Garden Qg300elt User manual

300W Electric

Line Trimmer

Model No: QG300ELT

Product No: 1938289001

ASSEMBLY REQUIRED

SAVE THESE INSTRUCTIONS

Please read & understand this manual, paying attention to the safety instructions, before use.

Incorrect use of the product could put the operator or machine in danger.

Whilst every effort has been made to ensure the accuracy of information contained in this

manual, our policy of continuous improvement determines the right to make modifications

without prior warning.

Images used are for illustration purposes only.

INSTRUCTION MANUAL

Permission is granted to reproduce this publication for personal & educational use only.

Commercial copying, redistribution, hiring or lending is prohibited.

No part of this publication may be stored in a retrieval system or transmitted in any other form or means without written

permission from Handy Distribution.

In all cases this copyright notice must remain intact.

CONTENTS

SPECIFICATION

IMPORTANT INFORMATION

GENERAL SAFETY INSTRUCTIONS

KNOW YOUR MACHINE

ASSEMBLY

OPERATION

MAINTENANCE & STORAGE

TROUBLE SHOOTING

PARTS DIAGRAM & LIST

DECLARATION OF CONFORMITY

WARRANTY

SPECIFICATION

The manufacturer reserves the right to change the product specification and livery

according to continued product improvements.

Model

QG300ELT

Product Number

1938289001

Voltage

220-240V, 50Hz

Power

300W

Idle Speed

10000 min-1

Working Width

250 mm

Trimmer Line Diameter

1.2 mm

Guaranteed Noise Power Level (LWA)

96 dB(A)

Vibration (ahv)

2.63 m/s2- uncertainty K: 1.5 m/s2

Net Weight

2.6 kg

Consistent with our policy of continuous improvement, QGARDEN reserves the right to

change the design and configuration of any of its products without notice or obligation.

Therefore, please treat the text and images in this manual as being for illustrative purposes

only. They may in no case serve as a basis for any legal claim.

If you require assistance with regards to the contents or operation of the machine, please

Tel: 01793 333212

Email: customerservice@handydistribution.co.uk

Opening hours weekdays:

February to October 8:30am - 5:30pm

November to January 8:30am - 5:00pm

(Closed Bank Holidays)

IMPORTANT INFORMATION

WARNING

Read this instruction manual carefully before operating this machine. Make sure that you are

familiar with the controls and properly operate the machine. Following these instructions can

reduce the risk of fire, electric shock and personal injury.

IF NOT USED PROPERLY THIS MACHINE CAN BE DANGEROUS!

This machine can cause serious injury to the operator and others, the warning and safety

instructions must be followed to ensure reasonable safety and efficiency in using this product.

The operator is responsible for following the warning and safety instructions in this manual

and on the machine. Never use the product unless the grass box or guards are correctly

positioned.

DESIGNED FOR DOMESTIC USE ONLY.

This machine is to be used exclusively for cutting natural grass edges of domestic lawns and

gardens. Never use the line trimmer for other purposes. Any other use can endanger your

safety and can involve damage to the line trimmer. Persons under 16 years of age and

persons who are not familiar with the user instructions must not use the machine.

The user is responsible for the safety of other people in the working area. Keep children and

domestic animals at a safe distance while the line trimmer is in use.

Before using, remove all foreign objects from the lawn edges which may be thrown by the

machine, stay alert for any foreign objects which may have been missed.

These operating instructions must be kept and referred to in order to ensure that the

equipment is properly used and maintained. The instructions contain valuable information on

operating, maintenance and servicing conditions.

TRAINING

Read the instructions carefully: Be familiar with the controls and the proper use of the

equipment.

Never allow children or people unfamiliar with these instructions to use the product. Local

regulations can restrict the age of the operator.

Never operate while people, especially children, or pets are nearby.

Keep in mind that the operator or user is responsible for accidents or hazards involving the

machine that occur to other people or their property.

WARNING

The equipment is to be used only for its prescribed purpose. Any other use is deemed to be a

case of misuse.

