Garland G20-SP User manual

Garland Commercial
Industries, LLC
185 East South Street
Freeland, PA 18224
Phone: [phone]
Fax: [phone]
Garland Commercial Ranges Ltd
1177 Kamato Road,
Mississauga, Ontario
L4W 1X4 CANADA
Phone: [phone]
Fax: [phone]
Enodis UK LTD
Swallowfield Way,
Hayes, Middlesex
UB3 1DQ ENGLAND
Telephone: [phone]
Fax: [phone]
Gas
Stock Pot Range
Item: ______________________________
Quantity: __________________________
Project: ____________________________
Approval: __________________________
Date: ______________________________
Gas Stock Pot Range
Models:
G20-SP G20-SPH
Standard Features:
• Heavy Duty modular
construction
• Black baked enamel fin-
ish, tubular legs front
and two sides.
• Adjustable 1-3/8" (35mm)
high zinc plated leveling
feet
• Removable valve control
panel
• Removable drip tray
• One piece cast iron top
grate with raised full ribs
for stable pots
• Four Spectro-Heat
Burners
• Infinite setting valve
between Low
12,000 BTU), Medium
(35,500 BTU) and High
(60,000 BTU) positions
for instant heat adjust-
ment
• Pressure regulator - not
supplied for use with
manufacture gas
• 100% positive "H" safety
pilot, to shut off gas if
pilot flame goes out,
Model G20-SPH
Optional Features:
Stainless steel front,
sides and legs
Specifications:
Gas stock pot range, with heavy duty modular con-
struction, removable easy clean drip tray and one
piece cast iron top grate with full width ribs. 20"
(508mm) wide x 20" (508mm) deep x 24" (610mm)
high, black baked enamel tubular legs, front and two
sides, stainless steel removable valve control panel
and 1-3/8" (35mm) high zinc plated leveling feet. Four
specto-heat burners and infinite valve settings allow
for versatility of heat, 60,000 BTU maximum output.
Constant shielding pilot for automatic lighting, 100%
positive type "H" safety pilot available to shut off gas
if pilot goes out, Model G20-SPH.
Model G20-SP
(stock pot and stirrer not included)
TM

Garland Commercial
Industries, LLC
185 East South Street
Freeland, PA 18224
Phone: [phone]
Fax: [phone]
Garland Commercial Ranges Ltd
1177 Kamato Road,
Mississauga, Ontario
L4W 1X4 CANADA
Phone: [phone]
Fax: [phone]
Enodis UK LTD
Swallowfield Way,
Hayes, Middlesex
UB3 1DQ ENGLAND
Telephone: [phone]
Fax: [phone]
Gas Stock Pot Range
Form# G20-SP (06/07)
20"
[508mm]
1"
[25mm]
24"
[610mm]
3/8" [10mm] MIN
1-7/8" [48mm] MAX
ADJUSTABLE
FEET
BOTTOM GAS
ENTRANCE
BACK GAS
ENTRANCE
3/4" NPT
GAS
CONNECTION
3-1/2"
[89mm]
2-1/4"
[57mm]
14-5/8"
[371mm]
8-3/8"
[213mm]
20"
[508mm] 4-3/4"
[121mm]
13-1/4"
[337mm]
1-1/8"
[29mm]
4"
[102mm]
BACK GAS
ENTRANCE
DRIP
TRAY
BOTTOM GAS
ENTRANCE
20"
[508mm]
20"
[508mm]
Model Dimensions Input Natural
Gas BTU Cu Ft Shipping Weight Lb/Kg
Width Depth Height
G20-SP 20" (508mm) 20" (508mm) 24" (610mm) 60,000 11 110/50
G20-SPH 20" (508mm) 20" (508mm) 24" (610mm) 60,000 11 110/50
Model Operating Pressure Gas Inlet
NPT
Natural Propane
G20-SP 7" WC 11" WC 3/4"
G20-SPH 7" WC 11" WC 3/4"
Gas input ratings are show for natural gas installa-
tions up to 2000 Feet (610m) above sea level. BTU
input ratings must be derated for high altitude
installations. Specify altitude of project if over 2000
feet (610m).
For other gases specify type, caloric value, specific
gravity and pressure at appliance.
Pressure regulator not supplied for use with manu-
factured gas.
A Satisfactory power ventilator properly adapted
for the range may be used.
NOTE: Many local codes exist, and it is the responsi-
bility of the Owner and the Installer to comply with
those codes.
Garland products are not approved or authorized
for home or residential use, but are intended for
commercial applications only. Garland will not pro-
vide service, warranty, maintenance or support of
any kind other than in commercial applications.
Combustible Wall Clearances
Sides Back
6" (152mm) 6" (152mm)
