Gantner GAT NET.Lock 7000 Quick guide

www.gantner.com HB_GAT-NETLOCK7000--EN_30 1
GAT NET.Lock 7000 System
Electronic RFID Locker Locks
Installation, Configuration, Operation
Document Version 3.0

GAT NET.Lock 7000 System
2 HB_GAT-NETLOCK7000--EN_30 www.gantner.com

GAT NET.Lock 7000 System
www.gantner.com HB_GAT-NETLOCK7000--EN_30 3

Copyright 2013, GANTNER Electronic GmbH, Schruns (Austria).
General warning and safety instructions
Dear customer,
we congratulate you on having selected a product (device resp. software) of GANTNER Electronic GmbH. So that our product
functions in your installation with safety and to your complete satisfaction, we take this opportunity to familiarise you with the following
ground rules:
1. Installation, commissioning, operation and maintenance of the product purchased must be carried out in accordance with in-
structions, i.e. in accordance with the technical conditions of operation, as described in the corresponding product documenta-
tion.
2. Before installation, commissioning, operation or maintenance it is therefore essential that you read the corresponding chapter
of this manual and observe its instructions.
3. If there are still some points, on which you are not entirely clear, please do not take a chance, but ask the customer adviser
responsible for you, or ring the GANTNER Electronic GmbH hotline.
4. Where not otherwise specifically laid down, appropriate installation, commissioning, operation and maintenance of the product
is the customer’s responsibility.
5. Directly on receipt of the goods, inspect both the packaging and the device resp. data carrier itself for any signs of damage.
Also check that the delivery is complete (-> accessories, documentation, auxiliary devices etc.).
6. If the packaging has been damaged in transport or should you suspect that it has been damaged orthat it may have a fault, the
product must not be put into service. In this case, contact your customer advisor. He will make every effort to resolve the
problem as quickly as possible.
7. Installation, commissioning and servicing of our appliances must only be carried out by suitably trained personnel. In particular,
electrical connections may only be made by correspondingly qualified specialists. Here, the appropriate installation provisions
in accordance with the relative national Electrical Engineers construction regulations (e.g. ÖVE, [Austrian] VDE, [German]...)
must be observed.
8. Where not otherwise stated, installation and maintenance work on our appliances is exclusively to be carried out when discon-
nected from the power supply. This applies in particular to appliances which are normally supplied by low-tension current.
9. It is prohibited to make alterations to the appliances or to remove protective shields and covers.
10. Do not attempt yourself to repair an appliance after a defect, failure or damage, or to put it back into operation again. In such
cases, it is essential you contact either your customer adviser or the GANTNER Electronic GmbH hotline.
11. GANTNER Electronic GmbH accepts no responsibility for any injuries or damage caused as a result of improper use.
12. Although every care is taken and we are continuously aiming for improvement, we cannot exclude completely the possibility of
errors appearing in our documentation. GANTNER Electronic GmbH therefore accepts no responsibility for the completeness
or the accuracy of this manual. The right is reserved to make alterations, and we may carry out alterations at any time without
giving prior notice.
13. Should you discover any fault with the product or in its accompanyingdocumentation, or have any suggestions for improvement,
you may confidently approach either your customer adviser or GANTNER Electronic GmbH directly.
!

GAT NET.Lock 7000 System
4 HB_GAT-NETLOCK7000--EN_30 www.gantner.com
14. However, even if you just want to tell us that everything has functioned perfectly, we still look forward to hear from you.
We wish you a successful application of our appliances. We will be pleased to welcome you as a customer again soon.
Contact address / manufacturer:
GANTNER Electronic GmbH
Montafonerstrasse 8
A - 6780 Schruns/Austria
Tel.: [phone] - 442
Fax: [phone] - 8020
Email: [e-mail]
Website: www.gantner.com

