Garland Mealstream CTM3 User manual

&84?FGE84@(I8AF)G'B3"FFH8
)4:8
,+ &%$ )&.-$ ** &%*
&%&+&$/'&*+&$ ** &%*)&$+$ )&.-%) +&)
&)')+*&%,+ %$ )&.-%)0
&84?FGE84@
,+/"&'.%
*)- $%,#
%%-&&(%,-"&!(+-(',(&"'-"('(/',
&'.-.++(&#'.+2

Mealstream Ovens Pt. No. 32Z3403 Issue 16
Page 2
Microwave safety precautions................................................. 3
Safety code ............................................................................. 4
Product specifications ............................................................. 5
Installation instructions............................................................ 6
Main features ....................................................................... 7-8
Principal components: LHS..................................................... 9
Principal components: RHS .................................................. 10
Principal components: Top.................................................... 11
Principal components: Back view.......................................... 12
Principal components: Door & cavity roof ............................. 13
Principal components: External Parts & accessories............ 14
Principal components: Cavity Parts ..................................... 15
Principal components: Electronic control panel assembly .... 15
Principal components: Tim Hortons Control panels .............. 16
Principal components: ( not shown in main views ) ............. 17
Principal components: Input wiring details ............................ 18
Principal components: Part no. identification charts ........19-21
Procedure for Microwave leakage test............................. 22-23
Procedure for Power output measurement ........................... 24
Procedures for Principal Component tests ...................... 25-26
Procedure for Door interlock adjustment and test ..........27-29
Procedure for building and fitting the door .......................30-34
Procedure for replacing door seal assembly.................... 35-36
Procedure for removing shelf runners & element cover........ 37
Procedure for replacing Heater Element............................... 38
Procedure for replacing Hot air Motor assembly................... 39
Procedure for replacing Magnetron assembly .................40-41
Procedure for Testing Membrane panel circuit ................ 42-43
Circuit diagrams ................................................................... 44
Error codes and diagnostics.................................................. 45
Appendix 1: Test Procedure for Tim Hortons........................ 46
Appendix 2: MenuKey® Download procedure ...................... 47
Appendix 3: Temperature Sensor resistance data................ 48
Appendix 4: Cleaning Procedure .......................................... 49
Appendix 5: Hot Air Motor Upgrade ...................................... 50
Appendix 6: Recommended Spares List............................... 51
Appendix 7: Door stop & Adjustable microswitch bracket..... 52
Appendix 8: Door arm guide ................................................. 53
Manual corrections and modifications................................... 54
TABLE OF CONTENTS

Mealstream Ovens Pt. No. 32Z3403 Issue 16
Page 3
CAUTION
WARNING TO SERVICE TECHNICIANS
PRECAUTIONS TO BE OBSERVED BEFORE AND DURING
SERVICING TO AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY
(a) Do not operate or allow the oven to be operated with the door open.
(b) Make the following safety checks on all ovens to be serviced before
activating the magnetron or other microwave source, and make repairs
as necessary:
1) interlock operation.
2) proper door closing.
3) seal and sealing surfaces (arcing, wear, and other damage).
4) damage to or loosening of hinges and latches.
5) evidence of dropping or abuse.
(c) Before turning on microwave power for any service test or inspection
within the microwave generating compartments, check the magnetron,
wave guide or transmission line, and cavity for proper alignment,
integrity and connections.
(d) Any defective or misadjusted components in the interlock, monitor, door
seal, and microwave generation and transmission systems shall be
repaired, replaced, or adjusted by procedures described in this manual
before the oven is released to the owner.
(e)(i) A microwave leakage check to verify compliance with the Federal
Performance Standard should be performed on each oven prior to
release to the owner. For U.S.A.
(e)(ii) A microwave leakage check to verify compliance with the Canadian
Regulation, HEALTH AND WELFARE, SOR/79 920 should be performed
on each oven prior to release to the owner. For CANADA.
MICROWAVE SAFETY PRECAUTIONS

