Installation
Instructions
Built-In Dishwashers
PDW8000,PDW8060
DesignGuidewith
Installation Instructions
GEAppliances
Safety Information
BEFORE YOU BEGIN
Read these instructions completely mid carefully.
•IMPORTANT S_,,'etheseinstructionsfor
local inspector's use. Observe all governing
codes and ordinances,
• Note to Installer - Be sure to leave these instruc-
tions with the Consmner.
• Note to Consumer - Keep these instructions with
your Owner's Mai_ual tot fllture reterence.
•Skill Level - Installation of this dishwasher requires
basic mechanical and electrical skills, Proper installa-
tion is the responsibility of the installer, Product
failure due to improper installation is not covered
under the GE Applimace Warranty.
•Completion Time -1 to 2 Hours. Nex_ installa-
tions require more time than replacement installa-
tions.
•IMPORTANT -ThedishwasherMUST
be installed to allow for future removal fl'om the
enclosure if serxice is required,
If you receixed a damaged dislmasher, you should
immediatelv contact wmr dealer or builder.
READ CAREFULLY.
KEEP THESE INSTRUCTIONS.
FOR YOUR SAFETY
Read and observe all CAUTION and WARNINGS
shown throughout these instructions.
CONTENTS
Design Information
Product Dimensions ....................................................... 3
Models Available ............................................................ 3
Advance Plam_ing .......................................................... 3
Installation Preparation
Materials Xibu Will Need ................................................. 4
Tools Ybu Will Need ....................................................... 4
Parts Supplied ................................................................. 5
Prepare Dishwasher Enclosure ..................................... 5
Drain Requirements ....................................................... 6
Prepare Electrical Wiring ............................................... 7
Prepare Hot Water Line ................................................. S
Custom Pm_el Dimensions
Custom Panels hw PDW8000 ........................................ 9
Installation Instructions
Step 1, Remo_,e Packaging ........................................... 10
Step 2, Install Leveling Legs ....................................... 10
Step 3, Remove Access Covers .................................... 10
Step 4, Install 90 ° Elbow ............................................... ] 0
Step 5, Install Power Cord ............................................ ] 1
Step 6, Level Dishwasher. ............................................. ] 1
Step 7, Slide Dishwasher into Opening ....................... ] ]
Step 8, Cmmect _vVater Line ........................................ 11
Step 9, Comaect Drain Line ........................................ 12
Step 10, Cmmect Electrical ......................................... 12
Step ] 1, Position and Level Dishwasher. ..................... 13
Step ] 2, Pre-Test Check List ........................................ 13
Step ] 3, Dishwasher Wet Test ..................................... 13
Step 14, Secure Dishwasher
to Cabinet or Countertop ....................................... 14
Step 15, Install Toekick ................................................ 14
Step 16, Install Side Filler Strips .................................. 15
2
Design Information
PRODUCT DIMENSIONS
34"
Adjustable
to 35"
DISHWASHER MODELS
Traditional Built-In
PD_V8000 BB, Black- Accepts 1/4" or 3/4" custom
panels
PD_V8000 W_V White -Accepts 1/4" or 3/4" custom
panels
PD_V8000 CC Bisque -Accepts 1/4" oi" 3/4" custom
panels
Trim Kits
• GPF725W (white), GPF725B (black) or GPF725C
(bisque) custon_ panel kits, supports a 1/4" thick
CtlStOlI/ door panel.
• ZPF675W (white), ZPF675B (black), ZPF675C
(bisque), custon_ panel kits support a 3/4" thick
custom door panel.
Stainless Steel Built-In
PD_vV8060 SS, Stainless steel door
ADVANCE PLANNING
• These dishwashers are designed for versatility,
adaptable to virtually any installation.
• All models have a flfll length door or a modified
door to accept a fifll cabinet panel without tile
traditional access panel
• Side tub flange trim is ac!justable and will conceal
any slight gap between tile dishwasher and a(!jacent
cabinetry.
• These dishwashers may be installed beneath
countertops of stone or other materials that will not
accept screws. No trim kit required.
Standard installation in 24" deep cabinets
• In standard 24" deep cabinets, tile dishwasher door
will be flush with ac!jacent cabinetry.
• Models with 3/4" thick custom door panel will tit
flush with ac!jacent cabinetry.
Supplied or Custom Toekicks
• A 2-piece toekick is supplied with all models. Tile
toekick is height and depth a(!justable.
