GE GSD500 User manual

Useand&re Guide
Dishwasher
Safety instructions.........................3
Operating Instructions, Tips
ApplianceRegistration.................................2
China, Crystal, Sterling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
CycleDescription......................................4,5
Cycle Selection
Chart....................................5
DetergentGuide.............................................7
Dispenser Cups ....,.........................................7
DryingOptions................................................4
Energy-SavingTips........................................5
Features .......................................................4, 5
Loading
........................................................8, 9
OperatingInstructions.............................4,5
Rinse Agent
.....................................................6
WaterTemperature.......................................6
Care and Cleaning
Air Gap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Winter Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Problem Solver ...................... I 3- I 5
More questions ?..,call
GE Answer Center” 800.626.2000
Preparation
Front Panel Change . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Consumer Services . . . . . . . . . . . . . . . . . . . 19
Important Phone Numbers 19
Model and Serial Numbers ..........................2
Repair Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Warranty ........................................Back Cover
~ Models GSD500GSD530 ~
Tc) obtain a Spanish language
Para obtener la versibn en
version of this book, call
espafiol de este manual,
GE Answer Center
Ilame a
800.626.2000
GE Answer Center~O
consumer information service.
servicio de informaci6n
para el consumidor,
telefono 800.626.2000.
GE Appliances

A note to consumer—
We’d like to thank you and congratulate you for making the wise decision in purchasing your dishwasher.
This User Guide is designed to be kept near your dishwasher at all times for quick and easy reference. Features
may vary on some dishwasher models. Please read the following tips to insure your dishwasher is operating at its
best performance.
We care about you and your appliance and we want your dishwasher to do its job for you.
*
● HOT WATER—Your dishwasher
needs hot water for best results. Water
entering the dishwasher should be at
least
120°F. but your dishwasher
performs BETTER with HIGHER
water temperatures not to exceed
150°F.
WATER HARDNESS-The hardness
of the water plays an important part in
how well your dishwasher cleans. In
areas where water is very hard (12 grains
or more), it may be necessary to install
a water softener. If you do
not know the
hardness of your water supply, contact
your local water department.
● DETERGENTS+nly use detergents
o
labeled for use in automatic dishwashers.
‘m
A Never use laundry detergents or
liquid soaps.. that will cause
oversudsing
%.
.-, -<..
0
and leaks. The amount of detergent you
use depends on the water hardness and the
amount of soil on your dishes. In most
cases, detergent amounts should be
increased for hard water and heavy soil.
&
● RINSE AGENT—should always be used:
— to reduce water spotting
o
— to improve drying.
$;
Always check and refill the rinse agent
when necess~.
● FOR BEST RESULTS—The cycles
2
and the options you choose hav~ an
effect on the results you get. The
following are examples. (Please, see the
Operating Instructions, Tips for more
information).
● WASH HEAT BOOST OPTION—
— use with heavily soiled loads.
— extends cycle to heat water for best
washing and drying.
“ POTSCRUBBER CYCLE—
—use with dried or baked-on heavily
soiled loads.
● HEATED DRY OPTION—
— assures faster drying.
— be sure to use a rinse agent.
o
Before using your dishwasher,
,“.
‘Q-,”’< ~
read this guide carefully.
> + ,..
It is intended to help you operate and
maintain your new dishwasher properly.
Keep it handy for answers to your questions.
If you don’t understand something or need more help, call
the GE Answer Centera 800.626.2000, 24 hours a day, 7
days a week.
%
If you received
a damaged dishwasher...
‘~1 Immediatelvcontactthedealer(or
builder) tha~ sold you the dishwasher.
Save time and money.
Before you request service...
Check the Problem Solver in the back of this guide. It lists
causes of minor operating problems that you can correct
yourself.
Write down the model
and serial numbers.
You’ll find them on a label fastened to the
tub
wall just inside the dishwasher door.
These numbers are also on the Consumer Product
Ownership Registration Card that came with your
dishwasher. Before sending in this card, please write
these numbers here:
Model Number
Serial Number
Use these numbers in any correspondence or service calls
concerning your dishwasher.
We ‘[l be there . . .
No matter what major appliance you buy from us, you
always get more than a quality product. You receive the
added assurance that, should you ever need our help, we’ll
be there.
We ask that you please be sure to read all the Important
Safety Instructions before operating your new appliance
to insure your safety.

