Galmet SGW(S) Mini Tower 100 User manual

www.galmet.euMade in Poland
Please read the instructions carefully before beginning the installation and use of the product.
Installation and operating manual
Heater (exchanger) for domestic tap water
SGW(S) Mini Tower (vertical)
SGW(S) Tower (vertical)
SGW(S) Big Tower (vertical)
SGW(S)B Tower Biwal (vertical)
SG(S) (vertical)
SGW(S) (horizontal)
Type: Cover: Colour: Spiral coils:
100
120
140
200
250
300
400
500
700
800
1000
1500
skay
articial leather
white
grey
red
blue
Version:
standard
slim
one
two (bivalent)
two in the lower
part of the tank
without spiral coils
Anode:
magnesium
titanium (option)
Insulation:
detachable
non-detachable
Cat. No./ Serial No. ..............................
Date of manufacture ...........................
QC

Installation and Operating Manual /Warranty Card - SGW(S), SGW(S)B, SG(S) © All rights reserved - Galmet Sp. z o.o. Sp. K.2
1. Operation and service ...................................................................................................................................................................................................3
1.1. Heater characteristics.........................................................................................................................................................................................3
1.2. Description.........................................................................................................................................................................................................3
1.3. Venting the coil in horizontal heaters.................................................................................................................................................................3
1.4. Installation.........................................................................................................................................................................................................3
1.5. Remember .........................................................................................................................................................................................................3
2. Schemes........................................................................................................................................................................................................................5
2.1. Exemplary connection scheme of the water heater in an open system ..............................................................................................................5
2.2. Exemplary connection scheme of the water heater in an closed system ............................................................................................................5
2.3. Installation diagram of the drain valve...............................................................................................................................................................6
2.4. Electrical diagrams.............................................................................................................................................................................................6
3. Troubleshooting............................................................................................................................................................................................................6
4. Titanium, maintenance-free, active anode ...................................................................................................................................................................7
4.1. Pros of the titanium anode.................................................................................................................................................................................7
4.2. Troubleshooting.................................................................................................................................................................................................7
5. Technical specication ..................................................................................................................................................................................................8
5.1. Pressure losses for water heaters with one spiral coil .........................................................................................................................................8
5.2. Technical specication of the SGW(S): MiniTower (100-140), Tower (200-500), BigTower (700-1500) .............................................................8
5.3. Scheme of the SGW(S): Mini Tower (100-140),Tower (200-500), BigTower (700-1500)....................................................................................9
5.4. Technical specication of the SGW(S)Tower Slim 200-300...............................................................................................................................10
5.5. Scheme of the SGW(S) Tower Slim 200-300 .....................................................................................................................................................11
5.6. Technical specication of the SGW(S)Tower Slim 800-1000.............................................................................................................................12
5.7. Scheme of the SGW(S) Tower Slim 800-1000 ...................................................................................................................................................13
5.8. Technical specication of the SGW(S)BTower Biwal 200-1500.........................................................................................................................14
5.9. Scheme of the SGW(S)B Tower Biwal 200-1500 ...............................................................................................................................................15
5.10. Technical specication of the SGW(S)BTower Biwal Max 200-500 with two spiral coils at the bottom part of the tank...................................16
5.11. Scheme of the SGW(S)B Tower Biwal Max 200-500 with two spiral coils at the bottom part of the tank..........................................................17
5.12. Technical specication of the SGW(S)BTower Biwal Slim 200-300...................................................................................................................18
5.13. Scheme of the SGW(S)B Tower Biwal Slim 200-300..........................................................................................................................................19
5.14. Technical specication of the SGW(S)BTower Biwal Slim 800-1000.................................................................................................................20
5.15. Scheme of the SGW(S)B Tower Biwal Slim 800-1000........................................................................................................................................21
5.16. Technical specication of the SG(S) 100-500....................................................................................................................................................22
5.17. Scheme of the SG(S) 100-500...........................................................................................................................................................................23
5.18. Technical specication of the SG(S) 700-1500..................................................................................................................................................24
5.19. Scheme of the SG(S) 700-1500.........................................................................................................................................................................25
5.20. Technical specication of the SGW(S) 140-300 (horizontal) .............................................................................................................................26
5.21. Scheme of the SGW(S) 140-300 (horizontal)....................................................................................................................................................27
6. Declaration of Conformity...........................................................................................................................................................................................28
7. Product che...............................................................................................................................................................................................................31
8. Guarantee terms and conditions.................................................................................................................................................................................33
Table of contents

