Gap Diagnostic IIDTool Pro User manual

IIDTool Pro, IIDTool BT
and IIDTool
For all supported vehicles
By
I1
User Manual Version 33
Firmware V3.0

2
IIDTool
GAP Diagnostic 2019-07-15 All Rights Reserved
User Manual : Version 33, Firmware V3.0
WARNING
For your safety and that of others, please read this manual be-
fore using the IIDTool. Failure to follow instructions could result
in serious consequences.
WARNING
The IIDTool is a powerful diagnostic device that allows reading
and clearing of logged faults as well as changing vehicle con-
guration and / or settings. It is designed for use by very well-
informed individuals or professional automotive technicians. It
is the sole responsibility of the user to make sure that he
has the necessary skills and training required to use the IID-
Tool.
Read this instruction manual carefully!
Disclaimers
Neither the distributors nor the manufacturer (GAP Diagnostic, Inc.) accept any responsibility or liability
for damages incurred through use of the IIDTool. This includes all damages to the vehicle itself, vehicle
systems or property. This also includes injuries to the user or other persons. The warranty is limited
to the functionality of the IIDTool itself (for further warranty details, please consult the last page of this
document). This includes especially:
• Damages incurred through improper use of the IIDTool
• Damages incurred through the use of the IIDTooltochangevehiclecongurationand/orset-
tings
• Damages incurred by changing the height settings of the electronic air suspension. Changing
the height settings either up or down can make the vehicle less stable. Do not drive vehicles
in an unstable condition!
• Damagesincurredthroughclearingfaultswithoute󰀨ectingproperrepairs
• Damages incurred through usage of any third party products delivered by the IIDTool.
WARNING The IIDTool is not designed to be left in place for long periods.
Please unplug after use!

2 3
IIDTool
GAP Diagnostic 2019-07-15 All Rights Reserved
User Manual : Version 33, Firmware V3.0
Terms and conditions
Do not copy or reverse engineer
Whileconsiderablee󰀨orthasbeenmadetomaketheinformationprovidedinthissectionascomplete
and accurate as possible, it does not and cannot cover all possible situations. The authors cannot ac-
cept any responsibility for any damages which may occur from the use or misuse of these procedures,
nor can the authors accept any responsibility for any damages which may result from personal injury
or property damage which allegedly may be caused by the use or misuse of these procedures. No
responsibility is accepted for missing or incorrect information. Those who use these procedures shall
accept all responsibility for performing the work which may be described below.
Specicationsaresubjecttochangewithoutpriornotice.
Suggestions
For convenience and even security purposes, it is suggested that the user keeps an updated version
of this manual in PDF format on his or her mobile devices. Thus, accessibility to procedures will be
possible anywhere and anytime. By the same token, the computerized version facilitate searching for
a particular topic.
You can proceed to download the User’s Manual on the manufacturer’s website :
https://www.gap-diagnostic.com/support/documents/IIDTool/
The manual is updated regularly.

4
IIDTool
1 Introduction..............................................................................17
1.1 IIDTool objectives.................................................................................. 17
1.2 Description of each IIDTool models .................................................... 17
1.3 Connectors descriptions...................................................................... 18
1.4 Brief descriptions of o󰀨ered Functions.............................................. 19
1.4.1 Functions categorized by Objectives ................................................. 19
1.4.2 Functions classication....................................................................... 20
1.4.3 Access levels to IIDTool Functions (licence) ..................................... 21
1.5 Additional Licence ................................................................................ 21
1.6 Supported vehicles/platforms ............................................................. 22
1.6.1 Model Year Identication...................................................................... 22
1.6.2 Model-Referent code of covered vehicles .......................................... 23
1.7 Interfaces ............................................................................................... 24
1.7.1 Interfaces presentation ........................................................................ 24
1.7.2 Availability of Interfaces for each tool ................................................ 27
1.7.3 Characteristics of each Interface ........................................................ 28
1.7.4 Mobile App............................................................................................. 29
1.7.5 Compatible mobile devices.................................................................. 29
1.7.6 App parameters..................................................................................... 30
Available settings and description...................................................................... 31
1.8 Demonstration Mode (Android Only) .................................................. 32
1.9 LogIn ...................................................................................................... 33
1.10 Binding................................................................................................. 34
2 Getting started.........................................................................35
2.1 Before rst usage ................................................................................. 35
2.2 Create a user account on the website ................................................ 36
2.3 Installing the Updater Software ........................................................... 37
2.4 Installing Interfaces .............................................................................. 39
2.4.1 Intalling the PC-based interface*......................................................... 39
Table of content

