MODEL SERIES:
DPGT750EC/GC
TECHNICALSERVICE GUIDE
GE Consumer Products
Profile Gas and
Electric Dryers
H
E
L
P
B
A
C
K
S
T
A
R
T
S
T
O
P
H
O
M
E
M
Y
C
Y
C
L
E
P
O
W
E
R
PUB # 31-9104 07/03

– 2 –
IMPORTANT SAFETY NOTICE
The information in this service guide is intended for use by
individuals possessing adequate backgrounds of electrical,
electronic, and mechanical experience.Any attempt to repair a
major appliance may result in personal injury and property
damage. The manufacturer or seller cannot be responsible for the
interpretation of this information, nor can it assume any liability in
connection with its use.
WARNING
If the information in this manual is not followed exactly, fire or explosion
may result causing property damage, personal injury or death. If you smell
gas:
– Do not try to light any appliance.
– Do not touch any electrical switch; do not use any phone in the
building.
– Immediately call the gas supplier from a neighbor’s phone. Follow
the gas supplier’s instructions.
– If you cannot reach the gas supplier, call the fire department.
WARNING
To avoid personal injury, disconnect power before servicing this product. If
electrical power is required for diagnosis or test purposes, disconnect the
power immediately after performing the necessary checks.
RECONNECT ALL GROUNDING DEVICES
If grounding wires, screws, straps, clips, nuts, or washers used to
complete a path to ground are removed for service, they must be returned
to their original position and properly fastened.
GE Consumer Products
Technical Service Guide
Copyright © 2003
Allrightsreserved.Thisserviceguidemaynotbereproducedinwholeorinpartinany
formwithout written permissionfrom the GeneralElectric Company.

– 3 –
Table of Contents
AirflowDiagram (Gas andElectric Models)....................................................................................15
Backsplash ...................................................................................................................................20
Belt Switch....................................................................................................................................26
BlowerMotor .................................................................................................................................27
ComponentLocatorViews.............................................................................................................16
ConsumerHelpScreens................................................................................................................13
ControlFeatures............................................................................................................................. 7
ControlQuickReferenceChart ......................................................................................................38
ControlSystem .............................................................................................................................20
DoorSwitch...................................................................................................................................25
DriveBelt.......................................................................................................................................26
DriveMotor ....................................................................................................................................27
Drum .............................................................................................................................................24
DrumLight ....................................................................................................................................26
DrumRollers .................................................................................................................................25
Dry Cycles ..................................................................................................................................... 9
DryerComponents ........................................................................................................................20
DryerControlPanel ........................................................................................................................ 7
DryerTemperature Settings (Gasand Electric)..............................................................................15
ErrorCharts...................................................................................................................................43
Factory Test Mode ........................................................................................................................36
FieldServiceMode........................................................................................................................35
FrontPanel ...................................................................................................................................23
GasValve......................................................................................................................................32
HeaterAssembly(Electric Models) ...............................................................................................29
Hi-LimitThermostat .......................................................................................................................32
Ignitor ............................................................................................................................................33
IgnitorandFlame Detector ............................................................................................................34
InletSafetyThermostat .................................................................................................................30
InletThermistor .............................................................................................................................30
Inverter ..........................................................................................................................................21
InverterandMainBoardPin Connectors ........................................................................................18
MainControlBoard andTouchScreenLCD ...................................................................................20
MembraneKeypanel .....................................................................................................................21
MoistureSensor............................................................................................................................34
My Cycles.....................................................................................................................................12
Nomenclature ................................................................................................................................. 4
OperationOverview ........................................................................................................................15
OutletThermistor ..........................................................................................................................31
OutletThermostat .........................................................................................................................31
Overview ......................................................................................................................................... 6
Parts .............................................................................................................................................48
Quick Start..................................................................................................................................... 8
ReversingtheDoorSwing..............................................................................................................58
SalesDemo Mode.........................................................................................................................14
Schematics...................................................................................................................................46
Signal(Beeper) .............................................................................................................................22
SummaryScreen ..........................................................................................................................10
Switching the Washer and Dryer Backsplashes ............................................................................60
TopCover ......................................................................................................................................23
Troubleshooting .............................................................................................................................39
TroubleshootingCharts..................................................................................................................40
Warranty ........................................................................................................................................ 5

