GE GTDS825GDMC User manual

GEAppliances.com
Dryers
234D1754P002 49-90462-3 11-12 GE
Safety Instructions........ 2,3
Operating Instructions
Appliance Communication . . . 10,11
Features.........................7
Loading and Using the Dryer......8
Operating Instructions .........4-7
Reversing the Door...........12,13
VentingtheDryer................9
Troubleshooting Tips . . . 14-16
Consumer Support
Consumer Support ..............18
Parts and Accessories ........ 3,18
Warranty .......................17
Write the model and serial
number here:
Model # __________________
Serial # ___________________
You can find them on a label
on the front of the dryer
behind the door.
Owner’s Manual
Printed in Mexico

2
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
This is the safety alert symbol. This symbol alerts you to potential hazards that can kill you or hurt you and others.
All safety messages will follow the safety alert symbol and the word “DANGER”, “WARNING”, or “CAUTION”. These
words are defined as:
Indicates a hazardous situation which, if not avoided, will result in death or serious injury.
Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
DANGER
WARNING
CAUTION
IMPORTANT SAFETY INSTRUCTIONS
To reduce the risk of fire, explosion, electric shock, or injury to persons when using your appliance, follow
basic precautions, including the following:
 Read all instructions before using the appliance.
 DO NOT dry articles that have been previously cleaned in, washed in, soaked in or spotted with gasoline, dry-cleaning
solvents, or other flammable or explosive substances, as they give off vapors that could ignite or explode.
 DO NOT allow children to play on or in this appliance. Close supervision of children is necessary when this appliance is
used near children.
 Before the appliance is removed from service or discarded, remove the door to the drying compartment.
 DO NOT reach into the appliance if the drum is moving.
 DO NOT install or store this appliance where it will be exposed to the weather.
 DO NOT tamper with controls.
 DO NOT repair or replace any part of this appliance or attempt any servicing unless specifically recommended in the user
maintenance instructions or in published user repair instructions that you understand and have the skills to carry out.
 DO NOT use fabric softeners or products to eliminate static unless recommended by the manufacturer of the fabric
softener or product.
 Do NOT dry articles containing rubber, plastic, foam or similar materials such as padded bras, tennis shoes, galoshes, bath
mats, rugs, bibs, baby pants, plastic bags, pillows, etc., that may melt or burn. Some rubber materials, when heated, can under
certain circumstances produce fire by spontaneous combustion.
 Clean lint screen before or after each load.
 DO NOT OPERATE THE DRYER WITHOUT THE LINT FILTER IN PLACE.
 Keep area around the exhaust opening and adjacent surrounding areas free from the accumulation of lint, dust and dirt.
 The interior of the appliance and exhaust duct should be cleaned periodically by qualified service personnel.

DO NOT place items exposed to cooking oils in your dryer. Items contaminated with cooking oils may contribute to a
chemical reaction that could cause a load to catch fire.

Keep all laundry aids (such as detergents, bleaches, etc.) out of the reach of children, preferably in a locked cabinet. Observe all
warnings on container labels to avoid injury.
 Keep the floor around your appliances clean and dry.
 The laundry process can reduce the flame retardancy of fabrics. To avoid such a result, carefully follow the garment
manufacturer’s care instructions.
 Unplug the appliance or turn off the circuit breaker before servicing. Pressing the Power or Start/Pause button DOES NOT
disconnect power.
 DO NOT attempt to operate this appliance if it is damaged, malfunctioning, partially disassembled, or has missing or broken
parts, including a damaged cord or plug.
 DO NOT use aerosols in or near the dryer.
 DO NOT operate this appliance if it is damaged, malfunctioning, partially disassembled, or has missing or broken parts,
including a damaged cord or plug.
 See “Electrical Requirements” located in the Installation Instructions for grounding instructions.
SAVE THESE INSTRUCTIONS
WARNING

