Gamma+ AURION COMPACT Parts list manual

USAGE INSTRUCTIONS
COMPACT
multipurpose trolley
CLASS I

pag. I 2
Copyright © 2014 GAMMA POLIURETANI S.R.L. All rights reserved.
IMPORTANT
Verify immediately the package content (pag. IN 11)
Reproducing, transmitting or saving the following information, or part of them, into an
information search system, as well as translating them, or part of them, into any
language and in any form, is strictly forbidden, unless a written authorization is given by
GAMMA POLIURETANI S.R.L. (from now on we will refer to it simply as GAMMA).
GAMMA decline responsibility for damages deriving from an improper use of the trolley.
It is therefore strongly advisable to read the present manual for a correct use of
COMPACT trolley.
GAMMA reserve the right to modify the technical/functional specifications and
characteristics of subsequent versions of this product at any time, without warning.
Instructions for use are an integral part of the trolley and therefore they must be
kept with it, so that they are always available for consultation. The present
document must follow the trolley’s lifecycle, even when it is transferred to other
users.
Requests for technical information or for other copies of this document are to be
addressed to
GAMMA POLIURETANI S.R.L.
Via Padova 9.
31046 Oderzo (TV) - ITALY
Always remember to quote the serial number printed on the plate (pag. IN 6)
Responsible or authorised representative of the manufacturer:
GAMMA POLIURETANI S.R.L.
Number and year of manufacture: see identification plate on the trolley
Identification code of the present document: 66990020
Revision: 01.00
Printing finished on: 03/2022

INDEX - pag. SO 1
INDEX
INFORMATION...............................................................................................IN 1
General information ........................................................................................IN 4
Identification of COMPACT and of its components ........................................IN 6
Safety..............................................................................................................IN 7
Environmental conditions..............................................................................IN 10
Trasportation and installation........................................................................IN 10
Before use.....................................................................................................IN 11
Safe usage....................................................................................................IN 12
Maintenance .................................................................................................IN 12
Long periods of non-usage...........................................................................IN 13
“Exceptional” trasportation............................................................................IN 13
De-commissioning and disposal...................................................................IN 14
BODY.............................................................................................................BO 1
Single piece body ..........................................................................................BO 2
Top surface....................................................................................................BO 2
Needle tub......................................................................................................BO 2
Sliding top surface .........................................................................................BO 3
Drawer with stainless steel tray.....................................................................BO 3
Transparent swinging pockets.......................................................................BO 4
Pocket catheter holder...................................................................................BO 4
Hooks.............................................................................................................BO 4
Oxygen bottle holder......................................................................................BO 5
Life-saving medicines drawer........................................................................BO 5
Waste bin with lid...........................................................................................BO 6
Water bottle holder ........................................................................................BO 6
Central locking system...................................................................................BO 6
Front opening space......................................................................................BO 8
Ampoule opener ............................................................................................BO 8
Wheels / braking system................................................................................BO 9
CONTAINERS (ACCESSORIES)................................................................. CO 1
Front drawers................................................................................................ CO 2
Dividers......................................................................................................... CO 3
Wirebaskets.................................................................................................. CO 4
Trays............................................................................................................. CO 5
Dispenser...................................................................................................... CO 6
Stainless steel shelves ................................................................................. CO 7
Basins........................................................................................................... CO 8
Doors with seal lock...................................................................................... CO 9
SUPPORTS (ACCESSORIES)......................................................................SU 1
I.V. pole..........................................................................................................SU 2
Telescopic I.V. pole .......................................................................................SU 3
Holding frame ................................................................................................SU 4
Holding bar.....................................................................................................SU 6
Basin holding frame.......................................................................................SU 7
Tub holder......................................................................................................SU 9
Shelf for suction pump.................................................................................SU 10
Oxygen bottle holder (SMALL or LARGE)...................................................SU 11
Rotating instrument carrying tray...................................................................SU 13
Lockable rotating instrument carrying tray...................................................SU 15
Cardiac massage board...............................................................................SU 17
Perimetral protection....................................................................................SU 19
Paediatric mattress......................................................................................SU 20
DEVICES (ACCESSORIES)..........................................................................DE 1
Multiple power outlet......................................................................................DE 2