A
WARNING-When using this
appliance, always exercise basic
safety precautions, including the
following:
● Use this appliance only for is intended
purpose, as you will find described in this
Use and Care Guide.
@
● This dishwasher must be properly
‘Q.,’”: ~
installed and located in accordance
> Q . . .
with the Installation Instructions
=. ‘
before it is used. If you did not
receive an Installation Instructions sheet with your
dishwasher, you can obtain one by calling, toll
free, the GE Answer Center$800.626.2000.
—This appliance must be connected to a grounded
metal, permanent wiring system; or an
equipment-grounding conductor must be run
with the circuit conductors and connected to
the equipment-grounding terminal or lead of
the appliance.
—Connect to a properly rated, protected and sized
power-supply circuit to avoid electrical overload.
● Do not store or use combustible
*
1
materials, gasoline or other
= flammable vapors and liquids
in the vicinity of this or any other appliance.
● Use only powder or liquid detergents or wetting
agents recommended for use in a dishwasher.
● Do not wash plastic items unless marked
“dishwasher safe” or the equivalent. For plastic
items not so marked, check the manufacturer’s
recommendations.
● Load light plastic items so they will not
become dislodged and drop to the bottom of the
dishwasher—they might come into contact with
the heating element and be damaged.
To minimize the possibility of injury.
● When loading items to be washed:
A. Locate sharp items so that they are not likely
to damage the door seal, and
B. Load sharp knives with the handles up to
reduce the risk of cut-type injuries.
● Do not tamper with controls,
● Do not touch the heating element during or
immediately after use.
● Do not operate your dishwasher unless all enclosure
panels are properly in place.
● Do not abuse, sit on, or stand on the door or dish
rack of the dishwasher.
● Close supervision is necessary if this appliance
is used by or near children. Do not allow children
to play inside, on or with this appliance or any
discarded appliance. Dispose of discarded
appliances and shipping or packing material
properly. Before discarding a dishwasher, remove
the door of the washing compartment.
● Keep all washing detergents and wetting agents
out of the reach of children, preferably in a locked
cabinet, Observe
dl warnings on container labels
to avoid personal injury.
%%
● To minimize the possibility of
/’
electric shock, disconnect this
/-
appliance from the power supply
before attempt~ng any maintenan~e. NOTE;
-
Turning the control dial to the OFF position
does not disconnect the appliance from the
power supply. We recommend having a qualified
technician service your appliance.
A
WARNING—H~ROGEN GAS is
produced by the chemical action
within your water heater. It can
accumulate in the water heater an~or
water pipes if hot water has not been used for a
period of two weeks or longer, HYDROGEN GAS
IS EXPLOSIVE. To prevent the possibility of
damage or injury, if you have not used hot water
for two weeks or more, or moved into a residence
in which the hot water system may not have been
used for some time, turn on all hot water faucets
and allow them to run for several minutes before
using any electrical appliance which is connected
to the hot water system. This will allow any
hydrogen gas to escape. Also, since the gas is
flammable, do not smoke or use an open flame
or appliance during this process.
SAVE THESE
INSTRUCTIONS
3

HOW TO OPERATE YOUR DISHWASHER
NOTE: If dishwasher drains into a food waste
disposal, operate the disposal until it is empty
before starting dishwasher.
Step 1.
Load your dishwasher. (See Loading section.)
Step 2.
Make sure the Cycle Indicator Dial is at the OFF
position and the door is unlatched. Add detergent
to the detergent dispenser. (See Detergent Guide.)
Use a rinse aid agent to help prevent spotting.
(See How to Use a Rinse Agent section.)
Step 3.
Latch the door.
Step 4.
Select the desired wash cycle.
● HEAVY WASH—For items such as pots, pans and
casseroles with dried-on or baked-on soils. Everyday
dishes
may be included. This cycle will get heavily
soiled dishes cleaner than the normal cycle. It
will
not remove burned-on foods.
● NORMAL WASH—For most loads of everyday
dishes, glasses
and cookware with medium soils.
Designed to yield high performance on normal soils.
● SHORT WASH—For most loads of everyday
dishes (loads consisting mostly of glasses) with
medium soils that have not dried on. This cycle
will allow you to quickly wash these loads.
● RINSE & HOLD—For rinsing partial loads which
will
he washed later. Dc) not use detergent. HEATED
DRY ON
i.s not re(omtnctzded,f{)t. thi.v cyc[e.
II
Step 5.
Select the desired Drying Options.
● HEATED DRY ON—Turns the drying heater on
for fast drying. When selected, the cycle time
will
be extended for 35 minutes.
● HEATED DRY OFF—Shuts off the heating unit,
thus saving energy. Dishes air-dry naturally. It takes
longer but saves energy. You can open the door after
the motor stops to speed drying. Excellent for
overnight drying.
Step 6.
~rn the Cycle Indicator Dial to selected wash cycle.
● Turning the dial to the selected wash cycle will
begin the cycle immediately. To
obtain the benefits
of a complete cycle, be careful that you
do not turn
the dial any farther than is necessary to start the
dishwasher. There is
a time delay between start-up
and water fill so you will not hear any wash action
right away.
4

