GAI-Tronics 13373 User manual

Pub. 43004-034C
GAI-Tronics Corporation 400 E. Wyomissing Ave. Mohnton, PA 19540 USA
610-777-1374 800-492-1212 Fax: [phone]
VISIT WWW.GAI-TRONICS.COM FOR PRODUCT LITERATURE AND MANUALS
GAI-TRONICS® CORPORATION
A HUBBELL COMPANY
Model 13353, 13363 and 13373
Addressable Amplified Speakers
Installation and Operation Manual

Pub.: 43004-034C
GAI-TRONICS®CORPORATION
A HUBBELL COMPANY
Model 13353, 13363 and 13373
Addressable Amplified Speakers
Installation and Operation Manual
TABLE OF CONTENTS
GAI-Tronics Corporation 400 E. Wyomissing Ave. Mohnton, PA 19540 USA
610-777-1374 800-492-1212 Fax: [phone]
VISIT WWW.GAI-TRONICS.COM FOR PRODUCT LITERATURE AND MANUALS
Foreword.........................................................................................................................................1
Scope of Manual......................................................................................................................................1
Nomenclature..........................................................................................................................................1
Ordering Replacement Parts.................................................................................................................1
Service and Repair..................................................................................................................................1
Confidentiality Notice.............................................................................................................................2
FCC Licensing Information...................................................................................................................2
Computer Software Copyrights.............................................................................................................3
Warranty .................................................................................................................................................3
Safety and General Information............................................................................................................4
Operational Cautions..............................................................................................................................5
Safe Handling of CMOS Integrated Circuit Devices...........................................................................6
Performance Specifications............................................................................................................7
General Information.......................................................................................................................9
Product Overview ...................................................................................................................................9
Features....................................................................................................................................................9
Available Models.....................................................................................................................................9
Replacement Parts and Kits.................................................................................................................10
Programming Software and Cable......................................................................................................10
System Layout Considerations ............................................................................................................11
Operating Modes...........................................................................................................................11
Generic Operation ................................................................................................................................11
DTMF Selective Operation ..................................................................................................................11
DTMF Selective with Manual Switch ................................................................................................................12
DTMF Selective with Voice Switch ...................................................................................................................12
Two-Tone Selective...............................................................................................................................12
Feed-Thru Operation............................................................................................................................13

TABLE OF CONTENTS PUB.43004-034C
GAI-Tronics Corporation 400 E. Wyomissing Ave. Mohnton, PA 19540 USA
610-777-1374 800-492-1212 Fax: [phone]
VISIT WWW.GAI-TRONICS.COM FOR PRODUCT LITERATURE AND MANUALS
Volume Adjustments.....................................................................................................................13
Remote Volume Adjustment................................................................................................................13
With Automatic Level Adjustment Disabled......................................................................................................13
With Automatic Level Adjustment Enabled .......................................................................................................14
Local Volume Adjustment ...................................................................................................................14
Acoustic Feedback ................................................................................................................................14
Output Contact..............................................................................................................................15
Battery Monitor.............................................................................................................................15
Programming and Set Up.............................................................................................................15
Required Programming Accessories...................................................................................................16
Opening the Addressable Amplified Speaker ....................................................................................16
LED Indicators......................................................................................................................................16
Card Suite Software......................................................................................................................17
Installation.............................................................................................................................................17
Connecting the Programming Cable...................................................................................................17
Programming the Addressable Amplified Speaker...........................................................................18
Initial Setup and File Creation ............................................................................................................................18
Operating Modes.................................................................................................................................................20
RF Programming Software (required only for Models 13363 and 13373) ......................................32
Installation ..........................................................................................................................................................32
Connecting the Programming Cable ...................................................................................................................32
Programming the Radio ......................................................................................................................................33
Installation ....................................................................................................................................36
Safety and General Information..........................................................................................................36
Outdoor Installation Product...............................................................................................................................36
Antenna Care ......................................................................................................................................................36
Electromagnetic Interference/Compatibility.......................................................................................................36
Mechanical Receipt Inspection............................................................................................................36
Cable Installation Safety Considerations............................................................................................36
Equipment Required ............................................................................................................................37
Programming ......................................................................................................................................................37
Tools ...................................................................................................................................................................37
Mounting................................................................................................................................................37
Cable Installation..................................................................................................................................38
Power......................................................................................................................................................38
Wire Connections..................................................................................................................................39
Typical Connection Scenarios ............................................................................................................................40
12506-001 Remote Volume Control Wiring Instructions..................................................................43
Hardware Configuration ..............................................................................................................44
Audio Line Termination Jumper ........................................................................................................44
Fuses.......................................................................................................................................................44