GAT NET.Lock 7000 System
Table of Contents
www.gantner.com HB_GAT-NETLOCK7000--EN_30 5
TABLE OF CONTENTS
1. INTRODUCTION............................................................................................................................................7
1.1 About this Manual ...................................................................................................................................7
1.2 Contact of Inquiries .................................................................................................................................7
2. General Information .....................................................................................................................................8
2.1 System Parts...........................................................................................................................................8
2.2 Ordering Guide........................................................................................................................................9
2.3 Basic Function of the GAT NET.Lock 7000 System.............................................................................11
2.4 Term Definitions....................................................................................................................................11
2.5 RFID Technology..................................................................................................................................12
3. Mounting .....................................................................................................................................................13
3.1 Definition of the Door Hinge (Right or Left Door)..................................................................................13
3.2 Metallic and Non-Metallic Doors ...........................................................................................................13
3.3 Dimension Drawings for the Mounting..................................................................................................14
3.3.1 Door Width.....................................................................................................................................14
3.3.2 Basic Dimensions of GAT NET.Lock 7000 and the GAT NET.Lock Bolt Sets..............................14
3.4 Door Status Contact..............................................................................................................................15
3.5 Mounting in Lockers with Non-Metallic Doors.......................................................................................16
3.5.1 Important Measures when Mounting the GAT NET.Lock 7000 and Bolt Set (Non-Metal Doors) .16
3.5.2 Steps for Mounting of the GAT NET.Lock 7000 at Non-Metallic Doors ........................................17
3.6 Mounting in Lockers with Metallic Doors...............................................................................................18
3.6.1 Cut-Outs in the Locker Door..........................................................................................................19
3.6.2 Important Measures when Mounting the GAT NET.Lock 7000 and Bolt Set (Metal Doors) .........19
3.6.3 Steps for Mounting of the GAT NET.Lock 7000 at Metallic Doors ................................................20
3.7 Points to be observed during Installation..............................................................................................21
3.8 Test Installation.....................................................................................................................................21
3.9 Replacement after a Burglary Attempt..................................................................................................21
4. Electrical Connection.................................................................................................................................23
4.1 System Structure...................................................................................................................................23
4.2 Cable Connection of the GAT NET.Lock 7000.....................................................................................24
4.2.1 Connection Cable ..........................................................................................................................24
4.2.2 Cable Outlets .................................................................................................................................24
4.2.3 Power Supply.................................................................................................................................24
4.3 Connections at the Slave Controller GAT NET.Controller S 7000........................................................25
4.3.1 GAT NET.Lock 7000 Connection ..................................................................................................25
4.3.2 Network Connection.......................................................................................................................25
4.3.3 Power Supply.................................................................................................................................27
4.3.4 LED Signals and Buttons...............................................................................................................28
4.4 Connections at the Master Controller GAT NET.Controller M 7000.....................................................29
4.4.1 Connection of the Slave Controllers GAT NET.Controller S 7000 to the Master Controller .........29
4.4.2 Ethernet Connection ......................................................................................................................29
4.4.3 Connection of the Power Supply ...................................................................................................30
4.4.4 LED Signals and Buttons...............................................................................................................30
5. Configuration And Operation....................................................................................................................31
5.1 Antenna Adjustment of the GAT NET.Lock 7000 .................................................................................31
5.2 Locker Operation by the Visitor.............................................................................................................31
5.2.1 Lock a Locker.................................................................................................................................31
5.2.2 Unlock and Open a Locker ............................................................................................................31
5.3 Restart a Controller GAT NET.Controller S 7000 or GAT NET.Controller M 7000 ..............................32
5.4 Delete Configuration Parameters of a Controller (= Reset to Default Settings) ...................................32
5.5 Status Information at GAT NET.Controller S 7000 and GAT NET.Controller M 7000 .........................33
5.5.1 Slave Controller .............................................................................................................................33
5.5.2 Master Controller ...........................................................................................................................33