OFF HEAWWASH
WASH
TWASH
1,
@
RINsE& HOLD IPRLSS IIIAT[O Dri,o,r)
HEATED
DRY ON
jHEATED
DRVOFF
Cycle Selection Chart
Wash Cycle
Water Use Tinle
Gallons
MillLites
Wash Cycles (approx.) (approx.) Cycle
SeqL]cncc
HEAVY WASH
10.4
55
mmmmmmF
NC) RMA1. WASH
8.7 50
mmmmmF
SHORT WASH 7.1 46
mmmBF
RINSE & HOI.D 3.() 9
mE
Drying Options:
HEATED DRY ON. Av~il:ihlc 011 :111 wtish cycles except RINSE & HO1.D. Add 35 nlinu{cs [() w:tsh cycle. [inlc
HIiATEtl DRY OFF. Drying hcti(cr is [urncd oft’. Dishes dry na(ur~lly.
ENERGY-SAVING TIPS
● Operate dishwasher only when it’s full. Let the ●
If you (ion ‘t need your dishes right uway, allow
dishes accumulate in dishwasher. When you put in the dishes
10 dI”y naturally over a longer period
only
a partial load, use the RINSE & HOLD cycle such as overnight.
to rinse off heavy soils.
● Always select the cycle that uses the least amount
of water that
will remove the soil from the load.
(See the Operating section,)
5

Good Dishwashing Starts with HOT Water
To get dishes clean and dry, you need hot water. For good washing and drying,
the entering water must be at least 120°F. To prevent dish damage, inlet water should not exceed 150°F.
How to Test Water Temperature
Check your water temperature with a candy or meat
thermometer. Turn on the hot water faucet nearest
the dishwasher. Put the thermometer in a glass and
let the water run continuously into the glass until the
temperature stops rising. If the water temperature is
below 120°F., adjust your water heater.
Helpful hints: lf outside temperatures are unusua]]y
low, or if your water travels a long distance from water
heater to dishwasher, you may need to set your water
heater’s thermostat up.
Ifyou have not used hot wa(er
for some time, the water in the pipes will be cold. Turn
on the
hot water faucet at the sink and allow it to run
until the water is hot. Then start the dishwasher, If
you’
ve recently done laundry or run hot water for
showers, give your water heater time to recover before
operating the dishwasher.
To improve washability if the water is less than 120°F.
and you cannot adjust your water heater: Select a
longer cycle
and fill both detergent cups at least hali-
full with detergent.
How to Use a Rinse Agent
The rinse agent makes water flow off dishes
quicker than usual. This lessens water spotting
and makes drying faster, too.
For best dishwashing performance, use of a rinse
agent such as JET-DRY brand is recommended.
Rinse agents come in either
liquid or solid form.
Your dishwasher uses the liquid form.
How to fill the rinse agent dispenser.
Unscrew the cap. Note the FULL
!- ,1,111,1, s,
line on the top of the cap. Add
liquid rinse agent until it just
reaches the top of the FULL line.
8
‘ 7’
Replace the cap. The dispenser
‘Y
Full
automatically releases the rinse
agent into the final rinse water.
Your dishwasher’s rinse agent container holds
approximately 47z ounces. This should last about
3 months. Fill as needed.
If you accidentally spill: Wipe up the rinse
agent with a damp
cloth. Don’t leave the spill in the
dishwasher. It can keep your detergent from working,
If you can’t find any rinse agent, write:
BENCKISER CONSUMER PRODUCTS, INC.
(“JET-DRY” )
Corporate Centre ]
5S Federal Road
P.O. Box 1991
Danbury, CT 068 13-i991
6