TABLE OF CONTENTS PUB.43004-034C
GAI-Tronics Corporation 400 E. Wyomissing Ave. Mohnton, PA 19540 USA
610-777-1374 800-492-1212 Fax: [phone]
VISIT WWW.GAI-TRONICS.COM FOR PRODUCT LITERATURE AND MANUALS
Connectors.............................................................................................................................................45
TB1 Wiring Connector .......................................................................................................................................45
TB2 Wiring Connector .......................................................................................................................................45
Radio Connector Pin-out.....................................................................................................................................47
Terminal Strip Designations ...............................................................................................................................48
Field Installed Options..................................................................................................................48
Model SPK200 Solar Interface Kit......................................................................................................48
Model XB001 External Long-Life Battery Enclosure.......................................................................48
Model BB133 Battery Backup Kit.......................................................................................................49
Model 12506-001 Remote Volume Control Assembly .......................................................................49
Model 190-002PS Weatherproof Power Supply Kit..........................................................................49
Definitions and Acronyms............................................................................................................50
Appendix A: Speaker Zoning Example.......................................................................................51

Pub.: 43004-034C
GAI-Tronics Corporation 400 E. Wyomissing Ave. Mohnton, PA 19540 USA
610-777-1374 800-492-1212 Fax: [phone]
VISIT WWW.GAI-TRONICS.COM FOR PRODUCT LITERATURE AND MANUALS
GAI-TRONICS® CORPORATION
A HUBBELL COMPANY
Model 13353, 13363 and 13373
Addressable Amplified Speakers
Foreword
Scope of Manual
This manual offers descriptive data and service information for the Addressable Amplified Speaker
Assemblies.
Nomenclature
The model number, located on the nameplate on top of the speaker, specifically identifies GAI-Tronics
equipment.
Ordering Replacement Parts
When ordering replacement parts or requesting equipment information, please include the complete
identification number. This applies to all components, kits, and chassis. If the component part number is
not known, the order should include the number of the chassis or kit of which it is a part and sufficient
description of the desired component to identify it. Order parts from:
Customer Service
GAI-Tronics Corporation
400 E. Wyomissing Ave.
Mohnton, PA 19540
US: 800-492-1212
Outside US: 610-777-1374
Service and Repair
Inoperative or malfunctioning equipment should be returned to the factory for repair. Please call
1-800-492-1212 or 610-777-1374 to obtain a Return Authorization number, published repair prices, and
shipping instructions.
NOTE:A purchase order or credit card number is required prior to processing non-warranty repairs.

Pub. 43004-034C
Model 13353, 13363, and 13373 Addressable Amplified Speakers Page: 2 of 52
f:\radio products-draft\gtc 43004\43004-034c\43004-034c.doc
05/10
Confidentiality Notice
This manual is provided solely as an operational, installation, and maintenance guide and contains
sensitive business and technical information that is confidential and proprietary to GAI-Tronics.
GAI-Tronics retains all intellectual property and other rights in or to the information contained herein,
and such information may only be used in connection with the operation of your GAI-Tronics product or
system. This manual may not be disclosed in any form, in whole or in part, directly or indirectly, to any
third party.
FCC Licensing Information
Your radio operates on General Mobile Radio Service (GMRS) frequencies and is subject to the Rules
and Regulations of the Federal Communications Commission (FCC). The FCC requires that all operators
using GMRS frequencies obtain a radio license before operating their equipment. To obtain the FCC
forms, go to http://wireless.fcc.gov/services/personal/generalmobile/index.html to obtain Forms 605 and
159, which include all forms and instructions.
Changes or modifications not approved by GAI-Tronics Corporation may void the user’s authority
granted by the FCC to operate this radio and should not be made. To comply with FCC requirements,
transmitter adjustments should be made only by or under the supervision of a person certified as
technically qualified to perform transmitter maintenance and repairs in the private land mobile and fixed
services as certified by an organization representative of the user of those services. Replacement of any
transmitter component (crystal, semiconductor, etc.) not authorized by the FCC equipment authorization
for this radio could violate FCC rules.
NOTE: Use of this radio outside the country where it was intended to be distributed is subject to
government regulations and may be prohibited.
Federal Communications Commission (FCC)
1-202-418-0177 1-800-418-FORM
1-800-418-3676
1-888-CALL-FCC
1-888-225-5322
Or: http://www.fcc.gov

