnect from the mains, when the device is not in use or before cleaning it. Only
handle the power cord by the plug. Never pull out the plug by tugging the power cord.
During initial start-up some smoke or smell may arise. This is a normal process and does not
necessarily mean that the device is defective, it should decrease gradually.
Please don't project the beam onto combustible substances.
Fixtures cannot be installed on combustible substances, keep more than 50cm distance with
wall for smooth air flow, so there should be no shelter for fans and ventilation for heat
radiation.
If the external flexible cable or cord of this luminaire is damaged, it shall be exclusively
replaced by the manufacturer or his service agent or a similar qualified person in order to
avoid a hazard.
3. Operation Instructions
-The moving head is for beam effect for onsite decoration purpose.
-Don’t turn on the fixture if it’s been through severe temperature difference like after
transportation because it might damage the light due to the environment changes. So make
sure to operate the fixture until it is in normal temperature.
-This light should be keep away from strong shaking during any transportation or movement.
-Don’t pull up the light by only the head, or it might cause damages to the mechanical parts.
-Don’t expose the fixture in overheat, moisture or environment with too much dust when
installing it. And don’t lay any power cables on the floor. Or it might cause electronic shock to
the people.
-Make sure the installation place is in good safety condition before installing the fixture.
-Make sure to put the safety chain and check whether the screws are screwed properly when
installing the fixture.
-Make sure the lens are in good condition. It’s recommended to replace the units if there are
any damages or severe scratch.


-Make sure the fixture is operated by qualified personnel who knows the fixture before using.
-Keep the original packages if any second shipment is needed.
-Don’t try to change the fixtures without any instruction by the manufacturer or the appointed
repairing agencies.
-It is not in warranty range if there are any malfunctions from not following the user manual to
operate or any illegal operation, like shock short circuit, electronic shock, lamp broke, etc.
4. Installation via clamp
Screw the clamps each via a M12 screw and nut onto the Omega holders.
Insert the quick-lock fasteners of the first Omega holder into the respective holes on the bottom
of the device. Tighten the quick-lock fasteners fully clockwise. Install the second Omega holder.
Pull the safety-rope through the holes on the bottom of the base and over the trussing system or
a safe fixation spot. Insert the end in the carabine and tighten the safety screw.
5. DMX-512 control connections
Connect the provided XLR cable to the female 3-pin XLR output of your controller and the other
side to the male 3-pin XLR input of the moving head. You can chain multiple
Moving head together through serial linking. The cable needed should be two core, screened
cable with XLR input and output connectors. Please refer to the diagram below.
DMX-512 connection with DMX terminator
For installations where the DMX cable has to run a long distance or is in an electrically noisy
environment, such as in a discotheque, it is recommended to use a DMX terminator. This helps
in preventing corruption of the digital control signal by electrical noise. The DMX terminator is


simply an XLR plug with a 120 Ωresistor connected between pins 2 and 3,which is then
plugged into the output XLR socket of the last fixture in the chain. Please see illustrations below.
6. LCD Display Operations
1. A001 display the products’ DMX address
2. 001 design the products’ DMX address cord
3. MENU
Rpan：Rotation Pan
Rtil：Rotation Tilt
Lamp：ON, OFF
Rset：Reset and enter, after 3 seconds, it will be reset.
Colo：Color model, Full Color MODE1, Half Color MODE2
Turn：Show 180 degree rotation
Disp：3 models, MODE1: Normal display, MODE2: Half bright, MODE3: Close (return by any
key).
The display will close after 30 seconds without operations.
1
23
PIN 3
PIN 2
120 Ω


