INSTALLATION / USER MANUAL

CC15250TBX/R1

G1500072 (Full Feature module)

G1500127 (Limited Feature module)

15” Std Brightness LCD monitor

This technical literature is subject to change.

Please contact NCR Display Engineering / GDS before designing product based on this

information.

This manual should be read in conjunction with Technical Specification SPE?????.

This document and information herein is the property of Global Display Solutions Ltd. and all

(UK).

MAN10158_0A 2 of 16

Contents

FCC Notice (U.S. Only) .................................................................................................................. 3

Safety Instructions ........................................................................................................................... 4

Cleaning the LCD Colour Monitor.................................................................................................. 5

Controls ........................................................................................................................................... 5

On-Screen Display Menu ................................................................................................................ 6

Specifications ................................................................................................................................ 10

Display Modes............................................................................................................................... 10

Pin Assignments – Limited Feature Module ................................................................................. 11

Signal - Analogue: 15 way HD VGA connector ....................................................................... 11

USB Mini B connector .............................................................................................................. 11

USB Standard connector ........................................................................................................... 11

Power connector: ....................................................................................................................... 11

Pin Assignments – Full Feature Module ....................................................................................... 12

Signal – Digital: 24 way DVI Female connector (If fitted):...................................................... 12

Power / USB: Plus Power USB connector (If fitted)................................................................. 12

Mechanical Drawings (G1500072) ............................................................................................... 13

Mechanical Drawings cont:........................................................................................................... 14

Mechanical Drawings (G1500127) ............................................................................................... 15

Mechanical Drawings Cont ........................................................................................................... 16

This document and information herein is the property of Global Display Solutions Ltd. and all

(UK).

MAN10158_0A 3 of 16

FCC Notice (U.S. Only)

FCC Class B – Applicable only to Limited Feature connections

This equipment generates, uses, and can radiate radio frequency energy and, if not installed and

used in accordance with the manufacturer’s instruction manual, may cause interference with radio

and television reception. This equipment has been tested and found to comply with the limits for a

Class B digital device pursuant to Part 15 of the FCC Rules.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions:

1 This device may not cause harmful interference.

2 This device must accept any interference received, including interference that may cause

undesired operation.

NOTICE: The FCC regulations provide that changes or modifications not expressly approved by

Global Display Solutions SpA. could void your authority to operate this equipment.

These limits are designed to provide reasonable protection against harmful interference in a

residential installation. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference with radio or television

reception, which can be determined by turning the equipment off and on, you are encouraged to try

to correct the interference by one or more of the following measures:

•Reorient the receiving antenna.

•Relocate the system with respect to the receiver.

•Move the system away from the receiver.

•Plug the system into a different outlet so that the system and the receiver are on different

branch circuits.

If necessary, consult a representative of NCR Corporation or an experienced radio/television

technician for additional suggestions.

The following information is provided on the device or devices covered in this document in

compliance with the FCC regulations:

•Product name: 15” Std Bright LCD Monitor

•Model number: G1500072 (Full Feature Module; All connectors present)

•Model number: G1500127 (Limited Feature Module; DVI Video / USB Plus Power

connectors removed)

•Company name: Global Display Solutions SpA

This document and information herein is the property of Global Display Solutions Ltd. and all

(UK).

MAN10158_0A 4 of 16

Safety Instructions

This model is a LCD display module for building into other equipment. It must be used for no

other purpose.

Read the Safety Instruction carefully and keep it for use later.

Beware of all warning and instruction signs marked on the monitor.

The monitor is designed as a display component for building into other equipment. It must be used

for no other purpose.

The chassis metalwork of the module must be properly bonded to the main earthing termination in

Class I equipment.

Care must be exercised in the application of this monitor to prevent overheating. Ensure that the

ambient temperature around the module does not exceed 50oC and provide adequate means of

ventilation to achieve this.

When cleaning, cut off the electrical supply at all times. Never use liquid or aerosol detergent, use a

soft damp cloth instead.

Never insert anything metallic into the monitor openings. This may create an electric shock hazard.

To avoid electric shock, never touch the inside of the monitor. Only a qualified technician should

open the monitor’s case.

Openings in the monitor cabinet are to allow for ventilation. To prevent overheating, these

openings should not be blocked or covered.

Do not expose the LCD to rain or use it near water. If the LCD accidentally gets wet, disconnect it

from electrical supplies immediately.

If the LCD does not operate normally - in particular, if there are any unusual sounds or smells

coming from it - disconnect it immediately.

Do not put pressure on the LCD panel screen because it is very fragile.

Do not touch the LCD panel with bare hands, the grease from skin is difficult to remove and may

damage the screen.

Always handle the LCD monitor with care when moving it.