Pub. 43004-034C
Model 13353, 13363, and 13373 Addressable Amplified Speakers Page: 3 of 52
f:\radio products-draft\gtc 43004\43004-034c\43004-034c.doc
05/10
Computer Software Copyrights
This product contains copyrighted computer programs stored in semiconductor memory. These programs
are copyrighted by GAI-Tronics Corporation and may not be reproduced in any form without expressed
written permission from GAI-Tronics.
Warranty
GAI-Tronics warrants for a period of one (1) year from the date of shipment, that any GAI-Tronics equipment supplied hereunder
shall be free of defects in material and workmanship, shall comply with the then-current product specifications and product
literature, and if applicable, shall be fit for the purpose specified in the agreed-upon quotation or proposal document. If (a)
Seller’s goods prove to be defective in workmanship and/or material under normal and proper usage, or unfit for the purpose
specified and agreed upon, and (b) Buyer’s claim is made within the warranty period set forth above, Buyer may return such
goods to GAI-Tronics’ nearest depot repair facility, freight prepaid, at which time they will be repaired or replaced, at Seller’s
option, without charge to Buyer. Repair or replacement shall be Buyer’s sole and exclusive remedy, and the warranty period on
any repaired or replacement equipment shall be one (1) year from the date the original equipment was shipped. In no event shall
GAI-Tronics’ warranty obligations with respect to equipment exceed 100% of the total cost of the equipment supplied hereunder.
The applicability of any such third-party warranty will be determined solely by GAI-Tronics.
Services. Any services GAI-Tronics provides hereunder, whether directly or through subcontractors, shall be performed in
accordance with the standard of care with which such services are normally provided in the industry. If the services fail to meet
the applicable industry standard, GAI-Tronics will, for a period of one (1) year from the date of completion, re-perform such
services at no cost to the Buyer. Re-performance of services shall be Buyer’s sole and exclusive remedy, and in no event shall
GAI-Tronics’ warranty obligations with respect to services exceed 100% of the total cost of services provided hereunder.
Limitations/Exclusions. The warranty on any equipment supplied hereunder is subject to Customer’s use in compliance
with applicable FCC regulations and manufacturer specifications. The warranties herein shall not apply to, and GAI-Tronics
shall not be responsible for, any damage to the goods or failure of the services supplied hereunder, to the extent caused by
accident, misuse, abuse, neglect, system design, product modification, failure to follow instructions contained in the product
manual, repair, or attempted repair by anyone not authorized by GAI-Tronics, improper installation, installation of parts that do
not conform to the quality or specifications of the original parts or accessories, damage or loss occurred during shipment, or any
unit which is not new when sold or upon which the serial number has been defaced, modified or removed. The warranty does not
extend to damage incurred by natural causes including Force Majeure. The warranty does not cover microprocessors if failure is
due to static damage or application of improper voltage. THE WARRANTIES AND REMEDIES CONTAINED HEREIN ARE
IN LIEU OF AND EXCLUDE ALL OTHER WARRANTIES AND REMEDIES, WHETHER EXPRESS OR IMPLIED BY
OPERATION OF LAW OR OTHERWISE, INCLUDING ANY WARRANTIES OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE.
Operational and Maintenance Procedures.Buyer acknowledges that any improper use, maintenance, or
modification of the equipment provided hereunder, or use of unqualified maintenance or service technicians will severely impair
the operational effectiveness of the entire communication system. Buyer hereby agrees to indemnify, defend and hold GAI-
Tronics harmless from and against any and all third party claims arising, in any manner, out of: (a) Buyer’s neglect of the
equipment; (b) Buyer’s use of technicians not authorized by GAI-Tronics to service the equipment; or (c) Buyer’s improper use
or modification of the equipment or failure to follow the operational and maintenance procedures provided with the equipment.
Limitation of Liability/Damages.In no event (even should circumstances cause the exclusive warranties and remedies
set forth in the Warranty section to fail of their essential purpose) shall either party be liable for any indirect, incidental, special or
consequential damages (including, but not limited to, loss of use, loss of anticipated profits, or damages arising from delay)
whether such claims are alleged to have arisen out of breach of warranty, breach of contract, strict or absolute liability in tort, or
other act, error or omission, or from any other cause whatsoever, or any combination of the foregoing.

Pub. 43004-034C
Model 13353, 13363, and 13373 Addressable Amplified Speakers Page: 4 of 52
f:\radio products-draft\gtc 43004\43004-034c\43004-034c.doc
05/10
Safety and General Information
Installation should only be performed by qualified service personnel in accordance with the
National Electrical Code or applicable local codes.
Power Sources - Operate this unit only from the type of power source indicated on the label. If
unsure of the type of power supply to use, contact qualified service personnel.
•For units intended to operate from battery power, refer to operating instructions.
•For units intended to operate with External Power Supplies, use only the recommended
approved power supplies.
•For units intended to operate with a limited power source, this power source must comply
with EN60950. Substitutions may damage the unit or cause fire or shock.
Outdoor Product:
Power Lines - An outdoor system should not be located in the vicinity of overhead power lines, electric
lights, or power circuits, or where it may contact such power lines or circuits, as this contact might be
fatal. Refer to the National Electrical Code Article 800 regarding installation.
User Instructions
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
Exposure to Radio Frequency Energy
Your radio is designed to comply with the following standards and guidelines regarding exposure of
human beings to radio frequency electromagnetic energy:
•FCC, Code of Federal Regulations; 47 CFR part 2 sub-part J
•American National Standards Institute (ANSI)/Institute of Electrical and Electronic Engineers (IEEE)
C95.1-1992
•Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999 Edition
•International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998
•Ministry of Health (Canada) Safety Code 6. Limits of Human Exposure to Radio Frequency
Electromagnetic Fields in the Frequency Range from 3 kHz to 300 GHz, 1999