© All rights reserved - Galmet Sp. z o.o. Sp. K. Installation and Operating Manual /Warranty Card - SGW(S), SGW(S)B, SG(S) 3
1. Operation and service
1.1. Heater characteristics
Hot tap water heater is designed to heat water and store it in a heated state. It can be used to meet the needs of households in establishments catering,
public welfare establishments, etc. The heater is designed to work only in horizontal or vertical position, depending on the type. It can be connected to the
water supply at a pressure not exceeding 0,6 MPa - about 6 bar (in the case of tanks with capacity from 100 liters to 140 liters) and 1 MPa - about 10 bar (in
the case of tanks with capacity from 200 liters to 1500 liters).The water can be heated by the spiral wound heat exchanger which (i.e. high surface area coil)
connected to the central heating boiler. The basic model is a hot tap water heater with one coil (pt. 5.3; 5.5; 5.7). We oer water heaters with two spiral coils
(bivalent): one coil for the CH system and the other for the solar heating system (pt. 5.10; 5.12; 5.14). Lower coil cooperates with a solar collector, and the
top coil with the CH boiler or a heat pump.We oer hot tap water reservoirs (pt. 5.16; 5.18) and horizontal water heaters (pt. 5.18). Anticorrosion protection
is provided by a ceramic enamel burned at 850°C. Moreover, large magnesium anode acts as an extra protection. Heaters are insulated with ecological
polyurethane or polystyrene foam, which reduces heat loss to an absolute minimum.
1.2. Description
The main part of the heater is a tank in which the water is heated.The tank is made of a steel sheet, which is coated on the inside with ceramic enamel.
Technological holes in the bottoms of the tank are closed with stoppers. The tank is equipped with two coil connections; the cold water outlet and inlet
connections are located next to each other on one side of the tank. In addition, there is also provided an opening for connecting the circulation and the
sensor cover - to which the sensor can be connected with the boiler thermostat (tube 3/8”). The standing heaters 100 to 140 l in the top of the bottom
anode is located, which is placed on the stopper 5/4”. Tanks are from 200 to 1500 l, there are two magnesium anodes: one is arranged in the opening of
the manhole M8 screw and the other is at the top of the bottom on the heels of 5/4”(200 - 500 l), 2”(700 - 1500 l). Heaters are equipped with additional
connections (3/4„ capacity. 100-140 l and 1”capacity. 200 -1500 l) where you can install the drain valve .
In the SGW(S)B 200 , SGW(S) SLIM 200-300 , SGW(S)B 200-300 SLIM and SGW(S) horizontal 140-300 water heaters it is recommended to install a tee on
the cold water inlet as well as a the drain valve in order to properly drain the tank (pt. 2.3).
1.3. Venting the coil in horizontal heaters
For easier (simpler) venting of the spiral coil it is necessary to:
- put the tank in a vertical position (on the lid),
- close the return from the coil (f.ex. by using a ball valve),
- pour water or glycol solution into the coil (depending on the type of installation),
- close the coil's supply connection (f.ex. by using a ball valve),
- mount the tank on the frame (not included),
- connect the tank to the installation.
1.4. Installation
Connection of the water heater should be done by the installer with the appropriate permissions. The installation must be conrmed in the warranty card.
The heater must be installed in vertical or horizontal position depending on the type of the tank.
The heater should be connected directly to the water supply (with the possibility of disconnection, f.ex. in the case of maintenance) at a pressure not
exceeding 0,6 MPa (tanks with the capacity between 100 and 140 l) and 1,0 MPa - about 10 bar (tanks with the capacity between 200 and 1500 l) while the
minimum pressure shall be not less than 0,1 MPa (approx. 1 bar). If the water pressure in the mains supply exceeds 0,6 MPa tanks with the capacity between
100 and 140 l) and 1,0 MPa - about 10 bar (tanks with the capacity between 200 and 1500 l) the pressure must be reduced by the use of a pressure regulator.
Safety valve must be installed on the cold water supply pipe (f. ex. ZB4/ZB8 valves from FACH Cieszyn or ZB7/ZB9 valves from Orkla Spain) according to the
direction of the arrow located on the tank. The safety valve can reduce pressure without the water overowing to the supply installation (it opens the ow
of the dierential pressure in the heater and installation amounting to 0,07 0,03 MPa, which is why cold water supply pipe must withstand a temperature of
90°C up to 5 meters from the safety valve (because of the possibility of the ow of hot water from the tank into the installation). An outow opening in the
safety valve must be constantly connected to the open atmosphere. Before using the installation it is necessary to check all of the connections for leakage,
1. Operation and service

