Gasmate CS4095 User manual

02934 08/12
Important: Retain these instructions for future use
Turbo Four Burner
Camping Stove
CS4095
Product Features:
• Taketheconvenienceofyour
 homestovewithyouinthe
great outdoors!
• Fourindependentburners;
 combinedoutputof
 16,500BTU
• Durablepowdercoatednish
• Lowpressureappliance– 
 completewithhoseandregulator
• Operatesonpropanegas
• Foroutdooruseonly
• AGAcertied

2
3
Gas Installation Codes
•Appliancesmustbeusedinaccordancewiththe
 installationrequirementsofyourgassupply
 authority,ortheAustralianStandardAS5601.
•Appliancesforusewithbottledgasarelabelled
 ‘propanegas’.
Clearances
MinimumClearancesfromcombustiblematerials
mustbe:
Rear-180mmAbove-600mm
Hose & Regulator Safety
Theregulatorandhoseassemblysuppliedwiththe
appliancearesuitableforpropanegasonly.
Agasregulatoradjustedtohaveanoutlet
pressureof2.75kPAissuppliedforconnectionto
thepropanegascylinder.Thepressureregulator
andhoseassemblysuppliedwiththeappliance
mustbeused.Replacementpressureregulators
andhoseassembliesmustbethosespeciedby
theappliancemanufacturer.
Whenconnectingthehoseandregulatorassembly
tothegascylinder,takecaretoavoidunnecessary
twistingorkinkingoftheexiblehose.
Aftertheassemblyhasbeensecured,turnonthe
gasandcheckforleaksbybrushingasoapand
watersolutionoverallconnections.
Ifyouareunabletocorrecttheleakbytightening
the connections, turn off the gas and contact the
supplierimmediately.
Alwaysensuretheapplianceiskeptawayfrom
ammablematerialsandthegascylinderclear
ofanyheatsource.Whenchangingoverfrom
anemptygascylindertoafullonemakesure
thisprocedureiscarriedoutinawell-ventilated
location,preferablyoutsideawayfrompeopleand
anysourcesofignition,suchasnakedames,
pilotames,electricheaters/equipment.

Specicationscanbefoundonthedatalabel
attachedtothebody.Hoseconnectionthreadis
GENERAL INFORMATION 3/8”BSP.
Gas Cylinder Use & Safety
Thisapplianceshallonlybeusedwithapropane
gascylindercertiedtoAS2469.
ITMAYBEHAZARDOUSTOATTEMPTTOFIT
OTHERTYPESOFGASCONTAINERS.
Gascylindersshouldbestoredoutdoorsinawell
ventilatedareaoutofreachofchildren.Anyindoor
storageshallcomplywithAS/NZS1596.
Onlyusethehoseassemblyassuppliedwiththis
applianceforconnectiontothecylinder-DONOT
USEADAPTORS.
Maximumhoselengthis100cm.
Afteruse,turnthegascylindervalveoff,waitfor
theametogoout,andthenturntheappliance
controlvalve(s)off.
Avoidtwistingorkinkingtheexiblehose.
Ifthereisaleakonyourappliance(smellofgas)
immediatelyattempttoturnoffthecylindervalve.
Removetheappliancetoawellventilatedlocation
awayfromanyignitionsource.Checkforleaks
usingsoapywater.Donottrytodetectleaksusing
aame.
Ifyoustoreyourapplianceindoors,ALWAYS
disconnectthecylinderrstandstoreitsafely
outside.Cylindersmustbestoredoutdoorsina
wellventilatedareaoutofreachofchildren,and
mustnotbestoredinabuilding,garageorany
otherenclosedarea.
Location of your Appliance
DONOTuseyourapplianceingarages,porches,
sheds,breezeways,orotherenclosedareas.Your
barbecueistobeusedOUTDOORS.Theappliance
isnotintendedtobeinstalledinoronrecreational
vehiclesand/orboatsandshouldnotbeplaced
underanysurfacethatwillburn.Donotobstruct
theowofcombustionandventilationairaround
theouterhousing.
Protect Children
Keepchildrenawayduringuseanduntilappliance
hascooledafteryouhavenished.Donotallow
childrentooperateappliance.
Alwaysensurethatnosportingorphysical
activitiesarecarriedoutincloseproximitytothe
applianceduringuseandwhilestillhot.

