Gasmate CATERER 4 User manual

1
Model No. BQ1050
Model No. BQ1051
Ideal heavy duty BBQ for sporting and social clubs
or anywhere large groups are entertained
Solid 5mm thick steel hotplate
Castors for easy moving
Stainless steel burners
Removable lid that doubles as a windshield
Foldable side shelves
Universal L.P.G.
Gas Certified to Australian and New Zealand Standards
Important: Retain these instructions for future use.
03339 05/16
Gasmate® is a registered trademark of: Sitro Group Australia Pty Ltd www.gasmate.com.au
Aber Holdings Ltd - Hamilton, N.Z. www.gasmate.co.nz
CATERER
4 & 6 BURNER BBQ

3
2
CONTENTS
Section Page
General Information 2-4
Parts List & Hardware List 5-6
Assembly Instructions 7-11
Care & Maintenance 12
Lighting Procedure 13
Burner Operation & Operating Procedure 14
Safe Appliance Locations 15
GENERAL INFORMATION
Gas Installation Codes
• Barbecues must be used in accordance with the
installation requirements of your gas supply authority,
or the appropriate installation code issued by
Standards Australia AS 5601.
• Barbecues for use with bottled gas are labelled
‘propane gas’ or Universal L.P.G.
• Barbecues for use with natural gas are labelled
‘natural gas’ and must be installed by an authorised
person. Check the gas type sticker attached to the
barbecue.
Clearances
Minimum Clearances from combustible materials
must be:
Rear - 300mm Sides - 300mm Above - 600mm
Hose & Regulator Safety
The regulator and hose assembly supplied with the
barbecue are suitable for Propane Gas or Universal L.P.G
only. A gas regulator adjusted to have an outlet pressure
of 2.75kPA is supplied for connection to the propane
gas cylinder. The pressure regulator and hose assembly
supplied with the barbecue must be used. Replacement
pressure regulators and hose assemblies must be those
specified by the barbecue manufacturer.
When connecting the hose and regulator assembly to the
gas cylinder, take care to avoid unnecessary twisting of
the flexible hose.
After the assembly has been secured, turn on the gas
and check for leaks by brushing a soap and water
solution over all connections.
If you are unable to correct the leak by tightening the
connections, turn off the gas and contact the supplier
immediately.
Always ensure the barbecue is kept away from flammable
materials and the gas cylinder clear of any heat source.
When changing over from an empty gas cylinder to a full
one make sure this procedure is carried out in a flame
free atmosphere.
Specifications
Barbecue specifications can be found on the data label
attached to the barbecue body.
Hose connection thread at gas inlet is 1/4” B.S.P.

3
2
Gas Cylinder Use & Safety
This is a low pressure barbecue and must only be used
with the hose and regulator supplied. Your barbecue
is designed for use with 4.5Kg or 9Kg gas cylinders
certified to AS 2469.
The gas cylinder should be filled by a reputable gas
supplier and visually inspected and re-qualified at each
filling.
Always keep cylinder in an upright position. Always close
the cylinder valve when the barbecue is not in use.
Do not subject gas cylinder to excessive heat.
NEVER STORE YOUR GAS CYLINDER INDOORS.
If you store your barbecue indoors, ALWAYS disconnect
the gas cylinder first and store the cylinder safely outside.
Cylinders must be stored outdoors in a well ventilated
area out of reach of children, and must not be stored in a
building, garage or any other enclosed area.
Location of your Barbecue
DO NOT use your barbecue in garages, porches, sheds,
breezeways, or other enclosed areas. Your barbecue is to
be used OUTDOORS. The barbecue is not intended to be
installed in or on recreational vehicles and/or boats and
should not be placed under any surface that will burn. Do
not obstruct the flow of combustion and ventilation air
around the barbecue housing.
Tools You Will Need
Standard Phillips-head screw driver (or cordless drill and
bits) and Adjustable Spanner.
Check Barbecue for any Damage
Inspect barbecue parts as you proceed with assembly.
Contact your supplier for assistance regarding
replacement of any damaged or missing parts. Do not
assemble or operate a barbecue that appears damaged.
Barbecues for use with gas cylinders are labelled
‘propane gas’ or Universal L.P.G. Check labelling at the
gas connection on your barbecue.
Protect Children
Keep children away from barbecue during use and until
barbecue has cooled after you have finished.
Do not allow children to operate barbecue.
Always ensure that no sporting or physical activities are
carried out in close proximity to the barbecue during use
and while still hot.
FOR YOUR SAFETY
• Do not store or use petrol or other flammable
liquids in the vicinity of this or any other appliance.
• Do not store empty or full spare gas cylinders under
or near this or any other appliance.
• Keep the gas hose away from hot surfaces and
protect from dripping grease. Avoid unnecessary
twisting of hose. Visually inspect the hose prior
to each use for cracks, excessive wear or other
damage. Replace the hose if necessary.
• Never test for gas leaks with a lit match or open
flame. Never light barbecue with hood closed or
before checking to ensure the burner tubes are fully
seated over gas valve orifices.
• Never lean over cooking surface when lighting.
• Never alter or modify the regulator or gas supply
assembly.
• This barbecue must not be used indoors.
• Ensure the barbecue is set up on a level and
stable surface.
• Do not move the barbecue while in use or when
hot. Remove the drip tray before moving.