INFORMATION - pag. IN 1
INFORMATION
This chapter contains all necessary information for both a correct and exhaustive
knowledge of all technical features and general functioning of COMPACT, and the
correct consultation of the present manual.
In order to avoid confusion and potential errors on the part of readers, all information
referring to specific components (containers, supports and devices) which might not be
present in your trolley (because they are accessories), are reported in the corresponding
sections (CONTAINERS, SUPPORTS AND DEVICES).
Note:
According to the CE declaration of conformity (supplied together with the trolley) the
manufacturer or his authorized representative in the Community declares and
guarantees that this product complies with the applicable provisions contained in the
directive.
Documents referring to components supplied by third parties and the various annexes
(necessary for a better understanding of the trolley for maintenance) are to be found
inside the package.

INFORMATION - pag. IN 2
CERTIFICATE OF GUARANTEE –PLEASE FILL OUT AND SEND A COPY
SENDER
COMPANY NAME: …………………………………………………………………………………………………………………………………………………………………………………..
ADDRESS: ……………………………………………………………………………………………………………………………………………………………………………………………...
TOWN: ………………………………………………………………………………….POSTCODE: ………………………………………………………………………………………
NATION: ……………………………………………………………………………………………………………………………………………………………………………………………….
DATE OF PURCHASE: …………………/…………………/…………………
TYPE: AURION COMPACT
SERIAL NUMBER: ……………………………………………………………………………………………………………………………………………………………………………….....

INFORMATION - pag. IN 3
GAMMA POLIURETANI S.R.L. GUARANTEE CONDITIONS FOR A PERIOD OF 24 MONTHS
1. This guarantee certificate must be kept until its expiry date and must be produced every time technical service under guarantee is needed. Users who are not able to produce this
document, will lose all guarantee rights. The guarantee starts on the date of delivery of the trolley, and is valid for 24 months.
2. During this period GAMMA guarantee the quality of materials and the sound construction of each trolley. The components of the appliance that in GAMMA’s undisputable opinion are
faulty because of material or manufacturing fault, will be substituted free of charge at the user’s premises by staff from the nearest assistance centre.
3. The guarantee will be valid only if a copy of the original invoice issued to the Customer is produced and the guarantee certificate is sent to GAMMA, complete with the following data:
-buyer’s name;
-model and registration number of the product;
-date of purchase.
GAMMA reserve the right to refuse acknowledgement of the guarantee should these data have been removed or tampered with after purchasing.
4. The following are not covered by guarantee:
4.1 damages (scratches, dents and similar) caused by carelessness, negligence, tampering, incompetent use, or repairs carried out by unauthorized staff;
4.2 damages due to incorrect installation of the appliance and of the accessories, or to faults caused by insufficient or unsuitable electrical installation, or alterations due to weather
or environmental conditions or conditions of any other nature;
4.3 light bulbs, glass components, knobs, rubber seals;
4.4 installation advice and comfort checks;
4.5 general maintenance;
4.6 what can be considered normal wear and tear.
5. GAMMA decline any responsibility for damages which may be directly or indirectly caused to things or people due to the lack of compliance with all prescriptions indicated in the
special “instructions” regarding assembly.
6. GAMMA will not be liable for any damages caused to people or things or by breakdowns or forced interruption of use of the appliance. The parts that are substituted under guarantee
will remain the property of GAMMA.