2
3
WARNING
USE OUTDOORS ONLY
 
 
with the appliance before connecting
 
 
 • Failuretocomplywiththeseinstructions
 couldresultinareorexplosionwhich
 couldcauseseriousbodilyinjury,deathor
 propertydamage.
 • Turnoffgassupplyatthecylinderafteruse.
 • Partssealedbythemanufacturerortheir
 agentmustnotbemanipulatedbytheuser.
 • Donotmodifythisappliance.
 • Neveroperatethisappliancewithout
 aregulator.
 • Ensurethegashoseisnotincontactwith
 theappliance.
If you smell gas:
 1.Shutoffgastotheapplianceatitssource,
 ifpossible.
 2.Extinguishanyopename.
 3.Ifodourcontinues,immediatelycallyour
 gassupplierorredepartment.
 • Important:Theappliancecontrolknobs
 mustbeinthe‘OFF’positionbeforeopening
 thecylindervalve.
 • Onlyuseinwellventilatedareas.
 •
Carbon monoxide hazard: Thisappliance
 canproducecarbonmonoxidewhichhas
 noodour.Usingitinanenclosedspace(for
 example:caravan,tent,car,mobilehome)
 maycausedeath.
 •Thisappliancemustnotbeusedindoors.
•Donotstoreorusepetrolorother
ammableliquidsinthevicinityofthis
oranyotherappliance.
•Donotstoreemptyorfullsparegas
cylindersnearthisoranyotherappliance.
•Keepthegashoseawayfromhotsurfaces
andprotectfromdrippinggrease.Visually
inspectthehosepriortoeachusefor
cracks,excessivewearorotherdamage.
Replacethehoseifnecessary.
•Nevertestforgasleakswithalitmatch
oropename.Checktoensurethe
burnertubeisfullyseatedovergasvalveorice.
•Neveralterormodifytheregulatororgas
supplyassembly.
•Ensuretheapplianceissetuponalevel
andstablesurface.
•Donotmovethisapplianceduringuseor
whenhot.
•Accessiblepartsmaybeveryhot.
•Keepyoungchildrenaway.
•Alwaysuseprotectivegloveswhenhandling
hotcomponents.
•Checkthatthesealsbetweentheappliance
andthegascylinderareinplaceandingood
conditionbeforeconnectingthegascylinder.
•DONOTUSEthisapplianceifithasdamaged
orwornseals.
•DONOTUSEthisapplianceifitisleaking,
damagedordoesnotoperateproperly.
•Duringusethesideandtopsurfaces
maybeDonotallowthehosetocome
intocontactwiththebodyorlidduringuse.
Nominal Hourly Gas Consumption
Gas Type Number of
Burners
Injector
Size
Total Gas
Consumption
MJ/h
Gas
Pressure
kPa
Propane
Small-1 0.48mm 3.2MJ/h
2.75kPaMedium - 2 0.53mm 4.4MJ/h
Large-1 0.59mm 5.2MJ/h

4
5
GENERAL ASSEMBLY
Connecting & Disconnecting to
the gas source
Familiariseyourselfwiththegeneralinformation
andsafetyguidelineslocatedatthefrontof
thismanual.
Note:Removeanytransitprotectionmaterial
Check:
1.Thecylinderislled.Asloshingsoundwillbe
 heardwhenshaken.
2.Theburnercontrolsareinthe‘OFF’position
Connecting:
1.Ensurecylindervalveisinitsfulloffposition.
2.Checkforanydamagetoeitherthecylinder
 connectionorthehose.NEVERattempttouse
 damagedequipment.
3.Whenconnectingthehosetothecylinder
 tightenthenuttoapositivestopbyhand
 orspanner.
4.Leaktestallconnectionswithasoapy
 watersolution.
5.Locatethegascylinderasafedistanceaway
 fromtheapplianceensuringthatthehoseisnot
 incontactwiththelidorbody.
Disconnecting:
1.Ensuretheburnercontrolsareinthe
 ‘OFF’position.
2.Ensurecylindervalveisinthefulloffposition.
Lighting the Stove
1.Turnthecontrolknobanti-clockwise1/4ofa
 turnandlightwithamatchorcigarettelighter.
2.Theamecanberegulatedfromhightolow.
LOW
OVEN GAS CONTROL FULL DOT INDICATES BURNER