Mealstream Ovens Pt. No. 32Z3403 Issue 16
Page 4
This manual is designed to assist engineers who have been on a recognised product familiarisation
and training course run by Garland. It has been prepared to offer technical guidance for the
Mealstream range of Combination Microwave Ovens.
Please remember that it is wiser not to attempt a service task if you are unsure of being able to
complete it competently, quickly, and above all safely.
To avoid injury to yourself, and to protect the appliance from possible damage, please follow this
Safety Code when servicing these ovens.
Before attempting to repair the oven, check it for microwave leakage.
Check that the oven is not emitting microwaves, even when supposedly not in
operation.
Check that the oven is not operating continuously, whether the display indicates
cooking or not.
Always discharge the HT capacitors before working on the oven using a suitably
insulated 10 M
Ω
Resistor.
Before removing any covers from the oven, do all of the following.
• Switch off the mains supply and remove the plug from the wall socket.
or
• If the oven is hard wired, ensure that the power is turned off at the isolator switch.
Note:
The On/Off switch on the oven is not adequate protection against electric
shock, as it does not isolate all of the internal wiring from the mains.
Upon completion of a service on a Mealstream oven, or before reconnecting the appliance to the
electrical supply for testing, check all of the following points:
• All internal electrical connections are correct (see wiring diagram Page 44-47).
• All wiring insulation is correct and is not touching a sharp edge.
• All grounding connections are electrically and mechanically secure.
• All door safety interlocks are secure and mechanically sound.
• The door operation is smooth, and the arms run freely in the slots.
• The door activates all three of the door interlock switches in the correct order
(see pages 27-29).
• The temperature sensor is correctly connected to the Power PCB.
Before finishing a service call, recheck the following points:
• All of the electronics are functioning correctly, and all of the touch pads are working.
• Microwave emissions are below permissible limit - 4 mW/cm².
• The power output of the oven is checked in accordance with page 24.
• Oven has correct 2 inch ( 50mm ) air gap all round and 2 inches ( 50mm ) above.
Air flow should not be restricted. (see page 6 installation).
SAFETY CODE

Mealstream Ovens Pt. No. 32Z3403 Issue 16
Page 5
Power
Requirements
208Volts
240Volts
208V ac 60Hz 30Amp 2P & G
240V ac 60Hz 40Amp 2P & G
Power Output Microwave 100%
Convection
Combination
1425W
3000W
1425W + 3000W
External
Dimensions
Height
Width
Depth
30 inches ( 765mm )
29.5 inches ( 770mm )
25 inches ( 635 mm)
Manufacturers
recommended
clearances
Height
Width
Depth
32 inches ( 815 mm )
31.5 inches ( 795 mm )
27 inches ( 685 mm)
Internal
Dimensions
Height
Width
Depth
Capacity
10.2 inches ( 260mm )
19.3 inches ( 490mm )
14.2 inches ( 360mm )
1.62 ft³ ( 45.86 litres )
Weight Nett
Gross packed
198 lb.s ( 90 kg )
227 lbs ( 103 kg )
Construction Cavity
Casework
304 Stainless Steel
Settings Microwave
Temperature
Timer
Programs
100%,75%,50%,25%, Convection only
Off, 300°F, 350°F, 400°F, 440°F, 480°F
Up to 30 minutes per stage
Cook Programs can have 3 cooking stages of up to 30
minutes for each stage
Model Number: + Voltage + Frequency + Phases + Controls + Country
Model No. CTM3
Voltage 208V 20
240V 24
Frequency 50Hz 50
60Hz 60
Phases Single 1
Three 3
Control Type Series 5 S5
UK UK
N.America A
Customer Variant N.America TH = Tim Hortons
Country
PRODUCT SPECIFICATIONS