Pub. 43004-034C
Model 13353, 13363, and 13373 Addressable Amplified Speakers Page: 5 of 52
f:\radio products-draft\gtc 43004\43004-034c\43004-034c.doc
05/10
Antenna Care
Unauthorized antennas, modifications, or attachments could damage the radio and may violate FCC
regulations.
Do NOT hold the antenna when the radio is IN USE. Holding the antenna affects the effective range.
Approved Accessories
Only use GAI-Tronics Corporation approved accessories. Please visit www.gai-tronics.com.
Electromagnetic Interference/Compatibility
Electronic equipment may be susceptible to electromagnetic interference. If you experience interference,
visit the FCC website at http://www.fcc.gov for possible solutions.
Operational Cautions
Hospitals or Health Care Facilities
To avoid electromagnetic interference and/or compatibility conflicts, turn off your radio in any facility
where posted notices instruct you to do so. Hospital or health care facilities may be using equipment that
is sensitive to external RF energy.
Aircraft/Airports
Airports may be using equipment that is sensitive to external RF energy. Any use of a radio must be in
accordance with applicable regulations.
Medical Devices - Pacemakers
These recommendations are consistent with the independent research by, and recommendations of the
U.S. Food and Drug Administration. Persons with pacemakers should:
•ALWAYS keep the radio more than six inches (15 cm) from their pacemaker when the radio is turned
ON.
•Do NOT carry the radio in the breast pocket.
•Turn the radio OFF immediately if you have any reason to suspect that interference is taking place.
Blasting Caps and Areas
To avoid possible interference with blasting operations, turn off your radio when you are near electrical
blasting caps, in a blasting area, or in areas posted: “Turn off two-way radio.” Obey all signs and
instructions.

Pub. 43004-034C
Model 13353, 13363, and 13373 Addressable Amplified Speakers Page: 6 of 52
f:\radio products-draft\gtc 43004\43004-034c\43004-034c.doc
05/10
Safe Handling of CMOS Integrated Circuit Devices
Many of the integrated circuit devices used in communications equipment are of the Complementary
Metal Oxide Semiconductor (CMOS) type. Because of their high open circuit impedance, CMOS
integrated circuits are vulnerable to damage from static charges. Care must be taken handling, shipping,
and servicing them and the assemblies in which they are used.
Even though protection devices are provided in CMOS integrated circuit inputs, the protection is effective
only against overvoltage in the hundreds of volts range such as is encountered in an operating system. In
a system, circuit elements distribute static charges and load the CMOS circuits, decreasing the chance of
damage. However, CMOS circuits can be damaged by improper handling of the modules, even in a
system.
To avoid damage to circuits, observe the following handling, shipping, and servicing precautions:
1. Prior to and while servicing a circuit module, particularly after moving within the service area,
momentarily touch both hands to a bare metal, earth-grounded surface. This will discharge any static
charge that may have accumulated on the person doing the servicing.
NOTE:Wearing a conductive wrist strap will minimize static build-up during servicing.
2. Whenever possible, avoid touching any electrically conductive parts of the circuit module with your
hands.
3. Power down the unit before installing or removing the circuit module.
4. When servicing a circuit module, avoid carpeted areas, dry environments, and certain types of
clothing (silk, nylon, etc.) because they contribute to static build-up. Similarly, disconnect the test
probe prior to removing the ground lead.
5. All electrically powered test equipment should be grounded. Apply the ground lead from the test
equipment to the circuit module before connecting the test probe.
6. If a circuit module is removed from the system, it is desirable to lay it on a conductive surface (such
as a sheet of aluminum foil) which is connected to ground through 100 k of resistance.
7. When soldering, be sure the soldering iron is grounded and has a grounded tip.
8. Prior to connecting jumpers, replacing circuit components, or touching CMOS pins (if this becomes
necessary in the replacement of an integrated circuit device), be sure to discharge any static build-up
as described in procedure 1. Since voltage differences can exist across the human body, it is
recommended that only one hand be used if it is necessary to touch pins on the CMOS device and
associated board wiring.
9. When replacing a CMOS integrated circuit device, leave the device in its conductive rail container or
conductive foam until it is to be inserted into the printed circuit module.
10. All low impedance test equipment (such as pulse generators, etc.) should be connected to CMOS
device inputs after power is applied to the CMOS circuitry. Similarly, such low impedance
equipment should be disconnected before power is turned off.
11. Replacement modules shipped separately from the factory will be packaged in a conductive material.
Any modules being transported from one area to another should be wrapped in a similar material
(aluminum foil may be used). Never use non-conductive material for packaging these modules.

