Humzor NC601 User manual

HUMZOR technology adheres to the responsibility of quality
and is committed to providing users with high quality and high
performance products. Adhere to technology to create advantages,
committed to promoting industrial progress through innovation,
support enterprise development and achieve product upgrading.
Adhere to service highlights value, committed to continuous
improvement of service to meet customers' growing expectations.

Trademarks
HUMZOR®, NEXZSYS®, NEXZLINK®, NEXZSCAN®, and
NEXZSYS® are trademarks of Shenzhen Hanzhi Technology Co.,
Ltd., registered in China, the United States and other countries. All
other marks are trademarks or registered trademarks of their
respective holders.
Copyright Information
No part of this manual may be reproduced, stored in a retrieval
system or transmitted, in any form or by any means, electronic,
mechanical, photocopying, recording, or otherwise without the
prior written permission of HUMZOR.
Disclaimer of Warranties and Limitation of Liabilities
All information, specifications and illustrations in this manual are
based on the latest information available at the time of printing.
HUMZOR reserves the right to make changes at any time without
notice. While information of this manual has been carefully
checked for accuracy, no guarantee is given for the completeness
and correctness of the contents, including but not limited to the
product specifications, functions, and illustrations.
HUMZOR will not be liable for any direct, special, incidental,
indirect damages or any economic consequential damages
(including lost profits).
IMPORTANT
Before operating or maintaining this unit, please read this manual
carefully, paying extra attention to the safety warnings and
precautions.
For Services and Support
www.humzor.com/www.humzor.cn
[email protected]/[email protected]
For details, please refer to the Service Procedures in this manual.
Safety Information
For your own safety and the safety of others, and to prevent
damage to the device and vehicles upon which it is used, it is
important that the safety instructions presented throughout this
manual be read and understood by all persons operating or coming
into contact with the device.
There are various procedures, techniques, tools, and parts for
servicing vehicles, as well as in the skill of the person doing the
work. Because of the vast number of test applications and variations
in the products that can be tested with this equipment, we cannot
possibly anticipate or provide advice or safety messages to cover
every circumstance. It is the automotive technician's responsibility to
be knowledgeable of the system being tested. It is crucial to use
proper service methods and test procedures. It is essential to
perform tests in an appropriate and acceptable manner that does
not endanger your safety, the safety of others in the work area, the
device being used, or the vehicle being tested.
Before using the device, always refer to and follow the safety
messages and applicable test procedures provided by the
manufacturer of the vehicle or equipment being tested. Use the
device only as described in this manual. Read, understand, and
follow all safety messages and instructions in this manual.
Safety Messages
Safety messages are provided to help prevent personal injury and
equipment damage. All safety messages are introduced by a signal
word indicating the hazard level.
DANGER/WARNING
Indicates an imminently hazardous situation which, if not avoided,
will result in death or serious injury to the operator or to bystanders.
Safety Warning
Always perform automotive testing in a safe environment.
Wear safety eye protection that meets ANSI standards.
Keep clothing, hair, hands, tools, test equipment, etc. away from all
moving or hot engine parts.
Operate the vehicle in a well-ventilated work area, for exhaust
gases are poisonous.
Put the transmission in PARK (for automatic transmission) or
NEUTRAL (for manual transmission) and make sure the parking
brake is engaged.
Put blocks in front of the drive wheels and never leave the vehicle
unattended while testing.
Be extra cautious when working around the ignition coil,
distributor cap, ignition wires and spark plugs. These components
create hazardous voltages when the engine is running.
Keep a fire extinguisher suitable for gasoline, chemical, and
electrical fires nearby.
Do not connect or disconnect any test equipment while the
ignition is on or the engine is running.
Keep the test equipment dry, clean, free from oil, water or grease.
Use a mild detergent on a clean cloth to clean the outside of the
equipment as necessary.
Do not drive the vehicle and operate the test equipment at the
same time. Any distraction may cause an accident.
Refer to the service manual for the vehicle being serviced and
adhere to all diagnostic procedures and precautions. Failure to do
so may result in personal injury or damage to the test equipment.
To avoid damaging the test equipment or generating false data,
make sure the vehicle battery is fully charged and the connection
to the vehicle DLC is clean and secure.
Do not place the test equipment on the distributor of the vehicle.
Strong electromagnetic interference can damage the equipment.