Mealstream Ovens Pt. No. 32Z3403 Issue 16
Page 6
Installation Instructions for Mealstream Combination Ovens
Power Supply Requirements
The Mealstream Series should be connected to a suitable electricity supply, which can cope
with the switching-on surge that occurs with certain types of catering equipment, including
microwaves. Because of this requirement, we strongly recommend that a separate, suitably
rated supply is installed for the oven.
The supply for the oven should be fitted with a Type "C" or Time Delay circuit breaker,
rated at:
50 Amp for 208V electrical supply ( 2PH + GND )
50 Amp for 240V electrical supply ( 2PH + GND )
30 Amp for 208V electrical supply ( 2PH + GND )
30 Amp for 240V electrical supply ( 2PH + GND )
If the oven is hard-wired to the supply, a double-pole isolator switch with a contact gap of at
least 1/8 inch ( 3 mm ) should be fitted.
32ins
31.5ins
16ins
27ins
Positioning the Oven
In order to maintain adequate ventilation for air intake
and exhaust, and to allow access for cleaning filters,
you must allow a minimum of 2 inches ( 50 mm )
clearance at the sides and rear of the oven,
and at least 2 inches ( 50 mm ) above.
Air intake temperature should not exceed 110°F/45°C
excessive temperature will lead to reduced operating duty
cycle, or premature ageing of internal components.
Failure to comply with these conditions will invalidate the
warranty.
Note:
The minimum recommended
clearance required for air flow
Grounding requirement
This appliance must be connected to a grounded, metallic, permanent wiring system, or an
equipment grounding conductor should be run with the circuit conductors and connected to the
equipment grounding terminal or lead on the appliance.
INSTALLATION INSTRUCTIONS
NEVER Install an oven above fryers,
grills, griddles or any other
major heat source.
NEVER Stack machines on top of
each other. Always use a
double stand or a separate
shelf.
ALWAYS Place containers in the cavity
carefully - impact damage
may chip the vitreous enamel
coating on the runners and
baffle plate.
Canada models
US models

Mealstream Ovens Pt. No. 32Z3403 Issue 16
Page 7
On/Off SWITCH
This is used to turn the oven On or Off.
IT DOES NOT ISOLATE INTERNAL
WIRING FROM THE MAINS SUPPLY.
EXHAUST VENTS
Allows exhausted air from the magnetron
cooling system to escape.
OVEN CAVITY
The oven cavity is mainly constructed
from stainless steel panels. It must be
kept clean.
BAFFLE PLATE
Forms the inside rear of the oven and
covers the hot air circulation fan. This
must be cleaned on a regular basis, and
kept free of debris.
RUNNERS
These are mounted on each side of the
oven cavity to support the rectangular
racks or oven trays.
HOT AIR FAN
Situated behind the baffle plate, and
circulates the hot air through the baffle
plate, over the heating element, and around
the edge of the baffle plate back into the
cavity.
RATING PLATE
The rating plate is situated on the rear of
the oven, and states the Model, Serial
Number, Electrical Ratings and
Manufacturers telephone number.
DOOR
The door consists of a thermally insulated
inner section, and an additional air gap
provided by a twin skinned door front to
lower the surface temperature.
DOOR SEAL
ELECTRICAL SUPPLY CORD
Electrical supply cord is situated on the rear
of the oven,
AIR FILTER
Main intake for cooling air for internal
components. Must be clear of obstructions.
a
b
c
d
e
f
h
i
j
g
b
k
f
c
b
d
e
g
h
i
k
j
a
MAIN FEATURES

Mealstream Ovens Pt. No. 32Z3403 Issue 16
Page 8
aStage LED's
bProgram & Time Display
eConvection Pad
fPower Pads
gTime / Preset Pads
hTemperature Set Pads
iCancel / Callback Pad
jProgram Pad
NMenukey™
ab
fg
i
j
Electronic control panel
h e
MAIN FEATURES
ab
M
M
L
K
N
O
KPreheat
LCancel
MIcon Cook Pads
NMenuKey™
OQuarter, Half & Full Batch Load
Tim Hortons control panel
N
MENU
KEY