INFORMATION - pag. IN 4
General information
Foreword
A new generation of hospital trolleys is born, fruit of innovative thinking (an innovative
and sophisticated material like Bayer’s Baydurwas used) and of a detailed design:
COMPACT.
COMPACT is specialised. The new system is designed to offer as many opportunities as
possible for customisation. Although different versions are already available for specific
hospital needs, there are further diversification opportunities thanks to an extremely wide
range of components and accessories.
COMPACT is beautiful. Its elegant shape, the absence of corners, its well harmonised
colours and the Italian style make it a working tool both useful and pleasant to the eye.
The multipurpose trolley you bought does cause particular risks for operators,
provided all prescriptions contained in this document are observed. Therefore, for
a correct and safe use of COMPACT it is necessary to read all chapters of this
manual (except those relative to accessories you are not supplied with) with
particular attention to chapter “Safety” on page IN 7.
Intended use
COMPACT is a medical device to be used solely as a support in giving assistance to
patients in hospital wards or in surgeries.
COMPACT can be used as a means of storing and transporting drugs, medications,
consumables, specialist medical equipment and clinical records, depending on the
accessories installed on it and on the maximum allowable loading weight of the various
components (according to the indications contained in the sections concerning the
various accessories - starting from pag. CO 1)
ATTENTION:
This device is addressed to properly trained staff. Using COMPACT is forbidden
for untrained staff. COMPACT must not be used improperly, i.e. for uses that are
different from its intended use.
Contraindications
All uses that do not correspond with the indications contained in the previous
paragraph (“Intended use”) are not to be considered as possible uses of the
GAMMA COMPACT trolley.
GAMMA do not guarantee safety of users, patients or third persons, if the trolley
is used for different purposes.
User’s responsibility
If the instructions on assembly, use and maintenance of the trolley contained in this
manual are disregarded, GAMMA decline any responsibility. GAMMA accepts no
responsibility for damages incurred to or caused by the trolley, due to:
-improper use of the trolley or use by untrained staff;
-use in contravention to specified National Standards;
-incorrect assembly;
-disregard for safety and personal protection;
-serious lack of periodic maintenance;
-incorrect preparation of the workplace or structure where the trolley is going to be
used;
-unauthorised modifications or servicing;
-use of spare parts of different manufacture;
-failure of the main power supply;
-use of an incorrect power supply.

INFORMATION - pag. IN 5
How to read this manual
The function of the present manual is to inform and guide users in the assembly, use
and maintenance of COMPACT and of its accessories.
Since the natural adaptability of COMPACT to customisation (in compliance with the
indications contained in the present document) make it impossible to supply a specific
document for each variant, the following “compromise” has been reached.
This manual was developed and subdivided into six different sections (the first three
are common to all trolley types, whereas the last three contain the accessories cards(*)),
identified by the icons placed in the lower part of each page (and by the specific page
number). This manual is available in four different languages (indicated by the icons on
the right).
This layout optimises navigation inside the manual, making the manual a dedicated
document, which is easy to consult.
Texts that are highlighted by the following drawing:
must be read very carefully. In fact, if the instruction contained in these texts are
disregarded, the safety of persons and of the trolley could be jeopardized .
(*) a card is composed of one or several sheets of paper containing the instructions
referring to each accessory that can or has actually been installed in order to integrate
the BODY of COMPACT. Cards are grouped in “families” of accessories: containers,
supports and devices.
Who should read the manual
The present document is addressed to all users of the trolley.
Glossary
Term
Meaning
Medical
accessory.
Product which is not a device, but was specifically designed to be
used with a device, in order to use it as was intended by the
manufacturer.
Patient.
Person who is subjected to medical care, tests and the like.
Residual risks.
Risks that prove not to be eliminable during design and
manufacture. The indications contained in this document, on the
plate and on the trolley itself are meant to “compensate” for these
risks.
Third persons
All persons (other than patients, users or doctors) who may have
something to do with the trolley.
User
Who uses the medical device (doctors, paramedical staff and, in
general, users different from patients).

INFORMATION - pag. IN 6
Identification of COMPACT and of its
components
Once the trolley has been unpacked (pag. IN 10), it can be identified thanks to the
special plate.
ATTENTION:
Do not remove the plate.
1) Manufacturer
2) Device in compliance with EU Regulation 2017/745
3) See the user manual
4) Medical device
5) Product number
6) Product code
7) Date of manufacture
8) Unique Device Identification
9) Serial number
This plate contains all essential information about the trolley.
In order to identify the accessories that have been supplied together with the trolley you
bought, it is necessary to refer to the transport document.
The COMPACT “family”
Starting from a standard body, COMPACT is designed to be customised with a wide
range of accessories (which are the distinguishing features of the various versions),
according to the specific needs of each hospital ward.
For this reason, your COMPACT is composed of a standard BODY - which is the same
for all trolleys –on which some accessories are then assembled by GAMMA or by
yourself.
Standard components (standard body)
As far as the description of standards components is concerned, refer to the layout on
page BO 1 and following.
“Accessory” components
Accessories have been divided by function:
-CONTAINERS (layout and description starting from pag. CO 1);
-SUPPORTS (layout and description starting from pag. SU 1);
-DEVICES (layout and description starting from pag. DE 1).
Note: obviously it is not possible to assemble all available accessories on one
single trolley! For additional information contact GAMMA.
ATTENTION:
Assembly and disassembly of all accessories are to be carried out when power
supply (if present) is disconnected form the trolley.
It is forbidden to use accessories that are not supplied by GAMMA.
Environmental conditions for the use of accessories are reported on pag. IN 10.
For a correct and safe use of accessories with COMPACT it is necessary to read
carefully the text contained in sections “INFORMATION” (from pag. IN 1) and
“BODY” (from pag. BO-1) of the usage instructions of the trolley.
1
2
4
3
5
6
7
8

