Moisture + Standard Gas Oven
Item: _______________________
Quantity: ___________________
Project: _____________________
Approval: ___________________
Date: _______________________
Moisture + Standard Gas Oven
Models:
MP- GS-10 -S MP-GS-20 -S MP- GD -10 -S MP-GD -20-S
Standard Features:
• Solidstatecontrol,(temperature
range;150°F/66°C-500°F/260°C),
1-hour,electro-mechanicaltimer,
andautomaticmoistureinjection
• 80,000BTUNaturalGas
• Two-speedfanwith3/4HPmotor
• Allstainlessconstruction
• Stainlesssteeloveninteriorwith
covedcorners
• Showerstallstylecavitybase
withdrain
• Singledoorwith"Split"window
foreasycleaning
• Quartzillumination
• 24"cookingcavityheight
• Sixovenrackswith13position
rackguides
• "Pull-Out"controlsectionforeasy
maintenance&service
• Serviceaccessibilityfromfront
(allbutwatersystem)
• Doublestackmodelavailable,
suffix-20-S
• Deep-Depthmodelavailable,pre-
fixMP-GD
• Oneyearlimitedpartsandlabor
warranty
OptionalFeatures:
 Deluxemicroprocessorcontrol,
(temperaturerange;150°F/66°C-
500°F/260°C),with9programma-
blerecipekeys,Cook&Hold,100-
hourtimer,andprogrammable
moistureinjection.Alsoincludes
externaltemperaturecore
p r o b e  f o r  r o a s t i n g   a p p l i c a t i o n s 
(availableonlyforDeluxefetaure
controlpackagedmodels).
 Wet-clean,on-boardsprayhose
system
 Extraovenracks
 Stainlesssteelbackenclosure
 Stainlesssteelopenbasewith
rackguidesandshelf
 Deckfasteners
 Gasflexhoseandquick-
disconnectwithrestraining
device
 Swivelcasterswithfrontbrakes
 Lo-profilecasterswithfront
brakes(doubleovensonly)
Specifications:
Moisture+Oven,Standard,isafull-size,multifunctionelectric
ovenwithasolidstatecontrol,(temperaturerange;150°F/66°C
-500°F/260°C),1-hour,electro-mechanicaltimer,andautomatic
moistureinjection.Oveninteriorisstainlesssteelwith6oven
racksand13-position,removablerackguides.Allmodelinte-
riorsmeasure29"(736mm)Wx24"(610mm)H,interiordepthfor
Standard-depth,prefixMP-GS,is24"(610mm)andforDeep-
depth,prefixMP-GD,28"(711mm).Exteriorisstainlesssteel.
Moisture+featuresinnovative,automaticintroductionofmois-
tureintothebaking/roastingprocess,producinghigheryields
andimprovedtaste,texture,andeyeappeal.
Model MP-GS-10-S
Note:Ovenssuppliedwithcastersmustbeinstalled
withanapprovedrestrainingdevice.

Garland Commercial Ranges Ltd
1177 Kamato Road,
Mississauga, Ontario
L4W 1X4 CANADA
General Inquires 1-905-624-0260
USA Sales, Parts and Service 1-800-424-2411
Canadian Sales 1-888-442-7526
Canada or USA Parts/Service 1-800-427-6668
Form#MPG10S(07/02/13)
InstallationNotes:
• Motor:3/4HP,twospeed,
114 0/17 25rpm
• Eachovendeckrequires
aseparateelectrical
connection
• Customermustprovidea1/8”
NPTwaterconnectioncapable
of20PSI*
• Garlandrecommendsthemin-
imumwaterqualitystandards,
whethertreatedorpre-treated
andbasedon10hoursofuse
perday,anddailycleaning/
descaleing,tobe:totaldis-
solvedsolids<60ppm,total
alkalinity<20ppm,silica<13
ppm,chlorine<30ppm,anda
pHfactorgreaterthan7.5*
• Customermustprovideafloor
drainorsimilardevice*
Thisovenmustbeinstalled
tocomplywiththeapplicable
federal,state,orlocalplumbing
codes.
*Consultalocalwatertreatmentspecialistforanon-sitewateranalysisforrecommendationsconcerningfeedwatertreatment(if
required),inordertoremoveorreduceharmfulconcentrationsofminerals.Theuseofhighlymineralizedwaterwillcausemore
frequentcleaningandreduceoperatingefficiency.Thefactthatawatersupplyispotableisnotproofthatitwillbesuitablefor
moisturemodeoperation.Componentfailure/servicerelatedtopoorwaterqualitywillnotbecoveredunderwarranty.
Clearances
Installation Entry
Sides Rear Crated Uncrated
1”
(25mm)
3”
(76mm)
44-1/2”
(1130mm)
32-1/2”
(826mm)
Model Oven Interior: In. (mm) Exterior : In. (mm) Ship Wt. Ship Size
Width Height Depth Width Height** Depth lbs/kgs Cu Ft
MP- G S-10 -S
29(736) 24(610)
24(610)
38(965)
60-3/4(1543) 40(1016) 510/232 42
MP-GS-20 -S 72-1/2(1842) 1024/464 84
MP- G D -10 -S
28(711) 60-3/4(1543) 4 4 (1118 ) 510/232 42
MP-GD -20 -S 72-1/2(1842) 1024/464 84
**Heightwithorwithoutstandardcasters.Heightwithlo–prolecasters(doubledeck)is70"(1778mm).
Input Ratings Manifold Operating Pressure
Gas Inlet BTU/HR kW Natural Gas Max Inlet
3/4”N.P.T. 80KNAT 23.5NAT 4.5”WC(11mbar) 13.8”WC(34mbar)@70°F
Gasinputratingsshownareper-oven,forinstallationsupto2000ft.[610m]continuous
waterpressureataflowof3gpmabovesealevel.
38"
[965mm]
2-1/4"
[57mm]
2-1/4"
[57mm]
32-3/4"
[832mm]
DOOR OPENING
REQUIRED
32"
[813mm]
58.5"
[1486mm]
26-1/2"
[673mm]
FLOOR
LINE
40" [1015mm]
ADD 4" [102mm]
FOR DEEP OVENS
32-3/4"
[832mm]
DOOR OPENING
REQUIRED
32"
[813mm]
32"
[813mm]
70-1/4"
[1784mm]
5-1/2"
[140mm]
6-1/4"
[159mm]
SINGLE DECK
GAS SUPPLY
3/4" NPT
1/8" NPT
WATER SUPPLY
DOUBLE STACK
GAS SUPPLY
1" NPT
15"
[381mm]
8-1/4"
[210mm]
10-1/2"
[267mm]
1-1/2" NPT
DRAIN CONNECTION
Moisture + Standard Gas Oven
