Advanced Patient Care Male Catheterization Simulator is an interactive
educational system developed to assist a certied instructor. It is not a
substitute for a comprehensive understanding of the subject matter and not
intended for clinical decision making.

2 | User Guide | Obstetric Susie®|

| Advanced Birthing Simulator®| User Guide | 3
Care and Cautions
Overall Warnings .................................................................................................. 5
General ................................................................................................................................................ 5
Storage ................................................................................................................................................ 5
Cleaning .............................................................................................................................................. 5
Getting Started
Overview................................................................................................................ 7
Appearance ......................................................................................................................................... 7
Simulator ............................................................................................................................................. 7
Other.................................................................................................................................................... 7
Contents................................................................................................................ 7
Terminology .......................................................................................................... 7
Equipment Set Up
Filling the Sacs. ................................................................................................................................... 9
Working with the Simulator
Simulator Features............................................................................................. 11
Bladder Catheterization ..................................................................................................................... 11
Male Catheterization ......................................................................................................................... 12
Rectal Examination............................................................................................................................ 12

4 | User Guide | Care and Cautions |
Care and Cautions

| Care and Cautions | User Guide | 5
Overall Warnings
Damage caused by misuse may void the
manufacturer’s warranty. Failure to comply with
the following guidelines may result in injury or
damage to the equipment. Additional warnings
are found throughout the document.
GENERAL
This simulator is constructed of material that
approximates skin texture. Therefore, in handling
the model, use the same gentle techniques as
you would in working with a patient.
Do not wrap this or any other Gaumard product
in newsprint.
Indelible marks made with ballpoint pens, ink or
marker cannot be removed.
Do not use alcohol, acetone, Betadine® or any
other antiseptic which contains iodine in this or
any Gaumard® simulator. These products could
damage or stain the skin of the simulator.
STORAGE
Improper storage may damage the simulator.
Keep it stored in the box and/or bag provided.
Store the simulator in a cool, dry place.
Extended storage should be between 32 - 85
degrees F (0-29 Celsius). Other temperatures
will cause the simulator to soften and slowly
warp.
Do not stack or store heavy materials on top
of the box and/or bag.
It is acceptable to operate the simulator at an
ambient temperature of 95 degrees Fahrenheit
(35 Celsius).
CLEANING
Clean the skin of the simulator after every
training session. The skin should be cleaned
with a cloth, dampened with diluted liquid dish
washing soap.
Do not clean with harsh abrasives.
Dry thoroughly.
The simulator is “splash-proof” but not water-
proof. Do not submerge or allow water to enter
the interior of the simulator.

6 | User Guide | Getting Started |
Getting Started

| Getting Started | User Guide | 7
Overview
The S230.7 Advanced Patient Catheterization
Simulator is an advanced training tool useful to
illustrate the following procedures:
• Male Catheterization
• Rectal Examination (Palpations)
The simulator is equipped with the following
features:
APPEARANCE
• Medium skin tone is the standard simulator
color; light or dark skin is available at no extra
cost.
SIMULATOR
• Full-size adult lower torso with leg stumps
OTHER
• One year limited warranty
Contents
Item Quantity Description
1 1 Real size lower human
torso with male genitalia
2 1 Internal suprapubic bag
3 1 Internal inatable bag with
squeeze bulb
41Mounted external/auxiliary
tank
51 Silicone oil bottle
61Metal stand with acrylic
base
7 2 Stoppers
8 1 Soap packet
91 Clamp
10 1 Instruction manual
11 1 Soft carrying bag
Terminology
FACILITATOR - the person conducting the
simulation; an instructor or lab staff member.
PROVIDER - a person participating in the
simulation as a healthcare provider.