Pub. 43004-034C
Model 13353, 13363, and 13373 Addressable Amplified Speakers Page: 7 of 52
f:\radio products-draft\gtc 43004\43004-034c\43004-034c.doc
05/10
Performance Specifications
Electronic
Output power ................................................................................................ 4 mW to 8 W (default 16 mW)
Current draw @ full output (8 watts)................................................................................................... 1 amp
Sound pressure level ...................................................................................... 107 dB SPL, 1 watt at 1 meter
Nominal coverage when surface-mounted to wall (ref. –6 dB)
Vertical....................................................................................................................................... Upward: 40º
Downward: 60º
Horizontal ................................................................................................................................................. 90º
600 Ωaudio input level............................................................................................................... 775 mVrms
Audio speaker volume adjustment range .............................................................................. 83–116 dB SPL
Audio speaker volume ...................................... Factory set @ nominal 89 dB SPL at a distance of 1 meter
Frequency response..................................................................................................... 450–3000 Hz +/-5 dB
Power Requirements
Model 40419-013 Power Supply (Included)
Input voltage ......................................................................................................... 100 to 240 V ac/50/60 Hz
Output voltage ................................................................................................................................... 15 V dc
Rated output current......................................................................................................................... 1.6 amps
Rated output power........................................................................................................................... 24 watts
Accessory Power Options
Model BB133 Battery Back-up Kit
Voltage............................................................................................................................................... 12 V dc
Capacity .............................................................................................................................................. 2.8 Ah
Battery life ............................................................................................................120 minutes at full output
Model XB001 External Long-Life Battery Kit (with 40201-008 battery)
Voltage............................................................................................................................................... 12 V dc
Capacity ............................................................................................................................................... 18 Ah
Battery life .................................................................................................................. 13 hours at full output
Model 190-002PS Kit (Includes 40404-060 DC Power Supply)
Output voltage (adjustable).................................. 13.2–15.0 V dc (Set to 15.0 V for battery trickle charge)
Rated output current......................................................................................................................... 2.1 amps
Rated output power........................................................................................................................... 25 watts
Input voltage ............................................................................................................ 85–264 V ac, 50–60 Hz
Input current................................................................................................ 0.7 A/115 V ac; 0.4 A/230 V ac
Solar panel output (at charge controller module)
Voltage (trickle charge) ..................................................................................................................... 12 V dc

Pub. 43004-034C
Model 13353, 13363, and 13373 Addressable Amplified Speakers Page: 8 of 52
f:\radio products-draft\gtc 43004\43004-034c\43004-034c.doc
05/10
Mechanical
Physical dimensions............................................................................................... 8.02 ×8.12 ×9.52 inches
Enclosure material ..................................................................... Glass-reinforced polyester, 0.20 inch thick
Hardware..................................................................................... Urethane gaskets, stainless steel hardware
Color ..................................................................................................................................................... Black
Shipping weights
Model 13353..................................................................................................................................6.6 lbs.
Model 13363 /13373 .....................................................................................................................7.3 lbs.
Environmental
Temperature range .............................................................................................................. -20° C to +60° C
Weatherproof rating ....................................................................................................................... Rainproof
Humidity ...................................................................................................................... 95% non-condensing
RF Receiver Module (Models 13363 /13373 only)
General
Frequency range............................................................................................................ VHF: 154–174 MHz
UHF: 450–470 MHz
Antenna impedance................................................................................................................................ 50 Ω
Operating voltage.............................................................................................. 9–18 V dc, 12 V dc nominal
Decoder................................................................................................................................ CTCSS/CDCSS
NOTE: Receiver measurement procedures made per ANSI/TIA/EIA-603
Sensitivity (12 dB SINAD) ............................................................................................................... 0.25 µV
Inter-modulation ................................................................................................................................... 60 dB
Spurious response ................................................................................................................................. 55 dB
Audio output ............................................................................................................................... 900 mVrms
3.5 kHz deviated signal
Approvals
FCC Identifier .............................................................................................................. VHF: AIERT 17-142
UHF: AIERT 17-442
FCC Compliance................................................................................................................................. Part 90
VHF Antenna
Dimensions ........................................................................................................ Maximum 3.00 inches high
Mounting............................................................................................................................... BNC connector
Impedance.............................................................................................................................................. 50 Ω
UHF Antenna
Dimensions ........................................................................................................ Maximum 3.00 inches high
Mounting............................................................................................................................... BNC connector
Impedance.............................................................................................................................................. 50 Ω

Pub. 43004-034C
Model 13353, 13363, and 13373 Addressable Amplified Speakers Page: 9 of 52
f:\radio products-draft\gtc 43004\43004-034c\43004-034c.doc
05/10
General Information
Product Overview
The GAI-Tronics Model 13353, 13363 and 13373 Addressable Amplified Speaker Assemblies are
designed for remote paging in temporary or permanent applications such as campuses, public gathering
locations, construction sites, or amusement parks.
Features
•Hardwired (600-ohm) and RF audio delivery
to speaker amplifier.
•One-way public address broadcasts.
•A high-efficiency (>80%) Class D amplifier
to provide up to 8 watts into an 8-ohm load
(116 dB SPL, measured at 1 meter on axis).
•Generic Operation - (common broadcast)
using input contact closure.
•Selective Operation - addressability for
individual unit, group/zone, or system-wide
broadcasts using DTMF or 2-Tone signaling
access.
•Remote volume control using DTMF
signaling.
•Automatic Level Adjustment automatically
adjusts volume during varying levels of
ambient noise.
•Universal ac input power supply provided.
•Battery trickle charge during normal operation
(battery optional).
•Programmable output control for strobe activation.
•PC programmable using the CARD Suite Programming Software Application.
Available Models
Part No. Description
13353 Hardwired 600-ohm audio input
13363 Hardwired 600-ohm input and/or VHF radio receiver input (154–174 MHz)
13373 Hardwired 600-ohm input and/or UHF radio receiver input (450–470 MHz)
Figure 1. Addressable Amplified Speaker Assembly