GEAppliances.com
ADDITIONAL GAS DRYER WARNINGS
For your safety, the information in this manual must be followed to minimize the risk of fire or explosion
or to prevent damage, personal injury, or death.
- DO NOT store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS:
 '2127WU\WROLJKWDQ\DSSOLDQFH
 '2127WRXFKDQ\HOHFWULFDOVZLWFK'2127XVHDQ\SKRQHLQ\RXUEXLOGLQJ
 &OHDUWKHURRPEXLOGLQJRUDUHDRIDQ\RFFXSDQWV
 ,PPHGLDWHO\FDOO\RXUJDVVXSSOLHUIURPDQHLJKERU·VSKRQH)ROORZWKHJDVVXSSOLHU·VLQVWUXFWLRQV
 ,I\RXFDQQRWUHDFK\RXUJDVVXSSOLHUFDOOWKHILUHGHSDUWPHQW
- ,QVWDOODWLRQDQGVHUYLFHPXVWEHSHUIRUPHGE\DTXDOLILHGLQVWDOOHUVHUYLFHDJHQF\RUWKHJDVVXSSOLHU
WARNING
California Safe Drinking Water and Toxic Enforcement Act
This act requires the governor of California to publish a list of substances known to the state to cause cancer, birth defects or other
reproductive harm and requires businesses to warn customers of potential exposure to such substances.
Gas appliances can cause minor exposure to four of these substances, namely benzene, carbon monoxide, formaldehyde and
soot, caused primarily by the incomplete combustion of natural gas or LP fuels.
Properly adjusted dryers will minimize incomplete combustion. Exposure to these substances can be minimized further by properly
venting the dryer to the outdoors.
PROPER INSTALLATION
This dryer must be properly installed and located in accordance with the Installation Instructions before it is used.
If you did not receive an Installation Instructions, you can receive one by visiting GEAppliances.com or by calling
800.GE.CARES (800.432.2737).
Properly ground dryer to conform with all governing codes
and ordinances. Follow details in Installation Instructions.
Install or store where it will not be exposed to temperatures
below freezing or exposed to the weather.
Connect to a properly rated, protected and sized power
supply circuit to avoid electrical overload.
Remove all sharp packing items and dispose of all shipping
materials properly.
Remove the colored protective tape from the control panel.
Do not obstruct the flow of ventilating air. Do not stack or
place laundry or throw rugs against the front or back of the
dryer.
Steam Water Hoses:
GE strongly recommends the use of factory specified parts.
A list of factory hoses available for purchase are listed
below. These hoses are manufactured and tested to meet
GE specifications.
GE strongly recommends the use of new water supply
hoses. Hoses degrade over time and need to be replaced
every 5 years to reduce the risk of hose failures and water
damage.
Parts and Accessories
Order on-line at GEApplianceparts.com today, 24 hours a
day or by phone at 800.626.2002 during normal business
hours.
Part Number Accessory
WE25M53 Complete Kit (hoses, Y-adapter
washers) (included)
OR
WE1M847 Long Hose and
WE1M849 Short Hose
PM14X10056 Dryer door opening vent brush
(not included)
WX14X10007 LintEater™ Dryer rotary tube brush
(not included)
DR07X10002 6’ Cable
DRM2E300V0 ACM, Splitter, two 6’ Cables & a 1’ Cable
Exhaust/Ducting:
1All dryers MUST be exhausted to the outside to prevent
large amounts of moisture and lint from being blown into
the room.
2Use only rigid metal 4ļdiameter ductwork inside the dryer
cabinet and use only rigid metal 4ļdiameter or UL
approved transition ducting between the dryer and the
home duct. USE OF PLASTIC OR OTHER COMBUSTIBLE
DUCTWORK CAN CAUSE A FIRE. PUNCTURED DUCTWORK
CAN CAUSE A FIRE IF IT COLLAPSES OR BECOMES
OTHERWISE RESTRICTED IN USE OR DURING
INSTALLATION.
For complete details, follow the Installation Instructions.
SAVE THESE INSTRUCTIONS 3

Operating instructions
4
A
B
&OHDQOLQWILOWHU 6HOHFWGU\LQJF\FOH 3XVKStart
Step 1 Step 2 Step 3 Step 4
$GGFORWKHV
6KXWGRRU
To reduce the risk of fire, electric shock, or injury to persons, read the IMPORTANT SAFETY INSTRUCTIONS before
operating this appliance.
WARNING!
WARNING WARNING
Explosion Hazard Fire Hazard
Keep flammable materials and vapors, such as gasoline, away
from dryer.
DO NOT dry anything that has ever had anything flammable on
it (even after washing).
Failure to do so can result in death, explosion, or fire.
No washer can completely remove oil.
Do not dry anything that has ever had any type of oil on it
(including cooking oils).
Items containing foam, rubber, or plastic must be dried on a
clothesline or by using an Air Dry cycle.
Failure to do so can result in death, explosion, or fire.
Throughout this manual, features and appearance may vary from your model.
Controls
&22/
'2:1
A
B C GD
E F
Power
Press to “wake up” the display. If the display is active, press to put the dryer into idle mode.
NOTE: Pressing Power does not disconnect the appliance from the power supply.
Start and Pause
Press Start to begin the cycle. NOTE: The door must be closed for the dryer to start the cycle. Pressing Start again will pause
the cycle, the Start will blink and “PAUSE” will scroll across the LCD.
To continue the cycle, press Start again.