GAT NET.Lock 7000 System
Table of Contents
6 HB_GAT-NETLOCK7000--EN_30 www.gantner.com
5.6 GAT Relaxx - Operation Software for GAT NET.Lock 7000 System................................................... 34
5.6.1 User Interface................................................................................................................................ 34
6. Technical Data ........................................................................................................................................... 37
6.1 GAT NET.Lock 7000............................................................................................................................ 37
6.2 GAT NET.Controller S 7000................................................................................................................. 37
6.3 GAT NET.Controller M 7000................................................................................................................ 38

GAT NET.Lock 7000 System
Introduction
www.gantner.com HB_GAT-NETLOCK7000--EN_30 7
1. INTRODUCTION
1.1 About this Manual
This manual contains all important information necessary to install the RFID locker locks GAT NET.Lock 7000 in the
lockers/depots. The operation by the end user is described as well. In order to use the GAT NET.Lock 7000 locks the
slave controller GAT NET.Controller S 7000 is necessary as well as the master controller GAT NET.Controller M
7000, a PC software (e.g. GAT Relaxx) for configuration and control of the installation and RFID user data carriers
for identification of the users at the locks. The installation and operation of these system parts are also described in
this manual. For the configuration software GAT Relaxx there is also a separat installation manual as well as a help
function, integrated into the software, available.
In chapter 2 "General Information" general information about the GAT NET.Lock 7000 system as well as an overview
of the single system parts with order information can be found.
Chapter 3 "Mounting" includes the description how the GAT NET.Lock 7000 locks are mounted in the lockers. Here
the mounting procedure of the locks and bolt sets with all important measures and information can be found. Because
there are many different types of lockers available, the mounting procedure is written in generally and not for a certain
locker type.
The chapter 4 "Electrical Connection" describes how the GAT NET.Lock 7000 and controllers are connected with
each other and connected to power supply. Included is also information about the dimensioning and installing of the
connection cables.
Chapter 5 "Configuration And Operation" describes the operation of the GAT NET.Lock 7000 by a user/visitor of the
facility. Furthermore the antenna adjustment and the reset and deleting of configuration parameters of the controllers
is described. The LED display signals and acoustic signals at the controllers are also described here. For the GAT
Relaxx configuration software a short overview is included in this chapter as well.
Chapter 6 "Technical Data" contains the technical data oft he GAT NET.Lock 7000 locks and the GAT NET.Controller
S 7000 and M 7000.
1.2 Contact of Inquiries
In case of inquiries concerning the GAT NET.Lock 7000 system devices please get in touch with your representative
/ distributor or directly with one of the GANTNER Access Technology branch offices. The addresses, phone and fax
numbers are listed on the inner side of the cover.

GAT NET.Lock 7000 System
General Information
8 HB_GAT-NETLOCK7000--EN_30 www.gantner.com
2. GENERAL INFORMATION
2.1 System Parts
The GAT NET.Lock 7000 system consists of the following system parts:
Figure 2.1 - System parts of the GAT NET.Lock 7000 system
12. Ethernet Patch Cable
4. GAT NET.Controller S 7000
(Slave Controller)
11. GAT NET.Lock Connector
Coupling for cable con-
nection
6. GAT NET.Power Supply 230V EU
Power Supply Unit
7. GAT NET.Power Plug
5. GAT NET.Controller M 7000
(Master Controller)
1. GAT NET.Lock 7000
2. GAT NET.Lock BoltSet 7100
(for non-metallic doors)
+
10. GAT NET.Lock Cable 4m
(connection cable,
length 4 m)
3. GAT NET.Lock BoltSet 7200
(for metallic doors, includes the
label carrier)
9. GAT NET.Lock Label GEA right
GAT NET.Lock Label GEA NUM right
GAT NET.Lock Label GEA left
GAT NET.Lock Label GEA NUM left
(Front labels in different variants)
8. GAT NET.Lock Tool 7000
(Center punch gauge for
bolt mounting)
13. GAT NET.Lock Basic Set B
GAT NET.Lock Basic Set F
GAT NET.Lock Basic Set ISO
(Five master cards and an as-
sumption of liability sheet)