Installation and Operating Manual /Warranty Card - SGW(S), SGW(S)B, SG(S) © All rights reserved - Galmet Sp. z o.o. Sp. K.4
even those factory sealed.
The heater can work in an open system (pt. 2.1) or in a closed system including an expansion vessel (pt. 2.2). In winter, when there is a possibility of the water
freezing, the water should be drained by removing the drain plug Ks (pt. 2.1 and 2.2).
1.5. Remember
1. Before installation of the heater it is recommended to read the installation and user manual that comes with the device.
2. Do not start using a water heater that is not lled with water.
3. Do not operate the water heater without a fully operational relief valve (proper functioning of the relief valve must be checked every 14 days by turning
its cap left or right to induce an outow of water from a discharge port located on the side of the valve. Following that, turn the cap in the opposite
direction until it snaps in place and press down to the valve body. If there is not outow of water while turning the cap, the valve is not operational. A
continuous outow of water after returning the cap to its previous position indicates valve head contamination. In such a case, ush the valve several
times by turning the cap to open the outow of water. Caution - there is a possibility of hot water outow. The company will not be responsible for
improper functioning of the relief valve caused by wrong installation or errors within the system, e.g. missing a pressure reducing valve in the cold water
removal system. The maximum pressure of full opening of relief valve must not exceed 0,7 MPa (100-140 l water heaters) and 0,97 MPa (200-1500 l
water heaters).
4. If there is a cold water system, supplying it to the heater, check valve or other device functioning as a check valve such as a pressure reducer must be
installed in the water bulk expansion vessel with a capacity of at least 5 % of the capacity of the boiler.
5. Installations equipped with a water heater cannot include devices that cause a "hydraulic stroke", f.ex. a ball valve used as a drain valve.
6. Do not prevent water from dripping from the relief valve – do not plug the discharge port of the relief valve. If water continuously leaks from the
relief valve, it indicates that the water main system pressure is too high, or that the relief valve is defective. Discharge port of the relief valve should
be oriented downwards. It is recommended to place a funnel underneath the relief valve to collect and drain water. A hose can also be tted over the
discharge port to remove water owing when the relief valve is being opened. The hose should be heat resistant up to +80°C, with internal diameter
of 9 mm and max. length of 1,2 m, run to a drain with a downgrade (min. 3%) in an environment of temperature not lower than 0°C.The hose must be
protected against bottlenecking (squeezing, plugging) and its discharge end should be visible (in order to verify operation of the valve).
7. The water quality shall be in accordance with the Regulation of the Minister of Health of 29 March 2007.
8. Conductivity should not be less than 100 uS / cm, this will ensure the proper operation of the magnesium anode.
9. Immediately turn o the heater if the tap emits steam (it should be reported to the manufacturer or to a designated service).
10. Continuous operation at a maximum temperature results in faster wear of electrical parts and the tank itself.
11. Adequate protection of the CH boiler connected to the tank ensures proper security of the water heater's spiral coils.
12. It is forbidden to connect the coil to the installation which does not meet one of the following standards: PN−91/B−02413 or PN−91/B−02414.
13. At least once every 12 months the water heater should be rinsed from the sediment.
14. Pollution lters should be used in order to extend the life of the tank and ensure the smooth operation of the safety valve.
15. „Galmet Sp. z o. o.”Sp. K. reserves the right to introduce any modication without prior notication.
16. Before starting operation of the heater, the user is required to read this document, it must be kept on-site and be accessible to the service.
17. The heating coil should be ushed by the installer before the rst use (besides, installing a lter is recommended to remove any impurities). If the
heating coil is not used (e.g. due to the use of an electric resistance heater), it must be completely lled with an appropriate glycol mixture in order to
prevent corrosion caused by condensed water. After lling, the heating coil must not be closed on both sides (thermal expansion of air).
18. The tank has an outer casing made of articial leather (skay, PVC foil), while the thermal insulation is made of polyurethane or polystyrene foam. It is
not allowed to manipulate open re directly next to the tank, as it may damage the outer casing as well as the thermal insulation
19. All maintenance and installation works must be performed in accordance with applicable health and safety regulations.
20. Unpleasant scents and darkening of the water from the heater may be the result of a hydrogen sulphide, which is formed by reducing the sulphate
content of bacteria that live in oxygen-free water. If cleaning the tank, replacing the magnesium anode and starting with a temperature above 60°C will
not yield result, we recommend using a titanium anode.
1. Operation and service

© All rights reserved - Galmet Sp. z o.o. Sp. K. Installation and Operating Manual /Warranty Card - SGW(S), SGW(S)B, SG(S) 5
2. Schemes
2.1. Exemplary connection scheme of the water heater in an open system
N - collection vessel for an open system
Zb - safety valve*
Z1 - shut o valve on cold water inlet
Z2 - shut o valve on hot water outlet
Z3, Z4 - shut o valve on water inlet from
the heating system to the coil
Z5 - shut o valve on water inlet from the
heating system to the coil
O - water heater's housing
Ks - water outlet (drain)
C - circulation
GE - connection for the heating element
W. S. - spiral coil
Tr. - thermometer
Cz. - sensor cover
2.2. Exemplary connection scheme of the water heater in an closed system
N - expansion vessel
Zb1 - safety valve*
Zb2 - CH installation safety valve.*
Z1 - shut o valve on cold water inlet
Z2 - shut o valve on hot water outlet
Z3, Z4 - shut o valve on water inlet
from the heating system to
the coil
Z5 - shut o valve on water inlet from
the heating system to the coil
O - water heater's housing
Ks - water outlet (drain)
C - circulation
GE - connection for the heating
element
W. S. - spiral coil
Tr. - thermometer
Cz. - sensor cover
P - circulation pump
* not included
2. Schemes

Installation and Operating Manual /Warranty Card - SGW(S), SGW(S)B, SG(S) © All rights reserved - Galmet Sp. z o.o. Sp. K.6
2.3. Installation diagram of the drain valve
cold water
In order to drain the tank it is necessary to:
1. Close the cold water inlet before the valve or the relief group.
2. Open the„ZS”drain valve.
3. Open the hot water faucet so the air could ow through to the tank.
2.4. Electrical diagrams
Legend:
1. Heating element
2. Bimetal thermostat
3. Temperature limiter
Ls. cz. - red light, info about the heater's work
Ls. z. - green light, info about the voltage in the heating module
230 V~ electrical scheme (heater 2-3 kW)
grz.
grz.
grz.
L1
L2
L3
A1
A2
A3
B1
B2
B3
2
N
PE 3
4
1
400 V~ electrical scheme (heater 4,5-9 kW) 400 V~ electrical scheme (heater 12-24 kW)
3. Troubleshooting
MALFUNCTION CAUSE METHOD OF REMOVAL
The relief valve does not open
(also at the attempt of blowing-
through).
-Relief valve is seized. -Clean or replace the valve.
Relief valve leaks. -The faying surface of the relief valve is
contaminated or damaged.
-Water pressure is too high.
-Clean or lap the faying surface of the relief valve.
-Use a pressure regulator.
DHW water is dirty. -Plenty of deposit in the tank, or the magne-
sium anode is used up.
-Clean the tank of any deposit, or replace the magnesium anode
(not covered by the warranty).
2. Schemes / 3. Troubleshooting