Trademarks
HUMZOR®, NEXZSYS®, NEXZLINK®, NEXZSCAN®, and
NEXZSYS® are trademarks of Shenzhen Hanzhi Technology Co.,
Ltd., registered in China, the United States and other countries. All
other marks are trademarks or registered trademarks of their
respective holders.
Copyright Information
No part of this manual may be reproduced, stored in a retrieval
system or transmitted, in any form or by any means, electronic,
mechanical, photocopying, recording, or otherwise without the
prior written permission of HUMZOR.
Disclaimer of Warranties and Limitation of Liabilities
All information, specifications and illustrations in this manual are
based on the latest information available at the time of printing.
HUMZOR reserves the right to make changes at any time without
notice. While information of this manual has been carefully
checked for accuracy, no guarantee is given for the completeness
and correctness of the contents, including but not limited to the
product specifications, functions, and illustrations.
HUMZOR will not be liable for any direct, special, incidental,
indirect damages or any economic consequential damages
(including lost profits).
IMPORTANT
Before operating or maintaining this unit, please read this manual
carefully, paying extra attention to the safety warnings and
precautions.
For Services and Support
www.humzor.com/www.humzor.cn
[email protected]/[email protected]
For details, please refer to the Service Procedures in this manual.
Safety Information
For your own safety and the safety of others, and to prevent
damage to the device and vehicles upon which it is used, it is
important that the safety instructions presented throughout this
manual be read and understood by all persons operating or coming
into contact with the device.
There are various procedures, techniques, tools, and parts for
servicing vehicles, as well as in the skill of the person doing the
work. Because of the vast number of test applications and variations
in the products that can be tested with this equipment, we cannot
possibly anticipate or provide advice or safety messages to cover
every circumstance. It is the automotive technician's responsibility to
be knowledgeable of the system being tested. It is crucial to use
proper service methods and test procedures. It is essential to
perform tests in an appropriate and acceptable manner that does
not endanger your safety, the safety of others in the work area, the
device being used, or the vehicle being tested.
Before using the device, always refer to and follow the safety
messages and applicable test procedures provided by the
manufacturer of the vehicle or equipment being tested. Use the
device only as described in this manual. Read, understand, and
follow all safety messages and instructions in this manual.
Safety Messages
Safety messages are provided to help prevent personal injury and
equipment damage. All safety messages are introduced by a signal
word indicating the hazard level.
DANGER/WARNING
Indicates an imminently hazardous situation which, if not avoided,
will result in death or serious injury to the operator or to bystanders.
Safety Warning
Always perform automotive testing in a safe environment.
Wear safety eye protection that meets ANSI standards.
Keep clothing, hair, hands, tools, test equipment, etc. away from all
moving or hot engine parts.
Operate the vehicle in a well-ventilated work area, for exhaust
gases are poisonous.
Put the transmission in PARK (for automatic transmission) or
NEUTRAL (for manual transmission) and make sure the parking
brake is engaged.
Put blocks in front of the drive wheels and never leave the vehicle
unattended while testing.
Be extra cautious when working around the ignition coil,
distributor cap, ignition wires and spark plugs. These components
create hazardous voltages when the engine is running.
Keep a fire extinguisher suitable for gasoline, chemical, and
electrical fires nearby.
Do not connect or disconnect any test equipment while the
ignition is on or the engine is running.
Keep the test equipment dry, clean, free from oil, water or grease.
Use a mild detergent on a clean cloth to clean the outside of the
equipment as necessary.
Do not drive the vehicle and operate the test equipment at the
same time. Any distraction may cause an accident.
Refer to the service manual for the vehicle being serviced and
adhere to all diagnostic procedures and precautions. Failure to do
so may result in personal injury or damage to the test equipment.
To avoid damaging the test equipment or generating false data,
make sure the vehicle battery is fully charged and the connection
to the vehicle DLC is clean and secure.
Do not place the test equipment on the distributor of the vehicle.
Strong electromagnetic interference can damage the equipment.