INFORMATION - pag. IN 7
Safety
Guarantees about safety and hygiene
If COMPACT is used properly and according to the instructions supplied by
GAMMA, it will not cause hazards for operators. GAMMA decline responsibility for
any damages which may be caused to persons or things due to an improper use
of the trolley.
Using spare parts different from those supplied by the manufacturer may cause
damages to people or to the trolley.
•COMPACT is safe. It is in line with the highest safety standards thanks to the
materials used, to its rounded shape, to the absence of sharp metal parts and to the
attention paid to the fitting of all the accessories.
•COMPACT is innovative. It was manufactured with state-of-the-art materials, such
as rigid polyurethane Baydur , which is unchangeable with time, resistant to
chemical agents, not subject to corrosion and auto extinguishing.
•The solutions adopted for the design and manufacture of the trolley comply with all
safety principles, considering the technological achievements universally
recognised.
•During the design and manufacturing processes, risks were eliminated or reduced
as much as possible (implementation of safety in the design and manufacture of the
trolley) and the necessary protection measures were adopted against those risks
that could not be eliminated.
•Users are informed on residual risks. For instance, in the case of components
and accessories that have to support a load (such as I.V. poles or drawers)
the maximum allowable load is indicated both in the corresponding card and
on the component itself. If the label is damaged or becomes unreadable, it is
necessary to replace it.
•Materials were chosen on the basis of their reduced toxicity and flammability.
•Considering the intended use of the trolley, attention was paid also to the mutual
compatibility between materials and fabrics, biological cells and body fluids.
•The trolley was designed so as to reduce as much as possible all risks due to the
accidental leakage of substances in the trolley (considering the trolley itself and the
characteristics of the environment it is to be used in)
•The trolley was designed, manufactured and packed in such a way that its features
and its performance –considering its intended use –are not subjected to alteration
during storage and transportation.
•The normal stress the trolley is subjected to under normal usage conditions does
not alter the features and performances described in this document; therefore, the
clinical condition of patients, their safety and the safety of third persons cannot be
jeopardised (during the device’s lifecycle)
•The distinguishing features of the materials used do not change when they come
into contact with human body fluids or other fluids (especially as far as flammability
is concerned); therefore, safety is guaranteed with all substances and materials that
come into contact with the trolley during normal use (or maintenance)
•It is necessary to report any major accident occurring in relation to the
devices to the manufacturer and to the competent authority of the Member
State in which it is established.
•COMPACT was designed and manufactured in compliance with the following
standards and decrees:
•the device comply with the general safety and performance requirements of
Regulation (EU) 2017/745 (MDR) Annex I,
•the manufacturing company is certified according to UNI EN ISO 9001 and UNI
CEI EN ISO 13485.

