GE ASL05 Operating instructions

0www.GEAppliances.com
©
Safety Instructions .......... 2, 3
Operating InsCruaions
Controls--Control I_mobs ..... 6, 7
Controls--Touch Pads ....... 4, 5
Care and Cleaning
Air Fiher . .................... 8
Batteries ..................... 8
Front Grille .................. 9
Grille and Case ............... 8
Outdoor Coils ................ 8
Installation Inslructions . . .10-13
Troubleshooting Tips ........ 14
Normal Operating Sounds ..... 14
Consumer Support
Consumer Support ........... 18
Product Registration ....... 15, 16
_'anantv .................... 17
ASF05
ASL05
ASM05
ASN05
AsQo5
ASV05
ASL06
AS?V06
©
Write the model and serial
numbers here:
Model #
Serial #
Find these numbers on a label on
the side ot the air conditionex:
DB98-15878A 494471 !7-03JR

IMPORTANTSAFETYINFORMATION.
READALLINSTRUCTIONSBEFOREUSING.
WARNING!
For your safe_ the information in this manual must be followed to minimize the risk of fire, electric shock
or personal injury.
SAFETYPRECAUTIONS
J; Use this appliance only %r its intended
• (
pml)ose as described in tins )wner s
Manual.
J; This air conditioner must be properly
installed in accordance with the Installation
Insmmtions 1)efore it is used.
_{_Turn the mode control OFFand unplug
your air conditioner before cleaning.
J; GE does not support any servicing of the air
conditioner VVestrongly recommend that
you do not attempt to ser\_ice the air
conditioner yourself.
J; Nexer unplug your air conditioner by pulling
on the power cord. Always g_i ) ping firefly
and pull straight out from the receptacle.
_t{_;Replace immediately all electric set\ice cords
that haw become flwed or othexwise
damaged. Do not use a cord that shows
cracks or abrasion damag_ along its length
or at either the plug or connector end.
_{:;Fox your safely...do not store or use
combusdl)le materials, gasoline or other
flammable vapors or liquids in the vicinity
of this or any other appliance.
_: All air conditioners contain refrigerants,
which under federal law must be remox>d
prior to product disposal. If you are g_tting
rid of an old product with refrigerants, check
with the company handling disposal about
what to do.
HOWTOCONNECTELECTRICITY
Do not, under any circumstances, cut or remove
the third (ground) prong from the power cord.
Forpersonal safe_ this appliance must be
properly grounded.
The power cord of this appliance is equipped
with a 3-prong (grounding) plug which mates
with a standard 3-prong (grounding) wall
outlet m minimize tim possil)ilitv of electric
shock hazard flom this appliance.
Have the wall outlet and circuit checked by
a qualified electrician to make sure the outlet
is properly grounded.
$&]]ere a 9-prong wall outlet is encountered,
it is your personal responsil)ilitv and obligation
to have it replaced with a properly grounded
3-prong wall outlet.
The air conditioner should always be plugged
into its own individual electrical antler
which has a xoltage rating that matches the
rating plate.
This provides the best perfommnce and
also prexents oxerloading house wiring
circuits which could cause a fire hazard
flom overheated wires.
See the Installation Instructions, Electrical
Requirements section fox specific electdca]
connection requirements.
2