– 4 –
GE Dryer
Feature Pack
CommonBrandFeatures
Exceptions:
H = Energy Star
P = Profile™
K, N = Special
S = Spacemaker®
D P G T 7 5 0 E C 0 W W
Capacity/Configuration
L = Large S = Super
X=Extra-Large K = Compact
G = Giant
Control Platform
B = Buttons (Touch Pad) T = Touch Screen
Q = QuickClean S = Stationary
R = Rotary F = Fabric Care
P = Portable H = Horizontal Axis
Drying Machine Heat Selections
Dryer Control
Fuel/Voltage
E = Electric
G = Gas
Model Year
Designator
Body Color
Backsplash
Color
Serial Number
The first two characters of the serial number
identify the month and year of manufacture.
Example: RF123456S = August 2003
A-JAN 2005 - H
D - FEB 2004 - G
F - MAR 2003 - F
G -APR 2002 - D
H-MAY 2001 -A
L- JUN 2000 - Z
M-JUL 1999 - V
R -AUG 1998 - T
S - SEP 1997 - S
T - OCT 1996 - R
V - NOV 1995 - M
Z - DEC 1994 - L
The letter
designatingthe
year repeats every
12 years.
Example:
T - 1974
T - 1986
T - 1998
Note: Model number and serial number are
located on the front panel inside the door.
•The technical sheet is located behind
the control panel.
Engineering
Revision
Number of Cycles
Nomenclature
Model & Serial Numbers

– 5 –
Warranty
For The Period Of: We Will Replace:
One Year Any part of the dryer which fails due to a defect in materials or workmanship. During this
From the date of the full one-year warranty, GE will also provide, free of charge, all labor and related service costs to
original purchase replace the defective part.
Second Year Any part of the dryer which fails due to a defect in materials or workmanship. During this
From the date of the additional one-year limited warranty, you will be responsible for any labor or related service costs.
original purchase
Third through Fifth Year The extra-large or super-capacity dryer drum and main electronic control board if any of these parts should
From the date of the fail due to a defect in materials or workmanship. During this additional three-year limited warranty,
original purchase you will be responsible for any labor or related service costs.
All warranty service provided by our Factory Service Centers or
an authorized Customer Care
®
technician. To schedule service
on-line, 24 hours a day, visit us at www.GEAppliances.com or
call 800.GE.CARES (800.432.2737).
■ Service trips to your home to teach you how to use
the product.
■Improper installation, delivery or maintenance.
■Failure of the product if it is abused, misused, or
used for other than the intended purpose or used
commercially.
■Replacement of the light bulb after its expected
useful life.
■ Replacement of house fuses or resetting of circuit
breakers.
■ Damage to the product caused by accident, fire, floods
or acts of God.
■ Incidental or consequential damage caused by possible
defects with this appliance.
■ Damage caused after delivery.
What Is Not Covered:
This warranty is extended to the original purchaser and any succeeding owner for products purchased for home use within the
USA. In Alaska, the warranty excludes the cost of shipping or service calls to your home. Proof of the original purchase date is
needed to obtain service under the warranty.
Some states do not allow the exclusion or limitation of incidental or consequential damages. This warranty gives you specific
legal rights, and you may also have other rights which vary from state to state. To know what your legal rights are, consult
your local or state consumer affairs office or your state’s Attorney General.
Warrantor: General Electric Company. Louisville, KY 40225
Note: The LCD screen is part of the main electronic board and under the 5 year part warranty. The
inverter board is covered by a 2 year part warranty.