INFORMATION - pag. IN 8
General Prescriptions
This paragraph contains all general prescriptions users must know for a safe and correct
use of COMPACT. Specific prescriptions are dealt with in the various paragraphs of the
present manual.
•COMPACT was designed and manufactured with the aim of guaranteeing the
utmost personal safety of users, patients and third persons; however an
improper use might cause damages to persons and to the trolley itself. The
fundamental rules for assembly, usage and maintenance contained in this
manual are to be observed in order to avoid altering the intrinsic safety of
COMPACT.
•All components and accessories must be housed in the special spaces that
are to be found on the trolley (see the corresponding cards and the lay-outs of
page CO 1, SU 1, and DE 1) and according to the procedure indicated. If
instructions are not followed, the manufacturer declines responsibility for
damages to things or persons.
•It is forbidden to use accessories that are not either supplied or authorised by
GAMMA.
•If COMPACT is used under operative or environmental conditions that are
different from those indicated in this manual, or if tampering, modifications or
substitution of components takes place, the manufacturer declines any
responsibility for damages due to defective products and the guarantee is not
valid.
•Since the trolley is not sterile and, as a consequence, can involve biological
risks, all products carried by the trolley must be contained in special
packages.
•It is forbidden to pour liquids and the like into the containers supplied with
the trolley.
•Suspend use of COMPACT if any of its parts are damaged. Failure in
observing this procedure can cause risks. For assistance ask your supplier.
•Do not keep COMPACT near a heat source and do not expose it to direct flame
heating elements: these actions might cause damages.
•If COMPACT is not going to be used for a long period of time, follow the
instructions reported on page. IN 13,
•Do not try to disassemble the trolley (unless it needs to be thoroughly
cleaned or disposed of) or alter any part of it. Operations of this kind might
cause damages. Internal inspections, modifications or fittings must be carried
out by technical staff authorised by your supplier.
•To clean the trolley use exclusively the products suggested in this document,
after disconnecting all electrical appliances.
•In case of serious malfunction, extra-ordinary maintenance or any other
problem for which no explanation can be found in this manual, we suggest
that you ask the manufacturer or your supplier.
Residual risk
COMPACT was designed and manufactured in such a way that its use cannot
jeopardise the safety and the clinical condition of patients, of users or of third persons,
provided it is used according to the conditions and for the purposes indicated.
It was not possible to eliminate some risks; however their level is acceptable (considered
the advantages it gives to patients) and they are compatible with a high level of health
and safety protection.

INFORMATION - pag. IN 9
RESIDUAL RISKS (exposed persons: users, patients and third persons)
Type of hazard
Risk area
Notes/ Preventive measures
Infection and contamination
due to substances or residues
of materials that were used or
came into contact with the
trolley.
Trolley.
The trolley was designed, manufactured and packed so as to minimise risks due to contaminants and residues for the personnel in
charge of transportation, storage and use, and for patients (particular attention was paid to exposed tissues and to the time and
frequency of exposure).
If the agent is particularly contaminant it is advisable to use appropriate personal protective equipment and to reduce to
the minimum frequency and exposure time.
Accidental leakage of
substances in the trolley.
Body.
If the trolley is equipped with electrical accessories and there is an accidental leakage of substances into the trolley,
disconnect all electrical appliances
Hitting against the trolley.
Trolley.
In order to reduce to the minimum damages caused by hitting against the trolley (and to facilitate cleaning operations), it was designed and
manufactured eliminating, as far as possible,sharp surfaces and adding a rubberprotection to the inferior part.
During transportation of the trolley, be careful not to hit against things or persons.
Electromagnetic hazard;
interference with other
devices.
Electrical
accessories (if
present).
During design/manufacture the possible influence of magnetic fields and electrical influence were taken into consideration. Risks
related to accidental electrical discharge both in normal usage and in first failure conditions were taken into consideration as well
(provided that the accessories of the trolley are assembled in the correct way).
Use electrical accessories according to the corresponding instructions.
Fire and overheating.
Trolley.
The trolley was designed and manufactured so as to reduce to the minimum any risks related to the trolley itself.
Use the trolley and its accessories according to the corresponding instructions.
Mechanical and thermal risks
Trolley.
In order to reduce these risks, the trolley underwent stability tests and other tests; The maximum allowable loading weight of each
component and accessory is reported on the various cards and on adhesive labels.
Use the trolley and its accessories according to the corresponding instructions.
Biological risk.
All containers.
All products that are used with the trolley must be properly packed, in that the trolley is not sterile and, therefore, can be
subjected to biological risks.
Incompatibility with consume
products / accessories / other
devices.
Trolley.
The trolley was designed and manufactured so as to minimise these risks (by means of compatibility tests). In case of
incompatibility, specific notes are to be found in the corresponding instructions.