How to Choose and Use the Right Detergent
Use only powder or liquid detergent specifically
made for use in dishwashers. Other types will cause
oversudsing.
How much detergent should you use? That depends.
1s your water “hard” or “soft”? With hard water, you
need extra detergent to get dishes clean. With soft water,
you need less detergent.
Your water department can tell you how hard your
water is.
So can your county extension agent or your
area’s water softener company. Just call and ask them
how many “grains” of hardness there are in your water.
Too much detergent with soft water not only wastes
money, it can be harmful. It can cause a permanent
cloudiness of glassware, called “etching.” An outside
layer of glass is etched away! Of course, this takes some
time. But why take a chance when it’s easy to find out the
hardness of your water.
Keep your detergent fresh and dry. Under the sink
isn’t a good place to store detergent because there is too
much moisture. Don’t put powder detergent into the
dispenser until you’re ready to wash dishes, either. (It
won’t be fresh OR dry.)
If your powder detergent gets old or lumpy, throw it
away.
Old detergent often won’t dissolve. If you use a
liquid dishwasher detergent, these precautions are not
necessary because liquid detergents don’t “lump” as
they age or come in contact with moisture.
Detergent Dispensers
You’ll find two detergent dispensers on the inside
Close the main cun.
/
.
NOTE: T(J open detergent cup afier it has been
closed, unlatch the door” and rotate the Cycle ~f’ .
Indicator Dial a,fuil turn to the OFFpositi(m.
&
>’
When the closed cup c(mtains soap it is
Grasp handle,
best that the door be in a partially open
rotate and
positi(m before rotating the Cycle
close tightly
Indicator Dial, This will help reduce the amount (~’
detergent and rinse aid agent spillage into the tub.
Detergent Usage Guide (powder or liquid)
I
SOFT WATER (0-3 grains hardness) I
MEDIUM WATER (3-7 grains) HARD WATER (7- 12 grains*)
CYCLES Main Cup Open Cup Main Cup Open Cup
Main Cup$
Open Cup~
HEAVY WASH Half Full ~ Half Full Completely
~ Half Full Completely
j Completely
Full
Full
Full
NORMAL WASH Half Full Half Full Completely
Half Full Completely Completely
Full Full Full
SHORT WASH Half Full
None Half Full None
Completely
None
Full
RINSE & HOLD Use no detergent Use no detergent Use no detergent
~: I z ~lalns and up is extrelncly hard water. A water softener is recommended. Without it, lime $Filled
Main Cup holds 3 tablespoons;
can build up in the water valve. The wtiter valve may stick while open and cause flooding. filled Open Cup holds 2 tablespoons.
How to Prepare the Dishes for Washing
If this is your first dishwasher, or if you’re
NOTE: You may also want to consider removing
replacing a much older model, you may wonder foods such as mustard, mayonnaise, vinegar, lemon
how much preparation your dishes need. Actually juice and other foods that can cause discoloration of
very little. Scrape oft bones, seeds, skins, toothpicks stainless steel if allowed to remain on dishes
for a long
and other hard solids. Remove excessive quantities of
period of time.
oi I or grease.
7

HOW TO LOAD YOUR DISHWASHER
NOTE: Do not load large platters or trays in front right corner
of lower rack. They may prevent detergent from circulating in the wash cycle.
The upper rack is best for glasses, cups and
saucers. Cups and glasses fit best
along the sides.
This is also the place for dishwasher-safe plastics.
Make sure small plastic items are lodged in tightly so
they can’t fall onto the heating unit. Arrange stemware
so that it cannot move easily. Don’t let the glasses
touch each other.
-- ,..,
,’;
-&
The upper rack is handy for all kinds of odd shapes. Sauce pans, mixing bowls and other items should be placed
face down. When iotiding dishwasher safe plastics make su;e each plas~ic item is secured over two finger~. This
will insure good washing results.
8

The lower rack is best used for plates, saucers, and
cookware.
Large items such as broiler pans and racks
should
go in the lower rack along the edge. Load
platters, pots
and bowls along the sides, in corners,
or in the back. For best washing results, all items
should be positioned with the soiled side of the dish
facing the center of the rack.
I
Put flatware in the removable basket with handles up
to protec[ your hands. Mix knives, forks and spoons
so they don’t nest together. Distribu{c evenly.
Small plastic itcrns, such as mc:tsuring spoons and
lids from small contfiincrs are no[ recommended for
automat ic di shwash i ng. I f placed i n di shwtisher, they
should go in bottom of silverware basket with
silverware on
(op.
Keep center area clear in the lower rack.
The wash tower rises through the center of the lower
rack during the wash and rinse portions of the cycle.
Don’t block it or load
tall things next to it. Also, be
careful not to let a portion of an item such as a pot or
dish handle extend-through the bottom rack. This
could
block the wash arm and cause poor washing results.
Don’t let anv
item extend”
through bottom
I
Precaution!
Take out anything that may fall or extend through the
bottom of the btisket.
9