Mealstream Ovens Pt. No. 32Z3403 Issue 16
Page 9
14
12
Left side
13
11
1A
2A
3A
6
1
2
3
4A
4
5A
7
9
8
No Description 208V 240V
1Fuse holder 30Z0231 30Z0231
1A Fuse 10 amp 30Z0217 30Z0217
2Fuse holder 30Z0231 30Z0231
2A Fuse 10 amp 30Z0217 30Z0217
3Fuse holder 30Z0285 30Z0285
3A Fuse 1 amp 30Z0957 30Z0957
4Fuse holder 30Z1178 30Z1178
4A Fuse 20 amp 30Z1177 30Z1177
5Fuse holder 30Z1178 30Z1178
5A Fuse 20 amp 30Z1177 30Z1177
6Electrical supply terminal block 31Z0149 31Z0149
7Filter ( Heater circuit ) 30Z0997 30Z0997
8Filter ( Microwave circuit ) 30Z0997 30Z0997
9Door spring 40C1141 40C1141
9Door springAModification Kit 10C0177 10C0177
10 Door arm stop assemblyC11C0279 11C0279
11 Microswitch ( Primary ) 30Z0240 30Z0240
12 Door hinge assembly ( LH )B11C0167 11C0167
13 Door arm assembly 11C0300 11C0300
14 Microswitch ( Monitor ) 30Z0240 30Z0240
112 Internal Filter LHS 40C0962 40C0962
118 Microswitch support bracket 40C0851 40C0851
Note B:
See page 17 for
parts
5
Note A:
Ovens before
June 2003
PRINCIPAL COMPONENTS
10
112
118
118
Note C:
For ovens later
than May 2005
See Appendix 7

Mealstream Ovens Pt. No. 32Z3403 Issue 16
Page 10
Right side
22
20
17
21
910
16
13
No Description 208V 240V
9Door spring 40C1141 40C1141
9Door spring KitA10C0177 10C0177
10 Door arm stop assemblyC11C0279 11C0279
13 Door arm assembly 11C0300 11C0300
16 Door hinge assembly ( RH )B11C0166 11C0166
17 Micro-switch ( Secondary ) 30Z0240 30Z0240
21 Steam vent guard 790061 790061
22 Temperature sensor 50E123 50E123
59 Rubber stop 31Z1150 31Z1150
90 Cavity Vent Pipe 40C1013 40C1013
95 Diode Board assy. with leads 11M0417 11M0417
113 Internal Filter RHS 40C1080 40C1080
118 Microswitch support bracketC40C0851 40C0851
20 Steam pipe 790046 790046
59
PRINCIPAL COMPONENTS
90
95
Note B:
See page 17 for
parts
Note A:
Ovens before
June 2003
113118
Note C: Ovens after May 2005 see Appendix 7

Mealstream Ovens Pt. No. 32Z3403 Issue 16
Page 11
23
23
24
28
27
24
27 26
26
Top view
62
60 61
63
63
PRINCIPAL COMPONENTS
87
87
Note D: This Capacitor is replaced with 30Z1251 0.88μf 2500V and 2 x 88mm
clips 30Z0521 included in a service kit Part No. 10C0172
Note E: All transformers are now replaced by the Multi-tap type Part No. 30Z1230
No Description 208V 240V
23 Magnetron (Panasonic) 30Z1171 30Z1171
24 Resistor 470 R 30Z0283 30Z0283
26 Capacitor 0.88μf (2300V)D30Z0861 30Z0861
26 Capacitor 0.88μf (2500V) Kit 10C0172 10C0172
27 Transformer E30Z1230 30Z1230
28 Twin blower motor 30Z1145 30Z1145
60 25mm OD Flexible conduit 314402 314402
61 20mm OD Flexible conduit 314401 314401
62 Capacitor clip (88mm) 30Z0521 30Z0521
63 Filter 30Z0997 N/A
87 Magnetron Thermal Trip 2571016 2571016

