GE Profile DPGT650E User manual

GE Profile HE Dryer (9/16/08)
GE CONFIDENTIAL & PROPREITARY INFORMATION - NOT FOR PUBLIC DISCLOSURE
Copyright 2008 General Electric Company 1
gGE imagination at work
GE Profile HE Dryer
DPGT650E/G

GE Profile HE Dryer (9/16/08)
GE CONFIDENTIAL & PROPREITARY INFORMATION - NOT FOR PUBLIC DISCLOSURE
Copyright 2008 General Electric Company 2
gGE imagination at work
Warranty

GE Profile HE Dryer (9/16/08)
GE CONFIDENTIAL & PROPREITARY INFORMATION - NOT FOR PUBLIC DISCLOSURE
Copyright 2008 General Electric Company 3
gGE imagination at work
Nomenclature

GE Profile HE Dryer (9/16/08)
GE CONFIDENTIAL & PROPREITARY INFORMATION - NOT FOR PUBLIC DISCLOSURE
Copyright 2008 General Electric Company 4
gGE imagination at work
Installation Exhaust

GE Profile HE Dryer (9/16/08)
GE CONFIDENTIAL & PROPREITARY INFORMATION - NOT FOR PUBLIC DISCLOSURE
Copyright 2008 General Electric Company 5
gGE imagination at work
Installation Exhaust

GE Profile HE Dryer (9/16/08)
GE CONFIDENTIAL & PROPREITARY INFORMATION - NOT FOR PUBLIC DISCLOSURE
Copyright 2008 General Electric Company 6
gGE imagination at work
LP Conversion
WE25X10026

GE Profile HE Dryer (9/16/08)
GE CONFIDENTIAL & PROPREITARY INFORMATION - NOT FOR PUBLIC DISCLOSURE
Copyright 2008 General Electric Company 7
gGE imagination at work
Control Function
Provide 2 selection “More Time” and “Less Time” to increase or decrease dry cycle timeAdjust dry cycle time
Provide an alert in different conditions (e.g. when one cycle is completed). 3 Options: High, Low, OffSignal
Provides drying of preset duration that is found on the conventional consumer dryerTime Dry
Provide user select different sensor dry cycleCycles
A dryer cycle option that adds extra tumbling time to the dryer cycleWrinkle care
Shows the operating status and special messages of the elected cycleProgress Status Display
Provides the user additional cycle information (i.e. estimated cycle time), error messages7 Segment LED display
Dry Cycle Modifiers include “Dry Level” and “Temp”. These features enable the user to adjust pre-determined
cycles to meet their specific dry requirements.
Dry Cycle (Modifiers)
Selections
Allows the user to save and subsequently recall 1 customized cycle (including options and modifiers)My Cycle Key
The start/pause key, which when pressed, starts the selected cycle, or pauses a currently running cycle.Start / Pause Key
The Power key is used to wake up or power down the control.Power Key
DescriptionKeys

GE Profile HE Dryer (9/16/08)
GE CONFIDENTIAL & PROPREITARY INFORMATION - NOT FOR PUBLIC DISCLOSURE
Copyright 2008 General Electric Company 8
gGE imagination at work
Cycle Selections Default
Y/NYYHighN/A
Time Dry
Y/NYNNo HeatN/A
Air Dry
Y/NYNMid highN/A
Dewrinkle
Y/NYNHighN/A
Speed Dry
Manual Dry
Y/NYN/AExtra LowLess Dry
Ultra Delicates
Y/NYN/AExtra LowLess Dry
Delicates
Y/NYN/ALowNormal
Active Wear
Y/NYN/AMediumNormal
Wrinkle Free
Y/NYN/AMid highNormal
Mixed Load
Y/NYN/AHighNormal
Cottons
Sensor Dry
Signal
(User default)
Wrinkle CareTime DryTempDryness LevelCycles SettingDryer Type
Table 7. Default Cycle Selections

GE Profile HE Dryer (9/16/08)
GE CONFIDENTIAL & PROPREITARY INFORMATION - NOT FOR PUBLIC DISCLOSURE
Copyright 2008 General Electric Company 9
gGE imagination at work
Cycle Selections
Y/NYYAllNone
Time Dry
Y/NYYNo HeatNone
Air Dry
Y/NYYAllNone
Dewrinkle
Y/NYYAllNone
Speed Dry
Manual Dry
Y/NYNExtra LowAll
Ultra Delicates
Y/NYNExtra LowAll
Delicates
Y/NYNLowAll
Active Wear
Y/NYNMediumAll
Wrinkle Free
Y/NYNMed HighAll
Mixed Load
Y/NYNHighAll
Cottons
Sensor Dry
Signal
Wrinkle
Care
Time
Dry
Temp
Dryness
Level
Cycles SettingDryer Type
Table 8. Allowable Cycle Selections

GE Profile HE Dryer (9/16/08)
GE CONFIDENTIAL & PROPREITARY INFORMATION - NOT FOR PUBLIC DISCLOSURE
Copyright 2008 General Electric Company 10
gGE imagination at work
Manual Dry Cycles
The Control shall implement following operating parameters for Manual cycles.
YesAllHighFixed Time540Time Dry
YesNo Heat OnlyNo HeatFixed Time530Air Dry
YesAllMid highFixed Time520Dewrinkle
YesAllHighFixed Time530Speed Dry
Drying Time
Change
Allowed
Allowed
Temp
Default
Temp
Cool Down
Type
Max Cool
Down Time
Default
Drying Time
Cycle

