Specifications for the
Gateway M675 Notebook
Specifications are subject to change without notice or obligation.
Processor and Core Logic
Processor options One Intel®Pentium 4™CPU with Hyper-Threading
technology
To determine your notebook’s processor speed:
■In Windows XP, click Start, My Computer, then click
View System Information. The processor is listed.
-OR-
■In Windows 2000, click Start, Programs,
Accessories, System Tools, then click System
Information. The processor is listed.
Processor packaging Intel socketable uFCPGA
Level 2 cache 512 KB
Core logic Intel 865PE, ICH5
Processor side bus speed 800 MHz Processor System Bus
BIOS ■Phoenix BIOS
■512 KB Flash ROM
■SMBIOS 2.3 support
■Advanced Configuration and Power Interface 1.0b
(ACPI 2.0) support
■Wired for Management 2.0 (WfM 2.0)

2www.gateway.com
System memory
Memory type ■333 MHz DDR SDRAM
-OR-
■400 MHz DDR SDRAM
Memory expansion options ■Two 200-pin industry standard DDR-SODIMM sockets
■Accepts two PC2700/PC3200 DDR SDRAM memory
modules
■2 GB maximum system memory
■No on-board memory
To determine your notebook’s memory:
■In Windows XP, click Start, My Computer, then click
View System Information. The memory is listed.
-OR-
■In Windows 2000, click Start, Programs,
Accessories, System Tools, then click System
Information. The memory is listed.
Video
Graphics controller ■ATI M10-P graphics processor
■2D hardware acceleration
■3D rendering acceleration
Video memory ■128 MB DDR-SDRAM
-OR-
■64 MB DDR-SDRAM
LCD display panel 15.4-inch active matrix (TFT) LCD color display
Maximum panel resolution: 1280 ×800 (WXGA)
Maximum color depth: 32-bit (16.7 million colors)
17.1-inch active matrix (TFT) LCD color display
Maximum panel resolution: 1440 ×900 (WXGA)
Maximum color depth: 32-bit (16.7 million colors)
LCD supported video modes WXGA
LCD maximum refresh rate 60 Hz
Controls ■Brightness level selectable through FNkeys (up, down)
■Auto dim on battery
■Auto bright on AC power
External video ■Supports dual display and extended desktop
■Integrated TV encoder

3
Specifications for the Gateway M675 Notebook
www.gateway.com
External CRT resolutions Supports standard IBM VGA compatible modes
Maximum resolution: 2048 ×1536
Maximum color depth: 32-bit (16.7 million colors)
External CRT maximum refresh rate 75 Hz
TV out (S-Video) jack Supports NTSC/PAL connection to standard TV monitors
with S-Video jack on notebook and port replicator
IEEE 1394 ■One 4-pin connector
■100/200/400 mbps
■Supports video and audio capture
■Software included for motion and still-frame capture
Audio
Audio chipset Sigmatel®Soft Audio 6-channel AC97 rev 2.3 codec
(STAC9758)
Sound support ■PCI interface audio
■Multi-stream Direct Sound and Direct Sound 3D
acceleration
■SoundBlaster Pro, MIDI, Windows Sound System
compatible, MP3, WMA
■S/PDIF output for PCM or AC-3 content through
mini-DIN on notebook or through Toslink jack on port
replicator
■PCI Power Management Interface (PPMI) 1.1
compliant
NOTE: This notebook does not have an internal
microphone.
Digital DVD audio Provides full 5.1 channel Dolby Digital output (AC-3)
from DVD decoder through mini-DIN on notebook or
through Toslink jack on port replicator.
Volume controls ■Volume control buttons on front of notebook
■Volume control keys on keyboard
■Software control provided through Windows
Internal speakers ■Stereo speakers built into front of notebook
■1.5 W maximum output
Audio jacks ■Stereo headphone output
■Stereo line input
■Monophonic microphone input