Put the transmission in PARK (for automatic transmission) or
NEUTRAL (for manual transmission) and make sure the parking
brake is engaged.
Put blocks in front of the drive wheels and never leave the vehicle
unattended while testing.
Be extra cautious when working around the ignition coil,
distributor cap, ignition wires and spark plugs. These components
create hazardous voltages when the engine is running.
Keep a fire extinguisher suitable for gasoline, chemical, and
electrical fires nearby.
Do not connect or disconnect any test equipment while the
ignition is on or the engine is running.
Keep the test equipment dry, clean, free from oil, water or grease.
Use a mild detergent on a clean cloth to clean the outside of the
equipment as necessary.
Do not drive the vehicle and operate the test equipment at the
same time. Any distraction may cause an accident.
Refer to the service manual for the vehicle being serviced and
adhere to all diagnostic procedures and precautions. Failure to do
so may result in personal injury or damage to the test equipment.
To avoid damaging the test equipment or generating false data,
make sure the vehicle battery is fully charged and the connection
to the vehicle DLC is clean and secure.
Do not place the test equipment on the distributor of the vehicle.
Strong electromagnetic interference can damage the equipment.

CONTENTS
1. Product Instructions
1.1 Product Description
1.2 Specifications
1.3 Accessories Included
1.4 Keyboard
1.5 Power
2. OBD (On-Board Diagnostics) II Introduction
2.1 On-Board Diagnostics(OBD)II
2.2 Data Link Connector (DLC)
3. OBD-II Diagnosis 5
3.1 Read DTCs (Diagnostic Trouble Codes)
3.2 Clear DTCs
3.3 Live Data 11
3.4 Freeze Frame Data 12
3.5 I/M Readiness Monitors 14
3.6 MIL Status
3.7 Vehicle Information 15
3.8 Mode 6 16
3.9 Mode 8 17
3.10 Smog Check
3.11 Fuel Analysis
4. HD OBD Diagnosis
4.1 Read DTCs
4.2 Clear DTCs
4.3 Live Data
4.4 Vehicle Information
5. Battery Test
6. Look up
7. Review
7.1 Review DTC
7.2 Printing Data
8. Setting 23
8.1 Language Setup 24
8.2 Help Function 24
8.3 Unit of Measure 25
8.4 Beep Setting 25
8.5 Device Self-Test 25
8.5.1 Screen Test 26
8.5.2 LCD Test 26
8.5.3 Key Test 26
8.6 Vehicle Coverage 27
8.7 Protocol Coverage 28
8.8 Test Mode Coverage 28
8.9 Product Trouble shooting 29
9. Update and Warranty 30
9.1 Software Update 30
9.2 Limited Three Year Warranty 30
9.3 Service Procedures 31
3
3
2
2
2
2
1
3
4
7
8
14
17
18
18
18
19
19
21
21
22
22
22
23

1. Product Instructions
1.1 Product Description
1.2 Specifications
1.3 Accessories Included
1.4 Keyboard
1.5 Power
2. OBD (On-Board Diagnostics) II Introduction
2.1 On-Board Diagnostics(OBD)II
2.2 Data Link Connector (DLC)
3. OBD-II Diagnosis 5
3.1 Read DTCs (Diagnostic Trouble Codes)
3.2 Clear DTCs
3.3 Live Data 11
3.4 Freeze Frame Data 12
3.5 I/M Readiness Monitors 14
3.6 MIL Status
3.7 Vehicle Information 15
3.8 Mode 6 16
3.9 Mode 8 17
3.10 Smog Check
3.11 Fuel Analysis
4. HD OBD Diagnosis
4.1 Read DTCs
4.2 Clear DTCs
4.3 Live Data
4.4 Vehicle Information
5. Battery Test
6. Look up
7. Review
7.1 Review DTC
7.2 Printing Data
8. Setting 23
8.1 Language Setup 24
8.2 Help Function 24
8.3 Unit of Measure 25
8.4 Beep Setting 25
8.5 Device Self-Test 25
8.5.1 Screen Test 26
8.5.2 LCD Test 26
8.5.3 Key Test 26
8.6 Vehicle Coverage 27
8.7 Protocol Coverage 28
8.8 Test Mode Coverage 28
8.9 Product Trouble shooting 29
9. Update and Warranty 30
9.1 Software Update 30
9.2 Limited Three Year Warranty 30
9.3 Service Procedures 31