5
4
WARNINGS
• Failure to comply with these instructions could result
in a fire or explosion which could cause serious
bodily injury, death or
property damage.
• Accessible parts may be very hot.
• Keep young children away.
• Any modifications to this barbecue
may be dangerous.
• Do not move this barbecue during use.
• Turn off gas supply at the cylinder after use.
• Read instructions before using the barbecue.
• Parts sealed by the manufacturer or their agent must
not be manipulated by the user.
• This barbecue is only to be used and
stored outdoors.
• Never operate this barbecue without
a regulator
• Do not test for gas leaks with an open flame
• If this information is not followed exactly, a fire
causing death or serious injury may occur.
• Do not store a spare gas cylinder under or near
this barbecue. Never fill the cylinder beyond 80%
full. This barbecue is only to be used and stored
outdoors.
• If you smell gas
1. Shut off gas to the barbecue at its source, if
possible.
2. Extinguish any open flame.
3. Open hood.
4. If odour continues, immediately call your gas
supplier or fire department.
• Do not connect your barbecue to a gas cylinder
exceeding the 9kg capacity specified.
• Never connect an unregulated gas cylinder to your
barbecue.
• Read carefully before assembling and operating your
barbecue.
Gas Type Length Width Height
4 Burner 1428mm 579mm 956mm
6 Burner 1817mm 579mm 956mm
Nominal Hourly Gas Consumption
Overall Barbecue Dimensions
Including Side Shelves
Model Injector size Total Gas Consumption Gas Pressure Gas Type
BQ1050 0.86 mm 40MJ/h 2.75 kPa U.L.P.G.
BQ1051 0.86 mm 60MJ/h 2.75 kPa U.L.P.G.

5
4
COMPONENTS - 4 BURNER
No. Description QTY
1 Lid Handle 1
2 Lid Hook 1
3 Lid 1
4 Warming Rack 1
5 Hotplate 1
6 Side Shelf 2
7 Side Handle 2
8 Cylinder Hook 1
9 Leg Assembly 2
10 Castor without Brake 2
11 Castor with Brake 2
12 Firebox 1
No. Description QTY
13 Burner 4
14 Cross Igniter 3
15 Burner Support 1
16 Heat Shield 2
17 Control Panel Assembly 1
18 Knob 4
19 Manifold 1
20 Horizontal Tube 2
21 Bottom Rack 1
22 Grease Cup 1
23 Grease Cup Holder 1

7
6
COMPONENTS - 6 BURNER
No. Description QTY
1 Lid Handle 1
2 Lid Hook 1
3 Lid 1
4 Warming Rack 1
5 Hotplate 1
6 Side Shelf 2
7 Side Handle 2
8 Cylinder Hook 1
9 Leg Assembly 2
10 Castor without Brake 2
11 Castor with Brake 2
12 Firebox 1
No. Description QTY
13 Burner 6
14 Cross Igniter 5
15 Burner Support 1
16 Heat Shield 2
17 Control Panel Assembly 1
18 Knob 6
19 Manifold 1
20 Horizontal Tube 2
21 Bottom Rack 1
22 Grease Cup 1
23 Grease Cup Holder 1

7
6
HARDWARE
IMPORTANT: Remove any transit protection material before use.
TOOLS: Phillips Head Screwdriver
Adjustable Spanner
M6x40mm (x12) M6x12mm (x6) M5x12mm (x8) M6 Shoulder Screws (x8)
ASSEMBLY INSTRUCTIONS
STEP 1
Attach the legs to the body using 8 x M6x40mm screws and the lower support beams using 4 x M6x40mm long
screws. Screw the castors into the legs as shown.
M6x40mm (x12)

9
8
STEP 2
Attach the handles to the top of the legs using 8 x M5x12mm long screws, then attach the cylinder hanging hook and
fat cup holder as shown using 4 x M6x12mm long screws..
M6x12mm (x4)
M5x12mm (x8)

9
8
STEP 3
Attach the folding side shelves as shown using 8 x M6 shoulder screws.
M6 Shoulder Screws (x8)

11
10
STEP 4
Attach the handle to the lid ensuring the lid hook is oriented as shown on the underside using 2 x M6x12mm screws.
The lower wire rack and warming rack can be installed as required.
M6x12mm (x2)