• Depending on cabinetry style, a custoln toekick can
also be installed to match cabinetry. Care must be
taken to assure door swing clearance above tile
toekick.
ADA-Compliant
Installation below 34" high countertops
A reduced height installation (32-1/2" rain.) beneath
a 34" co/mtertop, can be accomplished by removing
the fl'ont leveling legs. The rear legs should be
screwed in flush with the bottom support, as shipped.
Tile fl'ont of tile dishwasher i//tlSt be shimmed to
level tile dishwasher. _v_ater and electrical must be
routed through tile back wall.
Installation Preparation
MATERIALS YOU WILL NEED:
Materials Required for All Installations
[] 90° Elbow (3/8"NPTexternal thread on one end,opposite
end sizedto fit water supply)
Note: Usenew ferrule. Donot use oldparts.
[] Strain relief for electrical connection
[] Threadseal tape
[] ULListedwire connectors (3)
[] Screwtype hose clamps
Materials For New Installations Only:
[] Air gapfor drain hose, if required
[] Waste tee for house plumbing, if applicable
[] Electrical cable or power cord, if applicable
[] Handshut-off valve (recommended)
[] Water line 3/8" min. copper or 1/2" min. plastic (plastic
must betested for temperature and pressure)
[] Couplerfor extending drain line, if applicable
@
90° Elbow
ThreadSeal
Tape
©G
Screw TypeClamps
WireNuts
Shut-Off
WasteTee Valve
Air c°uO_pler
Gap
©
StrainRelief
ElectricalCable
or PowerCord
HotWaterLine
TOOLS YOU WILL NEED: FlatBladeScrewdriver Nut Driver
Tools Required for All Installations
[] Phillips head and flat blade screwdrivers
[] 3/8", 5/16" and 1/4" nutdrivers
[] Level
[] Carpenters square
[] Measuring tape
[] Safety glasses WireStrippers
[] Flashlight
[] Bucket to catch water when flushing the line
[] Tubingcutter
[] Glovesto protect against sharp edges
[] Wire strippers
For New Installations Only:
_ PhillipsHead
_z_, Screwdriver
SafetyGlasses _ ,4._,_,,_ _E_ _Uubtit_
+
[] Drill and appropriate bits
[] Holesaw set
Gloves
Level Square
Hole
SawSet
Installation Preparation
PARTS SUPPLIED:
Remove the hardware accessory bag and other parts
fl'om inside or taped to the outside of the dishwasher.
Check contents against illustrations to ii'Jsure that all
parts are included.
[] 2-piece toekick
[] 6 screws (see illustration)
[] 2 leveling legs
[] Junction boxcover Junction
BoxCover
with screws 2 Leveling Legs
Screws A Screws B
(2)Countertop (2)Cabinet
Mounting Mounting
Screws Screws
Screws C
(2)Color
Matched
Toekick
Screws
e_
2-PieceToekickwith
SoundInsulation
PREPARE DISHWASHER ENCLOSURE
ThisWallArea
mustbeFree/
34"to35" PipesorWires
Underside 1
ofCountertop
toFloor
24"Max
•The rough cabinet opening Inust be at lea.'t 24 deep,
_35 "
2. -,/8 rain. to 24" wide. The height should be 34" rain.
add _"
_)r) Ill}IX,
Note: ADA installation, beneath 34"high countertops may be accom-
plished byremoving front leveling legs. Drain hose,water and
electrical must be routed through the cutout onthe back of the
dishwasher.
• The dishwasher must be installed so that drain hose is
no more than 10 feet in length for proper drainage.
• The dishwasher inust be flfllv enclosed on the top, sides
and back, but should not support any part of the
eI/clostlI'e.
• The floor inside the opening must be even and level
with the finished floor of the kitchen, If the kitchen
floor is tile, it may be
higher than the floor of
the installation cutout,
Pieces of wood may be
placed into the cutout
floor to make it level or
higher than the room
floor, This will alh)w easy
removal fi)r any flmn'e
service,
CornerInstallation
• When installing into a
corner, allow 2" rain.
clearance between
dishwasher andadjacent
cabinet or wall.
• Allow 24-1/2"min. clearance
from the front ofthe
dishwasher for door
opening.
J Countertop
Dishwasher
,_/2"
/_ Clearancefor Door
/Opening 2" Minimum
5
Installation Preparation
DRAIN REQUIREMENTS
• Follow local codes and ordinances.
• Do not exceed ] 0 feet distance to drain.
• To prevent back flow into the dishwasher, COlmect
drain line to an air gap or use a 30" high drain loop,
depending on local codes.
