Gardenpro POWERPLUS POWXG2040 User manual

POWXG2040 EN
Copyright © 2012 VARO P a g e | 1 www.varo.com
1 APPLICATION..................................................................................2
2 DESCRIPTION .................................................................................2
3 PACKAGE CONTENT LIST.............................................................2
4 SYMBOLS........................................................................................2
5 GENERAL POWER TOOL SAFETY WARNINGS ..........................3
5.1 Work area ................................................................................................................3
5.2 Electrical safety.......................................................................................................3
5.3 Personal safety .......................................................................................................4
5.4 Power tool use and care.........................................................................................4
5.5 Service.....................................................................................................................4
6 ADDITIONAL SAFETY INSTRUCTIONS ........................................5
7 OPERATION.....................................................................................5
7.1 Assemble the cutting head to the unit...................................................................5
7.2 Adjust the cutting length........................................................................................5
7.3 Adjust the cutting angle .........................................................................................5
7.4 Starting and stopping the machine........................................................................5
8 CUTTING TIPS.................................................................................6
9 CLEANING AND MAINTENANCE...................................................6
10 TECHNICAL DATA..........................................................................6
11 SOUND EMISSION ..........................................................................6
12 TROUBLESHOOTING .....................................................................7
13 WARRANTY.....................................................................................7
14 ENVIRONMENT ...............................................................................8
15 DECLARATION OF CONFORMITY ................................................8

POWXG2040 EN
Copyright © 2012 VARO P a g e | 2 www.varo.com
TELESCOPIC HEDGE TRIMMER 800W 480MM
POWXG2040
1 APPLICATION
The hedge trimmer should only be used for trimming hedges, bushes and shrubs. Other use of
the trimmer, not included in this manual, could damage the trimmer or seriously injure the
operator and is therefore expressively excluded from the application range.
WARNING! Read this manual and general safety instructions carefully
before using the appliance, for your own safety. Your power tool should
only be passed on together with these instructions.
2 DESCRIPTION
1. Motor
2. Screw hole
3. Blade
4. Rotating know
5. Connection part
6. Shaft
7. Coupler
8. Coupler knob
9. Auxiliary handle
10. Locking auxiliary handle
11. Safety button
12. On/off switch
13. Rotating knob
14. Cable
15. Safety blade cover
16. Carrying belt
3 PACKAGE CONTENT LIST
Remove all packing materials
Remove remaining packaging and transit supports (if existing)
Check the completeness of the packing content
Check the appliance, the power cord, the power plug and all accessories for transportation
damages.
Keep the packaging materials as far as possible till the end of the warranty period. Dispose
it into your local waste disposal system afterwards.
WARNING Packing materials are no toys! Children must not play with
plastic bags! Danger of suffocation!
Telescopic Hedge trimmer
Safety blade cover Carrying belt Manual
When parts are missing or damaged, please contact your dealer.
4 SYMBOLS
In this manual and/or on the machine the following symbols are used:
Denotes risk of personal injury or damage to the tool.
Read instructions carefully
Wear safety glasses and ear protection

POWXG2040 EN
Copyright © 2012 VARO P a g e | 3 www.varo.com
Never operate the machine in the rain or in damp or wet condition. Moisture
is a shock hazard.
Don’t use the trimmer in any position that causes any part to come within 10m
of overhead electrical line
Keep hands away from blades, Don’t touch the blades when starting or while
operating the unit.
Remove the plug from the mains
Class II - The machine is double insulated; Earthing wire is therefore not
necessary.
5 GENERAL POWER TOOL SAFETY WARNINGS
Read all safety warnings and all instructions. Failure to follow all warnings
and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference. The term "power
tool" in the warnings refers to your mains operated (corded) power tool or
battery operated (cordless) power tool .
5.1 Work area
Keep work area clean and well lit. Cluttered and dark areas invite accidents.
Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or
fumes.
Keep children and bystanders away while operating a power tool. Distractions can cause
you to lose control.
5.2 Electrical safety
Always check that the power supply corresponds to the voltage on the rating plate.
Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets
will reduce risk of electric shock.
Avoid body contact with earthed or grounded surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or
grounded.
Do not expose power tools to rain or wet conditions. Water entering a power tool will
increase the risk of electric shock.
Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use
of a cord suitable for outdoor use reduces the risk of electric shock.
If operating a power tool in a damp location is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces the risk of electric shock.