Pub. 43004-034C
Model 13353, 13363, and 13373 Addressable Amplified Speakers Page: 10 of 52
f:\radio products-draft\gtc 43004\43004-034c\43004-034c.doc
05/10
Replacement Parts and Kits
Part No. Description 13353 13363 13373
61512-029 Wiring Harness, Weatherproof Amplified Speaker 
13327-021 Speaker 
19101-022 VHF Radio, 154–174 MHz 
19101-023 UHF Radio, 450–470 MHz 
19502-007 VHF Antenna, 150–162 MHz 
19502-009 UHF Antenna, 432–468 MHz 
61213-008 Cable, DB15 male to 8-pin (RF module to PCBA) 
69834-101 PCBA, Weatherproof Amplified Speaker 
BB133 Battery Backup Kit 
40201-010 Repl. Battery, 2.8 Ah, 12 V dc (included in BB133) 
XB001 External Weatherproof Long-life Battery Enclosure 
40201-008 Battery, 18 Ah, 12 V dc for XB001 
SPK200 Solar Power Interface Kit 
12506-001 Remote Volume Control L-Pad 
GTRFP7784
-108
Solar Panel Array, 30-Watt 
190-002PS Weatherproof 15 V dc Power Supply Kit,
85–265 V ac, 50/60 Hz

40408-009 Battery Charger for 40201-010 
40408-011 Battery Charger for 40201-008 
51809-019 3A SloBlo Fuse 
GTRFP6432-
006
Free Standing Tripod 
TPD001 Tripod Mounting Kit 
40419-013 Universal Input AC Power Supply 
Programming Software and Cable
Part No. Description 13353 13363 13373
19101-024 RF Module Programming Kit (software & cable) 
XAC1000A CARD Suite Programming Software CD 
XAC0004A Programming Cable (for speaker) 

Pub. 43004-034C
Model 13353, 13363, and 13373 Addressable Amplified Speakers Page: 11 of 52
f:\radio products-draft\gtc 43004\43004-034c\43004-034c.doc
05/10
System Layout Considerations
The installer must consider the system layout to assure proper audio delivery to the Addressable
Amplified Speakers.
•For hardwired installations, each speaker requires a balanced 600-ohm, 0 dBm input audio signal. A
contact closure may be required depending on the selected operating mode. Cabling (telephone cable,
cat-5/6, etc.) must be distributed appropriately to attain the necessary audio level and balance. Audio
distribution apparatus may be necessary to accomplish this task.
•For RF installations, each speaker must be located within line of site of the RF transmitting device
(repeater, base, or mobile radio).
Operating Modes
The Addressable Amplified Speakers can operate in three different modes, Generic, DTMF Selective,
and Two-Tone Selective. The mode of operation determines if the speakers will broadcast all audio
transmissions or only “selective” audio transmissions. Each operating mode is described in the following
sections.
Generic Operation
Generic Mode requires an external control input to activate (wake up) the Addressable Amplified
Speaker. Once active, the unit will broadcast any audio received from the transmitting device. Removal
of the activation input returns the speaker to the inactive (sleep) mode.
•For hardwired installations, the control input activation must be in the form of a voltage–free (dry)
contact closure.
•For RF installations, the control input activation is provided from the “RF carrier detect” control
circuit of the integral radio receiver. This simply means that audio (carrier) must be received on the
appropriately programmed radio frequency and PL code.
All Addressable Amplified Speakers are factory programmed for Generic Operation.
DTMF Selective Operation
Selective operation allows “addressable” access to each Addressable Amplified Speaker using DTMF
signaling (DTMF Selective) or Two-Tone signaling (Two-Tone Selective). Each speaker can be
programmed with up to eight different addresses. Upon receiving a valid DTMF or Two-Tone code, the
speaker becomes active and will broadcast any audio received from the transmitting device. The speaker
returns to the inactive (sleep) mode when the transmission is complete and a pre-programmed hold time
expires.

