Galaxy DX5 Use and care manual

1
Galaxy DX5 X 1 Printhead
Calibration and Maintenance
4th July, 2015
Version V3.0

2
Contents
Chapter 1: Computer Requirement ................................................................3
Chapter 2:Installation......................................................................................4
Chapter 3:Characteristic...................................................................................5
Chapter 4:Board System.................................................................................6
Chapter 5:Software Installation ......................................................................7
Chapter 6:Software Interface..........................................................................9
Chapter 7: Software Calibration......................................................................10
Chapter 8: Other Functions and Parameters .................................................14
Chapter 9: Maintenance..................................................................................16
Chapter 10: Troubleshoot................................................................................21
Chapter 11: Output Chart.................................................................................22

3
Chapter 1: Computer Requirement
1) Basic requirement:
-CPU: Intel(R) Core(TM)2 Duo CPU E4600 @ 2.4GHz
-Memory: 2GB or higher
-Hard disk: 200 GB (NTFS format, recommend 20GB free space)
-Mother board: USB 2.0 connection equipped
-Network card
-Operating system: Microsoft Windows (XP, 7, 8)
2) Recommendatory requirement:
-CPU: Intel(R) Core(TM) I3-2120 @ 3.10 GHz or higher
-Memory: 4 GB or higher
-Hard disk: 1 TB or higher (NTFS format)
-Motherboard: USB 2.0 connection equipped
-Network card
-Operating system: Microsoft Windows (XP, 7, 8)
NOTICE: Suggest user format your hard disk into 2 partitions (NTFS). The first partition is used for installing
OS and other software, the second partition is used to save pictures and work files.

4
Chapter 2: Installation
1) Move the packing box to the working site and avoid strong shaking.
2) Disassemble the wooden packing box from top to bottom. Check whether the parts are complete or not
according to the packing list.
3) Lift the printer out by a forklift, and move it to the installation site.
4) Check if the printer is level.
5) Get rid of all the parts that stabilize the carriage holder, and install all the spare parts.
6) Move the carriage to the right of printer, then move back to the left manually. During this process, checks if
there are abnormal resistance and carefully inspect the belt & the encoder sensor are situated in proper
position
7) Ground the printer. The grounded voltage shouldn’t be more than 0.3V, and the grounded resistance should
be less than 3Ω.
8) Connect the USB cable between printer and computer. Check if the wires and data cables are plugged in
properly.
9) Install the output and the rip software.
10) Move the carriage to middle of printing platform, turn on the printer, let the carriage move to home position,
and keep your hand on the emergency button for turning off the printer if problem happens suddenly.
11) Send a file to print to test the condition of the printer.
12) Install printhead and dampers, connect the ink tube from damper to special solvent, and use auto clean
function to clean the printhead
13) Load ink bottle, and use auto clean function to suck the ink from ink bottle to printhead.
14) Print nozzle checking and observe the condition of printheads. It is recommended to keep a copy of the test
for reference in the future.
15) Printhead alignment.
16) Start to Print.

5
Chapter 3: Characteristics
Printhead: 1pc (Epson DX5)
Resolution: 1440\1080\720DPI
Color: 4 colors
Print mode: 3,4,6,8,12 Pass
Output mode：File or TCP/IP(Rip and Print at the same time)
Output preview：Convert prn/prt file into a small bmp file for previewing
Printhead usage: Able to turn on/off each printhead channel
Print intelligently：Skip white area
Muti-printing: Able to print single or different image continuously
Automatically flash jetting：Automatically clean printheads by flash jetting during printing
Home flash jet: Prevent nozzles from clogging while not in printing state
Color bar ：Prevent nozzles from clogging, and observe nozzles status. Able to set the
width of color bar and the instance from image
Able to align printheads, step difference ,and bi-direction difference during printing
Printing direction: uni-direction to left, uni-direction to right, bi-direction
Edge feather: Lighten pass line
Cleaning System: auto-cleaning, no need to use tools (Syringe) to clean
Control Panel: use with control panel, it is more convenience

6
Chapter 4: Board System
Printhead Board
Main Board
Encoder sensor
Magnetic sensor
Processing
Indication
Optical Fiber plug
Printhead cable
plug 1
Power flat
cable plug
Status LED
Power LED
Printhead cable
plug 2
X Driver DB plug
Power cable Plug
Y Driver DB plug
Pump plug
Power supply
plug
USB 线接口
Processing Indication
Optical Fiber plug
Status LED
Power LED
Control panel plug