POWXG2040 EN
Copyright © 2012 VARO P a g e | 4 www.varo.com
5.3 Personal safety
Stay alert, watch what you are doing and use common sense when operating a power tool.
Do not use a power tool while you are tired or under the influence of drugs, alcohol or
medication. A moment of inattention while operating power tools may result in serious
personal injury.
Use safety equipment. Always wear eye protection. Safety equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing protection used whenever conditions require will
reduce personal injuries.
Avoid accidental starting. Ensure the switch is in the off position before plugging in.
Carrying power tools with your finger on the switch or plugging in power tools that have the
switch on invites accidents.
Remove any adjusting key or wrench before turning the power tool on. A wrench or a key
left attached to a rotating part of the power tool may result in personal injury.
Do not overreach. Keep proper footing and balance at all times. This enables better control
of the power tool in unexpected situations.
Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewellery or long hair can be caught in moving
parts.
If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of these devices can reduce dust related
hazards.
5.4 Power tool use and care
Do not force the power tool. Use the correct power tool for your application. The correct
power tool will do the job better and safer at the rate for which it was designed.
Do not use the power tool if the switch does not turn it on and off. Any power tool that
cannot be controlled with the switch is dangerous and must be repaired.
Disconnect the plug from the power source before making any adjustments, changing
accessories, or storing power tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
Store idle power tools out of the reach of children and do not allow persons unfamiliar with
the power tool or these instructions to operate the power tool. Power tools are dangerous in
the hands of untrained users.
Maintain power tools. Check for misalignment or sticking of moving parts, breakage of parts
and any other condition that may affect the power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents are caused by poorly maintained power
tools.
Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting
edges are less likely to stick and are easier to control.
Use the power tool, accessories and tool bits etc., in accordance with these instructions and
in the manner intended for the particular type of power tool, taking into account the working
conditions and the work to be performed. Use of the power tool for operations different from
intended could lead to a hazardous situation.
5.5 Service
Have your power tool serviced by a qualified person using only identical replacement parts.
This will ensure that the safety of the power tool is maintained.

POWXG2040 EN
Copyright © 2012 VARO P a g e | 5 www.varo.com
6 ADDITIONAL SAFETY INSTRUCTIONS
Do not use the trimmer in the rain.
If the cord is cut or damaged remove it immediately from the power point.
Keep hands and fingers well away from the blade.
Wear work gloves, eye protection, solid shoes and trousers when using this hedge trimmer.
Always grasp both handles when operating the unit.
Disconnect the trimmer from the mains supply when you have finished work, before
cleaning or if you have been interrupted.
This trimmer has been designed to cut soft, new growth and should not be used on
branches, hard wood or other forms of cutting.
Do not attempt to free a jammed blade before first switching off the machine and
disconnecting it from the mains supply
If you are interrupted when operating the trimmer, complete the process and switch off
before looking up.
Never allow untrained users or children to use the trimmer.
7 OPERATION
7.1 Assemble the cutting head to the unit.
The cutting head is supplied lonely, you must assemble it correctly before you use the unit.
Remove the plug from the power supply, and release the trigger.
Align the cutting head to the support housing and then rotate it by clockwise until it is
locked.
Align the hole in the support housing with the screw on the cutting head.
Tighten the screw securely by screwdriver. And then rotating the handle to the comfortable
position by press the locking knob.
Always ensure the front handle is fitted to the shaft whenever you operate
this tool!
7.2 Adjust the cutting length
Lift the knob (8) on the coupler.
Pull the lower shaft till it in a comfortable position.
Tighten the knob securely.
If the button does not release completely in the positioning hole, the shafts
are not locked into place. Slightly rotate from side to side until the button is
locked into place.
Be certain the knob is fully tightened before operating equipmentl check it
periodically for tightness during use to avoid serious personal injury.
7.3 Adjust the cutting angle
Press the rotating knob.
Adjusting the cutting head to a comfortable position.
Release the knob.
7.4 Starting and stopping the machine
To start the tool: press the safety button (11) and then press the trigger (12). Release the
safety button once the motor has started.

POWXG2040 EN
Copyright © 2012 VARO P a g e | 6 www.varo.com
To stop the trimmer: Release the trigger.
Do not connect to power supply until assembly is complete, Failure to
comply could result in accidental starting and possible serious personal
injury.
8 CUTTING TIPS
Assume a secure position, using two hands to hold the trimmer and switch on.
Trim both sides of the hedge, starting at the bottom. This prevents cuttings falling into the
area yet to be cut.
Pass the blade lightly through the surface of the hedge. Do not attempt to cut too deep.
Trim the top of the hedge.
For older hedges that require cutting back substantially, use pruning shears to cut the
thicker branches and then finish the job with the hedge trimmer.
Never use the hedge trimmer without check the tightness of the bracket.
9 CLEANING AND MAINTENANCE
Warning! Before performing any work on the equipment, pull the power
plug.
Check your machine regularly before starting the work.
Damaged cutting blades have to be repaired or exchanged by a qualified service man
before working with the machine
After each cutting operation, clean the cutting blade with a soft brush and cloth with
lubricating fluid oil and spray a thin layer of fluid protective oil on the completes blade.
Always keep the ventilation slots in motor housing clean
Never clean or spray a machine with water .clean the motor housing only with a moist cloth
and never apply detergents or solvents! These could ruin the plastic parts of the machine
,Finally, dry the motor housing carefully.
Store the machine with the supplied protection cover(15)
Only use original accessories and spare parts.
10 TECHNICAL DATA
Type
POWXG20
40
Voltage ~Frequency 230V~50Hz
Power input 800 W
Blade length 480 mm
Cutting length 360 mm
Cutting capacity 24 mm
No load speed 1500 /min
Telescopic length 1,5m tot 2,5m
Weight 5,6 kg
11 SOUND EMISSION
Noise emission values measured according to relevant standard.
Acoustic pressure level LpA 89dB (A) K = 3 dB(A)
Acoustic power level LwA 103dB (A) K = 3 dB(A)