GAT NET.Lock 7000 System
General Information
www.gantner.com HB_GAT-NETLOCK7000--EN_30 9
1. GAT NET.Lock 7000
Electronic RFID locker lock without connection cable and without bolt set.
2. GAT NET.Lock BoltSet 7100
Bolt set with door shackle and booster. Used for non-metallic doors. The bolt set is mounted on the inside of the
locker door.
3. GAT NET.Lock BoltSet 7200
Bolt set with door shackle and booster. Used for metallic doors. The bolt set is installed into locker door. The
label carrier is also included in this article.
4. GAT NET.Controller S 7000
The slave controller is a control unit to connect up to 24 GAT NET.Lock 7000. There are two different slave
controllers available, which differ in the type of RFID reader.
5. GAT NET.Controller M 7000
The master controller is a control unit to connect up to 8 slave controllers GAT NET.Controller S 7000. The master
controller is used to connect the slave controllers to a server / PC.
6. GAT NET.Power Supply 230V EU
Power supply unit for the slave and master controller (mains power plug is of type EU).
7. GAT NET.Power Plug
Plug to supply multiple controllers with a single power supply (see "4.3. Connections at the Slave Controller GAT
NET.Controller S 7000").
8. GAT NET.Lock Tool 7000
Center punch gauge for bolt mounting in the locker doors. With these gauges the drillings for the mounting can
be easily marked on the locker doors.
9. GAT NET.Lock Label 7000 GEA xxx
Different front labels in GANTNER design. The labels are available for right and left doors and with or without
printed locker numbers. On metallic doors the labels are sticked onto the label carrier. On non-metallic doors the
labels can be sticked directly onto the doors.
10. GAT NET.Lock Cable 4m
4-pin connection cable (4 metres) to connect a GAT NET.Lock 7000 to a slave controller. MOLEX plugs on both
sides.
11. GAT NET.Lock Connector
Connection socket to connect two GAT NET.Lock Cable 4m.
12. Ethernet Patch Cable
Standard network cable (min. CAT5) to connect the slave controller to the master controller.
13. GAT NET.Lock Basic Set xxx
Set consisting of five master cards and an assumption of liability sheet. The master cards have master key func-
tionality and can be used to open all lockers in an GAT NET.Lock 7000 locker system (e.g. used for service- and
cleaning personnel). Available for different RFID technologies ("B" for LEGIC®, "F" for MIFARETM and "ISO" for
ISO 15693 systems).
2.2 Ordering Guide
For the planning and ordering of the GAT NET.Lock 7000 system components, an ordering guide is available in a
separate document ("DK_GAT-NETLOCK7000--Bestellhilfe-EN").

GAT NET.Lock 7000 System
General Information
10 HB_GAT-NETLOCK7000--EN_30 www.gantner.com