– 6 –
Overview
General
The GE Profile Harmony Dryer is part of the GE Profile
Harmony Clothes Care System utilizing the latest
developments in dryer technology.
Most conventional drying systems have a single motor
that powers both the blower and the drum. Therefore,
the blower fan and dryer drum are powered at the same
rate of speed. If air flow is impeded by lint buildup or
lengthy venting, the dryer cannot increase the fan
speed without increasing the drum speed. The
Harmony Dryer System utilizes dual motors and
strategically placed sensors. This enables the dryer to
respond quickly to temperature changes and ensure
proper air flow to optimize drying effectiveness.
Other features include:
Communication Link to the Washer- The dryer uses a
serial cable to automatically receive information from
the washer about the nature of the wash load,
essentially presetting the dryer controls so the user
doesn’t have to.
Dual Motors - The dryer is equipped with dual motors -
one dedicated to the drum, the other to the blower fan.
The addition of a dedicated blower motor enables the dryer to alter fan speed whenever necessary to
optimize air flow. This capability greatly increases drying performance and efficiency. (See Drive Motor
and Blower Motor).
Variable Heater - The dryer's heater is capable of variable heat output. Its voltage regulation feature
allows the system to be rated at 6000 watts.
Dual Thermistors - Thermistors are much more sensitive to temperature changes and can relay the
information faster than thermostats. The dryer uses dual thermistors to monitor incoming air
temperature as well as the air temperature leaving the drum. The sensors work together with the
variable heater and blower to provide consistent even heat. (See Inlet Thermistor.)
Moisture Sensor - The moisture sensor allows the control to monitor the fabric for moisture content and
end the cycle at the desired moisture level. (See Moisture Sensor.)
Plastic Top & Backsplash - The dryer top and backsplash have UV stabilizers to prevent yellowing when
exposed to sunlight.
H
E
L
P
B
A
C
K
S
T
A
R
T
S
T
O
P
H
O
M
E
M
Y
C
Y
C
L
E
P
O
W
E
R

– 7 –
P
O
W
E
R
M
Y
C
Y
C
L
E
S
B
A
C
K
H
E
L
P
START
STOP
H
O
M
E
Features of
the dryer
control
panel
1 POWER. Press to “wake up” the display. If
the display is active, press to put the dryer
into standby mode. You may also press the
Touch Screen or any button to “wake up”
the display.
NOTE: Pressing POWER does not
disconnect the appliance from the power
supply.
2 MY CYCLES. Press to use, create, rename,
modify or delete custom dry cycles.
3 BACK. Press to return to the previous
screen.
4 TOUCH SCREEN. Press the graphics
on the interactive display to use the dryer
features.
Do not use sharp objects to press the Touch
Screen.
NOTE: If the dryer is inactive for 5
minutes, the Touch Screen will go into
standby mode, and the display will be dark.
Press the Touch Screen or any button to
“wake up” the display.
5 HOME. Press to return to the “TOUCH TO
SELECT Sensor DRY CYCLE” screen (Home
Screen).
6 START/STOP. Press to start a dry cycle.
If the dryer is running, pressing once will
pause the dryer. Press again to restart the
dry cycle.
NOTE: If the dryer is paused and the cycle
is not restarted within five minutes, the
dryer will enter standby mode and the
current dry cycle will be canceled.
7 HELP. Press to set machine preferences, to
find help using the Touch Screen or to find
troubleshooting tips for common dryer
problems.
Throughout this manual, features and appearance may vary from your model.
Control Features
Dryer Control Panel

– 8 –
Quick Start
Getting
Started
If the Touch
Screen is
dark, press
POWER or
the Touch
Screen to
access the
dry cycles
menu.
Clean the lint filter.
IMPORTANT: Clean the lint filter each time
you use the dryer.
Add clothes. Do not overload. This wastes
energy and promotes wrinkling.
Select one of the four drying methods from the
Home Screen:
• Press BY FABRIC to dry according to fabric
type.
• Press BY GARMENT to dry according to
clothing type.
• Press SPECIAL CYCLES to dry nongarment
items, to dry without heat or to dry using the
drying rack.
• Press TIMED DRY to specify a drying time
and temperature.
Change any of the automatic settings, if
desired, by pressing the Touch Screen and
following the on-screen instructions.
By changing the settings you can:
• Change the level of dryness
• Change the drying temperature
• Set a Delay Start or Extended Tumble, or
change the End-of-Cycle Signal volume
• Adjust time settings
Close the door and press START.
The dryer will not operate unless the door is
closed.
BY FABRIC BY GARMENT
TOUCH TO SELECT
Sensor DRY CYCLE
SPECIAL
CYCLES TIMED DRY
SUMMARY SCREEN
0:36
TIMEOPTIONS
TEMPDRYNESSCYCLE
COTTONS MORE DRY
START
STOP
SENDING INFO TO DRYER... RECEIVING...
Washer
Communicated
Cycles
If the Washer/Dryer Communication features
of your washer and dryer are turned ON, your
dryer will receive cycle information from your
washer to create a dry cycle that matches your
wash load.
After the wash cycle is complete,
communication begins once either the washer
or dryer Touch Screen is activated.
Once the information is received, your dryer
can then create the optimal dry cycle for your
load. You can then change any of the
automatic cycles, as desired.
NOTE: For some communicated wash cycles,
your dryer will prompt you to select a FABRIC
TYPE.
See “Final Setup” in the Installation
Instructions for attaching the serial cable for
Washer/Dryer Communication.
Washer Display Dryer Display
Home Screen