POWXG2040 EN
Copyright © 2012 VARO P a g e | 7 www.varo.com
ATTENTION ! The sound power pressure may exceed 85 dB(A), in this case
individual hearing protection must be worn.
aw (Vibration) 2,3 m/s
2
K = 1,5 m/s²
12 TROUBLESHOOTING
PROBLEM
CAUSE
ACTION
The hedge trimmer
runs slowly and
remains slightly
jammed
Too low voltage The extension cable core wire
not dimensioned sufficiently
On the starter being
pushed but the
motor will not start
The switch fuse was not pushed
in to release the starter
The extension cable coupling
released
Automatic fuse or switch open
An electric circuit on the unit
opens
Push the starter fuse before
pushing the starter
Check cable coupling
Check automatic fuse or
switch
Call authorised servicing
centre
The motor runs but
the blade not. Jammed in the gear box. Call authorised servicing center.
The unit is smoking The unit is faulty. Do not use it Call authorised servicing centre
The blade is so hard
to cut the branches
or find it’s smoking. No lubrication on the blade. After
each use, clean the blades
and lightly lubricate with general
purpose oil or spray lubricant.
13 WARRANTY
This product is warranted for a 36-month period effective from the date of purchase by the
first user.
This warranty covers all material or production flaws. It does not include defective parts
subject to normal wear & tear such as bearings, brushes, cables, and plugs, or accessories
such as drills, drill bits, saw blades, etc. ; damage or defects resulting from maltreatment,
accidents or alterations; nor the cost of transportation.
This warranty covers all material or production flaws, excluding batteries, chargers,
defective parts subject to normal wear and tear such as, in particular, bearings, brushes,
cables, plugs… Accessories such as drills, drill bits, saw blades etc. also do not fall under
this warranty.
Damage and/or defects resulting from inappropriate use also do not fall under the warranty
provisions.
We also disclaim all liability for any bodily injury resulting from inappropriate use of the tool.
Repairs may only be carried out by an authorised customer service centre for Powerplus
tools.
You can always obtain more information at the number 00 32 3 292 92 90.
Any transportation costs shall always be borne by the customer, unless agreed otherwise in
writing.
At the same time, no claim can be made on the warranty if the damage of the device is the
result of negligent maintenance or overload.
Definitely excluded from the warranty is damage resulting from fluid permeation, excessive
dust penetration, intentional damage (on purpose or by gross carelessness), inappropriate
usage (use for purposes for which the device is not suitable), incompetent usage (e.g. not
following the instructions given in the manual), inexpert assembly, lightning strike, erroneus
net voltage. This list is not exhaustive.

POWXG2040 EN
Copyright © 2012 VARO P a g e | 8 www.varo.com
Acceptance of claims under warranty can never lead to the prolongation of the warranty
period nor commencement of a new warranty period in case of a device replacement.
Devices or parts which are replaced under the warranty therefore remain the property of
Varo NV.
We reserve the right to reject a claim whenever the purchase cannot be verified or when it
is clear that the product has not been properly maintained. (Clean ventilation slots, carbon
brushes serviced regularly, etc.).
Your purchase receipt must be kept as proof of date of purchase.
Your appliance must be returned undismantled to your dealer in an acceptably clean state,
(in its original blow-moulded case if applicable to the unit), accompanied by proof of
purchase.
14 ENVIRONMENT
Should your appliance need replacement after extended use, do not discard it
with the household rubbish but dispose of it in an environmentally safe way.
Waste produced by electrical machine items should not be handled like normal
household rubbish. Please recycle where recycle facilities exist. Check with your
Local Authority or retailer for recycling advice.
15 DECLARATION OF CONFORMITY
VARO N.V. - Joseph Van Instraat 9 - BE2500 Lier - BELGIUM, declares that,
Product : Hedge Trimmer
Trade mark : POWERplus
Model : POWXG2040
Is in conformity with the essential requirements and other relevant provisions of the applicable
European Directives, based on the application of European harmonized standards. Any
unauthorized modification of the apparatus voids this declaration.
European Directives (including, if applicable, their amending directives):
2004/108/EC
2006/42/EC
2000/14/EC Annex V LwA 100dB(A) / 103dB(A)
European harmonized standards (including, if applicable, their amendments):;
EN60745-1 : 2009
EN55014-1 : 2006
EN55014-2 : 1997
EN61000-3-2 : 2006
EN61000-3-3 : 2008
The undersigned acts on behalf and under the power of attorney of the company
management,
Philippe Vankerkhove
Certification Manager
Date : 23/08/2011