© All rights reserved - Galmet Sp. z o.o. Sp. K. Installation and Operating Manual /Warranty Card - SGW(S), SGW(S)B, SG(S) 7
4. Titanium, maintenance-free, active anode
4.1. Pros of the titanium anode
- reliable, durable protection
- low consumption of anodes
- no sludge on the anode
- not required regeneration
- guaranteed long-term operation of the tank
1. Titanium anode
2. Potentiostat (AC)
3. Grounded cord
NOTE ! Before installing the anode CORREX, remove existing protective magnesium anode.
1. Cable supplied bipolar, connecting the anode CORREX and potentiometer plug must not be lengthened.
2. A random change in polarity causes the acceleration of corrosion.
3. It is recommended to use the socket 230 V in a short distance from the tank.
4.2. Troubleshooting
LED CONTROL CAUSE METHOD OF REMOVAL
ON - green colour -Anode CORREX working properly. Full
protection against corrosion.
-
OFF -Lack of electricity. -Check the voltage 230V.
ON - red colour -Lack of water in the tank.
-Cables between the electronic part and the
anode is connected incorrectly.
-Lack of contact between the ground (tank)
and the electrical part of the anode.
-The anode is contacted with the mass of
the tank.
-Fill the tank with water.
-Put the cables at the anode.
-Check and clean the rust all connections.
-Properly isolate the anode from the tank.
It is NECESSARY to use a dielectric connectors (made out of a plastic material - electrically nonconductive) between the hot and cold water
connections and the installation's connections in order to avoid iron-copper contact, also in case where the relief group is connected directly
to the tank. This extends the life of the water tank and prevents electrolysis phenomena, especially when the water is acidic (pH <7).
The symbol presented beside signies that it is prohibited to dispose of worn electrical and electronic devices together with other waste.
These products should be delivered to assigned waste collection points for waste processing. A proper recycling of electrical and electronic
devices helps to protect the natural environment and prevents negative impact on human health.
4. Titanium, maintenance-free, active anode

Installation and Operating Manual /Warranty Card - SGW(S), SGW(S)B, SG(S) © All rights reserved - Galmet Sp. z o.o. Sp. K.8
5. Technical specication
5.1.Technical specication of the SGW(S): MiniTower (100-140),Tower (200-500), BigTower (700-1500)
Specication Unit SGW(S) MiniTower SGW(S)Tower SGW(S) Big Tower
100 120 140 200 250 300 400 500 700 1000 1500
Storage capacity 1l102 114 129 197 247 309 405 513 694 1005 1433
Nominal capacity l106 120 136 210 262 322 420 523 705 1019 1442
Tank's max. working temp. °C 95 95 95 95 95 95 95 95 95 95 95
Coil's max. working temp. °C 110 110 110 110 110 110 110 110 110 110 110
Tank's max. working pressure MPa 0,6 0,6 0,6 1,0 1,0 1,0 1,0 1,0 1,0 1,0 1,0
Coil's max. working pressure MPa 0,6 0,6 0,6 1,6 1,6 1,6 1,6 1,6 1,6 1,6 1,6
Coil surface m20,6 0,95 0,95 1,4 1,4 1,4 1,8 2,0 2,4 2,7 2,7
Coil power (70/10/45°C) kW 16 23 23 33,6 33,6 33,6 43 48 57,6 64,8 64,8
Levelling feet -yes yes yes yes yes yes yes yes no no no
Bimetal thermometer -yes yes yes yes yes yes yes yes yes yes yes
Magnesium
anode
5/4" plug 325x390 25x390 25x390 38x400 38x400 38x400 38x400 38x600 38x600 38x600 38x600
M8 screw ---38x200 38x200 38x200 38x200 38x200 38x200 38x400 38x400
Eciency l/h 390 560 560 800 800 800 1030 1150 1380 1580 1580
Connections for the SGW(S) 100-400, 700, 1000 water heaters
h1 - Cold water inlet G" / mm ¾ / 210 ¾ / 165 ¾ / 165 1 / 210 1 / 210 1 / 130 1 / 240 -6⁄4/ 215 6⁄4/ 250 -
h2 - CH water outow G" / mm ¾ / 310 ¾ / 250 ¾ / 250 1 / 290 1 / 285 1 / 280 1 / 320 -1 / 375 1 / 450 -
h3 - Sensor cover G" / mm R 3⁄8 / 400 R 3⁄8 / 375 R 3⁄8 / 375 R 3⁄8 / 435 R 3⁄8 / 440 R 3⁄8 / 435 R 3⁄8 / 570 -R 3⁄8 / 575 R 3⁄8 / 590 -
crk - Circulation G" / mm ¾ / 500 ¾ / 450 ¾ / 450 ¾ / 680 ¾ / 600 ¾ / 650 ¾ / 770 -5⁄4/ 925 5⁄4/ 875 -
h4 - CH hot water inow G" / mm ¾ / 710 ¾ / 750 ¾ / 750 1 / 790 1 / 755 1 / 750 1 / 870 -1 / 1045 1 / 1000 -
h5 - DHW outow G" / mm ¾ / 790 ¾ / 920 ¾ / 1070 1 / 860 1 / 1085 1 / 1355 1 / 1470 -6⁄4/ 1715 6⁄4/ 1570 -
Connections for the SGW(S) 500, 1500 water heaters
h1 - Cold water inlet G" / mm -------1 / 180 - - 6⁄4/ 250
h2 - CH water outow G" / mm -------1 / 320 - - 1 / 450
h3 - Sensor cover G" / mm -------R 3⁄8 / 530 - - R 3⁄8 / 600
h4 - CH hot water inow G" / mm -------1 / 970 - - 1 / 1000
crk - Circulation G" / mm -------¾ / 1320 - - 5⁄4/ 1630
h5 - DHW outow G" / mm -------1 / 1650 - - 6⁄4/ 2250
Dimensions
Coupler for an electrical set G" 5/4 5/4 5/4 6/4 6/4 6/4 6/4 6/4 6/4 6/4 6/4
Inspection hole Ø - - - 180/120 180/120 180/120 180/120 180/120 280/205 280/205 280/205
d - Internal diameter Ø400 400 400 550 550 550 600 630 700 900 900
D - External diameter Ø518 518 518 670 670 670 700/8002755/8402855/86021055/1060211002
L - Height with insulation mm 1020 1120 1270 1100 1300 1615 1750 1950 2050/208021960/199022650/26802
Weight (empty) kg 55 60 65 84 108 118 137 157 260 415 540
1In accordance with the Commission Regulation (UE) 812/2013, 814/2013
2Detachable Neodul insulation
3Capacities 700, 1000 and 1500 l - magnesium anode plug 2"