Mealstream Ovens Pt. No. 32Z3403 Issue 16
Page 12
No Description 208V 240V
64 Hot air motor assembly 10C0192 10C0192
65 Capacitor (motor start ) 6μF 30Z1148 30Z1148
88 Overheat Safety Thermostat 30Z1024 30Z1024
94 Hot Air motor Resistor Assy N/A 11C0341
104 Twin Blower Resistor Assy N/A 11C0477
Back view
64
65
88
94 104
PRINCIPAL COMPONENTS

Mealstream Ovens Pt. No. 32Z3403 Issue 16
Page 13
No Description 208V 240V
53 M5 Hex/hd s/s Screw 101825 101825
67 Stirrer glass assy. ( inc. long seals ) 11C0319 11C0319
71 Door seal kit 11C0292 11C0292
72 Door choke 790007 790007
76 Door Handle Towel Rail 32Z1064 32Z1064
77 Bolt 1/4" 20 UNC 3/4" Hex 109050 109050
86 Cavity roof seal (short) 790052 790052
89 Door Handle 40C1020 40C1020
Door Assembly Garland 11C0336 11C0336
Door Assembly Tim Hortons 11C0380 11C0380
Door Assembly Unbranded 11C0418 11C0418
106 Flat Washer S/S M5 x 20 104036 104036
107 Nylon Washer 104250 104250
108 Spring Washer 31Z5005 31Z5005
109 Flat Washer S/S M6 x 20 104054 104054
117 Nut M4 S/S 31Z4015 31Z4015
93
67
86
Door and cavity roof
86
71
89
107
114
77
108
109
72
72
106
76
PRINCIPAL COMPONENTS

Mealstream Ovens Pt. No. 32Z3403 Issue 16
Page 14
External Parts and accessories
No Description All models before
February 2004
All models
after February 2004
96 Side Panel Left Side 790002 40C1182
97 Side Panel Right Side 790003 40C1183
98 Top Panel 790005 40C1181
99 Foot 32Z1052 32Z1052
100 Wire Rack 40C1011 40C1011
101 Crumb Tray RBR290X02 RBR290X02
111 Rear Outer Panel 40C0951 40C1180
114 Side bumper RMC6104 RMC6104
116 Air filter panel (removable) 40C0868 40C0868
119 Push fit bumper ( Rear Panel ) 31Z1187 31Z1187
121 Roof Corner cap n/a 40C1113
122 Front pillar LH n/a 40C1184
123 Front pillar RH n/a 40C1185
119
101
96
99
98
97
111
PRINCIPAL COMPONENTS
114
116
100
121
123
122

Mealstream Ovens Pt. No. 32Z3403 Issue 16
Page 15
No Description 208V 240V
29 On/Off Switch 30Z0503 30Z0503
30 Control Panel Assy with Menukey
(except Tim Hortons)
11C0379 11C0379
31 Logic Board (except Tim Hortons) 11C0377 11C0377
32 Relay Board (except Tim Hortons) 11C0316 11C0212
33 AC Ribbon connector (6 way) 11M0116 11M0116
73 MenuKey Assembly 10C0148 10C0148
125 PCB standoff 2243033 2243033
34 DC Ribbon connector (10 way) 11M0360 11M0360
Electronic Control Panel Assembly
Tim Hortons
See page 16
PRINCIPAL COMPONENTS
Control Panel Assembly on ovens manufactured before February 2004
Control panels now supplied are for the new style casework and not compatible with older models.
When replacing the control panel assembly remove the top trim/On-Off switch metal panel from the
existing control panel and substitute this for the top trim on the replacement unit.
32
31
33
34
29
30
73
No Description 208V 240V
57 Mesh washer 31Z5044 31Z5044
68 Heater element 40C0949 40C0948
69 Heater element
cover plate
790047 790047
70 Baffle 11C0311 11C0311
85 Dome Nut 80X7025 80X7025
115 Shelf Support
Tim Hortons
10C0174 10C0174
124 Shelf support fixing bolt 80T7133 80T7133
92 Shelf Support (Garland) 40C0950 40C0950
102 Hot Air Impeller 10C0236 10C0236
Heater Element and Cavity parts
115 Tim Hortons
69
57
68
70
70
92
92
102
85
125
124