• Air gap in ust be used when waste tee or disposer
COlmectioi_ is less than 18" above the floor to prevent
siphoning.
DETERMINE DRAIN METHOD
The type ot drain iI_stallati(m depends (m the fl)llowing
questions.
Do local codes or ordii_ances reqtlii'e an aii" gap?
Will waste tee or disposer COlmectioi_ be less than 18"
above the floor?
Will installation have a high drain loop less than 30"
above the floor?
If the answer to ANYof these questions is YES, Method 1
MUST be used.
• If all answers are NO, either inethod inay be used.
.M_ air gap MUST BE USED if the drain hose is con-
nected to a waste tee or disposer lower than 18" above
the floor level.
• Faihu'e to provide the proper drain COlmectioi_ using
an air gap or a 30" rain. high drain loop will result in
ilnproper drailfing of the dishwasher which inav cause
damage or poor wash peril)finance.
Method 1 - Air Gap with Waste Tee or Disposer
An air gap must be used when the waste tee or disposer
connection is less than 18" from the floor.
Method 2 - High Drain Loop with Waste Tee or
Disposer Install waste tee or disposer and air gapaccording
to manufacturer's instructions. l-
CABINET PREPARATION
• Drill a 1-1/9" dia. hole in the cabinet wall within
the shaded areas shown for the drain hose Colmec-
tion. The hole should be Slnooth with no sharp
edges.
ll DOlT YAVOIR tree coupure ai_tirefl)ulemei_t si le
ttlvat! de vidange est branch6 sur un raccord d'6gout ou
tin broyeur d'ordures a inoins de 46 cln (18 po) du sol.
• Si la vidange n'est pas branch_e correctement en
utilisant tree coupure ai_tirefoulelnei_t ou tm boucle
d'_gout d'au moins 76 Cln (30 po) de haut,
l'_coulemei_t de l'eau du lave-vaisselle n'est pas boil
ce q ui petit causer des dolmnages ou tm inauvais
lavage de la vaisselle.
Installation Preparation
PREPARE ELECTRICAL WIRING
FOR PERSONAL SAFETY: Remove
house fllse or open circuit breaker
before begimfing installation. Do not use
an extension cord or adapter plug with
this appliance.
r
POUR ASSURER LA S1_CURIT1_
PERSONNELLE, il flint enlex er le fllsible
ou couper le courant au disjoncteur
axant de commencer l'installation. Axec
cet appareil, il ne taut pas utiliser de
ralhmge ni d'adaptateur de prise.
Electrical Requirements
• This appliance must be supplied with 120V, 60 Hz., and
com_ected to an individual properly grounded branch
circuit, protected by a 15 or 90 ampere circuit breaker or
time delay fllse.
• Wiring must be 2 wire with ground and rated for 75°C
(176°F).
• If the electrical supply does not meet the above require-
merits, call a licensed electrician betore proceeding.
Grounding Instructions-Cable Direct
This appliance must be (mmected to a grom_ded metal
perlnai_ei_t wiring system, or an equipment-grounding
con ductor must be r/In with the circuit con ductors an d be
com_ected to the equipment-grounding terminal or lead
on the appliance.
Grounding Instructions-Power Cord
This appliance Inust be gromMed. In the event ot a
malflmction or breakdown, grounding will reduce the risk
of electrical shock by providing a path of least resistance
fin" electric current. The plug must be plugged into an
appropriate outlet that is installed and grounded in
accordance with all local codes and ordinances.
The improper cmmection of the eq uip-
merit-grounding conductor can result in
a risk of electric shock. Check with a
qualified electrician or service represen-
tative if vou are in doubt that the appli-
ance is properly gromMed.
"Cabinet
2"
Black White
Electrical Connections to Dishwasher:
The dishwasher junction box is located on the right side
at the fl'ont of the dishwasher. The electrical cable must
extend forward at least 24" to reach the junction box
when dishwasher is installed.
• The wiring inav enter the opening from either side,
rear or the floor within the shaded area.
• Cut a 1-1/9" max. dia. hole to admit the electrical
cable or use the same hole cut tor the drain hose. The
hole inust be flee of sharp edges. If the cabinet wall is
metal, the hole edge must be covered with a bushing.
• For power cord cmmections, install a 3-prong ground-
ing type receptacle in the sink cabinet rear wall, 6"
rain, or 18" max. fl'om the opening, and 6" to 18"
above the floor.