4www.gateway.com
Communications
Modem features ■Integrated Ambit AC 97 Soft V.92/56K data/fax modem
■Uses the RJ-11 jack on the back of the notebook
■Supports Wake on Ring from S3 power mode
10/100/1000 Mbps Ethernet interface
features
■Integrated Intel 82547EI IEEE 802.3 (10/100/1000
BASE-TX) Ethernet interface
■Uses the RJ-45 jack on the back of the notebook
■Supports Wake on LAN from S3 power mode
Wireless Ethernet interface features
(Factory installed option)
■Broadcom BCM94306 IEEE802.11g/b network card
embedded in the notebook
-OR-
■Broadcom BCM94300 IEEE802.11a/b/g network card
embedded in the notebook
Antenna: Uses factory-installed internal antenna
assembly
Operating channels: 11 selectable channels
Security: 128 and 64 bit WEP encryption
Operating Frequency
■2.4 GHz Direct Sequence Spread Spectrum
(IEEE 802.11b and IEEE 802.11g)
■5.0 GHz (IEEE 802.11a)
Maximum Data Rate
■54 Mbps (IEEE802.11g and IEEE 802.11a)
■11 Mbps (IEEE802.11b)

5
Specifications for the Gateway M675 Notebook
www.gateway.com
Input/Output (I/O)
Keyboard ■U.S. English keyboard
■Full-sized 83-key keyboard
■Full-sized 21-key keypad
■19 mm × 19 mm key pitch
■3.0 mm keystroke
Pointing device ■Gateway EZ-Pad™touchpad
■2-buttons plus scroll wheel
Multifunction buttons Five “hot keys” that turn on and off wireless Ethernet
emitter, and launch e-mail, Web browser, help
application, and My Computer
Status indicators ■Battery status
■Power/Suspend
■Hard drive access
■Left modular bay access
■Right modular bay access
■Caps lock
■Scroll lock
■PAD lock
Input/Output (I/O) ports ■Four USB 2.0 (4-pin)
■Parallel (bi-directional, EPP, ECP)
■IEEE 1394 (4-pin)
■V.92, 56K Modem (RJ-11)
■10/100/1000 Ethernet (RJ-45)
■External monitor (VGA)
■Three universal audio jacks supporting microphone,
headphone, stereo in, stereo out, S/PDIF in, and
S/PDIF out
■S-Video TV out
■PC Card socket (one Type II)
■Docking port
■DC input
PCMCIA ■Accepts one Type II device
■TI 4510 controller
NOTE: This notebook does not support Zoomed Video.

6www.gateway.com
Docking Solution
Type Port replicator
Docking supported ■Hot dock
■Warm dock
■Cold dock
Input/Output (I/O ports) ■Two PS/2
■Three USB 2.0 (4-pin)
■S-Video TV out
■External monitor (VGA)
■Parallel
■High-speed serial
■Modem (RJ-11)
■Ethernet (RJ-45)
■S/PDIF digital audio out
■Five universal audio jacks supporting microphone,
headphone, stereo in, and stereo out (including
surround sound)
■Docking port
■DC input
Storage
Hard drive controller Supports up to Ultra DMA 100 and up to PIO mode 4
Hard drive ■User removable
■2.5-inch diameter
■9.5 mm height
To find the hard drive capacity:
■In Windows XP, click Start, then click My Computer.
Right-click the drive letter, then click Properties. The
drive’s capacity and available space appears. If the
drive has multiple partitions (for example, C: and D:),
add the capacities of each partition to determine the
drive’s total capacity.
-OR-
■In Windows 2000, double-click the My Computer icon
on your Windows desktop. Right-click the drive letter,
then click Properties. The drive’s capacity and
available space appears. If the drive has multiple
partitions (for example, C: and D:), add the capacities
of each partition to determine the drive’s total capacity.