GE Profile HE Dryer (9/16/08)
GE CONFIDENTIAL & PROPREITARY INFORMATION - NOT FOR PUBLIC DISCLOSURE
Copyright 2008 General Electric Company 11
gGE imagination at work
Sensor Dry Cycles
100°FNoneExtra LowAllNormal5 / Adaptive
Ultra
Delicates
100°FNoneExtra LowAllNormal5 / Adaptive
Delicates
117°FNoneLowAllNormal5 / Adaptive
Active Wear
117°FNoneMediumAllNormal5 / Adaptive
Wrinkle Free
117°FNoneMid highAllNormal5 / Adaptive
Mixed Load
117°FNoneHighAllNormal5 / Adaptive
Cottons
Adaptive Cool
Down Temp
Allowed
Temps
Default
Temperature
Allowed Dryness
Levels
Default Dryness
Level
Max Cool Down
Time/Type
Cycle

GE Profile HE Dryer (9/16/08)
GE CONFIDENTIAL & PROPREITARY INFORMATION - NOT FOR PUBLIC DISCLOSURE
Copyright 2008 General Electric Company 12
gGE imagination at work
Default Dry Times
49More dry1:01More dry
58Very dry
ACTIVEWEAR
1:10Very dry
COTTONS
Default timeDry LevelCycles
Default
time
Dry LevelCycles
20Damp dry30Damp dry
26*Less dry37Less dry
34Normal
41*Normal
42More dry50More dry
50Very dry
Ultra Delicate
59Very dry
Wrinkle Free
16Damp dry49Damp dry
21*Less dry52Less dry
32*Normal
55*Normal
43More dry58More dry
53Very dry
Delicates
1:03Very dry
MIXED LOAD
18Damp dry
38Damp dry
23Less dry
44Less dry
36*Normal
54*Normal

GE Profile HE Dryer (9/16/08)
GE CONFIDENTIAL & PROPREITARY INFORMATION - NOT FOR PUBLIC DISCLOSURE
Copyright 2008 General Electric Company 13
gGE imagination at work
Temperature Settings
113°F118°FExtra Low
122°F131°FLow
154°F147°FMedium
158°F158°FMid high
165°F162°FHigh
GasElectric
Max Outlet Temp (RDB) in °F
Temperature Setting
Temperature Setting

GE Profile HE Dryer (9/16/08)
GE CONFIDENTIAL & PROPREITARY INFORMATION - NOT FOR PUBLIC DISCLOSURE
Copyright 2008 General Electric Company 14
gGE imagination at work
Target Temps (Electric)
NANANAN/AN/AN/AAIR
118Half (1)2,700EX-LOW
131Half (1)2,700LOW
420194315147Full (2)5,400MEDIUM
420194365158Full (2)5,400MED-HIGH
420194415162Full (2)5,400HIGH
2 Heater OffOn1 Heater Off
T-Inlet(target) °F
T-out (target)°FHeater
P(startup)
(Watts)
Heat Setting
Electric

GE Profile HE Dryer (9/16/08)
GE CONFIDENTIAL & PROPREITARY INFORMATION - NOT FOR PUBLIC DISCLOSURE
Copyright 2008 General Electric Company 15
gGE imagination at work
Target Temps (Gas)
N/ANANAN/AN/AAIR

113
22,000EX-LOW

122
22,000LOW
2200Btu-->2Btu194
420154
22,000MEDIUM
2200Btu-->1Btu194
420158
22,000MED-HIGH
2200Btu-->0Btu194
420165
22,000HIGH
OnOff
P(Working)
(Btu)
T-Inlet(target) °F
T-out(target)
°F
P(startup)
(Btu)
Heat Setting
Gas

GE Profile HE Dryer (9/16/08)
GE CONFIDENTIAL & PROPREITARY INFORMATION - NOT FOR PUBLIC DISCLOSURE
Copyright 2008 General Electric Company 16
gGE imagination at work
Cooling Phase Sensor Dry
• The SSD displays time remaining during the Cool Down
Phase
• Heater is turned off
• Default cooling time is 5 minutes.
• When Cooling Time is passed 5 minutes, but outlet
temperature has not reached the default temperature,
the dryer shall display 1min until reaching the default
temperature.
• When outlet temperature has reached the default
temperature, the control will complete the cycle

GE Profile HE Dryer (9/16/08)
GE CONFIDENTIAL & PROPREITARY INFORMATION - NOT FOR PUBLIC DISCLOSURE
Copyright 2008 General Electric Company 17
gGE imagination at work
Cooling Phase Manual Dry
• The SSD displays time remaining during the Cool Down
Phase
• Heater is turned off
• Cooling time is 5 minutes

GE Profile HE Dryer (9/16/08)
GE CONFIDENTIAL & PROPREITARY INFORMATION - NOT FOR PUBLIC DISCLOSURE
Copyright 2008 General Electric Company 18
gGE imagination at work
Control Lock
To lock and unlock control
•Press Dry level and Temp for 3 seconds
•Replacement control may be shipped in locked mode
cl

GE Profile HE Dryer (9/16/08)
GE CONFIDENTIAL & PROPREITARY INFORMATION - NOT FOR PUBLIC DISCLOSURE
Copyright 2008 General Electric Company 19
gGE imagination at work
Control Lock
To lock and unlock control
•Press Dry level and Temp for 3 seconds
•Replacement control may be shipped in locked mode

GE Profile HE Dryer (9/16/08)
GE CONFIDENTIAL & PROPREITARY INFORMATION - NOT FOR PUBLIC DISCLOSURE
Copyright 2008 General Electric Company 20
gGE imagination at work
Clean Filter
The clean filter light will flash when the dryer is powered up. This
is to remind the consumer to clean the lint filter prior to starting the
dryer. The Clean Filter light will go out when the start button is
pressed and the cycle started.
Clean Filter