8 | User Guide | Equipment Set Up |
Equipment Set Up

| Equipment Set Up | User Guide | 9
FILLING THE SACS.
1. Place the Male Catheterization Simulator in
the location where it will be demonstrated
2. Fill the external bladder tank with water and
position it on the stand next to the simulator,
ensure the clamp is tightened.
3. Insert the hose from the external bladder
tank to the simulator’s abdominal port.
4. To ll the internal bladder tank, raise the
external bladder tank above the simulator and
open the clamp.
5. When the water transfer has been
completed, put the auxiliary tank back on the
stand, apply the clamp and disconnect it from
the simulator.
6. Use the stopper to plug the open port on
the abdomen.

10 | User Guide | Working with the Simulator |
Working with the
Simulator

| Working with the Simulator | User Guide | 11
Simulator Features
BLADDER CATHETERIZATION
One of the most important elements of nursing
care is bladder catheterization, i.e. the removal
of urine from the bladder by the introduction of a
catheter. The S230.7 was designed with realistic
features that permit bladder catheterization
training. The simulator allows catheterization
in the seated or recumbent position. Internal
mechanisms of the simulator permit the
instructor to:
• Teach catheterization techniques.
• Familiarize trainees with male external
anatomy.
• Feel resistance during insertion of catheter.
• Feel simulated bladder contraction.
The gure below shows a simulated male
bladder catheterization with the use of a urinary
catheter.
DIRECTIONS FOR USE
When practicing catheterization, the penis must
be manipulated to permit the passage of the 18
Fr urinary catheter.
1. Collect items required for procedure, and
move simulator to desired position and
location.
2. Position a urine “catch-basin” below the
penis. The drain end of the catheter will lead
to here.
3. Please refer to “Filling the Sacs” in Chapter 3
“Equipment Set Up” to prepare the simulator
for use.
4. Apply lubricant to catheter.
5. Continue procedure following aseptic
technique.
Always lubricate the catheter using
silicone lubricant. Failure to lubricate
the catheter will damage the internal
valves and cause leakage.
SIMULATING BLADDER CONTRACTION
Bladder catheterization exercises may also be
carried out with the aid of an auxiliary tank placed
upon a stand near the simulator, to simulate
bladder contraction. Fill the tank with water,
apply the clamp and attach to the suprapubic
stoma of the simulator. The elevation of the tank
and loosening of the clamp provides gravity
feed of the uid to simulate bladder contractions
when catheter is inserted.
When you get a good feel for increasing the
urinary outow with the squeeze bulb, you may
also utilize it for simulating contractions.
INCREASING URINARY OUTFLOW
Bladder catheterization exercises may also
be carried out with the aid of the airbag and
squeeze bulb located in the anterior of the
manikin. Squeezing the bulb with the air valve
closed will cause the internal airbag to inate
and press upon the internal bladder tank,
simulating contraction.

12 | User Guide | Working with the Simulator |
The valve may be turned to open in order to
release air from the internal airbag.
WARNING
When inating the internal airbag with
the squeeze bulb, be careful to not
over-inate as this may damage the
airbag.
MALE CATHETERIZATION
The urethra is connected to an internal
urinary bladder. Leakage is minimized through
removable internal valves located between the
urethra opening and the bladder. Training on
asepsis and disinfection is also possible.
Apply silicone oil to the catheter tip
before catheterization.
RECTAL EXAMINATION
Rectal wall can be palpated using the simulator.