I'!_ll;/'|!aiI,"I,"I!K',I!t'I Le mauvais branchement du fil de raise h
la terre de l'&luipement petit causer tm
choc _lectrique. En cas de doute sin" la
raise h la terre de l'appareil, consulter un
_lectricien qualifi_ ou un repr_sentant
teclmiq tie.
Installation Preparation
PREPARE HOT WATER LINE
The line may enter fl'om either side, rear or floor
within the shaded area shown.
• The water line may pass through the same hole as
the electrical cable and drain hose. Or, cut an
additional l-1/2" dia. hole to admit the line. If a
power cord with plug is used, it must pass through
a separate hole.
Water Line Connection
• Turn o11 the water supply.
• Install a hand shut-otI valve in an accessible loca-
tion, such as under the sink. (Optional, but strongly
recommended and may be required bv local codes.)
• The hot water line should be 3/8" O.D. copper
tubing or 1/2" O.D. plastic tubing. The line must
extend forward at least 30" fl'om the left side or 40"
fi'om the i'eai" wall.
• The water line illtlSt be hmg enough to form a
smooth natural loop with no sharp bends or kinks
between the cutout entry.
/
/
i\
i \ \
Shut-offValve
\,,_
ii
ii
Hot[]::::
ii
ii
ii
CabinetFace_ fromWall 2" fromFloor
• At!just water heater to deliver temperatures of 120°F to
150°F.
• lqush watei" line to clean out debris.
• The hot water supply line pressure must be 90-190 PSI.
Custom Panel Dimensions
CUSTOM PANEL FOR MODELS
PDW8000
Panel kits must be ordered separately. Installation
of any custom panel should be completed before
the dishwasher is installed.
1/4" PANEL WITH GPF725 TRIM KIT
1/4"Thick I
DoorPanel 25-1/4"
23-1/8"
• Cut the panel to the climensions shown.
• The bottom left and right coi'nei's should be ctlt at
1/4" radius. See illustration.
3/4" PANEL WITH ZPF675 TRIM KIT
The ctlstom panel size xaries depending on your
installation.
Countertop Custom
Panel Size
Cabinets
A
S Floor -_11_
/Bottom of 3/4" Max.
AdjacentCabinetry
Top
3/4" Thick _Helght
DoorPanel
23-1/8"_
* Height is equal to A minus 5-3/8"
EXAMPLE:A =30-1/2"minus5-3/8"is equalto 25-1/8".
1. Measure Dimension A, fl'om underside of countertop
to bottom of a(!jacent cabinets.
2. Subtract 5-3/8". Control panel height is 5-1/8"..Mlow
1/4" clearance between countertop and control
panel.
3. The custom panel fits against bottom of the control
panel.
Installation Instructions
BEFORE YOU BEGIN:
CUSTOM PANEL INSTALLATION: Ifvou intend to
install custom door panels, (on some models) refer to
trim kit installation instructions. Custom panels should
be in place bet0re installing tile dishwasher.
ISTEP 1] REMOVE PACKAGING
Cut tile shipping carton and use it as a pad beneath tile
dishwasher. This will protect tile finished floor in tile
kitchen.
• Remove wrapping and uncoil tile drain hose in tile
back of tile dishwasher. Do not remove rear insulation
blanket,
• Lay the dishwasher on it's back, Do not kink or crush
the drain hose,
[STEP 2] INSTALL LEVELING LEGS
Min.
Rernove
RedPlugs
Unscrew
RearLegsto
Rear Installation
Insulation Height
Blanket
• Measm'e installation opening fi'om tile floor to tile
bottom of tile co/mtertop.
•Install tile fl'ont leveling legs into holes on tile brack-
ets. Use a wrench to screw tile legs in until tile overall
height of tile dishwasher is 1/4" less than tile installa-
tion opening height.
Note: InstaU the legs as shown, 1-1/4" min from the
bottom of the bracket.
• Remove and discard tile red plugs fl'om tile fl'ont
holes.
lSTEP31REMOVE ACCESS COVER
AccessCoverJuncti°_c"
•ReIllOX e sol/nO instllation board and tile access coxer
plate.
• Install UL listed strain relief on.jUllCtioi_ box.
lSTEP 41 INSTALL 90 °ELBOW
• Install tile 90 ° elbow onto tile water inlet. Use thread
seal tape or pipe thread compo/md. Thread seal tape
should be wrapped in sam e direction as tile threads on
tile elbow.
• Tile 90 ° elbow should time tile inlet water line.
10
