GBT FP-1336-18 Mounting instructions

ASSEMBLY INSTRUCTION
Figure 2
ASSEMBLY INSTRUCTION
Figure 1
Step 1
With assistance from other adults, place the Big shelf(C) face
down on a soft smooth surface. Insert the tenons of Connection
wood(O) into the corresponding holes of Big shelf(C). Secure
them with Bolt(H2), Spring washer(H3) , Flat washer(H4) and
Allen wrench(H5). DO NOT fully tighten bolts in this step for
later adjustment. As shown in Figure 1.
Step 2
With assistance from other adults, place the Big shelf(C) face
down on a soft smooth surface. Insert the tenons of Top rail(N) into
the corresponding holes of Big shelf(C). Secure them with
Bolt(H2) and Allen wrench(H5). DO NOT fully tighten bolts in
this step for later adjustment. As shown in Figure 2.
H2
H5
C
N
C
O
O
H2
H3
H4
H5

ASSEMBLY INSTRUCTIONASSEMBLY INSTRUCTIONASSEMBLY INSTRUCTION
Step 4
With assistance from other adults, put the Top(A) upside down on
the smooth and soft surface, make the smooth side of Front rail(F)
facing the front of the product, insert the tenons of Front rail(F) into
the holes of Top(A). Then attach them with Bolt(H2) by using
Allen wrench(H5). Do not tighten all bolts in this step for later
adjustment. As shown in Figure 4.
Step 3
With assistance from other adults, hold the Right partition(I)
vertically, slightly move parts to make the tenons of Big shelf( C)
correspondingly insert into the holes of Right partition(I). Then
attach them with Flat washer(H4), Spring washer(H3) and Bolt(H2)
by using Allen wrench(H5). Do not tighten all bolts in this step for
later adjustment. Attach the Left partition(H) onto the Big shelf( C)
by the same way, As shown in Figure 3.
H2
H5
A
F
F
A
H2 H3
H4
H5
H
I
C
I
C
The smooth side of Front rail(F).
Figure 4
Figure 3

ASSEMBLY INSTRUCTION ASSEMBLY INSTRUCTIONASSEMBLY INSTRUCTION
Step 5
With assistance from other adults, slightly move parts to make the
tenons of Left and Right partition(H & I) correspondingly insert
into the holes of Top(A), then attach them with Flat washer(H4),
Spring washer(H3) and Bolt(H2) by using Allen wrench(H5). Do
not tighten all bolts in this step for later adjustment. As shown in
Figure 5.
Step 6
With assistance from other adults, slightly move parts. The side
with groove on the Side post(G) should face down. Make the
tenons of Side post(G) correspondingly insert into the holes of
Top(A), then attach them with Flat washer(H4), Spring washer(H3)
and Bolt(H2) by using Allen wrench(H5). Do not tighten all bolts
in this step for later adjustment. As shown in Figure 6.
H2
H3
H4
H5
H
I
C
A
A
H2
H3
H4
H5
H
I
C
A
G
G
A
H
The side with groove
should face down.
Figure 5 Figure 6

ASSEMBLY INSTRUCTION ASSEMBLY INSTRUCTIONASSEMBLY INSTRUCTION
Step 8
With assistance from other adults, turn the mantel upright as
directed in the figure. As shown in Figure 8.
Step 7
With assistance from other adults, slightly move parts to make the
tenons of Side post(G) and Left and Right partition(H & I)
correspondingly insert into the holes of Base(B), then attach them
with Flat washer(H4), Spring washer(H3) and Bolt(H2) by using
Allen wrench(H5). Tighten all other bolts except the bolts that
attached the Side post(G) for later adjustment. Tighten all other
bolts (step1-7) in this step. As shown in Figure 7.
H
I
G
G
C
A
B
B
H
G
H2
H3 H4
H5
H5
H4H3
H2
Figure 7 Figure 8

ASSEMBLY INSTRUCTION ASSEMBLY INSTRUCTION
Not provided
Figure 13
Step 13
Let the holes of Hinge(H1) match the punctures on the Right
door(K) as shown in figure, then attach them with Flat head
screw(H10) using screwdriver(not provided). Please tighten
screws in this step. Repeat the above step to install Hinge(H1) to
Left door(J). As shown in Figure 13.
K
H1
H10
K
Figure 14
Step 14
With assistance from other adults, let the holes of Hinge(H1) of the Right
door(K) match the punctures on the Side post(G) and then attach them
with Flat head screw(H10) using screwdriver(not provided). Please
tighten screws in this step as shown in Figure 14. Attach Left door(J)
onto Side post (G) by the same way. As shown in Figure 14.
Not provided
H10
K
H1
K
J
GB
A
G
B
J