Pub. 43004-034C
Model 13353, 13363, and 13373 Addressable Amplified Speakers Page: 12 of 52
f:\radio products-draft\gtc 43004\43004-034c\43004-034c.doc
05/10
By assigning a combination of addresses to each Addressable Amplified Speaker, the overall system can
be segregated into multiple broadcast zones. In a typical multi-zone system, three access codes might be
assigned to each module.
•Address 1 – is always a unique address assigned to only that addressable amplified speaker. By using
this access code, an individual addressable amplified speaker is activated.
•Address 2 – could be an address assigned to a group of addressable amplified speakers located in the
same speaker broadcast area. When received, the group of Addressable Amplified Speakers is
activated simultaneously. This access method is used when an audio broadcast is required to a
particular broadcast zone.
•Address 3 – could be an address assigned to all Addressable Amplified Speakers in the system. By
using this access code, all speakers are activated simultaneously when a system-wide audio broadcast
is required.
DTMF Selective with Manual Switch
This mode is typically used in an RF application or in a hardwired application requiring additional
security to prevent unauthorized access. The DTMF Selective with Manual Switch mode requires an
external control input to activate (wake up) the Addressable Amplified Speaker. Once active, the unit
must receive a valid DTMF address. Upon receiving a valid address, the speaker will broadcast any audio
received from the transmitting device. Removal of the activation input returns the speaker to the inactive
(sleep) mode.
•For RF installations (Models 13363 & 13373), the control input activation is provided from the RF
carrier detect control circuit of the integral radio receiver. This simply means that audio (carrier)
must be received on the appropriately programmed radio frequency and PL code and the appropriate
DTMF address must be received.
•For hardwired installations (Model 13353), the control input activation must be in the form of a
voltage–free (dry) contact closure (additional wire pair).
GAI-Tronics CARD Suite Programming Software is used to assign the operating mode and DTMF
addresses. Valid DTMF addresses can contain two to eight digits followed by the “#” symbol. DTMF
digits 0-9 and A, B, C, and D are permitted.
DTMF Selective with Voice Switch
This mode is used for hardwired installation where a contact closure is not available from the transmitting
device. In this case, the Addressable Amplified Speaker constantly monitors the audio line for a valid
DTMF address. Upon receiving a valid address, the speaker will broadcast any subsequent audio
received from the transmitting device. The speaker returns to the inactive (sleep) mode after audio from
the transmitting device stops for a programmable amount of time.
Two-Tone Selective
GAI-Tronics CARD Suite Programming Software can also be used to assign Two-Tone access codes
instead of DTMF access codes. Valid access codes contain two frequencies in the 400–2700 Hz range.
Each Addressable Amplified Speaker can be programmed with up to eight different codes. By assigning
a combination of access codes to each device, the overall system can be segregated into different speaker
broadcast zones as described above for DTMF signaling. Two-Tone signaling is only applicable for RF
installations. Contact the Service Center at 1-800-492-1212 for instructions in using CARD Suite to
program Two-Tone Selective operation.

Pub. 43004-034C
Model 13353, 13363, and 13373 Addressable Amplified Speakers Page: 13 of 52
f:\radio products-draft\gtc 43004\43004-034c\43004-034c.doc
05/10
Feed-Thru Operation
The Addressable Amplified Speaker can be programmed to perform as a Lead unit or as a Slave unit in a
speaker grouping. This function is referred to as “Feed-Thru” operation and can be activated via the
CARD Suite Programming Software. This operation is primarily used in an RF installation and allows
the Lead Addressable Amplified Speaker to receive the source audio signal via the RF airwaves and
provide hardwired, 600-ohm redistribution of the audio (and page control, if required) to one or more
speakers within a grouping. This configuration could greatly reduce system costs by limiting the number
of RF speakers required.
When in Individual operation, the Lead speaker simply acts as a receiving point for the Slave speaker(s),
allowing the Slave speaker(s) to be addressed individually without activation of the Lead or other Slaves.
When in Follow-me operation, the Slave speaker(s) will activate upon activation of the Lead speaker.
This access includes adjusting volume control settings.
Refer to page 26 for detailed information.
Volume Adjustments
Each speaker assembly’s output volume can be adjusted via four different methods:
•Remotely, using DTMF signaling
•Programmed prior to installation using CARD Suite
•Locally using the optional Model 12506-001 L-pad
•Automatically, utilizing the ALA (Automatic Level Adjustment) feature. This feature would be used
if steady high noise levels sometimes occur but are not present continuously.
Remote Volume Adjustment
With Automatic Level Adjustment Disabled
To adjust the speaker output volume with the Addressable Amplified Speaker programmed for DTMF
selective operation, begin a broadcast using the speaker’s local address (Address 1) followed by a “#”
symbol. When the speaker becomes “active”, transmit a DTMF “*” symbol. Upon receiving the “*”, the
speaker will broadcast a test tone for a programmable amount of time. During this tone, transmit a “*” to
increase the volume or transmit a “#” to decrease the volume. Each press of the “*” will increase the
volume one level and each press of the “#” will decrease the volume one level. The speaker will
broadcast a test tone at the new volume level each time it is changed. Volume can be increased or
decreased between minimum and maximum in 11 steps. A low frequency warning will be broadcast
when the volume has reached either its upper or lower volume limit.
If the speaker under test is programmed for Generic Operation, it will have provisions for programming a
DTMF volume control address via the CARD Suite Programming Software. When properly
programmed, the speaker can be accessed for volume control by simply transmitting its volume control
address and changing the volume as described in the previous paragraph.
CARD Suite includes a test tone duration setting that is programmable between .5 and 6.0 seconds in .5
second increments. This test tone will automatically extinguish at the end of the pre-programmed
duration time or can be manually extinguished by sending a DTMF digit other than “*” or “#.” The
speaker stores its volume setting when the test tone ends.