WHAT YOU CAN USUALLY WASH SAFELY
IN YOUR DISHWASHER.
Usually
Safe
Material Exceptions (not safe) Special Instructions
Aluminum
Chinti
Stoneware
YES Some colored anodized
aluminum can fade.
Antique, metal-trimmed,
hand-painted or over-the-glaze
patterns fade. Gold leaf
will discolor.
Some darkening or spotting possible. Remove by
scouring with soap-filled steel wool pads.
If in
doubt, check with the manufacturer. Or test wash
YES
one piece daily for at least a month. Compare with the
rest of the set.
Crystal
YES Antique, metal-trimmed or
hand-painted patterns fade.
Gold leaf
will discolor.
Load securely to prevent movement. Check your
manufacturer’s instructions for your crystal.
Non-dishwasher
items—such
as electronic
air cleaner
filters, furnace
filters, paint
brushes, etc.
Glass
NO
Do not wash in dishwasher. Damage to dishwasher
and discoloration or staining of dishwasher may result.
YES
Iron NO
Iron will rust.
Pewter
NO
YES
Pewter tarnishes.
If it doesn’t say DISHWASHER SAFE, test one piece in
the top rack before dishwashing an entire set.
Rinse if not washing immediately. Salty or acidic foods
can stain if left on.
Plastics
Stainless steel
YES
Sterling silver
and silver plate
YES
YES
Don’t put in same silverware
basket with stainless
steel,
Contact between metals can
damage silver.
Don’t wash copper utensils in
the same
load. Silver may get a
brown film.
Adhesive used to attach some
hollow-handle knives can loosen.
Rinse if not washing immediately. Salty or acidic foods can
stain if left on. Dry detergent can cause difficult-to-remove
black spots. Place in back section of silverware basket to
avoid exposure to detergent from the detergent cup.
Non-stick
coatings After washing, wipe the non-stick coating area with
vegetable oil to keep it from losing its non-stick quality.
Tin NO Tin can rust.
Wood
NO Wood cart warp, crack or lose
its finish with any type of washing.
Forget a dish? Here>s when you can add it.
Add dishes any time during the RINSE & HOLD
cycle. With other wash cycles, you
can add dishes
at any time BEFORE the main detergent wash portion
of the cycle.
However, opening the door during any cycle
lessens cleaning power. So try to load everything
at the beginning.
Here’s how to add a forgotten dish:
1. Push the door latch to the left. Washing will stop.
2. Wait a few seconds until the water calms. Then
open the door. WARNING: Hot vapor may rise
from opened door.
3. Add dishes you’ve forgotten.
4. Close the door and push the latch to the far right.
When the door is locked, washing will continue.
10

USER MAINTENANCE INSTRUCTIONS
Clean the control panel with a lightly dampened
Appliance Polish Wax & Cleaner (Cat. No.
cloth. Dry thoroughly. Do not use abrasives or
WR97X02 16) is available from GE Service and
sharp objects on the panel. They can damage it.
Parts Centers.
Clean the outside with a good appliance polish The inside usually takes care of itself.
If it should
wax. The outside cabinet finish is durable, but it ever need cleaning, use a mild cleansing powder.
can scratch. So use no scouring pads, or harsh or Scouring pads and harsh cleaners can mar the finish.
gritty cleaners.
Not Using Your Dishwasher in Winter? Protect Against Freezing.
If your dishwasher is left in an
unheated place during the winter,
ask a service technician to:
● Cut off electrical power to the
dishwasher. Remove fuses or trip
circuit breaker.
● Turn off the water supply.
● Disconnect the water inlet line
from the water
valve.
Built-in Dishwashers Often
An air gap is a plumbing device.
It protects your dishwasher against
water backing up into it if a drain
clogs. The air
gap is not a part of
the dishwasher. And you may not
even have one. Not
all plumbing
codes require
air gaps.
Pump C&ver Screws
Use an Air Gap. Keep It Clean.
● Drain water from the inlet line
and water valve. (Use a pan to
catch the water.)
● Reconnect the water inlet I ine to
the water valve.
● Remove the plastic pump cover
in the tub bottom and use a
sponge to soak up water in
the rubber boot.
If you have an air gap, check it at
least once a month. IT IS NOT
PART OF YOUR DISHWASHER.
IT IS NOT COVERED IN YOUR
WARRANTY.
The air gap is easy to clean.
With most types, first turn off the
dishwasher, then lift off the chrome
cover. Then unscrew the plastic
cap
and check for any buildup of grit.
A toothpick makes cleaning easy.
Check the air gap any time your
dishwasher isn’t draining well.
11