© All rights reserved - Galmet Sp. z o.o. Sp. K. Installation and Operating Manual /Warranty Card - SGW(S), SGW(S)B, SG(S) 9
5.3. Scheme of the SGW(S): MiniTower (100-140),Tower (200-500), BigTower (700-1500)
cr
k
h3
h2
h1
h5
h4
SGW(S) 100-140 SGW(S) 200, 250, 400
cr
k
h3
h2
h1
h5
h4
cr
k
h3
h2
h1
h5
h4
SGW(S) 300, 700, 1000 SGW(S) 500, 1500
cr
k
h3
h2
h1
h5
h4
5. Technical specication

Installation and Operating Manual /Warranty Card - SGW(S), SGW(S)B, SG(S) © All rights reserved - Galmet Sp. z o.o. Sp. K.10
5. Technical specication
5.4. Technical specication of the SGW(S)Tower Slim 200-300
Specication Unit SGW(S) Tower Slim 200 SGW(S)Tower Slim 250 SGW(S)Tower Slim 300
Storage capacity 1l 205 247 292
Tank's max. working temp. °C 95 95 95
Coil's max. working temp. °C 110 110 110
Tank's max. working pressure MPa 0,1 0,1 0,1
Coil's max. working pressure MPa 0,6 0,6 0,6
Coil surface m20,8 1,0 1,4
Coil power (70/10/45°C) kW 21,4 23,6 33,6
Eciency l/h 526 585 814
Magnesium
anode
5/4" plug 38x400 38x400 38x400
M8 screw 38x200 38x200 38x200
Connections for the SGW(S) Tower Slim 200 water heaters
h1 - Cold water inlet G" / mm 1 / 140 - -
h2 - CH water outow G" / mm 1 / 225 - -
h3 - Sensor cover G" / mm ½ / 325 - -
h4 - Circulation G" / mm ¾ / 485 - -
h5 - CH hot water inow G" / mm 1 / 585 - -
h6 - DHW outow G" / mm 1 / 1025 - -
Connections for the SGW(S) Tower Slim 250-300 water heaters
h1 - Cold water inlet G" / mm - 1 / 140 1 / 140
h2 - CH water outow G" / mm - 1 / 225 1 / 225
h3 - Sensor cover G" / mm - ½ / 410 ½ / 470
h4 - CH hot water inow G" / mm - 1 / 695 1 / 775
h5 - Circulation G" / mm - ¾ / 1050 ¾ / 1140
h6 - DHW outow G" / mm - 1 / 1245 1 / 1495
Dimensions
d - Internal diameter Ø 500 500 500
D - External diameter Ø 600/6702600/7002600/7002
L - Height with insulation mm 1300/135521515/156521765/18252
Weight (empty) kg 72/77284/90296/1052
1In accordance with the Commission Regulation (UE) 812/2013, 814/2013.
2ErP class A.