www.GEAppliances.com
WARNING!
USEOFEXTENSIONCORDS--115-Voltmodelsonly
Because ofpotential safety hazards under certain
conditions, we strongly recommend against the
use of an extension cord.
Howex>t; if you must/lse an extension cord,
it is absolutely necessary that it be a UiAismd,
14 gauge, 3-wire grounding b'pe appliance
extension cord having a grounding type plug
and outlet and flint fl)e electrical rating of rite
cord be 15 amperes (minimum) and 195 x_lts.
CAUTION:
DO NOT use an extension cord with any ofthe
230/208 voltmodels.
USEOFADAPTERPLUGS--115-Voltmodelsonly
Because of potential safety hazards under certain
conditions, we strongly recommend against the
use of an adapter plug.
Howex>[; if you must/lse an adapte[; where
local codes permit, a temporary connection
may be made m a properly grounded 9-prong
wall outlet by use of a UiAisted adaptor
available at most local hardware stores.
The larger slot in fl_e adapter must be
aligned with the larger slot in file wall outlet
to provide proper polarity in the connection
of the power cord.
When disconnecting file power cord flom rim
adaptel, alwws hold tile adaptor in place with
one hand while pulling tile power cord plug
with the other hand. If this is not done, the
adapter ground mmfinal is x>tT likely' to b_eak
with repeamd use.
If the adapter ground temfinal breaks, DO NOT
USEthe air conditioner until a proper ground
has been established.
Attachingtheadaptergroundtermba/ to a waftoutlet
coverscrewdoesnotgroundtheapplianceunlessthe
coverscrewis metal,andnotbsulated, andthe waft
outlet is groundedthroughthehousewiring. Youshould
havethecircuitcheckedbya quafifiedelectricianto
makesuretheoutlet is properlygrounded.
READANDFOLLOWTHISSAFETYINFORMATIONCAREFULLY.
SAVETHESEINSTRUCTIONS

Aboutthe controlsontheair conditionermmodels with touchpads.
Features and appearance will vary.
Cool on Fan on
°°°° 0
ME_
77meron 0
Pm--O
0
0
@
Air ConditionerControls RemoteControl
OON/OFF
TtlYns aiY (-onditioneY on and of L
Oisplav
Shows tile set teml)erature, time remaining
on tilner or tim speed (I-LOW, 2-MED or
a-HIGH).
OMODE
Use to set tile air conditioner to COOLor
FANmode.
Increase •/Decrease •Pads
Use to set temperature when in COOL mode.
0FAN
Llseto set tile tim speed to LOW(l), MED(2)or
HIGH(3).
OTIMER
ON-X_]len tile air conditioner is off; it can be
set to automatically turn on in 1 to 12 hom_
at its l)revious setting. Each touch will set tile
time in hom_.
O
O
OFF-\_qlen tile air conditioner is on, it can be
set to automaficall_ turn off in 1 to 12 hom_.
Each touch will set the time in horn3.
To cancel tile timeL press tile TIMERpad
until tile display time disappeaI_.
ENERGYSAVER- Controls tile f_n.
ON-TIle tim and compressor cycle on and
off. This results in wider variations of room
teml)erature and hunfiditv: Nommllv used
when tile room is unoccul)ied. NOTE:The
thn will continue to IUn for a short time
after tile coml)ressor cycles off.
OFF-The tim iuns all the tilne, while the
coml)ressor cycles on and ott_
This switch must be set at OFFin order to use
the tim setdngs (on the inode control).
RemoteControlSignal Receiver
Power Outage Recovery Feature
In tile case ot a power outage or interrul)tioi L tile
Ulfit will autonmficallv re-start in the settings last
used after the power is restored. The rIMER teature
will reset to tile original setting. You Inay need to
set a new time if desired.
4
Remote Control
_: To enstli'e l)roper ol)eration ,aill/ tile I'elllote
control at tile signal receiver on tile air
conditioner.
!i?:Tile remote control signal has a range of
up to 21 teet.
_: Make sure nothing is between tile air conditioner
and the remote control that could ])lock the
signal.
_: Make sure batteries are fl'esh and installed
cori'ectlx_see tile Care and CIoaning section.