GAT NET.Lock 7000 System
General Information
www.gantner.com HB_GAT-NETLOCK7000--EN_30 11
2.3 Basic Function of the GAT NET.Lock 7000 System
The locker lock GAT NET.Lock 7000 is the ideal solution for the convenient electronic locking of wardrobe lockers in
fitness clubs, baths, golf resorts, and other individual company applications. The identification at the GAT NET.Lock
7000 is carried out via contactless RFID data carriers (Radio Frequency Identification).
The GAT NET.Lock 7000 is suitable for any type of material (sheet metal, wood, HPL, solid plastic) and can be used
for left- and right-hinged doors alike. The various operating modes enable the flexible use of these locks.
The GAT NET.Lock 7000 is installed on the inner side of the locker. A bolt set is mounted on the inside of the locker
door. This bolt set holds the door shackle, which inserts into the GAT NET.Lock 7000 and locks the door. The bolt set
also includes a passive booster in order to amplify the RFID reading field.
The GAT NET.Lock 7000 locks are controlled by the slave controllers GAT NET.Controller S 7000. To support the
different RFID technologies, there are two different slave controllers available - one for LEGIC®and one for MIFARETM
and ISO 15693 data carriers. Up to 24 GAT NET.Lock 7000 can be connected to one slave controller. The slave
controllers are connected to master controllers, which communicate over Ethernet with a software (e.g. the GAT
Relaxx software from GANTNER Electronic GmbH) on a host computer/server.
Using a locker
The user closes the door of a free locker and while holding the door shut puts his data carrier onto the reading centre
at the locker door (reading centre is indicated by the LED of the lock). The GAT NET.Lock 7000 reads the data carrier
information and communicates with the master controllers (via the slave controllers) for determination, if the user is
allowed to use the locker (depending on his authorisation). If the user is authorised to use the locker, a command is
sent to the GAT NET.Lock 7000 to lock the locker door.
To unlock a locker door the user only holds his data carrier to the reading centre at the previously locked locker door.
The GAT NET.Lock 7000 communicates with the controllers and in case of authorisation the GAT NET.Lock 7000
unlocks the locker door.
2.4 Term Definitions
Several terms are used often in this manual and are defined as described below.
Locker:
The term "locker" is used as a general term and can mean for example a changing locker, a depot or a private box,
which are locked by the GAT NET.Lock 7000.
Lock:
General term for the GAT NET.Lock 7000.
RFID (Radio-Frequency Identification):
Indentification at a short distance using radio frequency. An RFID data carrier is used as identification media.
Data Carrier:
A data carrier in this manual is an identification media which is used by the persons/visitors of a facility for identification
at the locker locks GAT NET.Lock 7000. Data carriers can have different forms like e.g. a wristlet or a chip card. Data
carriers are available in different technologies (LEGIC®, MIFARETM, ISO 15693).

GAT NET.Lock 7000 System
General Information
12 HB_GAT-NETLOCK7000--EN_30 www.gantner.com
FID (Company ID) and Site Key:
LEGIC systems use the FID number. In MIFARE systems the site key is used, which is a combination of the FID and
the read and write keys. The FID and site keys are unique numbers for every leisure facility installation. These num-
bers are encoded in every data carrier and every device and with this number it can be guaranteed that data carriers
of one installation are not used in other installations.
Slave Controller:
A slave controller GAT NET.Controller S 7000 is a device where the locks GAT NET.Lock 7000 get connected to (up
to 24 locks per slave controller). The slave controller receives control signals via the serial RS 485 network and
operates the connected electronic locks accordingly.
Master Controller:
A master controller GAT NET.Controller M 7000 is used to connect the slave controllers via Ethernet to a higher-
ranking PC/server with control software (e.g. GAT Relaxx).
Booster:
Electronic component for amplifying the RFID reading field of the GAT NET.Lock 7000. A booster is often used to
extend the RIFD reading range of the GAT NET.Lock 7000, e.g. at metallic or thick doors or small data carriers. The
bolt sets for the GAT NET.Lock 7000 already include boosters - 1 in the GAT NET.Lock BoltSet 7100 for non-metallic
doors and 2 in the GAT NET.Lock BoltSet 7200 for metallic doors.
GAT Relaxx:
PC software which is installed on a server/host computer and which is used to configure and control the connected
controllers and locks. A separate installation manual and integrated help is available for this software.
User / Visitor:
The terms "user" and "visitor" are used for the persons, which use the lockers and the GAT NET.Lock 7000.
2.5 RFID Technology
Identification of the users at the GAT NET.Lock 7000 is done via RFID (radio-frequency identification) with 13.56
MHz. There are three different technologies. A letter/letters are added to the designations of the GANTNER products
to mark the technology which the device supports:
- "B": LEGIC®
- "F": MIFARETM
- "ISO": ISO 15693
The GAT NET.Lock 7000 and the master controller GAT NET.Controller M 7000 can work with all of these technolo-
gies. The slave controller is available in two different versions, depending on the type of RFID technology:
- GAT NET.Controller S 7000 B: LEGIC®
- GAT NET.Controller S 7000 F/ISO: MIFARETM and ISO 15693
Therefore it is necessary that all devices and data carriers in a facility are of the same technology. The information in
this manual is written in general for all RFID types. If there is special information only valid for a certain technology it
will be noted.