4
5
OPERATING PROCEDURE
CARE & MAINTENANCE
Care & Maintenance
Aswithallappliances,propercareand
maintenancewillkeepthemintopoperating
conditionandprolongtheirlife.Byfollowing
thesecleaningproceduresonatimelybasis,your
appliancewillbekeptcleanandworkingproperly
withminimumeffort.
Flash-Back
Spidersandsmallinsectsoccasionallyspin
websormakenestsintheburnertubesduring
warehousingandtransit.Thesewebscanleadto
agasowobstructionwhichcouldresultinare
inandaroundtheburnertubes.
Thistypeofreisknownas‘FLASH-BACK’and
cancauseseriousdamagetoyourapplianceand
createanunsafeoperatingconditionfortheuser.
Althoughanobstructedburnertubeisnottheonly
causeof‘FLASH-BACK’itisthemostcommon
causeandfrequentinspectionandcleaningofthe
burnertubesisnecessary.
Ifreoccursinandaroundtheburner,
immediatelyturnoffgasatitssourceandturnthe
burnercontrolto‘OFF’,waituntiltheappliance
hascooled,thencleantheburnertubesand
burnerports.
Service
Iftheappliancecannotbeadjustedtoperform
correctlyitshouldnotbeuseduntilservicedor
repaired.ContactSitroGroupAustraliaforspare
partsandserviceinformation.
Thisappliancemustonlybeservicedbyan
authorisedperson.
IMPORTANT
  
POSITION FOR LIGHTING AND
 
• Donotleavetheapplianceunattended
 whenalight.
• Donotsmokeatanytimewhenattempting
 toignitetheburner.
WARNING
Bewareofspidersandwasps.Burnertubes
shouldbeinspectedandcleanedperiodically.
Improperinstallation,adjustment,alteration,
serviceormaintenancecancauseinjury
orpropertydamage.Anymodicationsor
adjustmentsmadetotheproductwithout
priorauthorityfromthemanufacturer
willvoidanywarrantyclaims.Readthe
installation,operatingandmaintenance
instructionsthoroughlybeforeinstallingor
servicingthisequipment.
Problem Possible Reason Solution
Burner will not ignite Valveoncylinderisclosed Openvalveoncylinder
Controlknobisclosed Turnknobtohighwhenlighting
Ignitorisfaulty Usealongbarbecuematch
Food is not cooking or
is taking too long
Burner has gone out Checkthatthegasbottleisnot
emptyandre-ignitetheburner
Cookingsurfacewasnotgiven
enoughtimetowarmupbefore
thefoodwasapplied
Removethefoodandgivethe
burnertimetowarmthecooking
surface(5-10minutes)
Burner operation
Theopeningsatthebaseoftheburnerprovideair
forcombustion,theyshouldneverbeobstructed.
Iftheamebecomessignicantlyorangecheck
theseopeningsforablockage.
Theinjectorscanbecleanedbyremovingthem
andsoakinginpetrol.

6
7
SAFE APPLIANCE LOCATIONS
Thisapplianceshallonlybeusedinanabove
groundopen-airsituationwithnaturalventilation,
withoutstagnantareas,wheregasleakageand
productsofcombustionarerapidlydispersedby
windandnaturalconvection.
Any enclosure in which the appliance is used
shall comply with the following:
Anenclosurewithwallsonallsides,butatleast
onepermanentopeningatgroundlevelandno
overheadcover(seeExample1).
Withinapartialenclosurethatincludesan
overheadcoverandnomorethantwowalls
(seeExample2&3).
DIAGRAMMATIC REPRESENTATIONS OF OUTDOOR AREAS
Thefollowingguresarediagrammaticrepresentationsofoutdoorareas.Rectangularareashavebeen
usedinthesegures–thesameprinciplesapplytoanyothershapedarea.
Within a partial enclosure that includes an
overhead cover and more than two walls, the
following will apply:
atleast25%ofthetotalwallareaiscompletely
open,andatleast30%oftheremainingwallarea
isopenandunrestricted(seeExample4&5).
In the case of balconies, at least 20% of the
total wall area shall be and remain open and


6
7
Thispagehasbeenintentionallyleftblank

8
For any queries or assistance call
Customer Service
(AustraliaOnly)
1300 174 876
Hoursofoperation:
MondaytoFriday8.30am-5.30pmEST

Keepyourpurchasereceipt,thiswillberequiredto
makeanyclaimsunderthe12monthwarranty.
Gasmate®isaregisteredtrademarkof:
SitroGroupAustraliaPtyLtdwww.gasmate.com.au
AberLtd-Hamilton,N.Zwww.gasmate.co.nz