5
IIDTool
4
2.4.2 Installing the Integrated Interface ....................................................... 39
2.4.3 Installing the Application (App) IIDControl ........................................ 39
2.5 Updating the IIDTool rmware ............................................................. 40
2.5.1 Steps for updating the IIDTool............................................................. 40
2.5.2 Update ECU les only (Pro)................................................................. 41
2.5.3 Language ............................................................................................... 42
2.6 Synchronizing the Mobile Application (BT/Pro)................................. 43
2.7 Safety and tips ...................................................................................... 45
2.7.1 Safety .................................................................................................... 45
2.7.2 Tips to avoid battery drainage............................................................. 46
2.8 General operation of the IIDTool.......................................................... 47
2.8.1 OBDII Port location............................................................................... 47
2.8.2 Connecting the IIDTool......................................................................... 49
2.8.3 Mobile Application, Navigation and Controls..................................... 50
Denition ............................................................................................................... 50
Integrated Interface replica.................................................................................. 51
Language............................................................................................................... 51
2.8.4 Integrated Interface, Navigation and Commands .............................. 52
2.8.5 PC interface Navigation and Commands (discontinued).................. 54
2.8.6 Disconnecting the IIDTool.................................................................... 56
2.9 Activation............................................................................................... 57
2.9.1 App, Activation using the mobile App, online mode ......................... 58
2.9.2 App, Activation using the mobile App, o󰀪ine mode ......................... 60
2.9.3 Activation using the Integrated (II) or PC Interface ........................... 62
2.9.4 Obtain the unlock code ........................................................................ 63
2.9.5 Pro, Additional activation steps .......................................................... 65
O󰀪ine mode.......................................................................................................... 65
Online mode .......................................................................................................... 65
2.9.6 Obtain an additional licence ................................................................ 67
2.9.7 Transfer of ownership .......................................................................... 69
2.9.8 Permissions........................................................................................... 70
3 Diagnostic Keys.......................................................................72
3.1 Fault Concept-1st Key ......................................................................... 72

6
IIDTool
3.1.1 Faults introduction ............................................................................... 72
3.1.2 Faults Detection.................................................................................... 72
3.1.3 Faults types, brief description............................................................. 74
3.1.4 Faults denitions .................................................................................. 75
3.2 Completing the Diagnosis-2nd Key ...................................................... 75
3.2.1 Diagnostic procedure in the presence of a Cascade E󰀨ect ............. 75
4 IIDTool Functions ....................................................................76
4.1 Introduction to Functions .................................................................... 76
4.1.1 Directory of Functions.......................................................................... 77
4.1.2 Denitions and examples of Functions usage................................... 78
4.1.3 General Access to Functions............................................................... 80
4.2 Function “ Version ” .............................................................................. 80
4.2.1 Denition ............................................................................................... 80
4.2.2 Access ................................................................................................... 80
4.3 Function “ Faults ” ................................................................................ 81
4.3.1 Sub-Function “ Read Faults ”............................................................... 81
Denition ............................................................................................................... 81
II Access ................................................................................................................ 81
App Access ........................................................................................................... 82
4.3.2 Sub-Function “ Clear Faults ”............................................................... 83
II Access ................................................................................................................ 83
App Access ........................................................................................................... 83
4.3.3 Faults decoding .................................................................................... 84
Structure of Fault codes provided by the IIDTool.............................................. 84
Code Elements...................................................................................................... 84
Element “ Denition ” ........................................................................................... 86
Additional information, freeze frames ................................................................ 87
Decoding status bits (4th element of the fault code).......................................... 87
Show All ECUs ...................................................................................................... 91
4.3.4 Sub-Function “ Advanced Read ” ....................................................... 92
Denition ............................................................................................................... 92
II Access ................................................................................................................ 92
App Access ........................................................................................................... 93
4.4 Function “ Height ” ................................................................................ 94

