Gazer CKR4400 User manual

USER MANUAL
SURROUND VIEW CAMERA SYSTEM
Gazer CKR4400/4400-ххх/4413-ххх

ENG
RU
UA
User manual _______________________________________________________________________________________________4-21
Руководство пользователя _________________________________________________________________________________22-39
Посібник користувача _____________________________________________________________________________________40-57

4
ENG
Contents
Warning ............................................................................................................................................................................................... 5
Important information ........................................................................................................................................................................... 6
Package contents .................................................................................................................................................................................. 7
Controls................................................................................................................................................................................................ 9
Installation ......................................................................................................................................................................................... 11
Setting up procedures.......................................................................................................................................................................... 13
Usage................................................................................................................................................................................................. 17
Specifications...................................................................................................................................................................................... 21

5
ENG
Warning
Congratulations on your purchase of Gazer surround view camera system.
Please, read this manual carefully before using the device.
Precautions:
• Avoid hitting, dropping and damaging the cameras and the central control unit mechanically.
• Do not attempt to repair the device yourself. In case of malfunctions, contact the vendor or the service center.
• Do not use switching units and wiring from other devices when installing the system. Failure to observe this precaution may result in
system malfunction.
• To install and connect the system without voiding your vehicle warranty, please contact an authorized service station.
• Neither the manufacturer nor the vendor shall be responsible for any damages or lost profit due to the use or loss of information obtained
with this device.
• The manufacturer reserves the right to change product specifications and/or configuration without prior notice.

6
ENG
Important information
Gazer surround view DVR system consists of 4 video cameras and a special video processing unit that merges the video feed from all
cameras into a single panoramic image. You can see everything that happens around the car on the monitor in real time and in “plan view”
without any blind spots. The DVR function allows recording video from each camera separately storing it on a micro SD card or a USB drive.
The model range of Gazer surround view systems comprises:
• Gazer CKR4400 universal surround view system designed for installation in any car model, includes the universal video cameras;
• Gazer CKR4400-ххх* surround view systems with stock video cameras designed for standard installation in a car;
• Gazer CKR4413-ххх* surround view systems designed for standard installation in a car, includes the stock video cameras and a special
video interface for direct Plug&Play connection to the car’s original head unit.
6
T
he model ran
g
e of Gazer surround view systems comprises:
•Gazer CKR4400 universal surround view system desi
g
ned for installation in any car model, includes the universal video cameras;
• Gazer CKR4400-ххх* surround view systems with stock video cameras desi
g
ned for standard installation in a car;
•Gazer CKR4413-ххх* surround view systems desi
g
ned for standard installation in a car, includes the stock video cameras and a special
v
ideo interface for direct Plu
g
&Play connection to the car’s ori
g
inal head unit.
*“ххх” in the name of the device indicates its compatibility with a specic car model.

7
ENG
Package contents
Control unit Rear view camera
(red jack)
User manual
Front view camera
(black jack)
Additional connection cable
Сonnection cable
for the control unit
Remote IR receiver
Right side view camera
(white jack)
Remote control
Left side view camera
(yellow jack)
CutterGazer micro SDHC memory card
Gazer CKR4400 surround view camera system package contents

8
ENG
Package contents
Control unit Rear view camera
(red jack)
User manual
Front view camera
(black jack)
Сonnection cable
for the video interface
(for Gazer CKR4413-ххх)
Сonnection cable
for the control unit
*Depending on the model appearance and the number of assembly components may vary.
Remote IR receiver
Right side view camera
(white jack)
Remote control
Left side view camera
(yellow jack)
Additional connection
cable (for Gazer
CKR4413-xxx)
Video interface for
connecting to the original
head unit (for Gazer
CKR4413-xxx)
Gazer micro SDHC
memory card
Gazer CKR4400-ххх/4413-ххх surround view camera system package contents*

9
ENG
The central unit controls
1-2. LED indicator:
blinking light – system power on;
constant light – system is operating.
3. Socket connection.
4. Switch panel.
5. Micro SD card slot.
Controls

10
ENG
Description the remote control
1. Turn the system on/off.
2. Return to the previous menu.
3. Enter the menu;
confirm selection – in menu mode;
start/pause playback – in viewing mode.
4. Navigate through the menu;
select a camera for viewing.
5. Save settings.
6. Select parameter – in menu mode;
skip forward – in viewing mode.
7. Entering data.
8. Select parameter – in menu mode;
skip back – in viewing mode.
ОК
0
123
456
789
1 2
3
4
5
6
7
8
Controls