7
Note: 1. After turning on the machine till the carriage moving back to home position, the processing indication
shows as: A. – 1 – 3– 4– 5 – 0.
Main board and Head board show the same indication.
2. The two power cable plug both are 20Pin.
3. In normal state, RUN LED is blinking; LINK LED is on; BUSY LED is on（On Main board, when
carriage moves, BUSY LED is on, otherwise it is off）;ERROR LED is off(only on when there is problem).
Chapter 5. Software Installation
This software consist of printer driver, printing adjustment and picture printing functions.
Please follow the following steps to install the software:
1) Turn on the computer till the system is ready, copy PrintExp_1.39 to your computer, un-zip to get
PrintExp_1.39 folder. Start to install:
2) Double click to install, select the language:

8

9
Chapter 6. Software Interface
1) Introduction: Double click to open the software.
2) Tools bar
We can speed up the implementation of commands by using tools bar which are commonly used function in the
software.
3)Status Bar
From the left to the right: Printer status, Flash jetting function status, Carriage position.
Preview
information
Condition bar
Tools bar
Directory of
printing jobs
Jobs to
print
Printing job list
Configuration definition：
UDT_LC_LD_1H ：LC or LD
model with 1 printhead.
UDT_LC_LD_2H ：LC or LD
model with 2 printheads.

10
Chapter 7. Software Calibration
1. Nozzle checking: Print the nozzle checking to check the condition of the printhead.
Make sure to turn off the Eclosion (Feather) function before doing the alignment.
2. Vertical calibration: Observe the physical alignment of printheads.
（This step is not aligned well which will affect the following adjustment）
Align the physical vertical position of printhead.
The first pass line is the reference; observe whether the second pass line is perfectly aligned with the first
pass line. If not, then we need to adjust the carriage plate. There are 3 situations:
1) The two pass is perfectly aligned, no need to adjust:
2) The second is on the left side of the first pass:
Adjust method:
A. Loosen the 3 screws on the carriage plate:
B. Turn the screw clockwise:
First pass
Second pass
First pass
Second pass

11
3) The second is on the right side of the first pass:
Adjust method:
Note: Every time after the adjustment, before print another vertical calibration, it is required to tighten 3
screws on the carriage plate. Keep adjusting until the second pass is perfectly aligned with the first
pass.
3. Color offset: Color offset is to align all color in order to print good quality images.
Tip: Based on the "0" position, the color lines should totally matched with the Black line, if not, find the best one
showing on the printed out color offset, then input the corresponding values in the software. Note that values are
accumulated.
If the "0" position is not the perfect matching one, then we have to adjust the figure on the software. Go to Option
–Calibration –Color Offset
:
A. Loosen the 3 screws on the carriage plate:
B. Turn the screw anti-clockwise:
First pass
Second pass
Values are input here.

12
After input the value, print the alignment again. And observe if the "0" position is the best or not. If not, repeat the
above procedure until the best result come out.
4. Bi-Dir offset
Bi-Dir offset is to make sure there is no bi-difference while using different speed to print. Bi-Dir offset will be set
for different printing speed.
If the "0" position is not the perfect matching one, then we have to adjust the value on the software. Go to Option
–Calibration -Bi-Dir Offset
Repeat the test until the “0” is facing each other perfectly.
5. Step offset
The Step offset locates on Option –Calibration –Step Offset
:
To adjust the step offset, firstly adjust the Base Step, then the value of other pass will be calculated
automatically. And slightly adjustment is needed according to actual printing.
Input the value here. This
value is accumulated. Press
“Print”to print the test
pattern.
0
4
OK
NG
-4
-8
8
16
-16
Input the offset
value
here.

13
Based on the "0" position, input the value which two line are perfectly overlapped. After input the value, test
again to check the result. The step value will be different according to different media.
Note: Turn off the Eclosion (Feather) function first while adjusting the step offset. Adjust to get the best
step value. Then test print to see whether there is banding on the image. If so, use the Eclosion (Feather)
function to reach your best image quality.
The adjustment of software has been completed now
Have to input +2.