7
IIDTool
6
4.4.1 Denition ............................................................................................... 94
4.4.2 Sub-function denitions....................................................................... 95
4.4.3 Limits ..................................................................................................... 95
4.4.4 App : Layout denition......................................................................... 97
Main screen layout ............................................................................................... 97
Changing a height setting.................................................................................... 98
Additional height modes (L322-02 only)............................................................. 99
4.5 Function “ Height Control ” (App,L319-10, L320-10, L322-10, L405, L494)102
4.5.1 Denition ............................................................................................. 102
4.5.2 Buttons description ............................................................................ 102
4.6 Function “ Calibration ” of systems and components..................... 103
4.6.1 Denition ............................................................................................. 103
4.6.2 Steering Angle Sensor (L322, L319, L320, L316*) ............................ 103
Steering angle sensor calibration ..................................................................... 103
Steering angle sensor renew (L322-02, L322-06)............................................. 103
4.6.3 Parking Brake (L322-06, L322-10, L319, L320) ................................ 103
Longitudinal Accelerometer Sensor Calibration ............................................. 103
4.6.4 Anti-lock Braking System (ABS)........................................................ 104
Yaw Rate Sensor Calibration (ABS, L319-10, L320-10, L322-10) ............... 104
4.6.5 Transfer Case (L319, L320, L322-06, L322-10, L405, L494) ............. 104
Clutch Calibration............................................................................................... 104
Position or Range Sensor Calibration .............................................................. 104
XY Sensor Calibration (gear position sensor, manual transaxles only)........ 104
4.6.6 Engine (L316-12 with DSC) ................................................................ 105
Steering angle sensor calibration ..................................................................... 105
4.6.7 Active Damping (L322-10) .................................................................. 105
4.6.8 Suspension.......................................................................................... 105
II Sensors calibration ......................................................................................... 106
App Sensors calibration .................................................................................... 110
Original standard heights .................................................................................. 112
4.6.9 Adaptive Cruise Control (L322-10) .....................................................113
4.6.10 Power Steering (L538) .......................................................................113
Calibration ........................................................................................................... 113
VIN learn .............................................................................................................. 113
4.7 Function “ Service Test ” .................................................................... 114

8
IIDTool
4.7.1 Denition ..............................................................................................114
4.7.2 Suspension...........................................................................................115
Test Valve............................................................................................................. 115
Re-Enable EAS.................................................................................................... 118
Deate modes ..................................................................................................... 118
Set tight / normal tolerance (All except L322-02)............................................. 119
Transport Mode (L322-02) and Build Mode (All except L322-02) ................... 119
4.7.3 Electronic Parking Brake ....................................................................119
Unjam (L322-06, L322-10, L319-04, L320-05, L319-10, L320-10)..................... 119
Normale or Service position (L405, L494, L538, L359 2013+)......................... 120
4.7.4 Engine .................................................................................................. 120
Clear Adaption Values (L316, Petrol : L322, L319, L320) ............................... 120
Fuel priming (petrol only, L319-04, L320-05).................................................... 121
Fuel Lift Pump Reset (Diesel only, L319, L320, L322*, L316).......................... 121
Injector Replacement (L316).............................................................................. 121
DPF Pressure Sensor Reset (L316-12) ............................................................. 121
DPF Replacement Reset (L316-12).................................................................... 122
Mass Air Flow Replacement Reset (L316-12)................................................... 122
Reset Oil Counter (L316-12*, L359 2013+)........................................................ 122
Turbocharger Replacement Reset (L316-12).................................................... 122
Renew security ID between 10AS and PCM (L316) ......................................... 122
High PSI Pump Reset (L316-07) ........................................................................ 123
Pilot Correction Learning (L316-07, L319-04 and L320-05)............................. 123
4.7.5 Fuel Burning/Auxiliary Heater (L322-10, L319, L320) ...................... 124
Fuel Priming ........................................................................................................ 124
Check Operation ................................................................................................. 124
4.7.6 Instrument Pack.................................................................................. 124
Service Interval Reset (All except L322-02, L359 2013+*, L538*) ................... 124
4.7.7 Transmission....................................................................................... 125
Adaption clear (L322-06, L322-10, L319, 6 speed) ........................................... 125
4.7.8 Body Control/Processor..................................................................... 126
Key programming (VIN locked L319-04, L320-05) ........................................... 126
Key Programming (VIN locked L322-06)........................................................... 127
Add a key (VIN Locked L322-10, L319-10, L320-10, L538, L359 2013+) ......... 128
Check number of keys (L322-10, L319-10, L320-10, L538, L359 2013+, L494, L405)
128
Battery Replacement (L322-10, L319-10, L320-10, L550) ................................ 129
Deactivate Valet Mode (L322-10, L319-10, L320-10) ........................................ 129
Transport Mode activation, deactivation (L322-02, L322-06).......................... 129

