Gateway 450ROG User manual

Gateway 450 Notebook
Customizing Troubleshooting
serviceguide

i
Contents
1 Replacing Gateway 450ROG Components . . . . . . . . . . . . . . . . . . . . . . . 1
Identifying the notebook model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Identifying components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Preparing your work space . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Preventing static electricity discharge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Preparing the notebook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Disconnecting from the port replicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Removing the batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Removing the main battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Removing the optional secondary battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Adding or replacing memory modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Replacing the IEEE 802.11 Mini PCI card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Replacing the hard drive kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Replacing the hard drive in the hard drive kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Replacing the keyboard cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Replacing the keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Replacing the modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Replacing the LED indicator panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Replacing the cooling assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Replacing the hinge covers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Replacing the LCD panel assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Replacing the palm rest assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Replacing the CMOS battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Replacing the power board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Replacing the system board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

ii

1
Replacing
Gateway 450ROG
Components
Use this service guide to help plan your maintenance tasks
for the Gateway 450ROG notebook. All tasks covered in
this guide can be performed by an authorized field
technician without jeopardizing the notebook’s warranty.
For information on the notebook’s general maintenance,
technical support, safety notices, and regulatory notices,
see the Gateway user’s guide.
If you have suggestions regarding the content of this guide,
send an e-mail with the subject “Service Guide Comments”
to [e-mail].
© 2003 Gateway, Inc. All rights reserved. Gateway, Gateway Country, the Gateway
stylized logo, and the black-and-white spot design are trademarks or registered
trademarks of Gateway, Inc. in the United States and other countries. All other brands
and product names are trademarks or registered trademarks of their respective
companies.
Important This service guide is not intended to be
provided to individual users or consumers.
It cannot be provided to anyone other than
an authorized service provider.

Thank you for purchasing this Factory Service
Manual CD/DVD from servicemanuals4u.com.
Please check out our eBay auctions for more great
deals on Factory Service Manuals:
servicemanuals4u

2
Replacing Gateway 450ROG Components
www.gateway.com
Identifying the notebook model
The label on the bottom of the notebook contains information that identifies
the notebook model and its features.
Warning It is important that you use the correct service guide for
the notebook. Failure to follow the approved tasks for the
notebook model may result in damage to the notebook.
Gateway
model
number

3
Identifying components
www.gateway.com
Identifying components
Where screw measurements are shown, the first number indicates screw head
width, and the second number indicates screw length.
Use this chart to identify the main components of the notebook. For a complete
list of replaceable parts, see the Contents.
LCD panel assembly
(see page 47)
Keyboard
(see page 29)
Palm rest assembly
(see page 53)
Cooling assembly
(see page 42)
Keyboard cover
(see page 26)
System board
(see page 66)

4
Replacing Gateway 450ROG Components
www.gateway.com
Preparing your work space
Before performing maintenance on the notebook, make sure that your work
space and the notebook are correctly prepared.
■Wear a grounding (ESD) wrist strap, and use a grounded or dissipative work
mat.
■Use a stable and strong table, and make sure that the table top is large
enough to hold each component as you remove it.
■Use bright lighting to make part identification easier.
■Keep your work surface free from clutter and dust that may damage
components.
■Use a magnetized screwdriver for removing screws.
■When removing components that are attached to the notebook by a cable,
unplug the cable before removing the screws, when possible, to avoid
damaging the cable.
■As you remove components and screws, lay them toward the rear of your
work surface (behind the notebook) or far enough to the side that your
arms do not accidentally brush them onto the floor.
■To help keep track of screws, try the following:
■Place each component’s screws in their own section of a parts sorter.
■Place each component’s screws next to the component on your work
surface.
■Print the first page of each task, then place the page toward the rear
of your work surface. As you remove screws, place the screws in their
respective boxes on the page. Where screw measurements are shown,
the first number indicates screw head width, and the second number
indicates screw length.
■After loosening screws that are deeply recessed in a hole (for example,
on the bottom of the base assembly), you can leave the screws in the
holes if you place small pieces of masking tape over the hole openings.
When reassembling the component, just remove the tape and tighten
the screws.
■When you place flat-headed screws on your work surface, stand them
on their heads to prevent the screws from rolling off the table.

5
Preventing static electricity discharge
www.gateway.com
Preventing static electricity
discharge
The components inside the notebook are extremely sensitive to static electricity,
also known as electrostatic discharge (ESD).
Before replacing components, follow these guidelines:
■Turn off the notebook.
■Wear a grounding wrist strap (available at most electronics stores) and
attach it to a bare metal part of your workbench or other grounded
connection.
■Touch a bare metal surface on your workbench or other grounded object.
■Unplug the power cord and the modem and network cables.
■Remove the main and optional secondary batteries. For more information,
see “Removing the batteries” on page 8.
■Disconnect all peripheral devices and remove any PC Cards.
Warning ESD can permanently damage electrostatic
discharge-sensitive components in the notebook. Prevent
ESD damage by following ESD guidelines every time you
open the notebook case.
Warning To avoid exposure to dangerous electrical voltages and
moving parts, turn off the notebook and unplug the power
cord and modem and network cables before opening the
case.
Warning To prevent risk of electric shock, do not insert any object
into the vent holes of the notebook.