INFORMATION - pag. IN 10
Safety labels
Each component or accessory of COMPACT containing or sustaining a load (such as a
medical devices) is provided with an adhesive label indicating the maximum allowable
loading weight.
Each time you use one of these components or accessories, verify that the load
you are going to place into or onto it does not exceed the maximum allowable
loading weight.
Obviously, in order to check the maximum weight it is necessary to add up all
loads that are to be placed on that component/accessory .
If one of these labels is ruined or not readable, it is necessary to replace it.
Following is an example:
We remind you that 1 kg corresponds to 2.204 lb.
Environmental conditions
COMPACT must be transported, used and stored in a dry environment and away from
heat sources.
Trasportation and installation
1 For the transportation of the
packed trolley (a) and of its
accessories (b) (if there are any)
use adequate lifting and
transportation means.
During transportation it is
possible to stack a maximum of 2
packed trolleys.
The figure on the right shows an
example of a correct load
configuration).
2Cut the packing strips (c) and
remove the reinforcing corners (d)
fixed to the pallet.
continued
a
b
c
d

INFORMATION - pag. IN 11
3Lift up the box and remove the
polystyrene protection at the top (a).
4To remove the trolley from the
polystyrene base four persons must take
hold of the top surface and lift the trolley
simultaneously.
5 Check the content of the package (next paragraph).
Package waste (bag, cardboard box , etc.) must be disposed of in compliance with the
local legislation in force. In any case, when it is possible do not get rid of packaging
material but keep it: it is the ideal container for “extra-ordinary” transportation”.
6 Open the packages of the various accessories, check their content and assemble
them on the trolley (accessories are described starting from pag. CO 1).
Checking the package content
Before starting to use COMPACT it is necessary to check the package content.
Inside the package you will find:
-The components of the standard model;
-The accessories of your model;
-Instructions for use of the trolley (the present document) and instruction for use of
the various accessories of third suppliers.
Check that all these components are in the package and make sure that they are
free from any damages due to inadequate transportation. If the content of the
package is damaged, contact the retailer you bought the trolley from.
In case of return, the trolley is to be given back in the same condition it was in
when received (that is in the package used for the consignment).
Before use
Before using the trolley it is necessary to clean it. See instructions on pag. IN 13.
It is also advisable to carry out some tests before using COMPACT, in order to make
sure that the trolley and its accessories are free from faults and that they are being used
in the correct way.
a

INFORMATION - pag. IN 12
Safe usage
Note: refer to the cards of the various components and accessories for their
specific usage.
1 To move the trolley, push it by
means of the special handles (a)
(control their direction by means of the
steerable wheel (pag. BO 9).
•Sudden movements of the
trolley may cause the material
placed on it to fall down
•During normal usage the trolley
is stable when its inclination
does not exceed 10°.
2 Once the desired position is
reached, wheels can be locked by
pushing on brakes (b) (pag. BO 9).
3 At the end of each working day disconnect the power supply (if it is connected),
clean the trolley superficially (pag. IN 13) and place it in a guarded room.
Maintenance
If COMPACT is used according to the instructions given in this manual, it does not
require particular maintenance interventions, apart from the ordinary cleaning operations
made necessary by usage.
ATTENTION:
•If some pieces need to be replaced, use exclusively original spare parts.
•The substitution of accessories (for which the procedure corresponds, in
most cases, to the assembly sequence in reverse order), is to be carried out
while the trolley is disconnected from power supply (if it was connected) and
using only compatible products.
•Carry out exclusively operations that are indicated in the present manual.
GAMMA. undertake to supply, on request, wiring diagrams, lists of component parts or
other information that might be useful to trained personnel for repairing the parts of the
trolley the manufacturer considers repairable.
a
a
b
b

INFORMATION - pag. IN 13
Daily cleaning of the trolley
1 Unplug the trolley (if it was plugged).
2 Remove waste and useless material from containers and supports.
3 The cleaning products which can be used are numerous, be they detergents,
degreasing agents or anti-bacterial agents. However their characteristics must be
compatible with the materials that are to be cleaned; therefore it is recommended
that no type of denatured alcohol or isopropyl is used, especially on swinging
pockets.
Apply a small quantity of the cleaning product to the surface and run a dry cloth over it.
Complete cleaning of the trolley
If a complete cleaning of the trolley is necessary, proceed as follows:
1 Unplug the trolley (if it was plugged).
2 Remove everything that was placed on the trolley.
3 Remove all components from the body (described starting from pag. BO 1).
4 Remove all components and accessories from the trolley (described starting from
pag. BO 1).
5 Apply a cleaning product and clean all visible surfaces.
The cleaning products which can be used are numerous, be they detergents,
degreasing agents or anti-bacterial agents. However their characteristics must be
compatible with the materials that are to be cleaned; therefore it is recommended
that no type of denatured alcohol or isopropyl is used, especially on swinging
pockets.
6 For the re-assembly of the trolley, follow the procedure described in steps 1-4 in
reverse order.
Long periods of non-usage
If the trolley is not going to be used for long periods, clean it thoroughly, re-pack it and
store it in a dry place.
“Exceptional” trasportation
If the trolley needs to be used in a new site, clean it thoroughly, re-pack it and transport it
by means of adequate lifting and transportation equipment.