GAT NET.Lock 7000 System
Mounting
www.gantner.com HB_GAT-NETLOCK7000--EN_30 13
3. MOUNTING
This mounting instruction describes how to mount the locker locks GAT NET.Lock 7000. Please read this
instruction carefully and follow it prior to working on the lockers or installing the locks.
As there is a wide variety of applications and locker types, a test installation including a functional testing
must always be performed prior to the serial production of the lockers and the installation of the locks (see
chapter "3.8. Test Installation").
Please also read the most important points for installation summarized in the chapter "3.7. Points to be
observed during Installation"!
3.1 Definition of the Door Hinge (Right or Left Door)
For the mounting, it is important to determine whether the door is hinged to the left or the right. This is defined as
follows:
Figure 3.1 - Definition of the opening direction of lockers (left/right)
In the following pages the mounting for right-hinged doors is desribed. The installation process for left locker doors is
in principle the same as for right locker doors, only with flipped lock and door orientation.
The hinges must not be equipped with retaining springs or other elements which keep the locker door shut!
The locker door must open up without resistance by itself when it is unlocked by the GAT NET.Lock 7000.
3.2 Metallic and Non-Metallic Doors
Because the RFID field of the GAT NET.Lock 7000 is distorted or blocked by metal (e.g. with metallic locker doors),
a cut-out has to be made in metallic locker doors and the GAT NET.Lock Bolt Set 7200 and the label carrier is then
mounted in this cut-out. For non-metallic doors no cut-out but only a drilling for the LED field is required.
Since the reading range of the GAT NET.Lock 7000 is limited, the locker door at non-metallic doors may not be too
thick. The maximum door thickness at non-metallic doors depends on the used RFID technology and data carriers.

GAT NET.Lock 7000 System
Mounting
14 HB_GAT-NETLOCK7000--EN_30 www.gantner.com
3.3 Dimension Drawings for the Mounting
3.3.1 Door Width
The minimum door width allowed (measured from the door shackle to the hinge) is 230 mm. If the door is narrower,
the door shackle would hit the locker when the door is being closed.
Figure 3.2 - Minimal door width
3.3.2 Basic Dimensions of GAT NET.Lock 7000 and the GAT NET.Lock Bolt Sets

GAT NET.Lock 7000 System
Mounting
www.gantner.com HB_GAT-NETLOCK7000--EN_30 15
Figure 3.3 - Dimensions of the GAT NET.Lock 7000 with GAT NET.Lock BoltSet 7100 for non-metallic doors
Figure 3.4 - Dimensions of the GAT NET.Lock 7000 with GAT NET.Lock BoltSet 7200 for metallic doors
1. GAT NET.Lock 7000
2. GAT NET.Lock BoltSet 7100 (for non-metallic doors)
3. GAT NET.Lock BoltSet 7200 (for metallic doors)
4. Door shackle
5. Door contact
6. Booster
7. Status LED
8. Label carrier
3.4 Door Status Contact
The GAT NET.Lock 7000 has a feedback which gets activated by the door contact (5) at the bolt set as soon as the
locker door is closed. To guarantee the correct functionality of the GATNET.Lock 7000 it is important, that this contact
is clean and not damaged.