The user/operator and not the manufacturer will be liable for any damage or injuries of any

kind caused as a result of this.

Please note that our equipment has not been designed for use in commercial, trade or

industrial applications.

Our warranty will be 90 days from the original date of sale for commercial, trade or industrial

businesses or for equivalent purposes.

GENERAL SAFETY INSTRUCTIONS

It is important that you read and understand the owner’s manual and labels affixed to the

machine. Learn its application and limitations as well as the specific potential hazards. Retain

these instructions for future reference. The operator is responsible for following the warnings &

instructions in this manual and on the product.

Read & understand operator’s

manual before using the

machine. Failure to follow

instructions could result in death

or serious injury.

Please keep in a safe place for

future reference.

Always wear eye

and ear protection

Keep all bystanders & animals

away from the machine during

operation. If approached, stop

the machine immediately.

SHARP ROTATING BLADES

Always wear gloves to protect your

hands.

Before working or undertaking

any servicing or cleaning of the

machine, ensure the electrical

cable is removed from the

power source.

Wear foot protection or sensible

shoes when using the machine

WARNING

Remove the plug from the

power source immediately if

the cable is damaged or cut.

Do not expose to rain or damp

conditions.

Keep guards in place and in

working order. Replace

damaged, missing or failed

parts before using it.

Moving Parts

Rotating parts can contact or

entangle hands, feet, hair, clothing

or accessories.

Traumatic amputation or severe

laceration can result

Class II Protection

Safety alert symbol. Used to alert you

to potential personal injury hazards.

Obey all safety messages that follow

this symbol to avoid possible injury.

DANGER

Indicates an imminently

hazardous situation which, if not

avoided, will result in serious

injury

WARNING

Indicates a potentially hazardous

situation which, if not avoided,

could result in serious injury

CAUTION

Indicates a potentially

hazardous situation which, if not

avoided, may result in minor or

moderate injury.

CAUTION

Used without the safety alert symbol

indicates a potentially hazardous

situation which, if not avoided, may

result in property damage.

CE Marking - the product meets

demand and regulations set by

the EU

Noise Level - See label on machine

According to the European directive 2012/19/EU for Waste Electrical and Electronic

Equipment and its implementation into national law, electrical and electronic

equipment that are no longer usable must be collected separately and disposed of in

an environmentally correct manner.

GENERAL SAFETY RULES

Before you put the machine into operation, you must read this instruction manual.

When using this machine, observe the following safety instructions to exclude the risk of

personal injury or material damage. Please also observe the special safety instructions in the

respective chapters. Where applicable, follow the legal directives or regulations for the

prevention of accidents in relation to the use of this machine.

WARNING

When using electric tools, basic safety precautions, should always be followed to reduce the

risk of serious personal injury and/or damage to the unit.

DANGER

Danger from contact with live parts!

Immediately disconnect the plug from the mains if the extension lead is damaged or

severed!

TRAINING

The operator must receive proper training in the use, adjustment and operation of the

machine, including prohibited operations.

1. Read the instructions carefully. Be familiar with the controls & proper use of the

equipment. Spend time to familiarise yourself with your machine before each use.

2. Never allow children or people unfamiliar with these instructions to use the machine.

Local regulations can restrict the operator age.

3. This machine is not intended for use by persons (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction concerning use of the machine by a

person responsible for their safety.

4. Never work while people, especially children, or pets are nearby.

5. The operator or user is responsible for accidents or hazards occurring to other people or

their property.

ELECTRIC SAFETY

1. The domestic mains voltage must match the mains voltage specifications in the technical

data; do not use any other supply voltage.

2. The fuse must be a residual current circuit- breaker with a measured residual current of no

more than 30 mA.

3. Ensure any extension leads used with this product, meets the minimum requirements of

the machine and is suitable for outside use.

4. Damaged or brittle machine cables or extension leads must not be used.

5. Always check the condition of your cable or extension lead before operating the

machine.

