GE Monogram ZBD6880NSS User guide

Dimensions and Specifications (in inches)
• The dishwasher must be installed so that the drain hose
is no more than 10 feet in length for proper drainage.
• Water and power supply should enter in the
shaded area.
• Electrical and water connections are at the right front
of the dishwasher. The hot water line should extend
forward 30" to 40" from the rear wall. The electrical must
extend forward at least 24" to reach the junction box.
• To prevent siphoning, an air gap must be used when
the waste tee or disposer connection is less than 18"
above the floor.
Cabinets
Square
and
Plumb
Floor MUST
be Even with
Room Floor
This Wall Area
must be Free of
Pipes or wires
34-1/2" Min.
Underside of
Countertop
to Floor
24"
Min.
24" Min.
5" 5"
4" 4"
6"
24"
*24"
34"
Adjustable
to 35"
Electrical Requirements
The dishwasher must be supplied with 120V, 60Hz, and
connected to an individual properly grounded branch
circuit protected by a 15- or 20-amp circuit breaker or
time-delay fuse.
ZBD6880NSS/ZBD6800NWW/BB
GE Monogram®Fully Integrated Built-In Dishwasher
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Specification Revised 2/08 150044
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
Listed by
Underwriters
Laboratories

Features and Benefits
• Stainless Steel Interior
• Hidden, Integrated Top Controls
• Long Door Design
• Powerful Forced-air Drying System
• CleanSensor Technology
• Nylon Upper and Lower Racks
• NSF®Certified To Sanitize
• ENERGY STAR®Qualified
• Model ZBD6880NSS – Stainless steel
• Model ZBD6800NWW – White on white
• Model ZBD6800NBB – Black on black
ZBD6880KSS
ZBD6880NSS/ZBD6800NWW/BB
GE Monogram®Fully Integrated Built-In Dishwasher
Specification Revised 2/08 150044