Mealstream Ovens Pt. No. 32Z3403 Issue 16
Page 16
US/ English 1/4 Load
TIM HORTONS CONTROL PANEL
French Canadian
Unbranded
No Description 208V 240V
30 Control Panel Assy with Menukey 11C0412 11C0412
31 Logic Board 11C0411 11C0411
32 Relay Board 11C0402 11C0403
No Description 208V 240V
30 Control Panel Assy with Menukey 11C0413 11C0413
31 Logic Board 11C0411 11C0411
32 Relay Board 11C0402 11C0403
No Description 208V 240V
30 Control Panel Assy with Menukey 11C0414 11C0414
31 Logic Board 11C0411 11C0411
32 Relay Board 11C0402 11C0403
US/ English
No Description 208V 240V
30 Control Panel Assy with Menukey 11C0332 11C0332
31 Logic Board 11C0331 11C0331
32 Relay Board 11C0316 11C0212

Mealstream Ovens Pt. No. 32Z3403 Issue 16
Page 17
12
No. Description All models
12 Door Hinge Assembly LH 11C0167
16 Door Hinge Assembly RH 11C0166
51 Pin 790027
52 Roller 40C0752
53 M5 Hex/hd s/s Screw 101825
54 M5 stainless steel Nut 80X7003
55 LH Hinge bracket 790024
56 RH Hinge bracket 790025
58 Stirrer motor assembly 11C0324
( not shown in main views )
54
53 53
54
Right Hand Door Hinge
Assembly
Left Hand Door Hinge
Assembly
55
Stirrer motor assembly
58
52
51
16
51
56
52
PRINCIPAL COMPONENTS

Mealstream Ovens Pt. No. 32Z3403 Issue 16
Page 18
Input wiring details
Black
White
Green/Yellow
48 46 47
6
L1 L2
Green
Hot Air Motor connections and Wiring
208V 60 Hz
L2
L1
240V 60 Hz
L2
L1
PRINCIPAL COMPONENTS
No. Description All models
6Electrical Supply Terminal Block 31Z0149
46 Cable Gland 31Z0500
47 Gland Nut 31Z0499
48 Electrical Supply Cord 3 Core 30Z1162
91 Electrical Supply Plug 50Amp
(Canada)
31Z0298

Mealstream Ovens Pt. No. 32Z3403 Issue 16
Page 19
No Description
Part No
Page No
208V 240V
1Fuse holder 30Z0231 30Z0231 9
1A Fuse 10 amp 30Z0217 30Z0217 9
2Fuse holder 30Z0231 30Z0231 9
2A Fuse 10 amp 30Z0217 30Z0217 9
3Fuse holder 30Z0285 30Z0285 9
3A Fuse 1 amp 30Z0957 30Z0957 9
4Fuse holder 30Z1178 30Z1178 9
4A Fuse 20 amp 30Z1177 30Z1177 9
5Fuse holder 30Z1178 30Z1178 9
5A Fuse 20 amp 30Z1177 30Z1177 9
6Electrical supply terminal block 31Z0149 31Z0149 9/18
7Filter ( Heater circuit ) 30Z0997 30Z0997 9
8Filter ( Microwave circuit ) 30Z0997 30Z0997 9
9Door spring Modification KitA10C0177 10C0177 9/10
Door spring( Long ) 40C1141 40C1141 9/10
10 Door arm stop assemblyC11C0279 11C0279 9/10
11 Microswitch ( Primary ) 30Z0240 30Z0240 9
12 Door hinge assembly ( LH ) 11C0167 11C0167 9/17
13 Door arm assembly 11C0300 11C0300 9/10
14 Microswitch ( Monitor ) 30Z0240 30Z0240 9
16 Door hinge assembly ( RH ) 11C0166 11C0166 10/17
17 Microswitch ( Secondary ) 30Z0240 30Z0240 10
20 Steam pipe S/S 790046 790046 10
21 Steam vent guard 790061 790061 10
22 Temperature sensor 50E123 50E123 10
23 Magnetron 30Z1171 30Z1171 11
24 Resistor 470 R 30Z0283 30Z0283 11
25 HT diode 11C0266 11C0266 11
26
Capacitor 0.88μf (2300V)D30Z0861 30Z0861 11
Capacitor 0.88μf (2500V) Kit 10C0172 10C0172 11
27 Transformer ( Multi-tap )E30Z1230 30Z1230 11
28 Twin blower motor 30Z1145 30Z1067 11
29 On/Off Switch 30Z0503 30Z0503 15
30 Control Panel Assembly (Except Tim Hortons) 11C0379 11C0379 15
Control Panel Assembly US Tim Hortons 11C0412 11C0412 16
Control Panel Assy. French C. Tim Hortons 11C0413 11C0413 16
Control Panel Assy. UnBranded Tim Hortons 11C0414 11C0414 16
PRINCIPAL COMPONENTS: Part Number Identification Chart 1
Note A: Ovens before June 2003
Note C: For ovens later than May 2005 See Appendix 7
Note D: This Capacitor is replaced with 30Z1251 0.88μf 2500V and 2 x 88mm clips 30Z0521
included in a service kit Part No. 10C0172
Note E: All transformers are now replaced by the Multi-tap type Part No. 30Z1230

