G2 AR-22.1 User manual

TREADMILL AR-22.1
OWNER’S MANUAL

1
2019/9/18V1.1+V1.0
Content
1. Overview Drawing ....................................................................................................................................................................... 3
2. SAFETY INSTRU TION ............................................................................................................................................................. 4
2.1. Power Requirement ..................................................................................................................................................... 7
2.2. Level Adjustment ......................................................................................................................................................... 8
2.3. Power Switch .............................................................................................................................................................. 8
2.4. Running Belt Adjustment ............................................................................................................................................. 9
2.5. Machine movement ................................................................................................................................................... 10
3. Assembly Instructions ................................................................................................................................................................11
3.1. Pre-Assembly heck List ...........................................................................................................................................11
3.2. Hardware Pack .......................................................................................................................................................... 12
3.3. Assembly steps ......................................................................................................................................................... 13
4. omputer console operation instruction .................................................................................................................................... 18
4.1. computer console construction .................................................................................................................................. 18
5. Sectional heartbeat ratio training ............................................................................................................................................... 20
5.1. Sectional heart rate training ....................................................................................................................................... 20
5.2. Heart rate monitor system ......................................................................................................................................... 21
6. Exercise Program ..................................................................................................................................................................... 23
7. Malfunction elimination .............................................................................................................................................................. 37
8. UNIT SWIT H BETWEEN E& ................................................................................................................................................ 38
9. Bluetooth module manual and APP(iOS) installation instruction ................................................................................................ 40

2
2019/9/18V1.1+V1.0
Norwegian import:
Gym2000AS
TRONDHEIM: Østre Rosten 102b, 7075 Tiller
Telefon: [phone]
VIKERSUND: Nedre Nedmarken 2, 3370
Vikersund
Telefon: [phone]
Service: [email protected]
E-post: [e-mail]
Firma/org.nr: GYM2000 AS / 9 7 651 067

3
2019/9/18V1.1+V1.0
1. Overview Drawing

4
2019/9/18V1.1+V1.0
2. SAFETY INSTRUCTION
When using this product, basic precautions should always be followed, including the following:
Please read the instruction carefully before starting to use this product.
 DANGER – To reduce the risk of electric shock：
Always unplug this product from the electrical outlet immediately after using and before cleaning.
 WARNING – To reduce the risk of burns, fire, electric shock, or physical injury：
The product should never be left unattended while plugged in. Unplug the product from the outlet when not in use.
lose supervision is necessary when this product is used by or near children, invalids, or disabled persons.
Be sure to use the product only for its intended use as described in this manual. Do not use any attachment not recommended by the
manufacturer in order to avoid any danger or accidents.
Never operate the product if it has a damaged cord or plug, if it is not working properly, if it has been damaged, or dropped into water.
Please return the product to the service center of seller for examination and repair.
Do not carry this product by the supply cord or use the cord as a handle.
Keep the cord away from hot surfaces or ground.
Never operate the product with the air vents blocked. Keep the air vents free of lint, hair, etc.
Never drop or insert any objects into any openings.
Do not use or operate outdoors.
Do not operate where aerosol (spray) products are being used or where oxygen is thin.
Before turning the product power off, turn all controls to the off position then remove the plug from the outlet.
onnect the product to a properly grounded outlet only.
If the power cord is damaged, be sure to ask the manufacturer for replacement to avoid accidents. The seller and correlative qualified
professionals are as well as eligible.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety. hildren should be supervised to ensure that they do not play with the appliance.
Incorrect or excessive training may cause injuries t health may results.

5
2019/9/18V1.1+V1.0
The equipment shall be installed on stable base and properly leveled.
A shall be safety area of 2,000mm x 1,000mm behind the equipment.
Maximum user weight is 180 Kgs.
When this treadmill is being used, it can not be folded at the same time.
Required to confirm the device completely stopped before folding
the safety level of the equipment can be maintained only if it is examined regularly for damage and wear.
any of the adjustment devices that could interfere with the user's movement should not be left projecting.
Users correct ergonomic position on the equipment shown in Figure
When you are ready for running, please do not stand on the running belt. Before starting the machine, turn on the power. Put your
hands on the side handrail and stand on the protection bar at both sides. And then press “START”, when the motor is working in low
speed, move your feet to the running belt to start running.
Please do not start the machine with high speed and do not jump to the machine, when there is an emergency, please hold the front
handrail or side handrail and jump your feet from running belt to the side protection bar.