1. Product Instructions
1.1 Product Description
NC601 is easy to carry, simple to operate, fast in diagnosis, large
in memory, comprehensive in code base, powerful in
performance and novel in design. It is a new generation OBDII
diagnostic tool tailored for the owner. Data Live, Freeze Frame,
Read DTC, Clear DTC, O2 Sensor Test, On-board Test (Mode 6),
Smog Check, I/M Readiness, EVAP Test (Mode 8), Vehicle Info,
MIL Status, Battery Test, Fuel Analysis, Performance Data, Engine
Data, DTC Query, Data Review, Printer, Settings are fully covered.
1
2
34
5
8
9
6
7
Figure 1-1 Product Display
1

1. LCD Screen: Indicates test results.
2. ESC Button: Returns to the previous screen. Checks Data stream
after selecting specific data items.
3. F1 Button: F1 is the help function in the main screen, and the
back to the main screen in the diagnostic screen
4. F2 Button: One-key I/M Readiness operations.
5. Up Button: Moves up through menu and sub-menus. Moves to
previous screen if information covers more than one screen.
6. Down Button: Moves down through menu and sub-menus.
Moves to next screen if information covers more than one screen.
7. Left Button: Moves to previous screen if information covers more
than one screen.
8. Right Button: Moves to next screen if information covers more
than one screen.
9. OK Button: Conforms a selection from a menu.
1.2 Specifications
1.3 Accessories Included
1. User's Manual-- Instructions on tool operations.
2. OBDII cable (DLC) -- Data Link Connector or Diagnostic Link
Connector, provides power to tool and communication between
tool and vehicle.
3. USB cable -- Used to print retrieved data and update software.
4. Protective ABS Case--A ABS case to store the tool when not in
use.
1.4 Keyboard
Table 1-1 Hardware Information
Display Screen TFT Color (320*240)
0 to 60℃ (32 to 140℉)
-20 to 70℃ (-4to 158℉)
8V to 30V (power provided by vehicle battery)
Operating Temperature
Storage Temperature
Power
2

1.5 Power
The scan tool is powered via the vehicle Data Link Connector (DLC).
Just follow the steps below to turn on the scan tool:
1. Connect the OBD II Cable to scan tool.
2. Find DLC on vehicle.
3. Plug OBD II cable to the vehicle's DLC.
4. Power up the scan tool, and wait for the Main Screen to appear.
2. OBD (On-Board Diagnostics) II Introduction
2.1 On-Board Diagnostics(OBD)II
The first generation of On-Board Diagnostics (called OBD I) was
developed by the California Air Resources Board (ARB) and
implemented in 1988 to monitor some of the emission control
components on vehicles. As technology evolved and the desire to
improve the On-Board Diagnostic system increased, a new
generation of On-Board Diagnostic system was developed. This
second generation of On-Board Diagnostic regulations is called
"OBDII".
Figure 3
Figure 1-3 Main Screen Interface
3

The OBD II system is designed to monitor emission control systems
and key engine components by performing either continuous or
periodic tests of specific components and vehicle conditions. When
a problem is detected, the OBD II system turns on a warning lamp
(MIL) on the vehicle instrument panel to alert the driver typically by
the phrase of "Check Engine" or "Service Engine Soon". The system
will also store important information about the detected
malfunction so that a technician can accurately find and x the
problem. Here below follow three pieces of such valuable
information：
1. Whether the Malfunction Indicator Light (MIL)is commanded ‘on’
or ‘off’;
2. Which, if any, Diagnostic Trouble Codes (DTCs) are stored
3. Readiness Monitor status.
2.2 Data Link Connector (DLC)
The DLC (Data Link Connector or Diagnostic Link Connector) is the
standardized 16-cavity connector where diagnostic scan tools
Interface with the vehicle's on-board computer. The DLC is usually
located 12 inches from the center of the instrument panel (dash),
under or around the driver's side for most vehicles. If Data Link
Connector is not located under dashboard. a label should be there
telling location. For some Asian and European vehicles, the DLC is
located behind the ashtray and the ashtray must be removed to
access the connector. If the DLC cannot be found, refer to the
vehicle's service manual for the location.
4
