INTRODUCTION
SBI INC., one of the most important wood stove and fireplace manufacturers in Canada,
congratulates you on your purchase and wishes to help you get maximum satisfaction
from your wood stove. In the pages that follow, we will give you advice on wood heating
and controlled combustion as well as technical specifications regarding installation,
operation and maintenance of the model you have chosen.
The instructions pertaining to the installation of your wood stove comply with ULC-S627
standards.
Read this entire manual before you install and use your new stove. If this stove is
not properly installed, a house fire may result. To reduce the risk of fire, follow the
installation instructions. Failure to follow instructions may result in property
damage, bodily injury, or even death.
Consult your municipal building department or fire officials about restrictions and
installations requirements in your area and the need to obtain a permit.
Keep this instructions manual for future references.
CAUTIONS:
•HOT WHILE IN OPERATION.KEEP CHILDREN,CLOTHING AND FURNITURE AWAY.CONTACT MAY
CAUSE SKIN BURNS.
•DO NOT USE CHEMICALS OR FLUIDS TO IGNITE THE FIRE.
•DO NOT LEAVE THE STOVE UNATTENDED WHEN THE DOOR IS SLIGHTLY OPENED.
•DO NOT BURN WASTES,FLAMMABLE FLUIDS SUCH AS GASOLINE,NAPHTHA OR MOTOR OIL.
•DO NOT CONNECT TO ANY AIR DISTRIBUTION DUCT OR SYSTEM.
•ALWAYS CLOSE THE DOOR AFTER THE IGNITION.

3
TECHNICAL SPECIFICATIONS
MODEL
TEST STANDARDS
HEAT OUTPUT RANGE
SHIPPING WEIGHT
COOK TOP HEIGHT
COOK TOP WIDTH
DEPTH
MINIMUM NON-COMBUSTIBLE
HEARTH SIZE
FIREBOX SIZE
DOOR OPENING SIZE
RECOMMENDED LOG SIZE
FLUE OUTLET
OPTIONS
OSBURN 1000
1. ULC S627 (CSA B366.2) RESIDENTIAL
2. UL 1482 RESIDENTIAL
3. AS/NZS 4013:1999 AS/NZS 2918:2001
6,000 -41,000 BTU/HR
BTU/HR OUTPUT WILL VARY WITH CORD WOOD
USAGE DEPENDING ON THE TYPE AND CONDITION OF
CORD WOOD USED.
122.5 KG (270 LB)
700 MM (27 1/2")
610 MM (24")
495 MM (19 1/2")
1016 MM X 1194 MM (40" X 47")
.042 M3(1.5 FT3)
209 MM X 394 MM (8 3/8" X 15 3/4")
152 MM X 406 MM (6" X 16")
152 MM (6") DIAMETER
-FAN
-OUTSIDE COMBUSTION AIR KIT

4
DOOR ADJUSTMENT
In order for your stove to operate properly, the door should be adjusted periodically to
provide an air tight fit. To adjust:
•Remove the lock pin (spring pin) by pulling and turning it using pliers ("wise grip")
•Turn the handle counter clock wise one turn to increase pressure
•Re-install the lock pin (spring pin) with a small hammer
Figure 1: Door Adjustment
THE BENEFITS OF INSTALLING A BLOWER
A blower can be installed at the back of your OSBURN stove. This option is necessary if
you wish to redistribute into a room the heat trapped at the back of your stove. By forcing
hot air toward the front, the blower enables you to extend the radiation power of your
stove. You can purchase this option through your OSBURN dealer.
