Ganz MDC-IR3.6N User manual

PRODUCT FEATURES
Selection of 330 and 540TV resolution and low light performance
surveillance camera with a built-in 1/3 type CCD
Integrated 3.6 mm fixed lens
Outstanding 0 lux performance with built-in 24 LEDs.
Photocell activates IR light at night
Designed for indoor or outdoor use
SAFETY PRECAUTIONS
1. The installation should be made by qualified service engineers and
should conform to all local codes.
2. To prevent fire or electric shock, do not expose the camera to rain or
moisture.
3. To prevent fire or electric shock, UL listed wiring should be used for
the DC 12V input.
4. Use only DC 12V regulated power supply marked class 2.
5. Never attempt to disassemble or modify the camera.
6. Be sure to connect each lead to the appropriate terminal.
Wrong connection may cause damage to the camera.
7. Do not attempt to aim the camera at the sun or other extremely bright
objects.
8. Do not allow the camera to be subject to unstable location, strong
shocks and vibration, and strong electromagnetic field.
9. If any abnormality occurs, immediately turn off the power and consult
your dealer.
PARTS DESCRIPTION
After un-packing, check if the following items are contained
inside.
¾MDC(H)-IR3.6N unit with Power and BNC Cable…1
¾User Manual… 1
¾Screw…4
¾Mating Power Connector …1
¾“L” Wrench ...1
INSTALLATION AND ADJUSTMENT
Note: The camera can be mounted on both ceiling and wall.
1. Mount the bottom plate on your desired location by screws. (See Pic. 1)
2. Assemble the Ball camera with middle and base rings to the bottom plate.
3. Set the camera angle by rotating the ball camera.(See Pic.2)
4. Fasten the middle ring and set with “L” wrench to secure the
camera angle. .(See Pic.2)
OUTDOOR IR COLOR CAMERA
MODEL: MDC-IR3.6N / MDCH-IR3.6N
Picture(1) picture(2)
Ball camera
Middle Ring
Base Ring

SPECIFICATIONS LENS SPECIFICATIONS
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including
interference that may cause undesired operation.
Disposal of your old appliance
1. When this crossed-out wheeled bin symbol is attached to a product it means the
product is covered by the European Directive 2002/96/EC.
2. All electrical and electronic products should be disposed of separately from the
municipal waste stream via designated collection facilities appointed by the
government or the local authorities.
3. The correct disposal of your old appliance will help prevent potential negative
consequences for the environment and human health.
4. For more detailed information about disposal of your old appliance, please contact your
city office, waste disposal service or the shop where you purchased the product.
440g
Weight
93mm(W) x 80mm(H)
External dimensions
IP66IP Rating
Operation : Max. 85%RH / Storage : Max. 95%RH
Ambient humidity
Operation : -10°C to +50°C (14deg F to 122 deg F)/ Storage : -20°C to
+60°C (-4 deg F to 140 deg F)
Ambient temperature
2.4 W
Power consumption
12V DC±10%Power Supply
ATW
White balance
1/60 sec. ～1/100K sec.Electronic Shutter
Internal onlySync. System
24 IR LEDsIR Illumination
0.45Gamma characteristic
More than 46 dB (at minimum AGC gain)S/N ratio
Digital
Day / Night
0 Lux (IR LED ON)
Minimum Illuminance
More than 540 TVLMore than 330 TVLHorizontal resolution
1.0Vp-p /75ΩVideo output
15.734kHz(H) x 59.94Hz(V)Scanning Frequency
768(H) x 494(V)510(H) x 492(V)
Effective Elements
1/3"-Type Interline transfer CCD
Image Sensor
2 : 1 InterlaceScanning system
NTSCTV System
MDCH-IR3.6NMDC-IR3.6NModel Name
54.8°V
74.1°H
95.4°D
Angle of view
(Wide to Tele)
FixedIris
2.0F No
3.6mmFocal Length
1 : 2.0
Max. aperture ratio
The specifications and/or appearance of the product may change without a prior notice