6. Always keep cable & extension lead out of the cutting area and routed away from the

machine.

7. Never run over the cable or extension lead with the line trimmer.

8. Protect the machine against moisture.

SAFETY INSTRUCTIONS FOR WORKING WITH YOUR LINE TRIMMER

1. Operate in daylight or good artificial lighting. If possible, do not use on overly wet ground.

2. Ensure good stability on slopes. Always operate across the slope, never up and down.

3. Be particularly careful if changing direction of travel on the slope.

4. Do not operate on steep slopes.

5. Operate whilst walking, do not run.

6. Be particularly careful when you turn or when you pull the machine towards you.

7. Stop the motor and blade, if it is to travel across other areas or must be transferred

to/from working area.

8. Never use the machine with damaged safety protection guards.

9. Do not change the motor regulation set up.

10. Carefully start the motor. Keep your feet clear of the blade.

11. Never reach behind or under the rotating parts with hands or feet.

12. Never lift or carry the machine other than when in operation mode, while the motor is on.

13. Switch the motor off and remove electrical plug from the power source, before

unblocking or removing obstacles from the blade or guard:

−Before releasing blockages, inspecting, cleaning or working on the machine.

−After hitting an obstruction. Search for damage on the machine & make repairs as

necessary. If the machine starts vibrating unusually, it should be inspected by an

Approved Service Dealer.

WORK AREA

1. Keep work area clean and well lit. Cluttered and dark areas invite accidents.

2. Check the landscape where the machine will be used and remove all objects such as

stones, toys, sticks and wires, which could be caught and thrown away from the work

area. Damage of the machine or operator’s injury could be caused.

3. Do not operate this machine in explosive atmospheres, in the presence of flammable

liquids, gases or dust. Machines create sparks which may ignite the dust or fumes.

4. Keep children & bystanders away while operating the machine. Distractions can cause

you to lose control.

PERSONAL SAFETY

1. This machine is not intended for use by persons (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction concerning use of the machine by a

person responsible for their safety.

2. Children should be supervised to ensure that they do not use or play with the machine.

3. Stay alert, watch what you are doing, use common sense when operating the machine.

4. Do not use this machine while you are tired, ill or under the influence of drugs, alcohol, or

medication. A moment of inattention while operating this machine can cause you to lose

control & may result in series personal injury.

5. Do not overreach. Always keep proper footing and balance. This enables better control

of the tool in unexpected situations.

6. Remove any adjusting tools before turning the machine on. A tool that is left attached to

a rotating part of the machine may result in personal injury.

7. Use safety equipment. Always wear eye protection. Safety equipment such as a dust

mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate

condition will reduce personal injuries.

8. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing & gloves

away from moving parts. Loose clothes, jewellery or long hair can be caught in moving

parts. Wear foot protection or sensible shoes when using the machine.

9. Prolonged use of the machine may lead to disorders of blood circulation in hands

caused by vibration. These effects can be worsened by low ambient temperatures

and/or by gripping the handgrips excessively tightly. Period of use you can extend with

appropriate gloves or regular breaks. Take frequent work breaks. Limit the amount of

exposure per day.

10. Do not force the machine. Use the correct machine for your application. The correct

machine will do the job better and safer at the rate for which it was designed.

11. Do not use the machine if the trigger levers do not work to turn the machine off. Any

machine that cannot be controlled with the trigger levers is dangerous and must be

repaired.

1. Turn machine off completely and the electrical plug removed from the power source

before making any adjustments, changing accessories, or storing. Such preventive safety

measures reduce the risks of starting the machine accidentally.

2. Store idle machines out of the reach of children and do not allow persons unfamiliar with

the machine or these instructions to operate. Electric machines are dangerous in the

hands of untrained users.

3. Maintain your machine. Check for misalignment or binding of moving parts, breakage of

parts & any other condition that may affect the operation. If damaged, have the

machine repaired by an Approved Service Dealer immediately. Many accidents are

caused by poorly maintained machines.