GAT NET.Lock 7000 System
Mounting
16 HB_GAT-NETLOCK7000--EN_30 www.gantner.com
3.5 Mounting in Lockers with Non-Metallic Doors
In lockers with non-metallic doors the GAT NET.Lock 7000 is mounted on the left or right inner locker wall (depending
if it is a right or left locker) and the GAT NET.Lock Bolt Set 71x0 is mounted on the inside of the locker door. Also a
drilling in the locker door is required for the LED status display. See the following figure and the steps afterwards for
the mounting instructions.
1. GAT NET.Lock 7000
2. GAT NET.Lock Bolt Set 7100
3. Mounting screws for the GAT NET.Lock 7000 (3x), type depending on the locker material
4. Door shackle
5. Door contact
6. Mounting screws for bolt set
7. LED (hole in the locker door)
Figure 3.5 - Mounting of the GAT NET.Lock 7000 in a locker with non-metallic door (right door)
3.5.1 Important Measures when Mounting the GAT NET.Lock 7000 and Bolt Set (Non-Metal Doors)
During the mounting, please pay particular attention to the following points:
- When the door is pressed shut, the gap between the bolt set and the front of the GAT NET.Lock 7000 must not
exceed 0.5 mm. Ideally the bolt set should touch the front of the lock (see measure in Figure 3.5).
- The middle of the door shackle (4) must be 1 mm higher than the middle of the door shackle opening in the GAT
NET.Lock 7000 (see measure in Figure 3.5). This ensures the door’s ability to close even if the door position is
modified 3 mm downwards or 1 mm upwards (tolerance ±2 mm).

GAT NET.Lock 7000 System
Mounting
www.gantner.com HB_GAT-NETLOCK7000--EN_30 17
- If right and left doors are used in a mix, please note the LED positions, since the GAT NET.Lock 7000 is mounted
upside-down on the left doors, compared to the right doors.
Figure 3.6 - LED positions of GAT NET.Lock 7000 at right and left doors
Before mounting all locks of the locker system a test installation of one lock in a mechanically finalized locker
and a subsequent function check must be performed like described below. Only if this check is successful,
the rest of the locks may be mounted in the same way!
3.5.2 Steps for Mounting of the GAT NET.Lock 7000 at Non-Metallic Doors
Please perform the following steps in order to mount the GAT NET.Lock 7000 at non-metallic doors.
Drill the 3 holes (3) for the GAT NET.Lock 7000 into the locker wall.
Attention: Position the 3 holes according to the information in "3.5.1. Important Measures when Mounting
the GAT NET.Lock 7000 and Bolt Set (Non-Metal Doors)"!
Plug-in the connection cable at the GAT NET.Lock 7000 (see "4. Electrical Connection").
Mount the GAT NET.Lock 7000 with 3 screws (3) on the inside locker wall.
Note: Use the right screws according to the type of locker material
Attention: The max. allowed tightening torque of the screws is 2 Nm.
Drill the 3 holes (6) on the locker door inside for mounting the GAT NET.Lock BoltSet 7100.
Drill a hole for the LED display in the locker door (7). The recommended hole diameter is 10 mm.
Note: A customer-specific front label can be used to cover the LED hole. A transparent (matt) field should be placed
on the label to show the LED light.
Mount the bolt set onto the inside of the locker door by using 3 screws.
Note: Use the right type and length of the screws according to the type of locker material.
Close the door to test, if the locker door can be closed easily and the door shackle inserts into the opening in the
GAT NET.Lock 7000.