14
Chapter 8. Other Functions and Parameters
1 Printhead voltage
Normally the voltage function is not being used. The range of adjusting voltage is -42V to +1.3V.
2. Other function
Click Option on the main interface of the software, it shows the following window:
Details of the print option:
1. Flash Jetting frequency:
Set the flash jetting frequency when the printer is on standby status.

15
2. Clean Option:
1) Click to set the carriage go back to the flash jetting position for jetting during printing;
2) Print pass is to set every XX pass, carriage go back to the flash jetting position for jetting;
3) Clean Mode is Flash Jetting;
4) There are three options in Clean Time, Fast means non-stop jetting, Normal means jetting for 0.5s,
, Long means jetting for 1s.
3. Eclosion(Feather function):
To blur the pass line, feather pass edge.
1) Option: Enable/Disable the feather function; 2) Type of Eclosion; 3) Value of Eclosion.
4. Color Bar:
1) Distance (mm): Setup for distance between the color bar and the picture;
2) Width (mm): Setup for the width of the whole color bars ;
3) Setup for the position of color bar (in the right/left/both side of the image ).
5. Smart Print:
Set up for automatically skip white.
6. Auto feed after printed:
Set up for automatically feed media after printing(mm).

16
Chapter 9. Maintenance
9.1 Normal Cleaning
Click Clean on the main interface of the software. There are two modes of cleaning, Standard and Depth.
Normally Standard mode is used.
9.2 Cleaning procedures for nozzle clogging:
1. Disconnect the tube connector for the tube from cartridge to the damper. Choose Standard clean mode the
suck out the ink in the damper. (2 times)
2. Use an extend tube to connect the damper, put the other side of the extend tube into the appointed Flush.
Choose Depth clean mode to clean the damper and the printhead at the same time.(3 times)
3. Take out the extend tube from the Flush, and keep it out in the air. Choose Depth clean mode to suck out the
Flush inside the damper and the printhead. After that connect the damper to the ink incoming tube and fill ink
again.
4. Test print.
9.3 Carriage Bearing and Steel Rail Maintenance
Due to the carriage slides on four steel plates and eight bearing, clean and lubricate four steel plates with grease
everyday.
Ⅰ. Wipe a thin layer of grease on steel plates to maintain cleanliness and grease everyday before and after
usage.
Ⅱ. Be aware of the smoothness of the carriage bearing.

17
9.4 Daily Maintenance
1. Print the nozzle checking before turn off the machine to make sure the printhead is in normal condition
2. Turn off the software, carriage go back to Home position automatically. Turn off the machine, the carriage stay
at the Home position.
3. Use sponge stick with appointed Flush to clean the cap and the wiper everyday before turning on the machine.
9.5 Short term shut down (3~7 days)
1. Disconnect the tube connector on top of the damper. Use Standard clean mode to empty the ink in the damper.
(2 times)
2. Use a extend tube to connect the damper to the appointed Flush.
Choose Depth clean mode to clean the damper and the printhead at the same time.(2 times)
3. Take out the extend tube from the Flush, and keep it out in the air. Choose Depth clean mode to empty the
Flush inside the damper and the printhead. Use the tube cover to seal the ink incoming tube, keep the cartridge
back to Home position and make sure the capping pad is perfectly capping the printhead.
9.6 Long term shut down (More than a week)
1. Print status before turn off the machine, make sure printhead in good condition..
2. Disconnect the tube connector on top of dampers, let the ink flow back to the cartridge.
3. Use the extend tube to connect them to the appointed Flush. Choose Depth clean mode to clean the damper
and the printhead at the same time. Clean one color at a time, use a cap to cover other three color channel.

18
4. Take out the extend tube from the Flush, and keep it out in the air. Choose Depth clean mode to empty the
Flush inside the damper and the printhead.
5. Take out the four tubes(K,C,M,Y) from the cartridge. Use the extend tube to connect them to flush.

19
Use a extend ink tube to connect the ink tube to ink pump
Choose “Ink Fill” mode at control panel, use ink pump to flush ink tube until it is clear. Then take out the tube from
the Flush, choose “Ink Fill” mode, empty the Flush inside the ink tube. Clean K,C,M,Y tube one by one
After cleaning, use cap and fresh warp to seal the ink tubes.

20
6. Take out four cartridges, use fresh wrap to seal the ink supply hole and keep the cartridges in the proper
place.
7. Keep the carriage back to Home position and make sure the cap is perfectly sealing the printhead.