4. Use the machine, accessories and tool bits etc., in accordance with these instructions

and in the manner intended for the particular type of electric machine, taking into

account the working conditions and the work to be performed. Use of the machine for

operations different from intended could result in a hazardous situation.

PERSON PROTECTION

1. In case of any injury, always proceed in accordance with the principles of first aid.

2. If someone is cut, cover the wound with a clean cloth & press hard to stop the flow of

blood.

3. Individuals with poor circulation who are exposed to excessive vibration may experience

injury to blood vessels or the nervous system. Vibration may cause the following symptoms

to occur in the fingers, hands or wrists: numbness, tingling, pain, stabbing sensation,

alteration of skin colour or of the skin. If any of these symptoms occur, see a doctor.

Put safety first in the case of fire:

4. If fire comes from the motor appears, at first distance yourself from the product to ensure

your physical safety.

5. Use a dry powder fire extinguisher on the fire to prevent it from spreading.

6. A panicked reaction could result in the fire and other damage becoming more

extensive.

KNOW YOUR MACHINE

1. On / Off Trigger

2. Main Handle

3. Cable Restraint

4. Safety Guard

5. Nylon Head, Spool & Cover

6. Cutting Knife

7. Motor Head

8. Front Handle

9. Adjustment Knob

ASSEMBLY

WARNING

Stop the motor and unplug the electrical cable before any repairs or maintenance

operations.

DO NOT attempt to start this machine without it first being FULLY assembled.

Your line trimmer has been supplied unassembled. Please follow the below steps to complete

assembly.

Unassembled

MAIN SHAFT

Align the upper handle with the lower shaft and push both sections together. You will hear an

audible click.

Secure the two sections by tightening the middle collar in a clockwise direction.

Assembled

FRONT HANDLE

Slide the front handle onto the upper shaft.

Slide the front handle fixing bolt through the handle and shaft.

Secure with the handle adjustment bolt, rotating clockwise.

PROTECTIVE GUARD

Slide the protective guard onto the machine. Secure over the front tab and fixing screw,

securing the guard to the motor head section. Remove the cutting knife protective cover.

CAUTION

Risk of injury!

On the underside of the protective guard there is a sharp blade designed to cut the nylon

line. Remove the transportation protection before operating.

OPERATION

DANGER

Risk of injury! The device may only be put into operation if there are no defects. If a part is

defective it must be replaced before the device is used again.

WARNING

Risk of injury! Before starting work, check the area & remove all objects which may be kicked

up by the unit.

CORRECT OPERATING POSITION

Hold the unit with the left hand on the front handle, and the right hand at approximately hip

level on the operating handle, balanced in a comfortable way. See image below:

To adjust the height of the front handle, loosen the adjustment knob and adjust to the

desired operating height, then tighten adjustment knob.

TRIM OR EDGE

Your machine can be used as an edger or trimmer.

Loosen the knob located at the mid-section of the machine and rotate the lower section to

become a trimmer or edger.

Handle Adjustment Knob

Head Adjustment Knob

CABLE RESTRAINT

Feed a loop of the electrical cable through the hole in the casing and onto the strain relief

hook (3) as shown with a loop. Pull it tight to ensure it is secure.

SWITCHING ON AND OFF

Switching on: Pull the On / Off trigger upwards (1).

Switching off: Release the On / Off trigger (1).

LENGTHENING THE NYLON LINE

When the unit no longer cuts cleanly, the nylon line has become too short.

The best cutting results are obtained when the nylon line is lengthened far enough to be cut

by the cutting knife/blade to the correct length.

LENGTHENING THE NYLON LINE IN OPERATION:

Briefly tap the underside of the spool on the ground when the machine is running. If the nylon

line is still not long enough, tap it on the ground again.

The nylon line will automatically be cut to the correct length by the cutting knife/blade

located on the guard.

LENGTHENING THE NYLON LINE BY HAND:

WARNING

When performing work on the spool, always unplug from the power source!