9
IIDTool
8
ECU renew (L322-02, L322-06)........................................................................... 129
Crash Status Reset (L359 up to 2012) .............................................................. 129
Driver/Passenger Door Glass Learn (L319-10, L320-10, L359, L322-10) ....... 129
4.7.9 Airbag (L322-10, L319, L320, L538) ................................................... 129
Set Normal Mode ................................................................................................ 129
4.7.10 HVAC Heat / Cool .............................................................................. 129
Learn Actuator Limits (L322-10, L319-10, L320-10) ......................................... 129
Stepper motor initialization (L319-10, L320-10, L405, L494)........................... 129
Set HVAC for AHCM (L322-10) ........................................................................... 129
4.7.11 All ECUs ............................................................................................. 130
Vehicle Reset (L322-10, L319, L320) ................................................................. 130
4.7.12 10AS (L316) ....................................................................................... 130
Key programming (VIN locked) ......................................................................... 130
Renew security ID between PCM and 10AS ..................................................... 130
4.7.13 Anti-lock Braking System (ABS)...................................................... 130
BT/Pro Brake bleeding (VIN locked, L319, L320, L322-06, L322-10) .............. 130
4.7.14 Rain sensor ....................................................................................... 131
Initialization (L322-02, L322-06)......................................................................... 131
4.7.15 Rear Di󰀨erential (VIN locked, L319, L320, L322-06, L322-10)......... 131
Self-Test ............................................................................................................... 131
4.8 Function “ Live Values ” (LV) .............................................................. 132
4.8.1 Denition ............................................................................................. 132
4.8.2 II Viewing live values when using the integrated interface............. 132
4.8.3 App Viewing live values when using the mobile App...................... 133
Live value selection and sampling rate ........................................................... 133
Basic controls ..................................................................................................... 133
Graph view options ............................................................................................ 135
Using the My Favorite feature ........................................................................... 138
Trigger feature..................................................................................................... 141
4.8.4 App Viewing and exporting logs ....................................................... 145
4.8.5 App Sharing Logs ............................................................................... 146
Access ................................................................................................................. 146
Sharing to friends ............................................................................................... 147
4.8.6 App Online Logs ................................................................................. 148
Viewing logs........................................................................................................ 148
4.9 Function “ Control Input / Output ”.................................................... 149

10
IIDTool
4.9.1 Denition ............................................................................................. 149
4.9.2 Electronic Parking Brake ECU........................................................... 150
Select Normal or Service position (L322-06, L319-04, L320-05)..................... 150
4.10 Function “ Car Conguration ”......................................................... 151
4.10.1 Denition ........................................................................................... 151
Car Conguration File ........................................................................................ 151
Congurations of the BCM and LCM (L322-02 L322-06)................................. 152
4.10.2 Uploading a conguration change.................................................. 153
II BCM and LCM Congurations (L322-02, L322-06)........................................ 153
II Car Conguration File ..................................................................................... 153
App BCM, LCM and CCF congurations .......................................................... 153
4.10.3 Congurations backup..................................................................... 154
4.10.4 II Recovery procedure ...................................................................... 154
4.10.5 App Recovery procedure ................................................................. 155
4.10.6 Pro BT Editing Untested CCFs (available on request) .................. 155
4.10.7 App Using the My Favorite Car Conguration feature .................. 156
4.11 Function “ ECU Flash ”...................................................................... 159
4.11.1 Denition............................................................................................ 159
4.11.2 Risk scale........................................................................................... 161
4.11.3 Recovery method.............................................................................. 162
General method .................................................................................................. 162
Body Control and Instrument Pack (L319-04, L320-05) .................................. 162
4.11.4 Available Re-Flash ............................................................................ 163
Engine Remaps, EGR blanking and the likes. ................................................. 163
Fast Lane Service ............................................................................................... 168
Suspension (L322-06, L322-10, L319, L320)..................................................... 169
Body Control (L319-04, L320-05)....................................................................... 170
Instrument Pack (L319-04, L319-10, L320-05, L320-10)................................... 171
Bluetooth (English UK*, L322-2005, L322-06, L319-04, L320-05) ................... 173
Bluetooth ECU (other languages, L322-2005, L322-06, L319-04) ................... 175
Navigation (L322-2005, L322-06, L319-04, L320-05) ........................................ 176
Transfer Case (L319-04, L320-05*) .................................................................... 183
Audio Control (L319-04, L320-05*) .................................................................... 183
Transmission (L319-10, L320-10, enabling appy paddles**)......................... 183
4.12 Function “ ECU Info ” ........................................................................ 184
4.13 Save / Restore .................................................................................. 186