INFORMATION - pag. IN 14
De-commissioning and disposal
When the trolley and/or its accessories are to be scrapped, remember that if you
get rid of it improperly you might cause environmental pollution, with all
consequences deriving from that.
Remember that all trolley components must be disposed of in compliance with the
legislation in force.
As far as the disposal of components supplied by third persons is concerned, refer to the
instructions supplied with them.
Proceed as follows:
1 Clean the trolley thoroughly (pag. IN 13).
2 Disassemble all components and accessories.
3 Sort the different electrical and recyclable materials (such as the body of the trolley,
which is made of Baydur ) and entrust them to firms that are authorised to recover and
dispose of them.
4 Scrap the remaining structures and store them in authorised gathering centres.

BODY - pag. BO 1
2
6
5
4
15
14
13
3
10
12
11
9
7
8
16
1
BODY
The body of the trolley - i.e. the basic configuration
of each COMPACT trolley –is supplied with the
following components:
1) Single piece body (pag. BO 2)
2) Top surface (pag. BO 2)
3) Needle tub (pag. BO 2)
4) Sliding top surface (pag. BO 3)
5) Drawer with stainless steel tray (pag. BO 3)
6) Transparent swinging pockets (pag. BO 4)
7) Pocket catheter holder (pag. BO 4)
8) Hooks (pag. BO 4)
9) Oxygen bottle holder (pag. BO 5)
10) Life-saving medicines drawer (pag. BO 5)
11) Waste bin with lid (pag. BO 6)
12) Water bottle holder (pag. BO 6)
13) Central locking system (pag. BO 6)
14) Front opening (pag. BO 8)
15) Ampoule opener (pag. BO 8)
16) Wheels / braking system (pag. BO 9)
TECHNICAL DATA
Height
920 mm
Depth
710 mm
Width
775 mm
Weight
42 kg

BODY - pag. BO 2
Single piece body
Function / Features
The single piece body is made of Baydur and is the sustaining structure of the trolley.
All components and prearrangements for accessories are installed on it.
Top surface
Function / Features
On the top surface there are handles (a) to move the trolley, prearrangements to install
the various supports and a transparent lid (b) to check the content of the life-saving
medicines drawer (pag. CO 5).
Usage
Place on the top surface only small objects (c)
Needle tub
Function / Features
The needle tub is fixed into the top surface (pag. CO 1).
ATTENTION:
Needle tubs are monouse and therefore they cannot be
reused.
Usage
1 Open the lid (a) and insert used needles or cotton into the tub.
In order to prevent any risks, be extremely careful when
inserting waste material into it
2 Close the lid.
3 When the tub is full, close the lid, remove the tub and dispose
of it according to the regulations in force in your hospital.
a
a
c
b
a

BODY - pag. BO 3
Sliding top surface
Function
The sliding top surface
shall be used to support
small objects and
documents.
Usage
1 When you slide the
surface open to its full
extension - by means of its
special handle (a) -, the
drawer underneath opens
as well, in order to share in
bearing the load.
Do not exceed the
maximum allowable
loading weight of 2kg.
2 Slide the surface closed
by pushing it and help the
drawer underneath sliding
closed.
Removal
1 To remove the sliding
top surface it is necessary
to remove the drawer with
stainless steel tray.
2 Remove the surface by
pulling it out.
Drawer with stainless steel tray
Function / Usage
Open and close the
drawer by means of its
special handle (a).
Removal
1 Remove the drawer
by pulling and lifting it up.
2 Remove the stainless
steel tray (b).
a
b
a