If the nylon line is too short and cannot be lengthened by tapping. They must be pulled from

the spool by hand.

1. Place the unit on the floor.

2. Using one hand, press the underside of the spool and pull both nylon lines out until they

reach slightly further than the edge of the guard. The nylon line will be cut to the correct

length by the blade next time the unit is used.

TRIMMING INSTRUCTIONS

Only cut with the left (shown here as light grey) area of the cutting unit when the unit is being

moved from right to left.

In the right (dark grey) area, the threads rotate in your direction.

This represents a high level of kickback risk and objects may be thrown in your direction by

the rotation of the thread. You may be hurt as a result.

When the unit is moved from left to right, ensure that the nylon line is kept away from the

grass to ensure that the grass is not thrown up.

Cut long grass from top to bottom to ensure grass does not get tangled around the spool.

Use tip of the nylon line. This uses less nylon line & avoids grass getting caught up in the spool.

Only take the nylon line as close as absolutely necessary to posts, walls, fences etc. Solid

objects will wear the nylon line.

Tree trunks, young trees and bushes may be damaged by the nylon line.

1. Walk, never run with the machine, be very careful when trimming uneven/rough ground.

2. Be careful when changing the direction of the trimmer on a slope. Trim across the face of

slopes, never down or up.

3. Do not trim excessively steep slopes.

4. Best results will be achieved if the grass is dry. Wet grass will clog the spool and rotation of

the head.

5. To prevent grass becoming entangled around the spool, cut longer grass in stages.

6. Check that all nuts, bolts and screws are well tightened.

7. When line trimming, always wear a long trousers and strong footwear.

8. Work only when there is enough light.

9. Turn off the motor and remove the electrical plug from the power source, if you must

leave the line trimmer unattended.

10. Never place your hands and feet underneath the guard while the motor is running.

11. Never change in any way the rated speed of the motor.

12. Never lift or carry the line trimmer above working height, while the motor is running.

13. Stop the motor and remove the electrical cable from the power source in these cases:

-Before any operation under the guard.

-Before any maintenance, repairing or checking operations.

-Before carrying, lifting or removing the line trimmer.

-If you leave the line trimmer unattended or changing the cutting height.

-After hitting a foreign object, stop the line trimmer and check thoroughly the

machine in order to see if it is damaged. Take the machine to a local Approved

Service Dealer for inspection if necessary. Repairs of this nature are not covered

under the Manufacturer’s warranty.

-If the line trimmer vibrates in an abnormal way, find the reasons why, and take your

line trimmer to a local Approved Service Dealer.

WARNING

After the motor has stopped, the nylon line will still rotate a couple of seconds.

CAUTION

Allowing anyone to operate this machine without proper instruction may result in injury.

Wear sturdy, full coverage footwear. Operating this machine with bare feet, or with open toe

shoes or sandals increases your risk of injury.

Do not use the machine at night or in poor light.

Be sure to transport the machine from one place to another with the motor off.

To prevent damage, check the machine for any signs of damage or other faults when

operated.

MAINTENANCE & STORAGE

WARNING

Improper maintenance & storage of the machine may void your warranty.

Keep the machine clean for better and safer performance.

Turn off the motor and remove the electrical plug from the power source before performing

any maintenance.

MAINTENANCE

Use only original equipment replacement parts. Other parts may not perform as well, may

damage the unit and may result in injury. In addition, use of other parts may invalidate your

warranty.

•Before each use, check all nuts & bolts to be sure they are sufficiently tightened.

•We recommend only manufacturer original parts are used when maintaining this

machine. Failure to do so could invalidate your manufacturer’s warranty.

•The motor must be switched off and the electrical plug removed from the power source,

before the machine is unassembled, cleaned, serviced or maintained.

CLEANING

CAUTION

Do not use a water hose or pressure washer to clean the machine. Water can damage the

motor.

•Keep your machine clean. Thoroughly clean the machine at the end of each use.

•Clean the motor air vents with a cloth or brush. Motor air vents should be free from debris

to allow air circulation around the motor during use.