© All rights reserved - Galmet Sp. z o.o. Sp. K. Installation and Operating Manual /Warranty Card - SGW(S), SGW(S)B, SG(S) 11
5.5. Scheme of the SGW(S) Tower Slim 200-300
h1
L
h2
h3
h4
h5
h6
h1
L
h2
h3
h4
h5
h6
SGW(S) Tower Slim 200 I SGW(S) Tower Slim 250÷300 l
5. Technical specication

Installation and Operating Manual /Warranty Card - SGW(S), SGW(S)B, SG(S) © All rights reserved - Galmet Sp. z o.o. Sp. K.12
5. Technical specication
5.6. Technical specication of the SGW(S)Tower Slim 800-1000
Specication Unit SGW(S) Tower Slim 800 SGW(S) Tower Slim 1000
Storage capacity 1l 790 925
Tank's max. working temp. °C 95 95
Coil's max. working temp. °C 110 110
Tank's max. working pressure MPa 1,0 1,0
Coil's max. working pressure MPa 1,6 1,6
Coil surface m22,4 3,7
Coil power (70/10/45°C) kW 44,5 60
Eciency l/h 1099 1468
Magnesium
anode
2" plug 38x600 38x600
5/4" plug 38x400 38x400
Connections
h1 - Cold water inlet G" / mm 6⁄4/ 210 6⁄4/ 210
h2 - CH water outow G" / mm 1 / 380 1 / 380
h3 - Sensor cover G" / mm ½ / 610 ½ / 610
h4 - CH hot water inow G" / mm 1 / 1030 1 / 1265
h5 - Circulation G" / mm 5⁄4/ 1352 5⁄4/ 1640
h6 - DHW outow G" / mm 6⁄4/ 1610 6⁄4/ 1910
Dimensions
d - Internal diameter Ø 790 790
D - External diameter Ø 95029502
L - Height with insulation mm 1990 2300
Weight (empty) kg 290 355
1In accordance with the Commission Regulation (UE) 812/2013, 814/2013.
2Detachable Neodul insulation.

© All rights reserved - Galmet Sp. z o.o. Sp. K. Installation and Operating Manual /Warranty Card - SGW(S), SGW(S)B, SG(S) 13
5.7. Scheme of the SGW(S) Tower Slim 800-1000
SGW(S) Tower Slim 800-1000
5. Technical specication

Installation and Operating Manual /Warranty Card - SGW(S), SGW(S)B, SG(S) © All rights reserved - Galmet Sp. z o.o. Sp. K.14
5. Technical specication
5.8. Technical specication of the SGW(S)BTower Biwal 200-1500
Specication Unit SGW(S)B Tower Biwal
200 250 300 400 500 700 1000 1500
Storage capacity 1l 197 244 299 395 496 683 992 1420
Nominal capacity l 210 259 322 420 525 705 1019 1442
Tank's max. working temp. °C 95 95 95 95 95 95 95 95
Coil's max. working temp. °C 110 110 110 110 110 110 110 110
Tank's max. working pressure MPa 1,0 1,0 1,0 1,0 1,0 1,0 1,0 1,0
Coil's max. working pressure MPa 1,6 1,6 1,6 1,6 1,6 1,6 1,6 1,6
Solar coil's surface m21,0 1,2 1,4 1,8 2,0 2,4 2,7 2,7
Solar coil's power (70/10/45°C) kW 24 29 33,6 43 48 57,6 64,8 64,8
Solar coil's eciency l/h 570 635 800 1030 1150 1380 1580 1580
CH coil's surface m20,7 0,7 1,1 1,1 1,1 1,2 1,5 1,5
CH coil's power (70/10/45°C) kW 17 17 26,4 26,4 26,4 28,8 36 36
CH coil's eciency l/h 410 410 630 630 630 690 880 880
Magnesium
anode
5/4" plug 338x400 38x400 38x400 38x400 38x600 38x600 38x600 38x600
M8 screw 38x200 38x200 38x200 38x400 38x200 38x400 38x400 38x400
Connections of the SGW(S)B 100-400, 700, 1000 water heaters
h1 - Cold water inlet G" / mm 1 / 130 1 / 210 1 / 130 1 / 240 - 6⁄4/ 215 6⁄4/ 250 -
h2 - Water outow to solar collector G" / mm 1 / 210 1 / 290 1 / 280 1 / 320 - 1 / 375 1 / 450 -
h3 - Sensor cover I G" / mm R 3⁄8/ 355 R 3⁄8/ 400 R 3⁄8/ 435 R 3⁄8/ 570 - R 3⁄8/ 575 R 3⁄8/ 590 -
crk - Circulation G" / mm ¾ / 450 ¾ / 595 ¾ / 650 ¾ / 770 - 5⁄4/ 925 5⁄4/ 880 -
h4 - Hot water inow from solar collector G" / mm 1 / 550 1 / 695 1 / 750 1 / 870 - 1 / 1045 1 / 1000 -
h5 - CH water outow G" / mm 1 / 635 1 / 795 1 / 860 1 / 980 - 1 / 1175 1 / 1100 -
h6 - Sensor cover II G" / mm 3⁄8/ 765 3⁄8/ 900 3⁄8/ 1030 3⁄8/ 1150 -3⁄8/ 1365 3⁄8/ 1250 -
h7 - CH hot water inow G" / mm 1 / 895 1 / 1005 1 / 1200 1 / 1330 - 1 / 1555 1 / 1440 -
h8 - DHW outow G" / mm 1 / 975 1 / 1085 1 / 1355 1 / 1470 - 6⁄4/ 1715 6⁄4/ 1570 -
Connections of the SGW(S)B 500, 1500 water heaters
h1 - Cold water inlet G" / mm - - - - 1 / 180 - - 6⁄4/ 250
h2 - Water outow to solar collector G" / mm - - - - 1 / 320 - - 1 / 450
h3 - Sensor cover I G" / mm - - - - R 3⁄8/ 530 - - R 3⁄8/ 600
h4 - Hot water inow from solar collector G" / mm - - - - 1 / 970 - - ¾ / 1000
h5 - CH water outow G" / mm - - - - 1 / 1090 - - 1 / 1100
h6 - Sensor cover II G" / mm ----R 3⁄8/ 1200 - - R 3⁄8/ 1250
crk - Circulation G" / mm - - - - ¾ / 1320 - - 5⁄4/ 1630
h7 - CH hot water inow G" / mm - - - - 1 / 1440 - - 1 / 1435
h8 - DHW outow G" / mm - - - - 1 / 1650 - - 6⁄4/ 2250
Dimensions
Coupler for an electrical set G" 6/4 6/4 6/4 6/4 6/4 6/4 6/4 6/4
Inspection hole Ø 180/120 180/120 180/120 180/120 180/120 280/205 280/205 280/205
d - Internal diameter Ø 550 550 550 600 630 700 900 900
D - External diameter Ø 670 670 670 700/8002755/8402855/86021055/1060211002
L - Height with insulation mm 1140 1300 1615 1750 1950 2050/208021960/1990226802
Weight (empty) kg 98 115 140 151 177 296 475 580
1In accordance with the Commission Regulation (UE) 812/2013, 814/2013.
2Detachable Neodul insulation.
3Capacities 700, 1000 and 1500 l - magnesium anode plug 2".

