Garudan GP-724-108 User manual

Index
Contexts ................................................................ ………….Chapter–Page
1 Safety ........................................................................….............…………..…….1-1
1.01 Directives..........................……..................…......................................……..…...1-1
1.02 Generalnoteson safety.........................…….….....................................………..1-1
1.03 Safetysymbols.................................................................................……….……1-2
2Proper use ……............................................................................…….....…......2-1
3Specifications ………......................................................................……........... 3-1
3.01 GP-710-148, GP-724-108.......................................…....................................….3-1
3.02 Needlesand threads…………...................................................…...…..........….3-2
3.03 Possiblemodelsand subclasses………..........................................…..........…..3-2
4Explanationofsymbols ……………...…........................................................... 4-1
5Controls ……….................................................................................................. 5-1
5.01 Keyson machine head (onlyformachineswith-D3/..)………….......................5-1
5.02 Bobbinthread monitoring withstitchcounting ………….............….....................5-2
5.03 Pedal…......................................................................…....…..............................5-2
5.04 Leverforlifting rollerpresser…………........................……................................. 5-3
5.05 Knee lever.................................................................…...................................... 5-3
5.06 Deyforseeting stitchlength……….................................................................. 5-4
5.07 Swing out rollerpresser............................…..............................….....................5-4
6Installationandcommissioning ...................……………..........….........……...6-1
6.01 Installation..................................……................................….............................. 6-1
6.01.01 Adjusting thetableheight.............................................…...…..............…......…. 6-1
6.02 Fitting the reelstand ...........................………….............................….................6-2
6.03 Tiltedwork base..................................……................................…….............….6-3
6.04 Tabletop cutout......................……..…............................................................ 6-4
6.05 Mounting thetabletop...............……………...............................….....................6-5
7Preparation.........................................................…............................................ 7-1
7.01 Inserting the needleonmodel GP-710…............................................................ 7-1
7.02 Inserting the needleonmodel GP-724........................…………......................... 7-2
7.03 Winding the bobbinthread; adjusting the bobbinthreadtension .........…...........7-3
7.04 Removing/Insertingthe bobbincase.......………………….................................. 7-4
7.05 Threading the bobbincase/Adjusting the bobbinthreadtension .....................7-4
7.06 Threading the needlethread and regulating itstension on modelGP-710……....7-5
7.07 Threading the needlethread and regulating itstension on modelGP-724.........7-6
7.08 Setting the stitchlength....................................................……….................…... 7-7
8Care and maintenance .......................................………........…..................…8-1 8.01
Checking/adjusting the airpressure....................................................................8-1
8.02 Cleaning the airfilterof theair-filter/lubricator............... ...............................…..8-2 8.03
Cleaning ...............................................…......................…................................ 8-3
8.04 Oiling the hook....................…....................…................................................... 8-4
8.05 Oil bowlforhooklubrication....….…….....……………………....…….................. 8-4
8.06 Filling the oilreservoirof the thread lubrication unit..............……….................8-5
8.07 Lubricating the bevelgears............................................………….....................8–6
9Adjustment ..............................………............................................................... 9-1
9.01 Noteson adjustment............................…............................................................ 9-1
www.garudan.cz