Pub. 43004-034C
Model 13353, 13363, and 13373 Addressable Amplified Speakers Page: 14 of 52
f:\radio products-draft\gtc 43004\43004-034c\43004-034c.doc
05/10
With Automatic Level Adjustment Enabled
The Automatic Level Adjustment (ALA) allows the speaker to automatically adjust its output to broadcast
at a pre-programmed level above the average ambient noise. Usually an offset of 10 dB is appropriate.
The speaker calculates the average ambient noise level every 5 seconds while it is not broadcasting. The
output level is then adjusted to compensate for the background noise. The first update to the calculated
ambient level will be at most 10 seconds after the standby time expires at the end of a broadcast.
Four settings are available for the ALA feature; Disabled, 5 dB Offset, 10 dB Offset, and 15 dB Offset.
To activate the ALA feature, select one of the three offset levels. The Offset Level is the level of audio
(in dB SPL) above the average ambient noise level, at which the speaker will broadcast.
With ALA enabled, the speaker will adjust its output, based on the steady background noise level in the
vicinity of the speaker, to some level between its maximum output (8 watts) and a programmed minimum
output level. To set this minimum output level, use CARD Suite or adjust the level remotely as described
in the previous section (ALA Disabled). As the background noise level decreases, the speaker output will
also decrease, but the speaker output will not drop below this minimum programmed setting, even when
the background noise drops to a very low level. This setting in CARD Suite is labeled as “Min. Volume
Level.”
Local Volume Adjustment
Local Volume Adjustment is achievable through the use of an L-pad volume control connected to the
speaker assembly (Model 12506-001). No test tone is generated during this adjustment as the user must
generate audio for this test while adjusting the L-pad.
This is a passive adjustment. The maximum output level is defined by the CARD Suite program. Since
the Local Volume Adjustment can only adjust the output level lower than the maximum programmed
level, it is recommended that the Addressable Amplified Speaker is programmed for maximum volume
level (8 watts).
Do not connect an L-pad if the Automatic Level Adjustment is enabled as the automatic adjustment
may be ineffective.
Acoustic Feedback
An audio broadcast command originating too close to an installed speaker (such as from telephones or
portable radios) may create acoustic feedback, depending on the volume level setting of the speaker. To
prevent feedback from occurring, originating distance from the speaker and orientation to the speaker (do
not position in front of the speaker) should be considered.
If the originating position with respect to the speaker’s location requires close proximity, the speaker can
be muted via a “shutdown” closure input. The shutdown closure input could be from a handset
hookswitch, relay, or other similar device.

Pub. 43004-034C
Model 13353, 13363, and 13373 Addressable Amplified Speakers Page: 15 of 52
f:\radio products-draft\gtc 43004\43004-034c\43004-034c.doc
05/10
Output Contact
The Addressable Amplified Speaker is capable of providing a low current output contact designed for
activating a GAI-Tronics Model 530-001 Strobe or other peripheral devices. The Output Contact
Function and its associated Hold Time are programmable via the CARD Suite Software Application and
can be enabled on all or selected DTMF addresses when in DTMF Selective mode. It is also available for
use in Generic mode. If enabled, the contact will activate when the speaker assembly begins to broadcast
audio. The contact will be deactivated either at the end of the audio broadcast (within a few seconds) or
after a selectable Hold Time (if applicable). Hold time can be programmed from 1 second to 30 minutes.
The output contact can be configured as either Normally Open or Normally Closed.
The output contact’s maximum current capability is 100 mA. To use with loads requiring higher current,
an interposing control relay will be required between the speaker assembly’s output contact and the actual
device.
NOTE:The output contact will remain in the “open” state when unit power is removed.
Battery Monitor
If the installed Addressable Amplified Speaker utilizes either the BB133 Battery Backup Kit or the
XB001/40201-008 Long-life Battery (usually used in solar power configuration), the speaker assembly
can be programmed to generate an alert tone when the battery charge falls below the factory-set limit.
Using CARD Suite, enable the Battery Checking feature under the Low Battery Alert section. The
volume of the Low Battery Alert Tone can be adjusted to one of three settings; 50%, 75%, or 100% of the
speaker volume setting. The alert tone will sound every four minutes (factory default setting) until the
battery is charged to a level above the Low Battery Alarm Limit.
NOTE:To avoid hearing an alert tone during initial power up after installation (assuming Battery
Checking has been selected in CARD Suite), it is recommended that the battery be fully charged prior to
installation. Battery charger No. 40408-009 can be used for the BB133 Kit (2.8 Ah) and charger No.
40408-011 can be used for the 40201-008 Battery (18 Ah). If a backup or long-life battery is not
installed, keep this Battery Checking feature disabled (factory default setting).
Programming and Set Up
The Addressable Amplified Speaker requires software configuration to set the operating parameters. It is
highly recommended to program and bench-test the unit prior to field installation.
A computer with a COM port (RS-232) and Windows95 or newer operating system is required to
program the Addressable Amplified Speaker. Windows NT operating system is not supported. If the PC
contains only USB ports, a USB–to–RS-232 converter is also required. Programming accessories are
sold separately. They are as described below:
The No. XAC1000A CARD Suite Programming Software (Version 4.3.0 or newer) and No. XAC0004A
programming cable are used to program the operating parameters of all Addressable Amplified Speaker
models.
The Model 13363 and 13373 RF Addressable Amplified Speakers also require the radio receiver to be
programmed. The No. 19101-024 RF Programming Kit includes the software and cable for programming
the desired frequency and optional PL code into the radio receiver.