11
ENG
Camera mounting
Rear view camera: The rear view camera is to be mounted at least
40 cm above the ground. Depending on the model of the system,
camera can be mounted: in a standard location (for Gazer CKR4400-
ххх and Gazer CKR4413-xxx models) instead of the license plate
light housing (with the light function preserved) or instead of the
trunk handle (with the button function preserved); using a universal
“butterfly” mount (for Gazer CKR4400 model).
Front view camera: The front view camera is to be mounted
at least 40 cm above the ground. Depending on the model of the
system, the camera can be mounted: in a standard location (for Gazer
CKR4400-ххх and Gazer CKR4413-xxx models) instead of the front
car emblem or in a stock mounting seat; using a universal “butterfly”
mount (for Gazer CKR4400 model).
Side view cameras: Side view cameras are to be mounted at least
40 cm above the ground. Depending on the model of the system,
cameras can be mounted: in a standard location (for Gazer CKR4400-
ххх and Gazer CKR4413-xxx models) instead of the lower parts of
wing mirrors; inside wing mirrors (for Gazer CKR4400 model).
To mount universal side view cameras, one needs to make 2 symmetrical holes in the left and right wing mirrors. Once the cameras are
mounted, adjust the viewing angle as shown in the diagram below:
Camera tilt
Camera
placement
Left side view
camera
Right side
view camera
Rear view
camera
Front view
camera
Fig. 2
Installation

12
ENG
Central control unit mounting
Once the cameras are mounted, connect them to the central control unit observing the color of connection wires (Fig. 3).
Mount the central control unit in the front of the vehicle (under the steering column or under the driver’s seat). For correct operation of the
G-sensor function, fix the central control unit tightly on the car body or any other stationary part of the car interior. Make sure you put the
USB cable in an easy-to-reach place. This way you will not have any trouble connecting a USB drive and copying video files.
Blue cable for
monitor control
Black
Yellow
Red
Pink
Orange
Green
GND
BAT+
ACC+
Left turn signal
Right turn signal
Reverse gear signal
4
5
6
7
8
2
3
1
9
1. Blue cable for monitor
control: switch-over to view a
surrоund video review (+12V).
2. USB port: USB drive
connection for copying video
files and updating firmware.
3. Black 3.5 mm jack: remote
control receiver connection.
4. Yellow AV jack: monitor
connection.
5. Black 4-contact jack: front
view camera connection.
6. Yellow 4-contact jack: left
side view camera connection.
7. White 4-contact jack: right
side view camera connection.
8. Red 4-contact jack: rear
view camera connection.
9. Power and control socket.
Fig. 3
Installation

13
ENG
Note: To activate the CCTV parking mode, set switches No. 1 and No. 2 in “Down” position.
Attention! When installing switches No. 1 and No. 2 to the “Down” position and switches No. 3 and No. 4 to the “Up” position, a built-
in G-censor will be not active.
Setting up CCTV parking mode
Gazer surround view system supports CCTV function in a parked car. When this function is activated, the system stops operating after ACC
signal is off and plays back a 120 second video recording only if the shock sensor (G-sensor) is tripped. Car battery discharge control function
will prevent the car battery from a critical discharge: the system will shut down completely at 11.7 V until ACC signal is on again.
Use the switches on the device control unit to adjust the system further.
Switch No. 1 (“Up” position): force system shutdown after ACC signal is off.
Switch No. 2 (“Up” position): disable car power system voltage control (set at 11.7 V).
Switches No. 3 and No. 4: shock sensor (G-sensor) sensitivity adjustment. To adjust the shock sensor (G-sensor) sensitivity, set the
switches as shown in the diagram below:
G-sensor
Switch
№1№2№3№4
Off UpUpUpUp
Level 1 Down Down Down Up
Level 2 Down Down Up Down
Level 3 Down Down Down Down
Setting up procedures

14
ENG
Caution! The distance from the front sheet to side sheets (P1, P2) as well as distances S1 and S2, O1, and O2 must be the same
(P1=P2; S1=S2; O1=O2).
System calibration
To ensure that information from each camera is displayed correctly and the feed from all cameras is merged into a single “plan view”, one
needs to calibrate the device before use. This requires: tape measure - 5 m (2 pcs) and 7.5 m (2 pcs); 1.6 m x 1.2 m calibration sheet (4 pcs).
To calibrate the system, follow the steps below:
1. Place calibration sheets in front of each camera as shown in the diagram below (Fig. 4). Red marks on the front and rear calibration
sheets must be aligned with the car’s central axis. Red marks on side calibration sheets must be aligned with the car’s wing mirrors
(mounting seats inside the mirrors).
2. Measure distances L, W, P1,and P2 (Fig. 4)
Fig. 4
P1
P2
S1
S1=S2
P1=P2
O1=O2
S2
O1
O2
Setting up procedures