9.02 tools, gaugesand otheraccessories........………………………………………......9-1
9.03 Adjusting thebasicmachine........………………..................................................9-2
9.03.01 Needleposition insewing direction on theGP-710……………….....……............9-2
9.03.02 Needleposition insewing direction on theGP-724…………...........…................ 9-3
9.03.03 Preliminary adjustmentofthe needleheight……………………........................... 9-4
9.03.04 Needlerise, hookclearance, needleheightand needlegrardon the
H962 ..…………………………………………………………….……………….……..9-7
9.03.05 Needlerise, hookclearance, needleheight and needlegrardon the
H961 ..…………………………………………………………….……………….……..9-9
9.03.06 Neelleposition crosswisetosewing direction on theGP-724 …...…….......…..9-12
9.03.07 Neelleposition crosswisetosewing direction on theGP-710 ….........…........ 9-13
9.03.08 Heightand strokeofthe bobbincaseopener....................................................9-14
9.03.09 Heightofthe feed wheelon the GP-724……............................................…......9-16
9.03.10 Heightofthe feed wheelon the GP-710............................................…..…....... 9-17
9.03.11 Stitchlengthcontrolenccentric...............................…........…........................... 9-18
9.03.12 Stitchlengthscaledisk...........................…........................................................ 9-19
9.03.13 Shaftcranktofeed wheeldrive...................…...................…..................…....... 9-20
9.03.14 Shaftcranktorollerpresser…….. ...........................…...................................... 9-21
9.03.15 Clearncebetween rollerpresserand feed wheel..............…………………....... 9-22
9.03.16 Rollerpresser... .................................................................................................9-23
9.03.17 Stitchlengthon stitchlengthscale………..........................................................9-24
9.03.18 Synchronizationofrollerpresserandfeedwheel .......................……………............ 9-25
9.03.19 Retainer onlyon model GP-724）............…...................................................9-26
9.03.20 Knee lever........................................................................................................9-27
9.03.21 Needleand tension release..............................…………..................................9-28
9.03.22 Thread checkspring (GP-710)...................…...............................9-29
9.03.23 Thread checksprings(GP-724)..................................................................9-30
9.03.24 Bobbinwinder.................……........................................................................... 9-31
9.03.25 Pressureofrollerpresser..................................................................................9-32
9.03.26 Lubrication .....................……………….............................................................. 9-33
9.03.27 Re-engage safetycoupling ..........................................….................................. 9-34
9.04 Adjusting theedge trimmer-D........................................................……………...9-35
9.04.01 Resting position ofthe rollerlever/radialposition of the controlcam.....…….... 9-35
9.04.02 Position of the thread catcherholder................................................................ 9-36
9.04.03 Distancebetween thread catcherand needleplate….......................................9-37
9.04.04 Position of the thread catcher................…….................................................... 9-38
9.04.05 Knifeposition and knifepressure.........……......................................................9-39
9.04.06 Bobbinthread retaining spring .............……….................................................. 9-40
9.04.07 Manualcutting test ............…….........................................................................9-41
9.04.08 Releasing the tension ...............................................…..................................... 9-42
9.04.09 Linkage rod (onlyforGP-724)................…................................................. 9-43
9.05 Adjustment of backtacking mechanism-D3/...............................……………..... 9-44
9.05.01 Needleinthe nendlehole onlyforGP-710）………………............…..........9-44
9.05.02 Coupling forrollerpresserdrive..................….................................................. 9-45
9.05.03 Bevergearsforfeed wheeldrive(on the GP-724)….…...............9-46
9.05.04 Bevel gearplay(onthe GP-724)..........……..................….............9-47
9.05.05 Bevel gearsforfeed wheeldrive(on theGP-710)......….......….……............ 9-48
9.05.06 Bevel gearplay(onthe GP-710)...……….......................................…............ 9-49
www.garudan.cz

Safety
1.01 Safetysymbols
Danger!
Pointstobe observed
Dangerofinjury foroperating and
specialist personnel！
Caution
Do not operatewithoutfingerguardand safetydevices.
Bbeforethreading,changing bobbinand needle,
cleaning etc.switchoff mainswitch.
1.02 作中的特殊
Importantpointsfortheuser
●ThisInstruction Manual isacomponent ofthe machine and must be availabletothe
operating personnelat all times.
●The Instruction Manual must be read beforeoperating the machine forthe first time.
●The operating and specialist personnelmust tobe instructed inthe safeguardsofthe
machine and safework methods.
●It isthe dutyofthe usertooperatethe machine inperfect running order.
●It isthe obligation ofthe usertoensurethatnone ofthe safetymechanismsareremoved or
deactivated.
●Itistheobligationoftheusertoensurethatonlyauthorizedpersonsoperateandworkonthe
machine.
www.garudan.cz

Safety
——————————
1.03 Danger
Aworking area of1meteristobe keptfree bothinfront ofand behind the machine inoperation
sothat the machine isalwayseasilyaccessible.
Neverreachintothe sewing area whilesewing!Dangerofinjurybythe needle!
Neverleaveobjectson the tablewhileadjusting the machine settings!
Objectscan becometrapped orbe slung away!Dangerofinjury!
Do not operatethe machine withoutsupport1!Dangerdue totop-heavysewing head!
Machine can tipoverbackwordswhen tilted!
www.garudan.cz