•Clean the underside of the guard with a stiff brush, before any maintenance is

undertaken to the spool.

STORAGE & TRANSPORT

The following steps should be taken to prepare your machine for storage.

STORING THE LINE TRIMMER

•Always unplug the machine from the mains for storage.

•For trouble free service, make sure the machine is clean and dry before storing.

•Please ensure the machine is stored away from direct sunlight.

•Store indoors or in a safe, locked protected area during severe weather and winter

months.

•If storing for an extended period, inspect, clean and repair the machine if necessary.

Store in a clean, dry, dust free area.

•Ensure the machine is stored in a position, where any persons cannot step on to attempt

to reach items up high, due to risk of movement.

TRANSPORT

•Always unplug the machine from the mains for storage.

•Use the original packaging to ship whenever possible.

TROUBLE SHOOTING

WARNING

Only perform the steps described in these instructions!

All further inspection, maintenance and repair work must be performed by an authorised

service specialist!

Contact your local authorised service dealer if the problem cannot be solved by yourself!

WARNING

If the product does not perform properly, makes unusual sounds, the motor does not start or

stop as described, the cutting device does not work properly, or any other irregularity or

malfunction occurs, do not attempt to repair the product by yourself.

PROBLEM

POSSIBLE CAUSES

REMEDIAL ACTION

Motor does not start

No power supply

Check fuse / extension lead.

Machine cable defective

Contact Approved Service Dealer.

Blade jammed

Clean exit chute: the blade must rotate

freely. Start on low grass or on the

section of lawn that has already been

mown; correct the cutting height.

Loss of motor

performance

Too much grass around

spool

Clean spool: the head must rotate

freely.

Cut longer grass in stages to prevent

grass from becoming tangled around

the spool.

Nylon line doesn’t

unwind

Nylon Line used up

Replace the spool

Spool blocked

Remove the cause of the blockage.

PARTS DIAGRAM & LIST

Item

No.

Part No.

Description

Qty

Item

No.

Part No.

Description

Qty

QG133-303-

7A22001

Right Lower

Body

QG133-120-

7A60201

Brush Holder

QG133-131-

ABBD40-1601

Screw M4x16

QG133-131-

NBCD30-0801

Screw M3x8

QG133-297-

7A22001

Right Upper

Body

QG133-118-

7A70101

Carbon Brush

QG133-131-

FDDD06-4501R

Screw M6x45

QG133-173-

7A22002

Connect Wire

QG133-171-

7A22001

Cable (BS

Plug)