15
ENG
Fig. 6
Fig. 7 Fig. 8
Fig. 5
3. Use the remote control to turn on the system, then go to the settings menu, select “Calibration” (Fig. 5) and enter password: 301530
(Fig. 6).
4. Go to “Calibr.” (Fig. 7) and view video feed from each camera consecutively using navigation buttons on the remote control. Make sure
that the image produced by the cameras matches the one on the diagram below (Fig. 8).
Left side view camera Right side view camera
Front view camera Rear view camera
Car body Car body
Car body Car body
Setting up procedures

16
ENG
5. After adjusting the camera view, go back to the previous menu using the “Back” button on the remote control. Enter L (Length), W
(Width), P (Pan) values in the corresponding fields in accordance with your data and then select “Аuto” (Fig. 9) in the menu. In case
calibration was successful, you will see a panoramic “plan” view of your car without any blind spots (Fig. 9).
Fig. 9
Note: In case of incorrect calibration, repeat the procedure.
Recommendation: Cameras must be mounted at least 40 cm above the ground. Follow this recommendation at all times to avoid
system malfunction.
Setting up procedures

17
ENG
Fig. 10 Fig. 11
Note: Current consumption is less than 12 mA in the parking mode when the device is in the standby mode.
DVR function
Settings menu
Gazer surround view system has a 4-channel DVR function that enables it to record 704х576 videos at 30 fps. Video is recorded continuously
thanks to the loop recording function. The system switches to the recoding mode automatically when ACC signal is on or when the shock
sensor is tripped in the parking mode.
Video clips are stored on a micro SD memory card or a USB drive. To view and manage recorded video files, go to “Record” in the menu and
select the required file from the list. To select or change the storage location of your video files, go to “Recording”/“Storage Location” and
then select the appropriate value.
“Record”: recorded files list. When selecting the required video file from the list, you can block it from loop overwriting. To do this, press the
“Left” button on the remote control and then select “Lock” in the settings menu.
Usage
“Recording”: recording, date and time settings.
“Channel”: select the source of recording. One can select a signle camera or four cameras simultaneously.
“Storage Location”: select a storage device for saving recorded video clips (SD memory card or USB drive).
Note: Do not eject the SD memory card or USB drive when the device is on. This may cause it to malfunction.

18
ENG
“Control”: system startup settings.
“Start by emergency signal”: 3 seconds after the car’s hazard warning button is pressed the system will turn on and display the image on
the monitor.
“Start by ACC”: the system will turn on and display the image on the monitor when the ignition key is turned (АСС “Accessories” signal is
on). The system will shut down only after ACC signal is off.
“Start by light signal”: the system will power on and display the image on the monitor when the car’s turn light is on.
“Rear gear turn off delay”: adjust the screen timeout after the reverse gear is off.
Note: It is possible to adjust the automatic screen timeout in “Start by emergency signal”, “Start by ACC”, “Start by light signal” menu
items.
Fig. 12 Fig. 13
Usage

19
ENG
“Calibration”: camera calibration settings (see “Calibration”, p. 14-16).
“System Setting”: screen setup and save settings menu.
Fig. 14
Fig. 15
Usage

20
ENG
“Language”: interface language selection.
“Output Format”: switch between PAL/NTSC video formats (make appropriate adjustments if your multimedia device supports only PAL or
NTSC).
“Left”/“Right”/“Top”/ “Bottom”: set image position in relation to monitor borders. Make appropriate adjustments if the image is
displayed incorrectly.
“Distance”: adjust the car’s scale on the display in relation to the environment (select an appropriate value from 06 to 25).
“Offset V”/“Offset H”: adjust the car’s vertical and horizontal offset in relation to the center of the monitor.
“Sideview”: adjust video feed display from each camera. This menu allows adjusting the viewing angle, scale and offset of each camera. To
do this, select a camera and adjust “Offset V”, “Offset H”, “Zoom setting”.
Note: “Trendline”, “Trajectory Reversal” and “Line offset” menu items are available for the rear view camera only.
Fig. 16 Fig. 17
Usage

21
ENG
Central unit
RAM 256 Mb, DDR2
Interfaces micro SD, USB
DVR function Yes
Recording format H.264
1 minute recording size (from 4 cameras
simultaneously) 15 Mb
4-channel recording Yes
Video signal format PAL/NTSC
G-sensor Yes, 3 sensitivity levels
Parking mode Yes, G-sensor activated recording
Car’s on-board power system voltage control Yes, complete system shutdown at 11.7V
Power DC 12V
Current consumption <500mA
Operating temperature -20°C ~ +70°C
Cameras
Sensor 1/3”
Effective pixels 720х480
TVL 580
Viewing angle 180°
Minimal luminance 0,1 Lux
Protection level IP67
Operating temperature -30°C ~ +70°C
Specications