© All rights reserved - Galmet Sp. z o.o. Sp. K. Installation and Operating Manual /Warranty Card - SGW(S), SGW(S)B, SG(S) 15
5.9. Scheme of the SGW(S)B Tower Biwal 200-1500
cr
k
h3
h2
h1
h5
h6
h7
h8
h4
cr
k
h3
h2
h1
h5
h6
h7
h8
h4
SGW(S)B 200, 300, 700, 1000 SGW(S)B 250, 400
SGW(S)B 500, 1500
cr
k
h3
h2
h1
h5
h6
h7
h8
h4
5. Technical specication

Installation and Operating Manual /Warranty Card - SGW(S), SGW(S)B, SG(S) © All rights reserved - Galmet Sp. z o.o. Sp. K.16
5. Technical specication
5.10. Technical specication of the SGW(S)B Tower Biwal Max 200-500 with two spiral coils at the bot-
tom part of the tank
Specication Unit SGW(S)B Tower Biwal Max
200 300 400 500
Coil - solar/ add.
source
solar/ add.
source
solar/ add.
source
solar/ add.
source
Storage capacity 1l 197 300 396 497
Nominal capacity l 210 322 420 523
Maximum allowable temperature °C 95 95 95 95
Maximum working pressure bar 10 10 10 10
Coil surface m21,0 / 1,0 1,0 / 1,0 1 ,8 / 1,0 2,0 / 1,0
Coil capacity l 7,0/7,0 7,0/7,0 12,6/7,0 14,0/7,0
Demand for heating water from CH boiler m3/h 2,7 2,7 3 3
Solar coil's power (70/10/45 °C) kW 24 24 43 48
Additional source coil's power (70/10/45 °C) kW 24 24 24 24
Dimensions
h1 - Cold water inlet G" / mm 1 / 130 1 / 130 1 / 160 1 / 160
h2 - Coil return I G" / mm 1 / 210 1 / 180 1 / 240 1 / 240
h3 - Coil return II G" / mm 1 / 280 1 / 250 1 / 325 1 / 340
h4 - Sensor cover I G" / mm 3⁄8/ 380 3⁄8/ 350 3⁄8/ 475 3⁄8/ 510
h5 - Sensor cover II G" / mm 3⁄8/ 480 3⁄8/ 475 3⁄8/ 625 3⁄8/ 640
h6 - Coil supply II G" / mm 1 / 580
(Circulation) 1 / 590 1 / 905 1 / 990
h7 - Coil supply I G" / mm 1 / 660
(Coil supply II) 1 / 670 1 / 990 1 / 1090
h8 - Circulation G" / mm ¾ / 750
(Coil supply I) ¾ / 1040 ¾ / 1290 ¾ / 1390
h9 - DHW outow G" / mm 1 / 895 1 / 1355 1 / 1470 1 / 1650
L - Height with insulation mm 1140 1615 1750 1950
d - Internal diameter Ø 550 550 600 630
D - External diameter Ø 670 670 700 755/8402
Insulation made of hard polyurethane foam mm 55 55 45 45
External enclosure - PVC lm
Magnesium anode plug 5/4" 5/4" 5/4" 5/4"
Weight (empty) kg 98 115 150 176
1In accordance with the Commission Regulation (UE) 812/2013, 814/2013.
2Detachable Neodul insulation.

© All rights reserved - Galmet Sp. z o.o. Sp. K. Installation and Operating Manual /Warranty Card - SGW(S), SGW(S)B, SG(S) 17
5.11. Scheme of the SGW(S)B Tower Biwal Max 200-500 with two spiral coils at the bottom part of the
tank
d
D
h7
h5
h3
h2
0
h4
h6
L
h8
h9
d
D
h7
h5
h3
h2
h1
0
h4
h6
L
h8
h9
SGW(S)B Tower Biwal Max 200
with two spiral coils at the bottom part of the tank
SGW(S)B Tower Biwal Max 300-500
with two spiral coils at the bottom part of the tank
5. Technical specication