6
Replacing Gateway 450ROG Components
www.gateway.com
Before working with notebook components, follow these guidelines:
■Avoid static-causing surfaces such as carpeted floors, plastic, and packing
foam.
■Remove components from their antistatic bags only when you are ready
to use them. Do not lay components on the outside of antistatic bags
because only the inside of the bags provide electrostatic protection.
■Always hold components by their edges. Avoid touching the edge
connectors. Never slide components over any surface.
Preparing the notebook
To prepare the notebook for maintenance:
■Make sure that the modular drive is empty.
■Disconnect all peripheral devices and remove any PC Cards.
■Turn off the notebook and unplug the power cord and modem and network
cables (if attached).
■Disconnect the notebook from the optional port replicator. For more
information see “Disconnecting from the port replicator” on page 7.
■Turn over the notebook and remove the main and optional secondary
batteries. For more information see “Removing the batteries” on page 8.
Warning To avoid exposure to dangerous electrical voltages and
moving parts, turn off the notebook, remove the main and
optional secondary batteries, and unplug the power cord
and modem and network cables before opening the case.
Replace the cover before you restore power or reconnect
the modem and network cables.

7
Disconnecting from the port replicator
www.gateway.com
Disconnecting from the port
replicator
To separate the notebook from the port replicator:
1Press down on both docking release latches. The notebook will spring up
slightly.
2Lift the notebook off of the port replicator.

8
Replacing Gateway 450ROG Components
www.gateway.com
Removing the batteries
Removing the main battery
To remove the main battery:
1Disconnect the AC adapter and modem and network cables and prepare
the notebook by following the instructions in “Preparing the notebook”
on page 6.
2Disconnect the notebook from the optional port replicator by following
the instructions in “Disconnecting from the port replicator” on page 7.
3Turn the notebook over so the bottom is facing up.
4Slide the battery release latch and lift the battery out of the bay.

9
Removing the batteries
www.gateway.com
Removing the optional secondary battery
To remove the secondary battery:
1Disconnect the AC adapter and modem and network cables and prepare
the notebook by following the instructions in “Preparing the notebook”
on page 6.
2Disconnect the notebook from the optional port replicator by following
the instructions in “Disconnecting from the port replicator” on page 7.
3Turn the notebook over so the bottom is facing up.
4Slide and hold the modular bay latch closest to the back of the notebook.
5Slide the other modular bay release latch. The battery moves out slightly.

10
Replacing Gateway 450ROG Components
www.gateway.com
6Slide the battery out.

11
Adding or replacing memory modules
www.gateway.com
Adding or replacing memory
modules
Tools you need to complete this task:
Important Use only memory modules designed for the
Gateway 450ROG.
Phillips #0 screwdriver
Memory
bay

12
Replacing Gateway 450ROG Components
www.gateway.com
To add or replace memory modules:
1Disconnect the AC adapter and modem and network cables and prepare
the notebook by following the instructions in “Preparing the notebook”
on page 6.
2Disconnect the notebook from the optional port replicator by following
the instructions in “Disconnecting from the port replicator” on page 7.
3Turn the notebook over so the bottom is facing up.
4Remove the main and optional secondary batteries by following the
instructions in “Removing the batteries” on page 8.
5Loosen the captive screw that secures the memory cover. (The screw cannot
be removed.)
6Lift the screw side of the cover upward, then slide the cover out.

13
Adding or replacing memory modules
www.gateway.com
7If you are removing a module, gently press outward on the clip at each
end of the memory module until the module tilts upward.
8Pull the memory module out of the slot.

14
Replacing Gateway 450ROG Components
www.gateway.com
9Hold the new or replacement module at a 30-degree angle and press it into
the empty memory slot. This module is keyed so it can only be inserted
in one direction. If the module does not fit, make sure that the notch in
the module lines up with the tab in the memory slot.
10 Gently push the module down until it clicks in place.
11 Replace the memory bay cover and tighten the cover screw.

15
Replacing the IEEE 802.11 Mini PCI card
www.gateway.com
Replacing the IEEE 802.11
Mini PCI card
Tools you need to complete this task:
To replace the IEEE 802.11 Mini PCI card:
1Disconnect the AC adapter and modem and network cables and prepare
the notebook by following the instructions in “Preparing the notebook”
on page 6.
2Disconnect the notebook from the optional port replicator by following
the instructions in “Disconnecting from the port replicator” on page 7.
3Turn the notebook over so the bottom is facing up.
Caution By law, only approved wireless modules provided by
Gateway, or a Gateway authorized representative,
explicitly for the Gateway 450ROG may be installed in this
notebook.
Caution Legal requirements dictate that a security screw (or other
means) be used to attach the mini-PCI cover to the chassis
in a manner that restricts end user access. End users are
strictly prohibited from having access to the wireless card.
Due to manufacturing process changes, Gateway 450ROG
notebooks manufactured after August 7, 2003 require a
Torx head security screw to attach the mini-PCI cover.
Caution Legal requirements dictate the mini-PCI cover be in place
during any and all operation of the notebook’s wireless
feature.
Phillips #0 screwdriver
-OR-
Torx T8 screwdriver