7
Specifications for the Gateway M675 Notebook
www.gateway.com
Super I/O controller ■NS PC87391 LPC super I/O controller
■Diskette drive controller
■IEEE 1284 compliant parallel port
Modular bays Two modular bays are available on the notebook.
Supports hot swapping of both bay devices:
■From taskbar
■Through an electrical switch
Optical Drive (right modular bay only)
To determine the type of optical drive in a bay, examine
the drive tray’s plastic cover. A CD Compact Disc logo
indicates a CD drive, a DVD logo indicates a DVD drive,
a CD-R/RW logo indicates a recordable/rewritable CD
drive, a DVD logo in combination with a CD-R/RW logo
indicates a DVD drive that also is a recordable/rewritable
CD drive, and a DVD-ROM/R/RW logo in combination
with a CD-R/RW logo indicates a recordable/rewritable
DVD drive that also is a recordable/rewritable CD drive.
Available drives include:
■CD
■DVD
■CD-RW
■Combination DVD/CD-RW
■DVD-RW/CD-RW
■DVD±R/±RW/CD-RW
Second Hard Drive (left or right modular bay)
■2.5-inch diameter
■9.5 mm high
Diskette Drive (left modular bay only)
■12.7 mm high
■3.5-inch diskettes
■720k/1.2MB/1.44MB support
Memory card reader (left modular bay only)
Supports the following card types:
■CompactFlash®
■IBM Microdrive™
■Memory Stick®
■MultiMediaCard™
■Secure Digital™
■SmartMedia™

8www.gateway.com
Power
Intelligent charger Supports dynamic charge current to achieve the best
charge performance
AC adapter ■19 VDC, 7.9A, 150 W output
■Automatically adjusts for 100 to 240 VAC, 50 to 60 Hz
power sources
■Three-wire design
Battery type ■Removable Lithium Ion battery pack
■Embedded controller inside to support smart battery
Battery capacity 12-cell Li-Ion
■6.6 Ah
■14.8 V nominal
■97 Wh
Battery life varies depending on configuration, programs,
power management settings, and features used.
Recharge time varies, depending on usage.
Power management ■Advanced Configuration and Power Interface 1.0b or
later (ACPI 2.0 or later) support
■SMBIOS 2.3
■PC 2001 compliant
Controls ■Keyboard-activated pop-up display gives battery
charge as a percentage remaining
■Icon on taskbar shows battery charge as a percentage
remaining
Power switch Power On/Off, Suspend/Resume, or Hibernate
Reset hole Resets whole system if notebook cannot recover by
power switch
Lid switch LCD On/Off, Suspend/Resume, or Hibernate
Security
Passwords ■Power-on password (2-level password support)
■Hard drive password
Physical ■System memory compartment screws
■Hard drive kit screw
■Kensington®security slot on notebook side

9
Specifications for the Gateway M675 Notebook
www.gateway.com
System software
Operating system ■Microsoft®Windows®XP Professional
■Microsoft®Windows®XP Home Edition
■Microsoft®Windows®2000
System management ■SMBIOS 2.3 BIOS support
■Advanced Configuration and Power Interface 1.0b
(ACPI 2.0) support
■Support for Wake on LAN from S3 power mode
■Support for Intel®LANDesk®Client manager 6.0
■Wired for Management 2.0 (WfM 2.0) enabled
System compatibility ■PC2001 specification
■Advanced Configuration and Power Interface 2.0
(ACPI 2.0) or later
■SMBIOS 2.3
■Windows Hardware Quality Labs (WHQL) certified
Quick boot Supported
Physical specifications
Dimensions ~1.5 ×15.7 ×10.6 in. (H ×W×D)
~38.5 ×400 ×270 mm (H ×W×D)
System weight ~8.8 lbs.
~4.0 kg
Includes Diskette drive, DVD drive, and 12-cell battery
AC adapter weight ~1.5 to 2.25 lbs
~0.7 to1.0 kg
Includes cord
Environment
Operating temperature 41°F to 95°F (5°C to 35°C)
Storage temperature -4°F to 140°F (-20°C to 60°C)
Operating humidity 20% to 80% relative humidity; no condensation
Storage humidity 10% to 90% relative humidity; no condensation
Operating altitude, maximum 8,000 feet at 59°F (2,438 meters at 15°C)
Storage altitude, maximum 12,000 feet (3,658 m)