Safety
——————————
Switchthe machine off beforetilting it backwards!
Dangerofinjury if the machine isstarted accidently!
Do not operatethe machine wihoutitstake-up-leverguard2!
Dangerofinjury due tothe motion of the take-uplever!
Onmachineswiththread lubricator, onlyoperatethe machine withtheeyeguard3lowered!
The eyeguard3protectsthe eyesfromoilparticlesfromthe thread lubrication!
Do not operatethe machine withoutbelt guard4!
Dangerofinjury byrotating drivebelt!
Do not operatethe machine withouttiltlock5!
Dangerofcrushing between sewing head and tabletop!
www.garudan.cz

2Properuse
GP-724-108 I sadouble-needle, high-speed post bed sewing machine withdriven feed
wheeland rollerpresser.
GP-710-148 Isasingleneedle,high-speed post bed sewing machine(post tothe rightof
the needle)withdriven feed wheeland rollerpresserand synchronized
needle.
The machinesareused forsewing lockstitchseamsinthe leatherand upholstery industries.
Anyuseof thesemachineswhichisnot approvedbythe manufacturershallbe
considered asimproperuse!The manufacturershallnot be liableforanydamage
arising out ofimproperuse!Properuseshall alsobe considered toinclude
compliancewiththeoperation,adjustment,serviceandrepairmeasuresspecified by
the manufacturer!
www.garudan.cz

3Specifications
3.01 GP-710, GP724
Stitchtype................................…...….....…......301 (lockstitch)
Clearacne underrollerpresser.....………….............7mm
Clearancewidth....................................................................... 245 mm
Clearanceheight.............…....................................................... 115 mm
Post height ....................................................................... 180 mm
Sewing head dimensions
Length.........................…............................................ approx.615 mm
Width................................................................….......approx.240 mm
Height (abovetable).......................…..........approx. 500mm
Bedplatedimensions……..................................…............ 518 x177 mm
Max.speed
GP-710,GP-724 Model…………................................ 3000spm◆
Connection data
Operating voltage................................................230 V±10%, 50/60 Hz
Max.powerconsumption ......................…...........................1.2kVA
Fuseprotection .......................................…............... 1x16 A,insert
Noisedata
Emission sound levelatthe work placeat appropriatespeed
DIN45 635-48-A-1,ISO11204, ISO3744, ISO4871)
(Noisemeasurement inaccordancewithDIN45 635-48-A-1, ISO11204, ISO 3744,ISO4871)
H962 and H961 at aspeed of2400spm…………………….…..LpA =79 dB(A) ■
Net weight ofsewing head ...........................…........approx.61 kg
Gross weight ofsewing head...........…......................approx.71 kg
▲Subjecttoalteration
◆Dependentonmaterial, workoperationand stitchlength
■KpA=2,5dB
www.garudan.cz

3.02 Needles andthreads
▲orsimilarstrengthsofothertypesofthread
3.03 Possiblemodelsandsubclasses
Additionalequipment
Subclass-D………………….…………………………………..Automaticedge trimmer
Subclass-D3…….Automaticedge trimmer,automaticpresserfootlifter,backtacker.
(Nm) GP-710 GP-724
1/100mm
40/3 90 134 134-35
Model
Thread
thickness ▲
(Nm)max. Needle thickness GP-710 GP-724
Synthetics 1/100mm Needlesystem Needlesystem
40/3 90 134 134-35
www.garudan.cz

4Explanationofsymbols
Inthisinstruction manual, work tobe carried outorimportantinformation isaccentuated bysymbolswhichhavethe
following meanings:
Note,information
Cleaning,care
Lubrication
Maintenance, repairs, adjustment,servisework
(onlytobe carried out bytechnical staff)
www.garudan.cz

5Controls
5.01 Keysonthemachinehead (onlyformachineswith-D3)
●Aslong askey 1ispressed
during sewing, the machine sewsinreverse
direction.
●Keys 2can be used forparametersettings,
Instruction manualofelectroniccontrol.
5.02 Bobbinthreadmonitoringwithstitchcounting
Machineswithout–D3/..
●About 100 stitchesbeforereachingthe preset
numberof stitches, LED 1Flashes.
●Afterthe thread hasbeen trimmed and the bobbin
changed, The stitchcounting beginsanew.
Presetting the numberofstitches, see
Instruction manualofelectroniccontrol.
5.03 Pedal
0 =Neutralposition
1 =Sewing
2 =Raiserrollerpresser(on machineswith-D3..)
3 =Trimsewing threads(on machineswith-D..)
61-006
www.garudan.cz