HOW TO CHANGE COLOR PANELS
If you are redecorating, you can change your dishwasher’s front panel to
match or blend with your new colors by flipping it over. Each side of each
panel is
a different color. You may also paint a panel with a color of your
own choice.
How to Change the Door Panel:
1. Take out trim screws on either side of the
dishwasher door. Remove the side trim.
2.
Slide the door panel out.
(Careful—edges
may be sharp.)
3. Turn the door panel around
and put the color you
want in front.
4. Replace the door panel, side trim and screws.
Wood panel Trim Kits (Available for both models)
Wood panel trim kits, contain trim and
instructions
for adding a decorative wood door
panel and lower access panel no thicker than 1/4”
to match kitchen cabinets.
Specify the trim color of your choice from the
following options:
GPF40BC (Chrome Trim and Screws)
GPF40BK (Black Trim)
GPF40WH (White Trim)
The kit is available for $5.00 (shipping and handling).
Make check payable to the General Electric Co.
NOTE: Do not operate
dishwasher while changing
panels or when lower access
panel is removed.
COIOr panels (For model GSD500 only)
If you have redecorated, and the color panels in
your dishwasher do not blend with your new
color
scheme you may order one additional color panel
without char&e.
Specify the color panel you would like from the
following options:
GPF24 White/Almond
GPF26 HarvestiBlack
Order a Trim Kit or a Color Panel from:
GE Appliances
c/o Dri-View Manufacturing
4706
Allmond Ave.
Louisville. KY 40209
12

PROBLEM
DISHWASHER
WON’T RUN
UNUSUAL NOISE
DISHES DON’T DRY
UNCLEAN DISHES
AND FLATWARE
DETERGENT
LE~
IN DISPENSER CUPS
DETERGENT CUP
LID WON’T LATCH
AFTER ADDING
DETERGENT
YELLOW OR
BROWN FILM
POSSIBLE CAUSE
A fuse in your home may be blown, or the circuit breaker tripped. Replace fuse or
reset circuit
breaker. Remove any other appliances from the circuit.
Utensils may not be secure on rack pins, or something small may have dropped from
the rack. Water is causing utensils to rattle. Make sure everything is securely placed
in dishwasher.
Make sure inlet water temperature is correct. (See How to Test Water
Temperature section).
Unload the bottom rack first. Water from dishes in the top rack may be spilling into
the bottom rack.
Check for improper loading. Dishes shouldn’t nest together. Avoid overloading.
Check the rinse agent dispenser to see that it’s not empty.
Check inlet water temperature. It should be at least
120°F. (To test, see How to Test
Water Temperature section).
Water pressure may be temporarily low. Turn on a faucet. Is water coming out slower
than usual? If so, wait until pressure is normal before using your dishwasher.
Plugged air gap. (See Care and Cleaning section).
Improper rack loading. (See Loading section).
Choose another cycle to give you longer washing time.
Water may not be reaching the detergent cups. Move dishes that maybe blocking
detergent cup.
The dispenser cover may not be opening or may be blocked by improperly loaded
items. If you used a powder detergent, open the cup and remove any caked-on
detergent. If the cup still doesn’t open automatically, call for service.
Detergent may be old. If the powder detergent is hard or caked in the box, throw it
away. The detergent may not be working
well. Try another brand.
Cycle Indicator
Dial must be OFF for cup lid to close and latch properly. If you
unlatch the door and open it to dry your dishes, the Cycle Indicator Dial does
not advance by itself.
Tea or coffee can stain cups. Remove the stain by hand, using a solution of 1/2 cup
bleach and 3 cups warm water.
An overall
yellow or brown film on dishes or glassware can be caused by iron
deposits in water. A special filter in the water supply line is the only way to correct
this problem. Your water softener company can tell you about the filter.
Yellow film on sterling silver results when you wash copper utensils in the same load.
Silver polish will usually remove this stain.
13
I
1