Take care that the monitor is disposed of correctly at the end of its life. The CCFL lamps used in the

monitor contain mercury. If in doubt refer to local ordinances or regulations for proper disposal.

This document and information herein is the property of Global Display Solutions Ltd. and all

(UK).

MAN10158_0A 5 of 16

Cleaning the LCD Colour Monitor

1. To clean the LCD panel:

-Wipe the screen gently with a clean lens brush made of camel hair, or a soft, clean,

lint free cloth. This is to remove dust and other particles without scratching the LCD

panel.

-If it is still not clean, then wipe with a damp lint free cloth and blow on it to dry.

2. Do not clean the panel with keton-type material (e.g. acetone), ethyl, toluene, ethyl acid,

methyl, or chloride. These may damage the panel.

3. Do not apply pressure to the panel.

Controls

The controls are three buttons found on the rear of the unit.

Button 1 (Menu) Displays the main menu and the other sub-menus.

Selects the chosen setting or function, and afterwards saves it.

Button 2 (-) Scrolls down the menu and adjusts the level of the control.

Button 3 (+) Scrolls up the menu and adjusts the level of the control.

To make picture adjustments, initially pressing the “Menu” button to bring up the OSD Main Menu.

Then, pressing the “-” or “+” button scroll through the Main Menu to highlight the various

functions. Pressing ”Menu” again selects the required command/sub menu.

If an adjustment has been made, there is no need to use a store command for this new setting as this

will occur automatically.

To exit the menu, select EXIT within the menu structure. If no buttons have been pressed for a short

period of time, the menu will automatically disappear from the screen.

This document and information herein is the property of Global Display Solutions Ltd. and all

(UK).

MAN10158_0A 6 of 16

On-Screen Display Menu

Exit:

Setup:

Picture:

This document and information herein is the property of Global Display Solutions Ltd. and all

(UK).

MAN10158_0A 7 of 16

Colour:

This document and information herein is the property of Global Display Solutions Ltd. and all

(UK).

MAN10158_0A 8 of 16

OSD:

This document and information herein is the property of Global Display Solutions Ltd. and all

(UK).

MAN10158_0A 9 of 16

System

After picture adjustments have been optimized, the settings are memorised automatically. The OSD

menu will disappear after 10 seconds of inactivity (timeout adjustable through the OSD menu) or

the OSD can be exited by selecting EXIT.

•Brightness: regulates the overall level of white light viewable on the

screen.

•Contrast: controls the range between black and white of the image on the

screen.

This document and information herein is the property of Global Display Solutions Ltd. and all

(UK).

MAN10158_0A 10 of 16

Specifications

LCD Panel: 15” AUO G150XG01 V1

Brightness: 350 cd/m2 typical

Contrast: 700/1 typical

Active Display: Horizontal: 304.1mm

Vertical: 228.1mm

Video Signal: Analogue RGB (0.7Vp-p positive into 75Ω)

Digital DVI 24 Pin Female (If fitted)

Sync signal: Separate LVDS sync.

Mechanical Dimensions: 346 (W) x 263 (H) x 43 (D) mm

Weight: 2.0 Kg

Temperatures: Operating temp: from 0 to 50ºC @ 95% RH or less

Storage temp: from -25 to 60ºC @ 95% RH or less

Display Modes

The monitor will accept the following display modes:

Resolution Frequency Phase Hor Width Hori - Pos Vert –Pos

Hori (KHz) Vert (KHz)

PIV0635 640 x 350 31.5 70 50 800 143 60

PIV0740 720 x 400 31.5 70 50 900 158 35

PIV0660 640 x 480 31.5 59.9 46 800 140 34

PIV0672 640 x 480 37.9 72 59 832 164 30

PIV0675 640 x 480 37.5 75 50 840 180 18

PIV0856 800 x 600 32.5 56 12 1024 196 23

PIV0860 800 x 600 37.9 60.3 55 1056 212 26

PIV0872 800 x 600 48 72 42 1040 180 28

PIV0875 800 x 600 46.9 75 35 1056 236 23

PIV1060 1024 x 768 48.4 60 14 1344 292 34

PIV1070 1024 x 768 56.5 70 55 1328 275 34

PIV1075 1024 x 768 60 75 55 1312 267 30

PIV1260 1280 x 1024 64 60 26 1688 355 40

PIV1275 1280 x 1024 80 75 40 1688 386 40

Note that the display is capable of displaying a 12.1” scaled image.

The monitor meets the VESA EDID and plug and play (DDC) standards.

This document and information herein is the property of Global Display Solutions Ltd. and all

(UK).