Mealstream Ovens Pt. No. 32Z3403 Issue 16
Page 20
PRINCIPAL COMPONENTS: Part Number Identification Chart 2
No Description
Part No
Page No
208V 240V
33 AC Ribbon connector (6 way) 11M0116 11M0116 15
34 DC Ribbon connector (10 way) 11M0360 11M0360 15
46 Cable Gland 31Z0500 31Z0500 18
47 Gland Nut 31Z0499 31Z0499 18
48 Mains Cable 3 Core 30Z1162 30Z1162 18
51 Pin 790027 790027 17
52 Roller 40C0752 40C0752 17
53 M5 Hex/hd s/s Screw 101825 101825 13/17
54 M5 stainless steel Nut 80X7003 80X7003 17
55 LH Hinge bracket 790024 790024 17
56 RH Hinge bracket 790025 790025 17
57 Mesh washer 31Z5044 31Z5044 14
58 Stirrer motor assembly 11C0162 11C0162 17
59 Rubber stop 31Z1150 31Z1150 10
60 25mm OD Flexible conduit 314402 314402 11
61 20mm OD Flexible conduit 314401 314401 11
62 Capacitor clip (88mm) 31Z0521 31Z0521 11
63 Filter 30Z0997 N/A 11
64 Hot air motor assembly Kit 10C0192 10C0192 12
65 Capacitor (Motor starter) 30Z1148 30Z1148 12
67 Stirrer glass Assy. ( Inc. long seals ) 11C0319 11C0319 13
68 Heater element 40C0949 40C0948 14
69 Element cover plate 790047 790047 14
70 Baffle 11C0311 11C0311 14
71 Door seal kit 11C0292 11C0292 13
72 Door choke 790007 790007 13
73 MenuKey Assembly 10C0148 10C0148 15
76 Handle 32Z1064 32Z1064 13
77 Bolt 1/4" 20 UNC 3/4" Hex 109050 109050 13
85 Dome Nut 80X7025 80X7025 13
86 Cavity roof seal (short) 790052 790052 13
87 Magnetron Thermal Trip 2571016 2571016 10
88 Cavity Overheat Thermostat 30Z1024 30Z1024 12
89 Door Handle 40C1020 40C1020 13
90 Cavity Vent Pipe 40C1013 40C1013 10
91 Electrical Supply Plug (50A Canada) 31Z0298 31Z0298 18
92 Shelf Support (Garland) 40C0950 40C0950 13
31 Logic Board (Except Tim Hortons) 11C0377 11C0377 15
31 Logic Board Tim Hortons 11C0411 11C0411 15
32 Relay Board (except Tim Hortons) 11C0316 11C0212 15