THE PROBLEM SOLmR
(continued)
PROBLEM
SPOTS AND
FILMING ON
GLASSES AND
FLATWARE
CLOUDINESS ON
GLASSWARE
CHIPPING OF CHINA
POSSIBLE CAUSE
Spotting can be caused by dl these things:
● Extremely hard water. (See How to Choose and Use Detergent section.)
● Low inlet water temperature. (See How to Test Water Temperature section.)
● Overloading the dishwasher.
● Improper loading. (See Loading section.)
● Old or damp powder detergent.
● Phosphate level in detergent too low. (See How to Choose and Use
Detergent section.)
● Rinse agent dispenser empty. (See How to Use a Rinse Agent section.)
● Too little detergent. (See How to Choose and Use Detergent section. )
Local water conditions and personal preferences vary. Try several brands of
detergents to find one that gives the best results for you. A liquid dishwasher
detergent may help reduce filming.
To remove stubborn spots and film from glassware:
1. Remove all metal utensils from the dishwasher.
2. Do not add detergent.
3. Select HEAVY WASH cycle.
4. Start the dishwasher and allow to run for 18 to 22 minutes. The dishwasher will
now be in the main wash.
5. Then open the door and pour 2 cups (500 ml) of white vinegar into the bottom of
the dishwasher.
6. Close the door and allow to complete the cycle.
If vinegar rinse doesn’t work: Repeat as above, except use 1/4 cup (60 ml) of citric
acid crystals instead of vinegar. (Most drugstores carry citric acid crystals. If
yours
doesn’t, call GE Factory Service).
Using a vinegar or citric acid crystal rinse more than twice a month? Consider a home
water softener.
If vinegar or citric acid crystal rinse doesn’t work, the cloudiness is “etching.”
The film cannot be removed.
It can be prevented: Use less detergent if you have soft water. Wash glassware in
the shortest cycle that will get them clean.
Water temperature entering dishwasher exceeds
150°F.
Rough handling can cause chipping. Load with care. Make sure glassware and china
are secure and can’t jar loose. (See Loading section.) Make sure tall glasses and
stemware will clear the top of the tub when you push the rack into the dishwasher.
Always use the top rack for delicate items.
14

PROBLEM
BLACK OR GRAY
MARKS ON DISHES
SMALL AMOUNT OF
WATER STANDING
IN THE BOTTOM
OF THE TUB
WATER WON’T PUMP
OUT OF THE TUB
SUDS IN THE TUB
DISHWASHER
LEAKS
MOTOR HUMS
STAINING OF
TUB INTERIOR
SOUNDS YOU
WILL HEAR
VAPOR AT
THE VENT
POSSIBLE CAUSE
Aluminum utensils often leave marks when they rub against dishes. Remove marks
with a mild abrasive cleanser.
Water around the outlet on the tub bottom at the back of the tub is normal. It is
clean
water. It’s there to keep the water seal lubricated.
If the entire bottom of the tub has water, you may have a drain problem. Clean the air
gap, if you have one. (See Care and Cleaning section).
Check the kitchen sink. Is it draining well? You may need a plumber,
If dishwasher drains into disposer, run disposer to clear. Be sure disposer is not
clogged.
Sudsing detergents are not meant for dishwashers. USE ONLY AUTOMATIC
DISHWASHER DETERGENTS TO AVOID
SUDSING.
To remove suds from the tub: Open the dishwasher. Let suds evaporate. Add
1 gallon of cold water to the tub. Close and latch the dishwasher. Pump out water
by slowly turning the control dial until a drain period is reached.
Repeat if necessary.
Suds can cause unit to overflow. That’s why it’s so important to use a detergent that’s
designed for automatic dishwashers.
Spilling the rinse agent can cause foam during washing. This can lead to overflowing.
Wipe up
accidentd spill of rinse agent with a damp cloth.
Dishwasher has not been used on a regular basis.
If you do not use your dishwasher often, set it to fill and pump out once every week.
This will help keep the sed moist, and the garbage disposer clear.
Some detergents contain colorant (pigment or dyes) that will discolor the tub
interior with extended use. Check the detergent cup for signs of any discoloration.
If cup is discolored, change to detergent without any colorant.
You’ll hear occasional clicking sounds. These are normal.
● Soft food disposal shredding action.
● Drain valve opening to pump water out.
● Timer control as cycle progresses.
● Detergent cup opening.
During the drying period:
● The motor stops.
Water vapor comes through the vent by the door latch during drying and when
water is being pumped out.
If you need more help. ..call, toll free:
GE Answer
Center@
800.626.2000
consumer information service
15

IF YOU NEED SERVICE
To obtain service, see the Consumer Services page in
the back of this guide.
We’re proud of our service and want you to be
pleased. If for some reason you are not happy with the
service you receive, here are three steps to follow for
further help.
FIRST, contact the people who serviced your
appliance. Explain why you are not pleased. In most
cases, this will
solve the problem.
NEXT, if you
are still not pleased, write all the
details—including your phone number—to:
Manager, Consumer Relations
GE Appliances
Appliance Park
Louisville, KY 40225
FINALLY, if your problem is still not resolved, write:
Major Appliance Consumer Action Panel
20 North
Wacker Drive
Chicago, IL 60606
16

