G2000 Series Deck Oven
Item: ______________________________
Quantity: __________________________
Project: ____________________________
Approval: __________________________
Date: ______________________________
G2000 Series Deck Oven
Models:
G2071 G2121 G2771 G2121-72 G2071-771
G2072 G2122 G2772 G2121-771
G2073 G2123 G2121-71 G2122-71
Specifications:
Bake Oven: G2000 Series Gas Bake and General Purpose Deck
Ovens with stainless steel front, sides, and legs. Aluminized
top and back panels. 7" high baking/general purpose com-
partments, 42" (1067mm) Wide x 32" (813mm) Deep, with two
“U” shaped burners, controlled by a heavy duty “snap/throttle”
thermostat 150°F (66°C) to 500°F (260°C), heating heavy steel
tread plate below the 1" (25 mm) thick Hearthite deck.
Roast Oven: G2000 Series Gas Roast Deck Ovens with stainless
steel front, sides, and legs. Aluminized top and back panels. 12"
high compartments, 42" (1067mm) Wide x 32" (813mm) Deep,
with two “U” shaped burners, controlled by a heavy duty
“snap/throttle” thermostat, 150°F (66°C) to 500°F (260°C)) heat-
ing heavy, 12 gauge steel hearth deck.
Standard Features:
• Stainless steel front, sides, and legs
• Aluminized top and back panels
• Snap/throttle temperature control 150°F (66°C) to 500°F (260°C)
• Balanced oven door opens full width, level with deck
• Controls outside the heat zone - front serviceable
• Canopy draft diverter provided - standard
• Bake Oven: 1" (25 mm) Hearthite deck with 7" interior height
• Roast Oven: 12 gauge steel hearth deck with 12" interior height
®
Optional Features:
Stainless steel back and top
Direct connect vent - no
charge -specify
One hour mechanical timer
Bake sections only:
Steam injection piping,
external connection, and
injectors
Window with interior light
12 gauge steel hearth in lieu
of Hearthite deck
Roast sections only:
1” (25mm) Hearthite deck in
lieu of steel hearth
Removable Intermediate
Shelf
Model G2071 Model G2121
Model G2771

Garland Commercial
Industries, LLC
185 East South Street
Freeland, PA 18224
Phone: [phone]
Fax: [phone]
Garland Commercial Ranges Ltd
1177 Kamato Road,
Mississauga, Ontario
L4W 1X4 CANADA
Phone: [phone]
Fax: [phone]
Enodis UK LTD
Swallowfield Way,
Hayes, Middlesex
UB3 1DQ ENGLAND
Telephone: [phone]
Fax: [phone]
G2000 Series Deck Oven
Form# G2000 (05/20/08)
G2121-71
G2073
7B
7B
7B
12R
7B
G2121-771
G2071
7B
12R
12R
T7B
T7B
12R
G2122
G2771
G2072
7B
7B
12R
12R
T7B
7B
7B
T7B
T7B
12R
12R
12R
G2123
G2122-71
G2772
G2071-771
G2121-72
G2121
12R
7B
7B
12R
MODEL A B C D E F G Total BTU
G2071 50" (1270mm) 58" (1473mm) 40.5" (1664mm) 31" (787mm) 40,000
G2072 58.5" (1270mm) 66.5" (1689mm) 31.5" (800mm) 49" (1283mm) 22" (559mm) 80,000
G2073 60" (1524mm) 68" (1727mm) 15.5" (394mm) 33" (838mm) 50.5" (1283mm) 6" (152mm) 120,000
G2121 55" (1397mm) 63" (1600mm) 40.5" (1664mm) 31" (787mm) 40,000
G2122 60.5" (1537mm) 68.5" (1740mm) 23.5" (597mm) 46" (1168mm) 14" (356mm) 80,000
G2123 75" (1905mm) 83" (2018mm) 15.5" (394mm) 38" (965mm) 60 .5" (1537mm) 6" (152mm) 120,000
G2771 60" (1524mm) 68" (1727mm) 40.5" (1664mm) 50.5" (1283mm) 31" (787mm) 50,000
G2772 62.5" (1587mm) 70.5" (1791mm) 15.5" (394mm) 25 .5" (648mm) 43" (1092mm) 53" (1346mm) 6" (152mm) 100,000
G2121-71 63.5" (1613mm) 71.5" (1816mm) 31.5" (800mm) 54" (1372mm) 22" (559mm) 80,000
G2121-72 65" (1651mm) 73" (1854mm) 15.5" (394mm) 38" (965mm) 55.5" (1410mm) 6" (152mm) 120,000
G2121-771 57.5" (1460mm) 65.5" (1664mm) 15.5" (394mm) 38" (965mm) 48" (1219mm) 6" (152mm) 90,000
G2122-71 70" (1778mm) 78" (1981mm) 15.5" (394mm) 38" (965mm) 60 .5" (1537mm) 6" (152mm) 120,000
G2071-771 60.5" (1537mm) 68.5" (1664mm) 23.5" (597mm) 41" (1041mm) 51" (1295mm) 14" (356mm) 90,000
17"
(432mm)
G
C
D
E
F
B
A
3/4" NPT
GAS INLET
55-1/4"
(1416mm)
10-5/8"
(280mm)
2"
(51mm)
1"
(25mm)
2-1/4"
(57mm)
3"
(76mm)
27-7/8"
(708mm)
2"
(51mm)
38-1/4"
(972mm)
All Models Natural Propane
Manifold
Operating Pressure
5.5" WC
(13.7 Mbar)
10.0" WC
(24.9 Mbar)
Minimum
Supply Pressure
7.0" WC
(17.4 Mbar)
11.0" WC
(27.4 Mbar)
Clearances To Combustible Wall
Sides Back
1” (25mm) 6” (152mm)
7B = 7" Bake
T7B = Twin 7" Bake
12R = 12" Roast