When the air conditioner is turned on, it will
automatically start in the setting last used.
www.GEAppliances.com
COOLMode
Use tile COOLmode with HIGH (3),MED (2)or
LOW(1)tim fin" cooling. Use tile INCREASEA/
DECREASE•pads to set tile desired temperature
between 64°F and 86°F in 1°F increments,
A them_ostat is used to maintain tile room
temperature. The compressor will cycle on and off
to kee I) the room at the set level of comtort. Set the
them_ostat at a lower numl)er and tile indoor air
will becolne cooler Set the thelinostnt at a higher
nulnber and tile indoor air will becolne vamnei:
NOTE:If theair conditioneris off andis thenturnedon
whileset to COOL,it will takeapproximately3 m&utes
for the compressorto startand coolingtobegin.
CoolingDescriptions
For Normal Cooling-Select tile COOL mode and
HIGH(3)or MED (2)tim with a middle set
temperature,
For Maximum Cooling-Select tile COOL mode
and HIGH (3)tim with a lower set temperature,
For Quieter& Nighttime Cooling-Select tile
COOLmode and LOW(1)tim with a middle set
temperamre.
NOTE:If youswitch from aCOOLsettingto OFForto
a fan setting,wait at least3 minutesbeforeswitching
back to a COOLsetting.
FAN Mode
Use tile FAN at HIGH (3),MED (2)or LOW(l) to
provide air circulation and filtering without cooling.
Since tim only settings (lo not provide cooling, a
temperature setting will not be displayed.
Vent Control (on some models)
Tile vent control is located on tile inside of tile
air lou\'e_ in tile l()wer right corne_:
_]_en set at CLOSE, only tile air inside tile room
will be circulated and conditioned, \_]/en set at
OPEN, some inside air is exhausted outside.
I
(/
Toopen flTevent, push the lever to the right.
Toclose it, push it to the left.
Air Direction--Up and Down (on some models)
Fingertip pressm'e on tile horizontal lou\'e_ a(!justs
tile air direction up or down. OR
Air Direction--Side-to-Side (onsomemodels)
On some models, tile side-to-side air (lirecfion is
ac!justed by tile louver leveI5 or b)' grasping and
m eying tile ironer vertical lou\'e_. 0.

Aboutthecontrolsonthe air conditionermmodelswith controlknobs.
Features and appearance will vary.
OFF
LOW HI
FAN FAN
LOVOHI
COOL COOL
MED
COOL
OFF
HIGH_HIGH
LOW_II,m' MED
FAN _ COOL
LOW
COOL
OFF
HI OIHI
FAN OOL
LOW LOW
FAN COOL
MODECONTROLS
Yourmodel will have one of the above type controls.
EST COOLEST COOLEST
TEMPCONTROLS
Yourmodel will have one of the above type controls.
Controls
oode Controls
HIGHCOOL,MED COOLand LOWCOOLpro'dde
cooling with difterent thn speeds.
LOWFANor HIGHFANprovides air circulation
and filtering without cooling.
NOTE."If you move the switch from a cool setting to OFF or
to a fan setting, wait at least 3 minutes before switching back
to a cool setting.
Cooling Descriptions
ForNormal Cooling-Select HIGHCOOLor MED
COOLwith the temp control at midpoint.
For Maximum Coolingt-Select HIGH COOL with the
temp control at the highest number available on
wmr knob.
@TempControls
The temp control is used to maintain the
room temperature. The compressor will cycle
on and off to kee I) the room at the same
level of comfiwt. When w)u turn the knob to
a higher numbe_; the indoor air will become
coole_: Turn the knob to a lower number
and the indoor air will become wannei:
For Quieter & Nighttime Cooling-Select LOW COOL
with the temp control at midpoint.

www.GEAppliances.com
Additional controls and important information.
Vent Control (on some models)
The vent control is located on the inside of the
air lou\'e_ in the lower right corne_;
_4]_en set at CLOSE, only the air inside the roon/
will be circulated and conditioned. _l_en set at
OPEN, some inside air is exhausted outside.
Toopen the vent, push the lever to the right.
Toclose it, push it to the left.
A_Direction--Side-to-Side
(-)n some models, the side-to-side air direction is
a(!iusted by the h)uver leveI_ or by grasping and
moving the inner vertical h)u\'e_,
OR
Air Direction--Up and Down (onsomemodels)
Fingertip pressm'e on the horizontnl lou\'e_ a(!iusts
the air direction up or down.
OR
7