NOTES
18

Wdll Be There
With the purchase ofyour new GE appliance, receive the assurance tiat ifyou ever need
information or assistance from GE, we’ll be
tiere. All you have to do is call—toll-free!
h-Home Repair Service
80MEXARES(80M32-273fl
A (;E consumer service professional will provide expert repair service, sched-
uled
at a time that’s cc~nvenient for you. Many GE Consumer Service company-
operated locations offer you service today or tomorrow, or at your convenience
(7:00 a.m. to 7:00 p.m. weekdays, 9:00 a.m. to 2:00 p.m. Saturdays). Our factory-
trained technicians know your appliance inside and out—so most repairs can be
handled in just one visit.
GEAnswer Centep
80~62E2000
Whatever your question about any GE major appliance, GE Answer [;enter@
information service is available to help. Your call—and your question—will be
answered promptly and courteously. And you can call any time. GE Answer
(;enter@ servi(e is open 24 hours a day, 7 days a week.
SECT, O.A.A
,., ,.. ...7. .,...,. ,s7. ”,.”.”.,”
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
kr Customem With Special Needs...
80~6262000
Upon request, GE will provide Consumers with impaired hearing or speech who have
Braille controls for a variety of GE access to a TDD or a conventional teletypewriter
may
appliances, and a brochure to call 800-TDD-GEAC (800-833-4322) to request infi)rrna-
assist in planning a barrier-free tion or service.
kitchen for persons with limited
mobility. To obtain these items,
free of’charge, call 800.626.2000.
Service Contracts
80&626-2224
Y()(l can have [he secure feeling that GE Gonsumer Service will still be there
af’ter your warranty expires. Purchase a GE contract while your warranty is still
in eflkc[ and you’ll receive a substantial discount. With a multiple-year contract,
you’re assured of’ f’uture service at today’s prices.
Pafls andAccessories
80@626-2002
Individuds qualified to service their on appliances User maintenance instructions contained in this booklet
can have needed parts or accessories sent directly to cover procedures intended to be performed by any user.
their home. The Gk: parts system provides access to over Other servicing generdy shodd be referred to qualified
47,000” parts... and all GE Genuine Renewal Parts are service personnel. Caution must be exercised, since
fully warranted. VISA, Master(lard and Discover cards improper servicing may cause unsafe operation.
are accepted.

YOUR GE AUTOMATIC DISHWASHER
Staple sales slip or cancelled check
here. Proof of original purchase date
WARRANTY
is needed to obtain service
II
under warrantv.
WHAT IS COVERED
FULL ONE-YEAR WARRANTY
For one year from date of original
purchase, we will provide, free of
charge, parts and service labor in
your home to repair or replace any
part of the dishwasher that fails
because of a manufacturing defect.
FULL TEN-YEAR WARRANTY
This warranty is extended to
the original purchaser and any
succeeding owner for products
purchased for ordinary home use
in the 48 mainland states, Hawaii
and Washington, D.C. In Alaska the
warranty is the same except that it
is LIMITED because you must pay
to ship the product to the service
For ten years from date of original shop or for the service technician’s
purchase, we will provide, free of travel costs to your
home,
charge, parts and service labor in All warranty service will be
your home to repair or replace the
tub or door /iner if it fails to contain
provided by our Factory Service
Centers or by our authorized
water because of a manufacturing
defect such as cracking, chipping, Customer
Care@ servicers during
normal working hours.
peeling or rusting. Should your appliance need
sewice, during warranty period or
beyond, call 800-GE-CARES
(800-432-2737).
WHAT IS NOT COVERED
● Service trips to your home to teach
you how to use the product.
Read your Use and Care material.
If you then have any questions
about operating the product, please
contact your dealer or our
Consumer Affairs office at the
address below, or call, toll free:
GE Answer
Cente@
800.626.2000
consumer information service
● Improper installation.
● Replacement of house fuses or
resetting of circuit breakers,
● Cleaning or servicing of air gap
device in drain line.
● Failure of the product if it is used
for other than its intended purpose
or used commercially,
● Damage to product caused by
accident, fire, floods or acts of God
WARRANTOR IS NOT
RESPONSIBLE FOR
CONSEQUENTIAL DAMAGES.
If you have an installation problem,
contact your dealer or installer.
You are responsible for providing
adequate electrical, plumbing and
other connecting facilities.
I
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion
may not apply to you. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
To know what your legal rights are in your state, consult your local or state consumer affairs office or your state’s Attorney General.
Warrantor: General Electric Company
If further help is needed concerning this warranty, write:
Manager—Consumer Affairs, GE Appliances, Louisville, KY 40225
This book is printed on recycled paper.
Pad No. 165 D4700P016
GSD5L
Pub No. 49-5678
GSD53(
I
I
9-94 CG
Printed in Louisville,
K}