11
IIDTool
10
4.13.1 Denition ........................................................................................... 186
4.13.2 Save (except L359, L538) ................................................................. 186
4.13.3 Restore............................................................................................... 186
Air Suspension (except L359, L538) ................................................................. 186
Car Conguration File CCF ............................................................................... 186
Car Cong (L322-02, L322-06) ........................................................................... 186
4.14 IIDTool Cong.................................................................................... 187
4.14.1 Find ECUs.......................................................................................... 187
4.14.2 II Voltage displayed........................................................................... 187
4.14.3 Enter unlock code............................................................................. 187
Limited Warranty .......................................................................188
Glossary .....................................................................................189
Appendix....................................................................................190
Menu tree ................................................................................................... 191

12
IIDTool
Figure 1. Micro USB socket for USB cable used to connect the IIDTool to a computer ......... 18
Figure 2. OBDII connector allowing connection of the IIDTool to a vehicle ............................ 18
Figure 3. App : Menu overview .............................................................................................. 25
Figure 4. App : Integrated Interface replica overview ............................................................ 25
Figure 5. II 3-lines display, L319-10, L320-10, L322-10 ........................................................ 26
Figure 6. II One line display, L319-04, L320-05, L322-02, L322-06 ...................................... 26
Figure 7. PC Interface overview ............................................................................................. 26
Figure 8. App : Parameters.................................................................................................... 30
Figure 9. Settingsdenition .................................................................................................... 31
Figure 10. App : Demonstration mode................................................................................... 32
Figure 11. App : Example of live values, demonstration mode .............................................. 32
Figure 12. Login...................................................................................................................... 33
Figure 13. Tool Binding ........................................................................................................... 34
Figure 14. Register on the GAP Diagnostic website............................................................... 36
Figure 15. Updater software download................................................................................... 38
Figure 16. Updater software overview.................................................................................... 41
Figure 17. Overview, “ Program Flash File Only ” button......................................................... 41
Figure 18. App : File download or synchronization................................................................ 44
Figure 19. OBDII Connector, L319, L320, L322 2007 onwards, L359, L538, L405, L494...... 47
Figure 20. OBDII Connector L322 2002-2006........................................................................ 48
Figure 21. OBDII Connector L316 .......................................................................................... 48
Figure 22. App : Mobile App representation .......................................................................... 50
Figure 23. App : Representation of the integrated interface .................................................. 51
Figure 24. Cruise control commands...................................................................................... 52
Figure 25. Audio commands, L319-10.................................................................................... 53
Figure 26. PC interface representation................................................................................... 54
Figure 27. App : Activation ->tool selection........................................................................... 58
Figure 28. App : Activation when connected to the internet................................................... 59
Figure 29. App : Activation ->tool selection........................................................................... 60
Figure 30. App : Activation when connected to the internet................................................... 61
Figure 31. Steps to get an unlock code from the website....................................................... 63
Figure 32. Activation form....................................................................................................... 63
Figure 33. Unlock code shown on the website ....................................................................... 64
Figure 34. Pro, additional activation steps, 1......................................................................... 65
Figure 35. Pro, additional activation steps, 2......................................................................... 66
Figure 36. Additionallicenceeldonthewebsite................................................................... 67
Figure 37. App : mobile device connected to the internet. Steps for pre-unlocking the tool.. 68
Figure 38. App : Viewing permission example....................................................................... 70
Figure 39. App : Permissions, tool not activated.................................................................... 71
Figure 40. App : Permissions, tool activated and connected on an unlocked vehicle ........... 71
Figure list