Careand cleaning oftheair conditioner.
How to Insert the Batteries
] Remove the battery cover by sliding it
according to the arrow direction.
] Insert new batteries making sure that the (+)
and (-) of battery are installed correctly:
] Reattach the coxer b) sliding it back
into position.
NOTES:
::Ji::Use 2 "_%" (1.5 volt) batteries. Do not use
recha_geable batteries.
::Ji::Remove the batteries fl'om the remote control if'
the svstenl is not going to be used tor a long tilne.
Grille and Case
Turn the air conditioner off and remo_e the
plug fl'om the wall outlet before cleanin ,
To clean, use water and a mild deteroent
Do not use bleach or abrasives.
OutdoorCoils
The coils on the outdoor side of the air conditioner
should be checked regularly. If they are clogged
with dirt or soot, they may be proti_ssionally
steam cleaned, a service available through yore"
GE service outlet.
Air Filter
The air filter behind the front grille should be
checked and cleaned at least execv 30 days or
i/loi'e ()lien i[ necessai-v.
Clean the filter Mth wamL soapy water: Rinse and
let the filter dry betore replacing it.
CAUTION:DONOroperatetheair
conditioner without a filter becausedirt and lintwill clog it
andreduceperformance.
Toremove (on some models):
[]Open the inlet grille upward by )ullin,* out
the bottom of the inlet *rille
] Using the tab, pull up slightly on the filter to
release it and pull it down.
Toremove (onsome models):
[]Open the inlet grille dowmvard by pulling out
the upl)er corne_ of the inlet grille. I,ift it up
and off.
] (;rasp the filter at the top center and slide
it out.
Toremove (on some models):
Toremove (on some models):
Grabthetabson
thefilter andpull
it upandou_
Grabthe tabon thefilter
andpull it tothenght.
8

Front Grille and Case
Turn the air conditioner off and remove the plug
from the wall outlet beiore cleaning.
To clean, rise water and a mild detergent, Do not
use bleach or abrasives.
To remove the front grille:
] On some models, remo',e the knobs and the
screw behind the leit knob.
www.GEAppliances.com
] (;enflx but firefly gras ) the lower grille cornet_
and pull fi)rward to release.
c_ 0
\
\\
On some models, remove the knobs, filter and
S(TeW 1)ehind the filter bottom.
On some models, remoxe the bottom eight
gcille sccew.
] i,i_t the top of the grille up and off to release
fl'om the tabs.
Toreplace thegrille:
] Hook the ti'ont otthe oTille onto the tabs
on the top of the case.
] Snap the bottom sides of the gcille into
the case slots.
] Replace the screw and attach the knobs.
/
/
On some models, open the inlet gcille fl'om
the sides and remove it. Remove the screw
fl'om the lower eight corner if present.

Installation
Instructions Air Conditioner
-?-i Questions? Call 800.GE.CARES (800.432.2737) or Visit our Website at: www.GEAppliances.com I
BEFORE YOU BEGIN
Read these instructions completely
and carefully.
• IMPORTANT - Savethese
instructions for local inspector's use.
• IMPORTANT - Observeall
governing codes and ordinances.
•Note to Installer - Be sure to leave these
instructions with the Consumer.
•Note to Consumer - Keep these
instructions for future reference.
• Skill level - Installation of this appliance
requires basic mechanical skills,
•Completion time - Approximately 1 hour
• We recommend that two people install
this product.
•Proper installation is the responsibility
of the installer.
• Product failure due to improper installation
is not covered under the Warranty.
(_) ELECTRICAL REQUIREMENTS
Some models require a 115/120-volt a.c.,
60 Hz grounded outlet protected with a
15-amp time delay fuse or circuit breaker.
The 3-prong grounding plug minimizes the
possibility of electric shock hazard. If the wall
outlet you plan to use is only a 2-prong outlet,
it is your responsibility to have it replaced with
a properly grounded 3-prong wall outlet.
©
@
Some models require 230/208-volt a.c.,
protected with a time delay fuse or circuit
breaker. These models should be installed
on their own single branch circuit for
best performance and to prevent
overloading house or apartment wiring
circuits, which could cause a possible
fire hazard from overheating wires.
CAUTION:
Do not, under any circumstances, cut or
remove the third (ground) prong from the
power cord.
Do not change the plug on the power cord
of this air conditioner.
Aluminum house wiring may present special
problems--consult a qualified electrician.
TOOLS YOU WILL NEED
Phillips head screwdriver
Adjustable wrench Ruler or tape measure
Pencil Scissors or knife
Level