7. DMX Channels
Chanel Function
V
alues Description
1 Pan 0-255 0～450
2 Tilt 0-255 0～270
3 Speed 0-255 Speed of PAN/TILT, from fast to slo
w
4 Strobe
0-050 White
051-240 Linear Dimming
241-249 White
250-252 Empty
253-255 White
5 Dimmer 0-255 0-100% linear dimmer
6 Color
0-014 White
015-029 Color 1
030-044 Color 2
045-059 Color 3
060-074 Color 4
075-089 Color 5
090-104 Color 6
105-119 Color 7
120-127 Color 8
128-191 Clockwise stream effect from fast to slo
w
192-255
A
nticlockwise stream effect from fast to slo
w
7 Gobo 0-014 White
015-029 Gobo 1
030-044 Gobo 2
045-059 Gobo 3
060-074 Gobo 4
075-089 Gobo 5
090-104 Gobo 6
105-119 Gobo 7
120-127 Gobo 8
128-191 Clockwise stream effect from slow to fas
t
192-255
A
nticlockwise stream effect from slow to fas
t
8 Gobo
Shaking
0-191 Gobo shaking from slow to fas
t
192-255 White
9 Fros
t
0-255 Linear frost effect
10 Pan Fine 0-255 16Bit for PAN
11 Tilt Fine 0-255 16Bit for TILT
12 Reset 0-234 Empty
235-255 Reset


8. Technical Specifications
Input Voltage: AC100-120V 50/60Hz or AC210~240V, 50/60HZ
Lamp: Philips MSR GOLD 300/2 MINI FAST
Control Signal: DMX512, master-slave and sound activated or auto operation
Control Channel: 12 DMX Channels
Power Consumption: 400W
Dimensions: 396X390X630mm
Packing Dimensions: 515X440X785mm
Net Weight:17kgs
Gross Weight:19kgs
9. Key Features
Extremely new design optical unit
Philips MSR GOLD 300/2 MINI FAST
850H lifespan (750 average) and 8600K color temperature
22000LM luminous flux
Normally 8° beam angle
One Color wheel with 8 interchangeable colors plus open (unilateral rotation rainbow effect;
full color mode or half color mode switchable)
One GOBO wheel with 8 interchangeable gobos (4 image gobos and 4 beam angle reduction
gobos) plus open (variable rotation rainbow effect; full color mode or half color mode
switchable)
Outstanding linear frost effect from 0-100%
0-13t/s strobe effect (auto strobe mode and pulse strobe mode available)
12 DMX channels
540°PAN movements with 8bit/16bit resolution


270°TILT movements with 8bit/16bit resolution
Automatic Pan/Tilt reposition accidental movement not controlled by control unit
3-pin DMX connectors for input and output
Graphic LED display with shuttle wheel
Aluminium structure with die-cast plastic cover
Two side handles for transportation
PAN and TILT lock for transport and maintenance
Lamp ON/OFF control from the lighting console with delay function
Function reset from the lighting console with delay function
Intelligent electric rectifier making the unit much brighter and stable
Switch power supply with short circuit protectionction
Forced ventilation with axial fans
Hanging system with fast-lock OMEGA clamp on the base
In conformity to CE standards and GB 7000. 15-2000 Standard
10. Maintenance and Cleaning
The following points have to be considered during the inspection:
1) All screws for installing the devices or parts of the device have to be tightly connected and
must not be corroded.
2) There must not be any deformations on the housing, color lenses, fixations and installation
spots (ceiling, suspension, trussing).
3）Mechanically moved parts must not show any traces of wearing and must not rotate with
unbalances.
4）The electric power supply cables must not show any damage, material fatigue or sediments.
Further instructions depending on the installation spot and usage have to be adhered by a
skilled installer and any safety problems have to be removed.


In order to make the lights in good condition and extend the life time, we suggest a regular
cleaning to the lights.
1) Clean the inside and outside lens each week to avoid the weakneness of the lights due to
accumulation of dust.
2) Clean the fan each week.
3) A detailed electric check by approved electrical engineer each three month, make sure that
the circuit contacts are in good condition, prevent the poor contact of circuit from
overheating.
We recommend a frequent cleaning of the device. Please use a moist, lint- free cloth. Never use
alcohol or solvents.
There are no serviceable parts inside the device. Please refer to the instructions under
“Installation instructions”.
Should you need any spare parts, please order genuine parts from your local dealer.