13
IIDTool
12
Figure 41. App : Permissions, tool activated and connected on a vehicle not unlocked ....... 71
Figure 42. App : Faults by ECUs ........................................................................................... 82
Figure 43. App : Show All Faults............................................................................................ 82
Figure 44. Decoding example, status bits............................................................................... 90
Figure 45. App : Status bits.................................................................................................... 90
Figure 46. App : ECU list ....................................................................................................... 91
Figure 47. App : Advanced Read, bit selection...................................................................... 93
Figure 48. App : Height function layout.................................................................................. 97
Figure 49. App : Changing a height setting ........................................................................... 98
Figure 50. App : Current other height modes settings ........................................................... 99
Figure 51. App : Accessing other height modes .................................................................. 100
Figure 52. App : Editing other height modes ....................................................................... 101
Figure 53. Height Control...................................................................................................... 102
Figure 54. Wheel measuring................................................................................................. 107
Figure 55. Wheel measuring..................................................................................................110
Figure 56. App : Calibrations values.....................................................................................111
Figure 57. App : Guided Calibration steps............................................................................111
Figure 58. App : Test valve ...................................................................................................117
Figure 59. Regular IIDTool generation.................................................................................. 127
Figure 60. App : LV : Calling the top bar .............................................................................. 133
Figure 61. App : LV : Top bar options................................................................................... 133
Figure 62. App : LV : Graph options..................................................................................... 134
Figure 63. App : LV : Axis displayed .................................................................................... 135
Figure 64. App : LV : Y axis displacement ........................................................................... 136
Figure 65. App : LV : Vertical zooming................................................................................. 136
Figure 66. App : LV : Horizontal zooming ............................................................................ 137
Figure 67. App : LV : Return to the current time .................................................................. 137
Figure 68. App : LV : New Favorite ...................................................................................... 138
Figure 69. App : LV : Modify a Favorite list .......................................................................... 138
Figure 70. App : LV : Modify a live value name in a favorite list........................................... 139
Figure 71. App : LV : Favorite live values selection ............................................................. 139
Figure 72. App : LV : Favorite, Fast Add method. Adding a Live Value. .............................. 140
Figure 73. App : LV : Favorite, Fast Add method. Selecting the list..................................... 140
Figure 74. App : LV : Trigger, start stop ............................................................................... 141
Figure 75. App : LV : Trigger, event ..................................................................................... 141
Figure 76. App : LV : Erasing trigger settings ...................................................................... 141
Figure 77. App : LV : Start time............................................................................................ 142
Figure 78. App : LV : Stop time ............................................................................................ 142
Figure 79. App : LV : Target ................................................................................................. 142
Figure 80. App : LV : Trigger when increasing and exceeding the threshold....................... 142
Figure 81. App : LV : Trigger when decreasing and crossing the threshold......................... 142
Figure 82. App : LV : Trigger when the value and target are equal...................................... 142

14
IIDTool
Figure 83. App : LV : Trigger when the value and target are not equal................................ 142
Figure 84. App : LV : Trigger enabling ................................................................................. 142
Figure 85. App : LV : Buzzer usage example....................................................................... 143
Figure 86. App : LV : Start stop example ............................................................................. 143
Figure 87. App : LV : Event usage example......................................................................... 144
Figure 88. App : LV : Viewing and exporting logs ................................................................ 145
Figure 89. DL : Log sharing .................................................................................................. 146
Figure 90. DL : Log Sharing screen...................................................................................... 147
Figure 91. DL : Log Sharing screen...................................................................................... 147
Figure 92. DL : Viewing online logs ...................................................................................... 148
Figure 93. App : CCF : Modify a Favorite list....................................................................... 156
Figure 94. App :CCF:Modifyacongurationnameinafavoritelist.................................. 156
Figure 95. App:CCF:Denecongurationvaluesinafavoritelist ................................... 157
Figure 96. App:CCF:Favorite,FastAddmethod.Addingaconguration. ....................... 157
Figure 97. App : CCF : Favorite, Fast Add method. Selecting the list. ................................ 158
Figure 98. Regular IIDTool generations................................................................................ 163
Figure 99. IIDTool BT generations ........................................................................................ 164
Figure 100. BTandregular,updatingtheIIDToolwitha“Custom”rmware. ..................... 164
Figure 101. App:Backupcopyoftheoriginalrmware(engineECU) ............................... 165
Figure 102. UploadoftheengineECUoriginalrmware ..................................................... 165
Figure 103. BTandregular,updatingtheIIDToolwithaBASle,...................................... 166
Figure 104. Pro, BT,updatingtheIIDToolwithanadditionalBASle, ................................ 166
Figure 105. Battery fuse holder location............................................................................... 170
Figure 106. Fuses 15 and 16, Body Control ECU ................................................................ 170
Figure 107. Regular IIDTool generations.............................................................................. 173
Figure 108. IIDTool BT generations ...................................................................................... 177
Figure 109. BT :Navigation:updatingtheIIDToolrmwareto,“special”V3.01Build 2682, Nav
On Move................................................................................................................................. 177
Figure 110. Regular IIDTool generations .............................................................................. 178
Figure 111. Diagnostic mode, Navigation ............................................................................. 181
Figure 112. Enter pin code for diagnostic mode, Navigation ................................................ 181
Figure 113. Diagnostic menu, Navigation ............................................................................. 182
Figure 114. “ Show MMM Information ”, Navigation ............................................................. 182
Figure 115. “MainCPUSoftware/BootloaderVersion”,Navigation ..................................... 182
Figure 116. App: ECU Info results ....................................................................................... 185