6
2019/9/18V1.1+V1.0
If there is any emergency, there are two emergent stop systems for you to stop the machine.
(a) Key and clip:
When you are running, please clip the clip to your cloth on the waist. If there is any danger, pull out the key with the cable
to stop the machine.
(b) STOP key:
Press downwards the STOP key to make the key withdraw from the control box and the running belt will stop.
Notice Pull back the key to the control box to make the machine back to the standby status.
Before using this product, you should step on the it then turn on the product. Do not turn on the treadmill before step on it.
Running surface Width dimensions 560*1475mm
ustomer Address
AR-22.1( P14L9HB1D)

7
2019/9/18V1.1+V1.0
2.1. Power Requirement
 This treadmill needs special power supply
Power Voltage（V） Frequency（HZ） Rated urrent（A）
100 50/60 15
120 50/60 15
200 50/60 8
220 50/60 8
230 50/60 8
240+ 50/60 8
Wirings should be transported according to the electric law of the local country. High pressure wires, low pressure wires and
underground wires should be transported separately and can’t connect with or twist other wires.
Improper connection of the grounding plug can result in the risk of electric shock. heck with a qualified electrician or serviceman if
you are in doubt as to whether the products are properly grounded. Do not modify the plug provided with the product – If it will not fit
the outlet, have a proper outlet installed by a qualified electrician.
Figure
Grounding methods

8
2019/9/18V1.1+V1.0
2.2. Level Adjustment
The treadmill will wobble during workout and the incline angles will be affected if it is placed on uneven ground.
The level adjustment method is as follows:
Turn A counter-clockwise to loosen it
Adjust B to the proper height
Turn A clockwise to tighten it.
The left side adjustment method is the same with the right side
2.3. Power Switch
The Power Switch is on the bottom panel of the treadmill. 1 means on, 0 means off.

9
2019/9/18V1.1+V1.0
2.4. Running Belt Adjustment
If you need to adjust the running belt tightness, please follow these steps:
After assembling and stabilizing the treadmill, check whether the running belt is running properly.
First, determine that the power supply meets the requirements. After the power is plugged in, start the treadmill, press the QUI K
START button, and then press the up-speed key to increase the speed to 4.0 miles per hour (MPH), or 6.4 k km/h (KPH).
When you need to tighten it, rotate both sides by 1/4 turn clockwise.
When you need to loosen, rotate both sides by 1/4 turn counterclockwise.

10
2019/9/18V1.1+V1.0
2.5. achine movement
When the machine is moving, you can put the handling tube (K) into the back of the box to move the machine.

11
2019/9/18V1.1+V1.0
3. Assemb y Instructions
Ready the operation instructions carefully before use, then choose a flat position to assemble.
This treadmill also can use other way to account the HR . When in fitness,user can wear the chest pulse belt and
the HR will show in Pulse windows.
3.1. Pre-Assembly Check List
ITEM Description Qty ITEM Description Qty
A Treadmill frame 1 G Electronic meter 1
B Treadmill’s hand-stand pipe (left) 1 Water cup 2
C Treadmill’s hand-stand pipe (right) 1 I Stand pipe decorative cover (left) 1
D andrail pipe (left) 1 J Stand pipe decorative cover (right) 1
E andrail pipe (right) 1 K Transporting pipe 2
F Water cup frame 1 L Electronic meter decorative cover 1

12
2019/9/18V1.1+V1.0
3.2. Hardware Pack
ITEM Description Qty ITEM Description Qty
a
Inner hexagon steel screw
M10x25
of
umbrella head 8
j
Umbrella head crossed screw
(tail cutting)
M4x15 2
b Spring washer M10 16 k
Type L hexagon wrench + crossed
screwdriver 5x35x115mm 1
c Washer φ10xφ25x2.0t 16 l Type T wrench 6mm 1
d
Inner hexagon steel screw M8x
100
of
socket head 4
m Type T wrench 10mm 1
e Spring washer M8 8 n Power cord switch sleeve 1
f Washer Φ8xΦ19x2.0t 4 o Umbrella head crossed screw M4x10 2
g
Inner hexagon screw
M10x2
0
of
umbrella head, stainless steel 8
p Spring washer M4 2
h
Inner hexagon steel screw
M
8
x
7
5
of
umbrella head 4
q CABLE adapter 1
i
Umbrella head crossed screw
(
tail
cutting) M5x15 4
r Bushing 4

13
2019/9/18V1.1+V1.0
3.3. Assembly steps
In case of danger, the machine assembly must be jointly carried out by two or more people and do not assemble alone.
 STEP 1
Use the magic belt attached to the left and right treadmill’s hand-stand pipes to tighten the wires on both sides of the platform. Pass it
through the square hole at the bottom of the left and right treadmill’s hand-stand pipes and pull it above the pipe.
Fix the left and right treadmill’s hand-stand pipes (D, E) by screw (A), spring (b) and washer ( ) without fastening.
※ Please be careful not to clip the wire when assembling

