Ganz ZM-TY110A User manual

EG-2
1. Read Instructions : All the safety and operating instructions should be read before the appliance is
operated.
2. Retain Instructions : The safety and operating instructions should be retained for future reference.
3. Heed Warnings : All warnings on the monitor and in the operating instructions should be adhered to.
4. Follow Instructions : All operating and use instructions should be followed.
5. Cleaning : Unplug this monitor from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners.Use a damp cloth for cleaning.
CONTENTS
IMPORTANT SAFEGUARDS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EG-2
GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EG-4
FRONT PANEL COMPONENTS AND CONTROLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EG-5
REAR PANEL COMPONENTS AND CONTROLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EG-6
CONNECTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EG-6
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EG-7
SPECIFICATIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EG-7
IMPORTANT SAFEGUARDS
Graphic Symbol Explanation
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert
the user to the presence of uninsulated ‘dangerous voltage’within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
CAUTION
CAUTION : TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Warning-To Prevent Fire or Shock Hazard, Do Not ExposeThis MonitorTo Rain or
Moisture.
Caution
Power source is indicated on the rear of the set. It contains high-voltage parts. If you remove
the cover, it may cause fire or electric shock.Do not remove the cover by yourself. (Control
switches are at the front of the monitor).

EG-3
Exception. A monitor that is meant for uninterrupted service and that for some specific reason, such as
the possibility of the loss of an authorization code for a CATV converter, is not intended to be unplugged
by the user for cleaning or any other purpose, may exclude the reference to unplugging the monitor in
the cleaning description otherwise required in Item 5.
6. Attachments : Do not use attachments not recommended by CBC as they may cause hazards.
7.Water and Moisture : Do not use this monitor near moisted environment a bathtub, wash bowl, kitchen
sink, or laundry tub, in a wet basement, or near a swimming pool and the like.
8. Accessories : Do not place this monitor on an unstable cart, stand, tripod, bracket, or table.The
monitor may fall, causing serious injury to a child or adult, and serious damage to the appliance.Use
only with a cart, stand, tripod, bracket, or table recommended by CBC, or sold with the monitor. Any
mounting of the monitor should follow CBC’s instructions, and should use a mounting accessory
recommended by CBC.
9.Ventilation : Slots and openings in the cabinet are provided for ventilation and to ensure reliable
operation of the monitor and to protect it from overheating, and these openings should never be blocked
by placing the monitor on a bed, sofa, rug, or other similar surface.This monitor should never be placed
near or over a radiator or heat register.
This monitor should not be placed in a built-in installation such as a bookcase or rack unless proper
ventilation is provided or CBC’s instructions have been adhered to.
10. Power Sources : This monitor should be operated only from the type of power source indicated on the
making label. If you are not sure of the type of power supply to your installation site, consult your CBC
dealer or local power company.
11. Grounding or Polarization : For monitors equipped with a 3-wire grounding-type plug having a
third(grounding)pin.This plug will only fit into a grounding type power outlet.This is a safety feature.If
you are unable to insert the plug into the outlet, contact your electrician to replace your obsolete outlet.
Do not defeat the safety purpose of the grounding-type plug.
12. Power : Cord Protection-Power supply cords should be routed so that they are not likely to be walked
on or pinched by items placed upon or against them, paying particular attention to cords at plugs,
convenience receptacles, and the point where they exit from the monitor.
13. Lightning : For added protection for this monitor during a lightning storm, or when it is left unattened
and unused for long periods of time, unplug it from the wall outlet and disconnect the cable system.This
will prevent damage to the monitor due to lightning and power-line surges.
14. Overloading : Do not overload wall outlets and extension cords as this can result in a risk of fire of
electric shock.
15. Object and Liquid Entry : Never push objects of any kind into this monitor through openings as they
may touch dangerous voltage points or short-out parts that could result in a fire or electric shock.
Never spill liquid of any kind on the monitor.
16. Servicing : Do not attempt to service this monitor yourself as opening or removing covers may expose
you to dangerous voltage or other hazards.Refer all servicing to qualified service personnel.
17. Damage Requiring Service : Unplug this monitor from the wall outlet and refer servicing to qualified
service personnel under the following conditions.
a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the monitor.
c. If the monitor has been exposed to rain or water.
d. If the monitor does not operate normally by following the operating instructions. Adjust only those
controls that are covered by the operating instructions as an improper adjustment of other controls
may result in damage and will often require extensive work by a qualified technician to restore the
monitor to its normal operation.
e. If the monitor has been dropped or the cabinet has been damaged.
f. When the monitor exhibits a distinct change in performance-this indicates a need for service.
18. Replacement Parts : When replacement parts are required, be sure the service technician has used
replacement parts specified by CBC or have the same characteristics as the original parts.
Unauthorized substitutions may result in fire, electric shock or other hazards.
19. Safety Check : Upon completion of any service or repairs to this monitor, ask the service technician to
preform safety checks to determine that the monitor is in proper operating condition.