Installation and Operating Manual /Warranty Card - SGW(S), SGW(S)B, SG(S) © All rights reserved - Galmet Sp. z o.o. Sp. K.18
5. Technical specication
5.12. Technical specication of the SGW(S)BTower Biwal Slim 200-300
Specication Unit SGW(S)B Tower Biwal Slim 200 SGW(S)B Tower Biwal Slim 250 SGW(S)B Tower Biwal Slim 300
Storage capacity 1l 199 240 286
Tank's max. working temp. °C 95 95 95
Coil's max. working temp. °C 110 110 110
Tank's max. working pressure MPa 1,0 1,0 1,0
Coil's max. working pressure MPa 1,6 1,6 1,6
Solar coil's surface m20,8 1,0 1,4
Solar coil's power (70/10/45 °C) kW 21,4 23,6 33,6
Solar coil's eciency l/h 526 585 814
CH coil's surface m20,6 0,8 0,8
CH coil's power(70/10/45 °C) kW 14,2 21,5 21,5
CH coil's eciency l/h 351 533 533
Magnesium
anode
5/4" plug 38x400 38x400 38x400
M8 screw 38x200 38x200 38x200
Connections for the SGW(S)B Tower Biwal Slim 200 water heaters
h1 - Cold water inlet G" / mm 1 / 140 - -
h2 - Water outow to solar collector G" / mm 1 / 225 - -
h3 - Sensor cover I G" / mm ½ / 325 - -
h4 - Circulation G" / mm 1 / 485 - -
h5 - Hot water inow from solar collector G" / mm 1 / 585 - -
h6 - CH water outow G" / mm ½ / 695 - -
h7 - Sensor cover II G" / mm ¾ / 820 - -
h8 - CH hot water inow G" / mm 1 / 945 - -
h9 - DHW outow G" / mm 1 / 1025 - -
Connections for the SGW(S)B Tower Biwal Slim 250-300 water heaters
h1 - Cold water inlet G" / mm - 1 / 140 1 / 140
h2 - Water outow to solar collector G" / mm - 1 / 225 1 / 225
h3 - Sensor cover I G" / mm - ½ / 410 ½ / 470
h4 - Hot water inow from solar collector G" / mm - 1 / 695 1 / 775
h5 - CH water outow G" / mm - 1 / 805 1 / 895
h6 - Sensor cover II G" / mm - ½ / 940 ½ / 1030
h7 - Circulation G" / mm - ¾ / 1050 ¾ / 1140
h8 - CH hot water inow G" / mm - 1 / 1145 1 / 1255
h9 - DHW outow G" / mm - 1 / 1245 1 / 1495
Dimensions
d - Internal diameter Ø 500 500 500
D - External diameter Ø 600/6702600/7002600/7002
L - Height with insulation mm 1300/135521515/156521765/18252
Weight (empty) kg 80/86293/1002108/1182
1In accordance with the Commission Regulation (UE) 812/2013, 814/2013.
2ErP class A.

© All rights reserved - Galmet Sp. z o.o. Sp. K. Installation and Operating Manual /Warranty Card - SGW(S), SGW(S)B, SG(S) 19
5.13. Scheme of the SGW(S)B Tower Biwal Slim 200-300
h1
L
h2
h3
h4
h5
h6
h7
h8
h9
h1
L
h2
h3
h4
h5
h6
h7
h8
h9
SGW(S)BTower Biwal Slim 200 I SGW(S)B Tower Biwal Slim 250÷300 l
5. Technical specication

Installation and Operating Manual /Warranty Card - SGW(S), SGW(S)B, SG(S) © All rights reserved - Galmet Sp. z o.o. Sp. K.20
5. Technical specication
5.14. Technical specication of the SGW(S)BTower Biwal Slim 800-1000
Specication Unit SGW(S)B Tower Biwal Slim 800 SGW(S)B Tower Biwal Slim 1000
Storage capacity 1l 780 910
Tank's max. working temp. °C 95 95
Coil's max. working temp. °C 110 110
Tank's max. working pressure MPa 1,0 1,0
Coil's max. working pressure MPa 1,6 1,6
Solar coil's surface m22,4 3,7
Solar coil's power (70/10/45 °C) kW 44,5 60
Solar coil's eciency l/h 1099 1468
CH coil's surface m21,2 1.8
CH coil's power (70/10/45 °C) kW 24,5 39
CH coil's eciency l/h 600 958
Magnesium
anode
2" plug 38x600 38x600
5/4" plug 38x400 38x400
Connections
h1 - Cold water inlet G" / mm 6⁄4/ 210 6⁄4/ 210
h2 - Water outow to solar collector G" / mm 1 / 380 1 / 380
h3 - Sensor cover I G" / mm ½ / 610 ½ / 610
h4 - Hot water inow from solar collector G" / mm 1 / 1030 1 / 1265
h5 - CH water outow G" / mm 1 / 1145 1 / 1380
h6 - Sensor cover II G" / mm ½ / 1245 ½ / 1510
h7 - Circulation G" / mm ¾ / 1352 ¾ / 1640
h8 - CH hot water inow G" / mm 1 / 1465 1 / 1810
h9 - DHW outow G" / mm 1 / 1610 1 / 1910
Dimensions
d - Internal diameter Ø 790 790
D - External diameter Ø 95029502
L - Height with insulation mm 1990 2300
Weight (empty) kg 290 355
1In accordance with the Commission Regulation (UE) 812/2013, 814/2013.
2Detachable Neodul insulation.