14
2019/9/18V1.1+V1.0
 STEP 2
Put the water bottle shelf （F）on the left and right upright tubes, and then connect the wires from the upright tubes with the wires in the
water bottle shelf. Pull the handrail and the heart pulse wires in the water bottle shelf out from the upper holes on the left and right
tubes.
※ After connecting Cable, the Cable (middle) plastic sleeve shall be inserted into the Cable metal connector.
Lock with screw (g) and washer (b, c) but not tightly. onfirm that the water cup frame (F) is locked with all the screws of the left and
right treadmill’s hand-stand pipes and then use the tool to lock all the screws.
Please be careful not to clip the wire when assembling

15
2019/9/18V1.1+V1.0
 STEP 3
onnect the wires in the water bottle shelf with the left and right upright tubes （D、E）. After arranging, insert into the upright tubes
（D、E）.
Use screw (d), spring washer (e), Bushing (r) to lock the left and right handrail pipes (D, E) tightly as shown in the figure and fix them
on the left and right treadmill’s hand-stand pipes.
※ Please be careful not to clip the wire when assembling

16
2019/9/18V1.1+V1.0
 STEP 4
Put the Electronic meter (G) on the water cup frame previously assembled and connect the wire of the water cup frame to the wire of
the Electronic meter. Use the screw (h) and washer (e, f) to lock Electronic meter tightly and fix it on the water cup frame.
over the Electronic meter decorative cover (L) and lock it tightly with the screw (j), and pay attention that the cover should not be
pressed on the wire.
※ Please be careful not to clip the wire when assembling.
※ Cable is reserved for TV system, which is not needed in this model.

17
2019/9/18V1.1+V1.0
 STEP 5
over the left and right stand pipe decorative covers (I, J), and tighten them with screws (i). Insert the power cord into the power cord
socket according to the figure position. over the power cord switch sleeve (n) and lock it tightly with screws (o) and spring washer (p).
Finally, put the water cup (H) into the rack frame.

18
2019/9/18V1.1+V1.0
4. Computer conso e operation instruction
This treadmill provides a convenient computer console, and users can input the personal information into the console and set the goal
of the exercises.
4.1. computer console construction
A
WORKOUT PROFILE
WINDOW
Show the incline changes during the exercise, the height of the cursor means the percentage
of the incline.
B MESSAGE ENTER
Show the operation steps of all the programs and the relative information about all the control
and conduction program operation, such as calorie, distance/stride, time, incline and speed.
1
During exercise to increase
incline angle
During exercise to increase incline angle, max is 20% (10% for pushing mode), STEP 0.1%.
(Under PROGRAM to set LEVEL program, during exercise, this key is invalid.)
2
During exercise to decrease
incline angle
During exercise to decrease incline angle, minimum is 0% , STEP 0.1%.
(Under PROGRAM to set LEVEL program, during exercise, this key is invalid.)

19
2019/9/18V1.1+V1.0
3
During exercise press this key
to increase speed
During treadmill mode, press this key to increase speed, max is 15.6mph (25km), STEP 0.1.
During pushing mode, press this key to increase pushing power, minimum is THRUST
LEVEL 15, STEP 1.
4
During exercise press this key
to decrease speed
During treadmill mode, press this key to decrease speed, minimum is 0.3mph( 0.5km)，STEP
0.1.
During pushing mode, press this key to decrease pushing power, minimum is THRUST
LEVEL 0, STEP 1.
D ENTER
onfirm the digital number for program setting or specific case selection, such as exercise
time, speed, weight, distance, exercise target, gender, and target heart ratio and so on. Use
SPEED”+”,”-“to input information, press ENTRE to confirm.
E MODE
Selection of PROGRAM theme, include GOAL‧HR ‧PHYSI AL TEST‧PROGRAM‧
TRAINING‧FIT TEST. Under pushing mode, only GOAL,HR , Thrust INTERVAL, Thrust
INTERVAL USTOM is valid.
F QUI K START
Press this key to get fast entrance to the user preset mode, no need to choose program
setting, during program execution process, use direction key or digit key to adjust incline and
speed (pushing power).
The initial speed is 0.6mph(1km).
G1 Heartbeat ratio display Show the heartbeat ratio when the user use sensor or breast band heart rate belt.
G2 Sectional heartbeat ratio panel
Input the user’s age to calculate according to the formula and then take the result to show the
current heartbeat ratio sectional display, this function cannot be valid unless the age is input.
H Pause/stop
During exercise, press this key once to enter into pause status, press again to back to
standby status.
I Incline 3,6,9 fast key
During treadmill mode and pushing mode, press this key, incline will do 3,6,9 fast switch.
(Under PROGRAM to set LEVEL program, during exercise, this key is invalid.)
J Speed 3,6,9 fast key During treadmill mode, press this key, speed will do 3,6,9 fast switch.