MAN10158_0A 11 of 16

Pin Assignments – Limited Feature Connections

Signal - Analogue: 15 way HD VGA connector

Pin Function Pin Function

1 Red video 9 +5V supply (DDC)

2 Green video 10 Sync ground

3 Blue video 11 Monitor ID bit 0

4 Monitor ID bit 2 12 SDA (DDC data)

5 Ground 13 Horizontal sync.

6 Red video ground 14 Vertical sync.

7 Green video ground 15 SCL (DDC data)

8 Blue video ground

USB Mini B connector

USB Standard connector

Power connector:

Pin Function

1 +24VDC

2 Ground

This document and information herein is the property of Global Display Solutions Ltd. and all

(UK).

MAN10158_0A 12 of 16

Pin Assignments – Full Feature Connections (not to be used)

Signal – Digital: 24 way DVI Female connector (If fitted):

Pin Function Pin Function

1 DATA2- 13 DATA3+

2 DATA2+ 14 +5V

3 DATA2/4_SHLD 15 GND

4 DATA4- 16 H_PLUG_DET

5 DATA4+ 17 DATA0-

6 DDC_CLK 18 DATA0+

7 DDC_DATA 19 DATA0/5_SHLD

8 A_VSYNC 20 DATA5-

9 DATA1- 21 DATA5+

10 DATA1+ 22 CLK_SHLD

11 DATA1/3_SHLD 23 CLK+

12 DATA3- 24 CLK-

1 8

17 24

Power / USB: Plus Power USB connector (If fitted)

Pin Function

1 Vbus

2 D-

3 D+

4 Ground

5 Ground

6 +12VDC

7 +12VDC

8 Ground

5 8

1 4

This document and information herein is the property of Global Display Solutions Ltd. and all

(UK).

MAN10158_0A 13 of 16

Mechanical Drawings (G1500072)

191919 31

646464

47 220 63

90 102 71

1off R2.6 SLOT

122

4 off R2 SLOTS 4 off M4 x 8 STUDS

346

330

304.10 (ACTIVE AREA) 152.05 13

114.05

228.10(ACTIVEAREA)

131

17 263

43 16

84 149 29

18 18

45 172

23613

16847

29 203

DISPLAYCENTER

1-offR2.6

CLOSED SLOT

This document and information herein is the property of Global Display Solutions Ltd. and all

(UK).

MAN10158_0A 14 of 16

Mechanical Drawings cont:

111

97 128 75.0

330(REFERENCE)

92 75.0

173 23

4 off M4SCREW

ENGAGEMENT 6mm

FROM SURFACE

18 18 18 930 36

127

DUAL USB

SINGLE USB MINI-B

USB 24V DVI VGA

PLUS

POWER

This document and information herein is the property of Global Display Solutions Ltd. and all

(UK).

MAN10158_0A 15 of 16

Mechanical Drawings (G1500127)

131

263

114.05

228.10 (ACTIVEAREA)

45 172

18 18

84 149 29

12.76304.10(ACTIVEAREA)

152.05

330

346

108 128

90 32 70 71 STUDS- M4x8

4-OFF R2

SLOTS

DISPLAY CENTER

47 168

203

47 220 63

3119191919 64646432

This document and information herein is the property of Global Display Solutions Ltd. and all

(UK).

MAN10158_0A 16 of 16

Mechanical Drawings Cont

111 18 36 966

DUAL USB

SINGLE USB MINI-B

USB 24V VGA

92 75.00 95

12.00

128 75.00 127

330(REFERENCE)

263(REFERENCE)

4xM4 SCREW

ENGAGEMENT

6mm FROM SURFACE

This manual suits for next models

Table of contents

Other GDS Monitor manuals

GDS

GDS GasVac LG-1 User manual

GDS

GDS CD15270TBX/24 Instruction Manual

GDS

GDS CD15270TTX/24 Instruction Manual

Popular Monitor manuals by other brands

IBM

IBM 5291 1 Operator's guide

Sharp

Sharp LC-20VM2 Operation manual

Z-EDGE

Z-EDGE U24C user manual

Lenovo

Lenovo ThinkVision 27 3D user guide

AOC

AOC AGON AG275QXN user manual

Iiyama

Iiyama ProLite B1906S-1 user manual

Sharp

Sharp LCD MONITOR user manual

Parker

Parker 71-213 Series Assembly instructions

Touch Dynamic

Touch Dynamic Breeze Touch B13 manual

ViewSonic

ViewSonic ViewBoard S user guide

LG 17MB15P-B owner's manual

Wohler

Wohler RMT-170e-HD user guide

Cochran

Cochran EMC-16 manual

NEC

NEC MultiSync EA192M Outline Drawing

AOC

AOC F22S user manual

Acer

Acer X153W user manual

Samsung

Samsung TFT-S22C150NS user manual

Alpha Communications

Alpha Communications PENTHA GB2 Quick guides

GDS CC15250TBX/R1 Instruction Manual

Popular Monitor manuals by other brands