EG-4
FCC & ICES Information
Warning
This equipment has been tested and found to comply the limits for a class A digital device, pursuant to part
15 of the FCC Rules and ICES-003 of Industry Canada.These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial environment. This
equipment generate, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.
User-Installer Caution
Your authority to operate this FCC verified equipment could be voided if you make changes or
modifications not expressly approved by the party responsible for compliance to part 15 of the FCC Rules.
GENERAL
Scope
The information in this instruction manual covers the installation and operation of the Colour Monitors.
These units should be installed using approved materials and wiring practices in accordance with the
National Electrical Code and applicable local wiring ordinances.
Introduction
The Colour Monitors are designed primarily for industrial applications this monitor accepts standard EIA
colour input signals.
Operating controls (BRIGHT, CONTRAST, COLOUR, TINT, SHARP, VOLUME) are located on the front
panel. A power switch is also located on the front panel.
A regulated power supply maintains excellent performance during fluctuations in line voltage.
The Colour Monitors are housed in a metallic dark-gray colour cabinet.

EG-5
FRONT PANEL COMPONENTS AND CONTROLS
Power Switch
On/off switch. If you press this button, the monitor is turned on and the LED of
selected input signal is lit.
VIDEO Input Selection Switch
It selects video and audio input signal.To change input signal, press this button.
VOLUME, DATA Control Switch
VOLUME key has two functions :
• Volume Controls : To change volume, press only this key.
• Data Controls : If you press CONTRAST, BRIGHT, COLOUR, TINT or SHARP
and then VOLUME key, you can change the value of each key.
CONTRAST Switch
This control adjusts the contrast of the screen image.Press CONTRAST switch and
then VOLUME(DATA) switch to control the contrast. (Default is 60).
BRIGHT Switch
This control adjusts the brightness of the screen image. Press BRIGHT switch and
then VOLUME(DATA) switch to control the brightness.(Default is 50).
COLOUR Switch
This control adjusts the colour intensity of the screen image.Press COLOUR switch
and then VOLUME(DATA) switch to control the colour intensity. (Default is 50).
TINT Switch
With this switch, you can control the colour to be close to natural colour.
For the best result, control screen image with this switch so that skin colour is
natural.Press TINT switch then VOLUME(DATA) switch to control the colour.
(Default is 50).
SHARP Switch
This control adjusts the sharpness of the screen image.Press SHARP switch and
then VOLUME(DATA) switch to control the sharpness.(Default is 50).
SHARP TINT COLOR BRIGHT CONTRAST VOLUME
DATA
A
B
C
VIDEO POWER
ZM-TY110A
ZM-TY114A ZM-TY115HA ZM-TY121A
POWER
VIDEO
DATA
VOLUME
CONTRAST
BRIGHT
COLOR
TINT
SHARP