15
IIDTool
14
Table 1. Functions categorized by Objectives ........................................................................ 19
Table 2. Functions categorized by Objectives (continuation) ................................................. 20
Table 3. Functionsclassication ............................................................................................. 20
Table 4. Access levels to IIDTool Functions (licence) ............................................................. 21
Table 5. Additional licence ...................................................................................................... 21
Table 6. Determining a vehicle Model Year using the VIN...................................................... 22
Table 7. Model-Referent code of supported vehicles ............................................................. 23
Table 8. Interfaces presentation.............................................................................................. 24
Table 9. Availability of Interfaces for each tool........................................................................ 27
Table 10. Characteristics of each Interface............................................................................. 28
Table 11. Compatible mobile devices ..................................................................................... 29
Table 12. Abstractofoperationstocompletebeforerstusage............................................. 35
Table 13. Troubleshooting, updater software.......................................................................... 42
Table 14. Tips to avoid battery drainage................................................................................. 46
Table 15. App : Legend of controls for the Integrated Interface replica ................................. 51
Table 16. Legend of controls for the Integrated Interface replica ........................................... 53
Table 17. Legend of controls for the PC-based interface ....................................................... 55
Table 18. Fault types, brief description ................................................................................... 74
Table 19. Directory of Functions ............................................................................................. 77
Table 20. Denitionsandexamplesoffunctionsusage.......................................................... 79
Table 21. Structure of Fault codes provided by the IIDTool .................................................... 84
Table 22. 2nd element interpretation ........................................................................................ 85
Table 23. HEX and Binary....................................................................................................... 88
Table 24. Interpretation of each “status bit” ........................................................................... 89
Table 25. Heightsub-functiondenitions................................................................................ 95
Table 26. EAS Internal limits................................................................................................... 95
Table 27. Example of current calibrations............................................................................... 95
Table 28. Possible adjustments for this example.................................................................... 96
Table 29. Required data, front left calibration ...................................................................... 108
Table 30. Required data, rear left calibration........................................................................ 108
Table 31. Calculus, new left side calibration value ............................................................... 108
Table 32. Required data, front right calibration .................................................................... 109
Table 33. Required data, rear right calibration...................................................................... 109
Table 34. Calculus, new left side calibration value ............................................................... 109
Table 35. Original standard height.........................................................................................112
Table 36. Denition,riskscale .............................................................................................. 161
Table 37. Risk, Engine Remaps, EGR blanking and the likes .............................................. 163
Table 38. Risk, fast lane service ........................................................................................... 168
Table 39. Risk, updating the suspension ECU...................................................................... 169
Table 40. Risk, updating the Body Control ECU................................................................... 170
Table list

16
IIDTool
Table 41. Risk, updating the Instrument Pack ECU.............................................................. 171
Table 42. Risk, updating the Bluetooth ECU......................................................................... 173
Table 43. Risk, updating the Navigation ECU....................................................................... 176
Table 44. Risk, updating the transfer case ECU................................................................... 183
Table 45. Risk, updating the Audio Control ECU .................................................................. 183
Table 46. Risk, updating the transmission ECU.................................................................... 183