QG133-3369-

A00060701R

Bearing 607

QG133-131-

FDDD06-7501R

Screw M6x75

QG133-115-

7A22101

Rotor

Assembly

QG133-196-

7C10301

Cable Shealth

QG133-3369-

A00060802R

Bearing 608

QG133-131-

ABBD40-1201

Screw M4x12

QG133-117-

7A22101

Stator

Assembly

QG133-220-

7J11001

Cover Plate

QG133-268-

7A20501

Rubber Plate

For Stator

QG133-139-

7J12602

Switch

QG133-287-

7A20201

Bracket For

Stator

QG133-344-

7A22101

Trigger Spring

QG133-131-

ABAD40-5001

Screw M4x50

QG133-293-

7A22101

Trigger

QG133-129-

7A20201

Washer

QG133-141-

7A22001

Capacitor

QG133-116-

7A20201

Fan

QG133-131-

ABBD40-1601

Screw M4x16

QG133-3132-

A0602R

Nut M6

QG133-220-

7J11001

Cover Plate

QG133-129-

7A20202

Rubber Ring

QG133-173-

7A22001

Wire

QG133-344-

7A20202

Spring

QG133-131-

ABBD40-1601

Screw M4x16

QG133-356-

7A20201

Spool

QG133-220-

7J11001

Cover Plate

QG133-175-

7A20201

1.2 Nylon Line

QG133-297-

7A22002

Left Upper

Body

QG133-287-

7A20202

Spool Cover

QG133-299-

7A22101

Front Handle

QG133-3133-

B050501R

Eyelet

QG133-295-

7A22101

Adjuster Knob

& M6 Nut

QG133-317-

7A22101

Guard

QG133-295-

7A22101

Adjuster Knob

& M6 Nut

QG133-131-

ABGD40-1601R

Screw M4x16

QG133-303-

7A22002

Left Lower

Body

QG133-183-

8A20101

Cutting Knife

QG133-287-

7A60201

Motor Dust

Cover

QG133-131-

ABBD40-1401

Screw M4x14

For pricing and availability, please contact our Spares Team on 01793 333212, option 1 for

assistance.

Every effort is made to have parts available, depending on demand and cost effectiveness of

producing, stocking and supplying individual components. Therefore, we reserve the right to supply

certain parts as a complete assembly only.

EC DECLARATION OF CONFORMITY

We Handy Distribution Ltd - SN3 5HY (Importer) declare that the product:

Designation: Electric 300W Line Trimmer

Model(s): QG300ELT

Product Number: 1938289001

Type/Serial No. As per rating label on machine

Motor Power: 300W

Voltage: 220-240V, 50Hz

Electrical Safety Class: Class II

Complies with the following directives:

2006/42/EC –Machinery Directive

2014/30/EU - Electromagnetic Compatibility Directive

2000/14/EC & 2005/88/EC - Outdoor Noise Directive

The conformity assessment procedure followed was in accordance with

EN 60335-1:2012/A13:2017, EN 50636-2-91:2014, EN 62233:2008

EN 55014-1:2017, EN 55014-2:2015, EN 61000-3-2:2014, EN 61000-3-3:2013

Guaranteed Sound Power Level:

(LWA) 96 dB(A)

Emission Sound Pressure Level:

(LPA) 84.2 dB(A) - uncertainty K: 3 dB(A)

Vibration Measurement according to EN50636 Annex BB:

2.63 m/s2- uncertainty K: 1.5 m/s2

Notified Bodies:

TÜV Product Service GmbH

Address(es):

Certification Body, Ridlerstraße 65, 80339 Munich, Germany

Authorised signatory & technical file holder

Date:

16/11/2020

Signature:

Name:

Mr Simon Belcher

Position:

Chairman

Company:

Handy Distribution Ltd

Address:

Murdock Rd, Dorcan, Swindon, Wiltshire, SN3 5HY.

GJ HANDY & CO LTD USER WARRANTY POLICY

Users Statement of Warranty

Each new machine is warranted against defective material or assembly of material under

normal usage. The warranty applies to the original purchaser and covers faulty parts and the

labour involved in replacing and repairing those parts, which are of original manufacture.

Period of Warranty

The Handy (Petrol & Electric only), Webb (excludes Dynamic, Heritage, Legacy), Sanli Engine

a) 2 years from the original date of sale to the first domestic user.

b) 90 days from the original date of sale to the professional/commercial user.

c) 90 days from the original date of sale when used for hire.

d) A reduced warranty period of 90 days applies to those items which are subject to normal

wear and tear (e.g. but not limited to wheels, tyres, cutter bars, cylinders, cutting blades,

blade boss, belts, cables, nylon line & spool, collection bags, spark plugs).

e) Engines are supplied with a separate warranty to the machine. The engine

manufacturers warranty statement which will be supplied within the engine instruction

manual. All enquiries and warranty repairs should be discussed with the engine

manufacturer or approved warranty repair dealer.

f) 90 days from the original date of purchase for Replacement Spare Parts (unless normal

wear & tear component, which are covered for 30 days).

g) All machines’ must be serviced within the first 12 months from the original date of

purchase to comply with the warranty (if applicable), failure to do so will invalidate the

2nd year of the warranty.

Webb Dynamic, Heritage & Legacy, Handy (All non-Petrol & Electric), Mowerland,

Q-Garden

a) 1 year from the original date of sale to the first domestic user.