– 9 –
Dry Cycles
Drying by
Fabric Type
If the Touch Screen is dark, press POWER or the Touch Screen to access the dry cycles menu.
The default cycle settings are based on standard load types. Always follow the fabric manufacturer’s
care label when laundering.
• Blends
• Cottons
• Delicates
• Knits
• Polyester
• Silks (Washable)
BY FABRIC
Drying by
Garment
Type
• Athletic Wear
• Blouses
• Delicates
• Dress Shirts
• Easy Care
• Everyday
Wear/Casual
• Jackets/Coats
• Jeans
• Khakis
• Knits
• Lingerie
• Mixed Garments
• Play Clothes
• Silks (Washable)
• Sweaters
• Swimwear
• Underwear
BY GARMENT
Select By FABRIC to dry loads sorted by fabric type.
FABRIC CYCLES include:
Select By Garment to dry loads sorted by garment type.
GARMENT CYCLES include:
Drying
Using
Timed Dry
1 Press TIMED DRY.
2 Use the arrows to set more or less time; then press OK.
3 Use the arrows to set the temperature; then press OK.
4 Press START.
TIMED DRY
Select TIMED DRY to set your own drying time.
Timed Dry is also recommended for small loads.
Drying
Using the
Special
Cycles
• Air Dry
• Blankets (Cotton)
• Blankets (Other)
• Comforter
• Dewrinkle
• Dryel™
• Pet Bedding
(Washable)
• Pillows (Washable)
• Rack Dry
• Sheets
• Sneakers
• Throw Rugs
(Washable)
• Towels
• Warm Up
SPECIAL
CYCLES
Select SPECIAL CYCLES to dry loads of nongarment items, use the
drying rack or to tumble using low or no heat.
SPECIAL CYCLES include:

– 10 –
Summary Screen
SUMMARY SCREEN
0:36
TIMEOPTIONS
TEMPDRYNESSCYCLE
COTTONS MORE DRY
About the
Summary
Screen
After selecting a dry cycle, the Summary Screen
displays the automatic settings for the cycle you
have chosen. You can adjust these by touching
the screen location for any of the settings
shown.
If you change any of the automatic settings,
you can save the new settings as a custom
“My Cycle” by pressing the MY CYCLES button
while on the Summary Screen and choosing
SAVE CURRENT SETTINGS.
DRYNESS
MORE DRY
LESS DRY
DRY
OK
Changing
the Dryness
Level
To change the dryness level, touch the
DRYNESS pad on the Touch Screen; then use
the arrows to select the level of dryness. Press
OK when you have reached the desired setting.
MORE DRY – Use for heavy-duty fabrics.
DRY – Use for a normal dryness level suitable
for most loads. This is the preferred cycle for
energy saving.
LESS DRY – Use for lighter fabrics.
DAMP – Use to leave items partially damp.
TEMPERATURE
HIGHER
LOWER
EXTRA
LOW
OK
Changing
the Drying
Temperature
To change the drying temperature, touch
the TEMP pad on the Touch Screen; then
use the arrows to select higher or lower
temperature. Press OK when you have
reached the desired setting.
HIGH – For regular to heavy cottons.
MEDIUM – For synthetics, blends and items
labeled permanent press.
LOW – For delicates, synthetics and items
labeled Tumble Dry Low.
EXTRA LOW – For delicates, lingerie and
special-care fabrics.
AIR DRY – For tumbling items without heat.