17
IIDTool
GAP Diagnostic 2019-07-15 All Rights Reserved
User Manual : Version 33, Firmware V3.0
16
1 Introduction
1.1 IIDTool objectives
The IIDTool was designed to achieve four objectives in order to meet the demands of Land Rover
ownersforautonomyintheire󰀨orts.
• Diagnosemechanicalproblemsormalfunctionsresultingfromelectrical/electronicproblems
• Participateintherepairprocesstobemoree󰀩cientandtimely
• Customizecertainvehiclecomponents
• AdministerECUsofthevehicle,includingupdating
Note: The IIDTool is not a repair tool, but can help identify the cause of a problem. Achieving the
Objectives is done by using IIDTool functions (section 1.4 and section 4) in a dened sequence (see
section 3).
1.2 Description of each IIDTool models
IIDTool (regular)
Short for “Integrated Interface Diagnostic Tool”. A diagnostic tool using an integrated interface, soli-
citing vehicle components for display and control.
IIDTool BT
Diagnostic tool equipped with a Bluetooth Smart transceiver that can be used in conjunction with a
mobile device such as a tablet or smartphone. The integrated interface can also be used as needed.
IIDTool Pro
Diagnostic tool designed for professionals. Also equipped with the Bluetooth transceiver. The integra-
ted interface can also be used as needed.
Note : To lighten the text of this manual, the term IIDTool will be used to designate the IIDTool “regular”,
IIDTool BT and IIDTool Pro when no distinction apply.
The following diminutives are used in this document to separate items that are either related to
the integrated interface II or exclusive to IIDTool BT or IIDTool Pro.
II: The diminutive IIindicatesspecicfeaturesassociatedwithusageoftheintegratedinterface(all
tools).
BT : The diminutive BT indicatesspecicfeaturesassociatedwithusinganIIDTool BT.
Pro :The diminutive Pro indicatesspecicfeaturesassociatedwithusinganIIDTool Pro.
App : The diminutive App indicatesspecicfeaturesassociatedwithusageofthemobileApplication.

18
IIDTool
GAP Diagnostic 2019-07-15 All Rights Reserved
User Manual : Version 33, Firmware V3.0
Foradditionaldenitionsordescriptionsofabbreviationsusedinthismanual,refertotheGlossary
located at the end of this manual.
The complete list of products and selected distributors contact information are available on the manu-
facturer’s website www.gap-diagnostic.com
1.3 Connectors descriptions
Figure 1. Micro USB socket for USB cable used to connect the IIDTool to a computer
Figure 2. OBDII connector allowing connection of the IIDTool to a vehicle

18 19
IIDTool
GAP Diagnostic 2019-07-15 All Rights Reserved
User Manual : Version 33, Firmware V3.0
1.4 Brief descriptions of o󰀨ered Functions
ThethreeIIDToolmodelso󰀨erarangeoffunctionstoachievethefourmainobjectives,categorizedin
the following table.
Note : Functions denitions, examples and operating procedures are found in section 4 of this manual.
1.4.1 Functions categorized by Objectives
Diagnostic Personnalisation Repair process Administer ECU
Faults
Read/Clear
Advanced Read
Height : Height
modication,airsus-
pension
Calibrations ECU Information
Live values (surveil-
lance) CarConguration Service routines Save/Restore
ControlIO(Inputs/
Outputs)
ECU update (Re-
Flash)
Convenience
Height Control
Table 1. Functions categorized by Objectives
Note : Some functions can help achieve more than one goal; this is particularly the case for the “Fault”
function and “Re-Flash” after a repair. Please consult Diagnostic Keys (section 3) for details.

20
IIDTool
GAP Diagnostic 2019-07-15 All Rights Reserved
User Manual : Version 33, Firmware V3.0
Some functions refer to the IIDTool itself.
IIDTool settings
Version
IIDCong
Table 2. Functions categorized by Objectives (continuation)
1.4.2 Functions classication
Thefunctionsaredividedintotwoclasses.Thisdistinctiona󰀨ectstheaccesslevelofIIDToolfunctions.
Full diagnostic capability Advanced programming functions*
Reading and clearing fault codes Systems and components calibrations
Live values Height (air suspension)
Control IOs Changingcongurationsorparametersofthevehicle
(CCF)
Service routines Changing congurations or parameters of individual
ECUs (L322-02, L322-06 and L316)
Height control Key programming
ECU info ECU update, Re-Flash
Engine re-mapping, EGR (exhaust gas recirculation)
blanking,speedlimitmodicationandmore**
Save/Restore(suspensionandcongurations)
Table 3. Functionsclassication
*Advancedprogrammingfunctionsareonlyaccessibleoncethetoolisactivated(section 2.2 and sec-
tion 2.9).
**Sold separately by Bell Auto Services (BAS Remaps) and delivered by the IIDTool. Please visit http://
bellautoservices.co.uk/ for more details.