5.04 Leverforlifting rollerpresser
●The rollerpressercan be raised byturning lever1.
5.05 Kneelever
●The rollerpressercan be raised bypressing the
knee lever 1inthe direction of the arrow.
5.06 Keyforsetting stitchlength
●The stitchlengthisset bypressing key 1and turning
the balancewheel(see Chapter 7.08 Settingthe
stitchlength).
www.garudan.cz

5.07 Swing out rollerpresser
●Whenthe rollerpresserisraised, itcan be swung
out bypulling itlightlydownwards.
www.garudan.cz

6Installationand commissioning
The machine must onlybe installed and commissioned byqualified personnel!
Allrelevant safetyregulationsmust be strictlyadhered to!
If the machineisdelivered withoutatable, besuretouseastand and tabletopthatcanholdthe
weight of the machine withitsmotor.
It isvery importanttoensurethat the stand ofthe machine isfirmand steady, alsoduring
sewing.
6.01 Installation
The sitewherethe machine isinstalledmust be provided withsuitableconnectionsforelectric
current.
It must beensured that the standing surfaceofthe machine siteisfirmand horizontal,and that
sufficientlighting isprovided for.
Forpacking and transportation reasonsthe tabletop isinthelowered position.The
tableheightisadjusted asdescribed below.
6.01.01Adusting the table height
●Loosen screws 1and 2and set the tableheightasrequired.
●Firmlytightenscrew 1.
●Set therequired pedal position and tighten screw 2
www.garudan.cz

6.02.01 Fittingthe reel stand
lFitthe reel stand asshownin Fig.
●Afterwardsinsert the stand inthe holeof the table
top and secureit withthe nutsprovided.
6.02.02Fitting the tilt lock
6.02.03Fitting the machine cover
www.garudan.cz

6.02.04Mounting theflange motortothe bearingplate
6.02.05 Mounting the flange motortothe machine
www.garudan.cz

6.02.06
6.02.07 Mounting the belt guardofthe flange motor
●Inthispositionfit toofhed belt1.
●Swing the bearing plate2of the motor,sothatthe toothed belt istensioned.
●Inthispositiontightenscrews3.
www.garudan.cz

6.02.08 Connectingthesafetyswitch
6.01 Commissioning
6.02 ●Check the machine, particularlythe electrical wriringforanydamage.
●Clean the machine thoroughtlyand then oil it orfill oilin (see Chapter 11 Care and
maintenance).
●Haveamechaniccheck whetherthe motorofthe machine can be operated withthe
availablepowersupply, and thatthe motoriscorrectlyconnected inthe junctionbox.If
thereareanydiscrepancies. the machine mustnotbeoperatedunder any
circumstances.
The machine onlybe connected toan earthed socket!
●Whenthe machine isrunning,the balancewheelmustturntowardsthe operator.Ifitdoes
not, the motorconnection must bechanged byamechanic.
●Machineswithpneumaticequipment must be connectedtothe compressed airsupply.
The pressuregauge shouldindicateapressureof6bar. If necessary, adjust tothe
correct setting (see Chapter 11.07 Checking adjusting theairpressure).
●Connectplug 1ofsafetyswitch2as
shownin Fig.
Whenthesewing headis
tiltedback,thesafetyswitch
preventsthemachinestarting
whenthemainswitchison.
www.garudan.cz

6Installation andcommisioning
6.04 Tiltedworkbase
6.05 Tiltedworkbase
6-4
www.garudan.cz

6.06 Mountingthetabletop
www.garudan.cz

Preparation
——————————
7Settingup
Allinstructionsand regulationsinthisinstrution manualmust be
observed .
Special attention must be paidtoallsafetyregulations!
Allsetting-up work mustonlybe carriedoutbypersonnelwiththeappropriatetraining.
Forallsetting-up work the machine must be disconnected fromitspowersupplyby
turning off the on/off switch, or
removing the plug fromthe electricpowersocket.
7.01 Insertingneedleonmodel GP710-108
Switchthe machine off!
Dangerofinjuryifthe machine isstarted
accidentally!
Onlyuseneedlesofsystem 134
●Raisethe rollerpresser 1and swing it out.
●Loosen screw 2and insertthe needlesasfaraspossible.
The long groovemustfacetolefton model GP-710.
●Tighten screw 2and swing roller
presser 1back toposition.
The Choiceofneedledependson the modelofthe machine and the thread and materialused (see Chapter
3.02 Needles and threads).
www.garudan.cz