| Appendix | User Guide | 13
Appendix

14 | User Guide | Appendix |
Warranty
EXCLUSIVE ONE-YEAR LIMITED WARRANTY
Gaumard warrants that if the accompanying Gaumard product proves to be defective in material or
workmanship within one year from the date on which the product is shipped from Gaumard to the
customer, Gaumard will, at Gaumard’s option, repair or replace the Gaumard product.
This limited warranty covers all defects in material and workmanship in the Gaumard product, except:
Damage resulting from accident, misuse, abuse, neglect, or unintended use of the Gaumard product;
Damage resulting from failure to properly maintain the Gaumard product in accordance with Gaumard
product instructions, including failure to property clean the Gaumard product; and
Damage resulting from a repair or attempted repair of the Gaumard product by anyone other than
Gaumard or a Gaumard representative.
This one-year limited warranty is the sole and exclusive warranty provided by Gaumard for
the accompanying Gaumard product, and Gaumard hereby explicitly disclaims the implied
warranties of merchantability, satisfactory quality, and tness for a particular purpose. Except
for the limited obligations specically set forth in this one-year limited warranty, Gaumard will not
be liable for any direct, indirect, special, incidental, or consequential damages, whether based on
contract, tort, or any other legal theory regardless of whether Gaumard has been advised of the
possibilities of such damages. Some jurisdictions do not allow disclaimers of implied warranties or the
exclusion or limitation of consequential damages, so the above disclaimers and exclusions may not
apply and the rst purchaser may have other legal rights.
This limited warranty applies only to the rst purchaser of the product and is not transferable.
Any subsequent purchasers or users of the product acquire the product “as is” and this limited warranty
does not apply.
This limited warranty applies only to the products manufactured and produced by Gaumard.
This limited warranty does not apply to any products provided along with the Gaumard product that
are manufactured by third parties. For example, third-party products such as computers (desktop,
laptop, tablet, or handheld) and monitors (standard or touch-screen) are not covered by this limited
warranty. Gaumard does not provide any warranty, express or implied, with respect to any third-party
products. Defects in third-party products are covered exclusively by the warranty, if any, provided by
the third-party.
Any waiver or amendment of this warranty must be in writing and signed by an ofcer of Gaumard.
In the event of a perceived defect in material or workmanship of the Gaumard product, the rst
purchaser must:
Contact Gaumard and request authorization to return the Gaumard product. Do NOT return the
Gaumard product to Gaumard without prior authorization.
Upon receiving authorization from Gaumard, send the Gaumard product along with copies of (1) the
original bill of sale or receipt and (2) this limited warranty document to Gaumard at 14700 SW 136
Street, Miami, FL, 33196-5691 USA.
If the necessary repairs to the Gaumard product are covered by this limited warranty, then the rst
purchaser will pay only the incidental expenses associated with the repair, including any shipping,
handling, and related costs for sending the product to Gaumard and for sending the product back
to the rst purchaser. However, if the repairs are not covered by this limited warranty, then the rst
purchaser will be liable for all repair costs in addition to costs of shipping and handling.
Extended Warranty In addition to the standard one year of coverage, the following support plans are
available: Two-Year Extension (covers second and third years)
Call for pricing (USA only)

Contact Us
E-mail Technical Support: [email protected]
Before contacting Tech Support you must:
1. Have the simulator’s Serial Number
2. Be next to the simulator if troubleshooting is needed.
E-mail Sales and Customer Service: [email protected]
Phone: Toll-free in the USA: [phone]
Worldwide: 01 [phone]
Fax: [phone]
Post: Gaumard Scientic
14700 SW 136 Street
Miami, FL 33196-5691
USA
Ofce hours: Monday-Friday, 8:30am - 4:30pm EST (GMT-5, -4 Summer Time)
General Information
Gaumard®, ZOE®, Michelle®, Mike®, PEDI®, Susie Simon®, Susie®, Simon® Code Blue®, SIMA
Models®, SIMA GYN/AID®, Virtual Instruments®, Codemaker®, Code Blue®, NOELLE®, Simulation
Made Easy™, HAL®, CPRLink™, Zack™, RITA™, Chloe™, Seatbelt Susie™, Krash Kids™, Premie™,
GIGA®, Omni®, SmartSkin™ are Trademarks of
© Gaumard Scientic Company, 2013
All rights reserved.
Gaumard®, NOELLE®, HAL® are trademarks of Gaumard Scientic Company, Inc.
Patented; Other Patents Pending
Always dispose of this product and its components in compliance with local laws and regulations.