GAT NET.Lock 7000 System
Mounting
18 HB_GAT-NETLOCK7000--EN_30 www.gantner.com
3.6 Mounting in Lockers with Metallic Doors
In lockers with metallic doors the GAT NET.Lock 7000 is mounted on the left or right inner locker wall (depending if it
is a right or left locker). In the door 2 cut-outs have to be made - one on the inside door sheet and one on the outside
door sheet. The two parts of the GAT NET.Lock Bolt Set 7200 are then mounted into the locker door. See thefollowing
figure and the steps afterwards for the mounting instructions.
1. GAT NET.Lock 7000
2. GAT NET.Lock BoltSet 7200
3. Mounting screws for the GAT NET.Lock 7000
4. Door shackle
5. Door contact
6. Mounting screws for bolt set (pan-head metal Torx Ø 3.5 x 9.5 mm)
7. LED position
8. Cut-out for GAT NET.Lock BoltSet 7200
9. Cut-out for label carrier
10. Label carrier
Figure 3.7 - Mounting of the GAT NET.Lock 7000 in a locker with metallic doors (right door)

GAT NET.Lock 7000 System
Mounting
www.gantner.com HB_GAT-NETLOCK7000--EN_30 19
3.6.1 Cut-Outs in the Locker Door
On the inside and outside walls of the locker door the following cut-outs must be made in order to mount the GAT
NET. Lock BoltSet 7200 and the label carrier. The measurements for the cut-outs are as follows.
Figure 3.8 - Cut-Outs in Metallic Doors
3.6.2 Important Measures when Mounting the GAT NET.Lock 7000 and Bolt Set (Metal Doors)
During the mounting, please pay particular attention to the following points:
- The door thickness must be between 18 and 26 mm (see Figure 3.7).
- When the door is pressed shut, the gap between the bolt set and the front of the GAT NET.Lock 7000 must not
exceed 0.5 mm (see measure in Figure 3.7). Ideally the bolt set should touch the front of the lock.
- The middle of the door shackle (4) must be 1 mm higher than the middle of the door shackle opening in the GAT
NET.Lock 7000 (see measure in Figure 3.7). This ensures the door’s ability to close even if the door position is
modified 3 mm downwards or 1 mm upwards (tolerance ±2 mm).
Before mounting all locks of the locker system a test installation of one lock in a mechanically finalized locker
and a subsequent function check must be performed like described below. Only if this check is successful,
the rest of the locks may be mounted in the same way!

GAT NET.Lock 7000 System
Mounting
20 HB_GAT-NETLOCK7000--EN_30 www.gantner.com
3.6.3 Steps for Mounting of the GAT NET.Lock 7000 at Metallic Doors
Please perform the following steps in order to mount the GAT NET.Lock 7000 at metallic doors.
Drill the 3 holes (3) for the GAT NET.Lock 7000 into the locker wall.
Attention: Position the 3 holes according to the information in the previous section "3.5.1. Important Measures
when Mounting the GAT NET.Lock 7000 and Bolt Set (Non-Metal Doors)"!
Plug-in the connection cable at the GAT NET.Lock 7000 (see "4. Electrical Connection").
Mount the GAT NET.Lock 7000 with 3 screws (3) on the inside locker wall.
Note: Use the right screws according to the type of locker material
Attention: The max. allowed tightening torque of the screws is 2 Nm.
On the inner wall of the locker door make the cut-out (63.2 x 68 mm) for the GAT NET.Lock Bolt Set 7200.
On the inner wall of the locker door drill the 4 holes (6) for mounting the GAT NET.Lock Bolt Set 7200.
On the outer wall of the locker door make the cut-out (68.2 x 94 mm) for the label carrier.
Mount the bolt set onto the inside wall of the locker door by using the 4 screws included in the scope of supply (Torx Ø
3.5 x 9.5 mm) as shown in Figure 3.8 on the previous page.
Note: Use the following screws (which are included in the scope of supply): Torx, Ø 3.5 mm, length 9.5 mm
Push the label carrier onto the outside wall of the locker door. The label carrier will hold in place with the lashes on
the label carrier - no screws are required.
Stick the front label onto the label carrier.
Note: A customer-specific front label can be used to cover the LED hole. A transparent field should be placed on
the label to show the LED light
Figure 3.9 - Label carrier with front label
Close the door to test, if the locker door can be closed easily and the door shackle inserts into the opening in the
GAT NET.Lock 7000.