EG-6
REAR PANEL COMPONENTS AND CONTROLS
VIDEO LINE
Input/output terminals for video signal.
Video A and Video B are composite input/output terminals.
AUDIO LINE
Input/output terminals for audio signal.
A and B must be selected with Video A and Video B respectively.
IN
Video A
OUT IN
Video B
OUT
VIDEO LINE AUDIO LINE
A
B
IN OUT
IN
Video A
OUT IN
Video B
OUT IN
Video C
OUT
VIDEO LINE AUDIO LINE
A
B
C
IN OUT
ZM-TY110A
ZM-TY114A ZM-TY115HA ZM-TY121A
CONNECTIONS
IN
Video A
OUT IN
Video B
OUT
VIDEO LINE AUDIO LINE
A
B
IN OUT
IN
Video A
OUT IN
Video B
OUT IN
Video C
OUT
VIDEO LINE AUDIO LINE
A
B
C
IN OUT
ZM-TY110A
ZM-TY114A ZM-TY115HA
ZM-TY121A
CAMERA
CAMERA (S-video out)
VCR
S-VHS VCR
CAMERA
VCR

EG-7
Model Number ZM-TY110A ZM-TY114A ZM-TY115HA ZM-TY121A
CRT
10”, 0.63mm Stripe Pitch 14”, 0.66mm Stripe Pitch 15”, 0.28mm Dot Pitch 21”, 0.17mm Stripe Pitch
90°Deflection
TV System NTSC / PAL
Video Input x2, composite 1.0Vp-p 75Ω
x2, composite 1.0Vp-p 75Ω
x1,Y/C separate
Y : 1.0Vp-p 75Ω, C : 0.286/0.3(NTSC/PAL)Vp-p 75Ω
Video Output x2, composite 1.0Vp-p 75Ω
x2, composite 1.0Vp-p 75Ω
x1,Y/C separate
Y : 1.0Vp-p 75Ω, C : 0.286/0.3(NTSC/PAL)Vp-p 75Ω
Horizontal Resolution More Than 280 TV Lines More Than 360TV Lines More Than 650TV Lines More Than 450 TV Lines
Convergence (Center) Less Than 0.4mm Less Than 0.3mm Less Than 0.4mm
High Voltage 18kV ±1.0kV 24kV ±1.0kV 25kV ±1.5kV
Horizontal Frequency NTSC 15.75kHz ±500Hz
Stability PAL 15.625kHz ±500Hz
Vertical Frequency NTSC 60Hz ±4Hz 60Hz ±4Hz 60Hz ±4Hz 60Hz ±4Hz
Stability PAL 50Hz ±4Hz 50Hz ±4Hz 50Hz ±4Hz 50Hz ±4Hz
Subcarrier Frequency NTSC 3.579545MHz ±500Hz (Room Temperature)
Sync. Range PAL 4.433618MHz ±500Hz (Room Temperature)
Audio Input x2, Phono, –5dBu, High-impedance x3, Phono, –5dBu, High-impedance
Audio Output x2, 0.8W x2, 1.0W x3, 1.0W x3, 1.0W
Power Supply 90 to 260VAC (50/60Hz)
Power Consumption 50W (Max.) 62W (Max.) 85W (Max.) 70W (Max.)
OperatingTemperature 0 to 40°C (32 to 104°F)
Operating Humidity 0 to 90% (Non-Condensing)
Weight Approx. 7kg Approx. 12kg Approx. 14kg Approx. 25kg
Dimensions (W x H x D) 265 x 260 x 330mm 365 x 342 x 391mm 490 x 444 x 482mm
Standards CE / FCC
SPECIFICATIONS
MAINTENANCE
If the quality of the picture on the COLOUR MONITOR is poor and cannot be improved, inspect all system
connections and cable runs.
Repairs should be performed by a qualified technician with adequate test equipment and facilities.
Features and specifications are subjected to change without any notice for further improvement.