Display and Status Lights
The display shows the approximate time remaining until the end of the cycle.
In addition, this display will, “scroll” the dryer status:
PAUSE The message “PAUSE” will scroll across the display when the dryer’s cycle is paused. The cycle may be
re-started by pressing the Start button.
door The message “door” will be displayed when the door is opened during the dryer’s cycle.
CyCLE The message “CyCLE” will be displayed when the clothes are dry and the washer is recommending a
preferred cycle for the next load (see CleanSpeak section).
dELAY The message “dELAY” will be displayed when Delay Dry is initiated. It will be replaced with the
estimated time when cycle starts.
ES Dryer in a delay start (4 hour maximum) awaiting lower energy rates (see About Appliance
Communication - Energy Smart section).
Cycle status lights
Shows whether the washer is in the DRYING, DAMP, or COOL DOWN cycle.
Feature status lights indicate:
The My Settings feature is on for this cycle.
The dryer is locked - will blink once if you press any button or turn the cycle knob.
The signal is on. See the Variable Signal description.
The Energy Smart feature is selected. See About Appliance Communication - Energy Smart section.
The Clean Lint Filter light will stay on for 15 seconds after the cycle stops.
The eDry feature is selected.
A Delay Dry time is set.
Drying Cycles-Sensor cycles automatically determine fabric dryness.
Timed cycles run for the selected time.
Timed Dry Set the Cycle Selector at the desired drying time.
Quick Fluff/ For freshening or fluffing up already dry clothing, fabric, linens and pillows.
No Heat Provides 10 minutes of no-heat tumbling.
Quick Dry For small loads that are needed in a hurry, such as sport or school uniforms. Can also be used if the
previous cycle left some items damp, such as collars or waistbands. NOTE: On some models, the time
remaining in the cycle will show counting down in the display.
Delicates For delicate items, special-care fabrics and knits.
Jeans For jeans.
Cottons For cottons and most linens.
Normal/Mixed For loads consisting of cottons and poly-blends.
Loads
Casuals / For wrinkle-free, permanent press, delicate items and knits.
Permanent Press
Active Wear For sports and exercise wear.
Towels/Sheets For most towels and linens.
Bulky Items For large coats, bed spreads, mattress covers, sleeping bags and similar large/bulky items such as
blankets, comforters, jackets, and small rugs.
Steam Refresh For slightly wrinkled dry garments. Significantly reduces wrinkles.
NOTE: A single extremely light fabric item may need to have an additional item included in
the Steam Refresh cycle to achieve optimum results.
Steam Dewrinkle For use with larger loads than Steam Refresh. Ideal for loads left in the dryer for an extended time.
Steam Cycle ( & ) Notes:
 Important - The temperature setting must be set to HIGH and water must be turned on before running the steam cycles.
 The Extended Tumble option will be turned on.
 After the steam cycle, the unit will beep (if Variable Signal is on) and display “00”.
 Do not use a steam cycle with items such as wool, leather, silk, lingerie, foam products or electric blankets.
 Do not use steam cycles on new clothes without first washing.
 Steam cycles are not intended for use with towels.
D
5
GEAppliances.com
C
h
h

6
Options
Delay Dry
As the Delay Dry button is repeatedly pressed, the delay time sets to from 1 to 9 hours, and back to clear (0). After selecting the delay
time, press Start and the delay time will count down the time remaining until the cycle starts.
If the Delay Dry button is pressed for 3 seconds, it clears (regardless of the delay time) or terminates a delaying cycle.
Extended Tumble
Use this option to minimize the wrinkles in clothes. It provides 1 hour of no-heat tumbling after the clothes are dry. If you are using
the Variable Signal and you select the Extended Tumble option, a signal will sound at the end of the drying time and every 5 minutes
during the Extended Tumble cycle. This will remind you that it is time to remove the clothes.
eDry
Available for Bulky Items,Towels/Sheets,Cottons,Normal/Mixed LoadsJeans,Casuals/Permanent Press,Active Wear, and
Delicates. When the eDry button is pressed, cycle settings change to reduce the total energy consumption of the selected sensor
cycle. NOTE: Cycle times will change when eDry is selected.
The eMonitor lights display the relative energy use of your selected cycle and options. They are provided as an energy guide and
range from Good (1 light) to Better (5 lights). Cycle (time), dryness level, temperature, and additional tumble options can increase or
decrease your energy efficiency. Some special cycles will not provide a display.
F
Settings
Individual settings for Timed Dry cycle minutes (Time), dryness level (Level), and temperature (Temp) can be set from the minimum
(lowest in column) to maximum (highest in column). In general, the higher up the column, the more energy will be used.
Time - Selection only for Timed cycles.
Each “setting” allows you to specify a lower (1 tap) or an upper (2 taps) time working your way from a
minimum 10 minute to a maximum 99 minute dry time (10, 20, 30, 40, . . . 80, 90, 99, 10 . . .)
Dryness Level - Selection only used for Sensor cycles. Timed cycles run for the selected time.
More Dry Use for heavy-duty or mixed type fabrics.
Dry Use for a normal dryness level suitable for most loads. This is the preferred cycle for energy savings.
Less Dry Use for lighter fabrics.
Damp For leaving items partially damp.
Temperature
High For regular to heavy cottons. NOTE: Steam Dewrinkle and Steam Refresh require the High temperature setting.
Medium For synthetics, blends, delicates and items labeled permanent press.
Low For delicates, synthetics and items labeled tumble dry low.
Extra Low For delicates, synthetics and items labeled tumble dry low.
E
Operating instructions

7
Sensor Dry
Time Dry This feature is activated in Timed Dry &Quick
Fluff cycles. The time (10, 20, 30, 40, . . . 80, 90,
99) is specified via the Time button.
This feature activated in all but the Timed
(Timed Dry & Quick Fluff) and Steam (Steam
Refresh & Steam Dewrinkle) cycles.
The Sensor Dry provides greater drying
accuracy than standard machines, resulting
in shorter dry times and better clothes care.
As the clothes tumble, they touch a moisture
sensor. The sensor will stop the heating cycle
as soon as the clothes have reached the
selected dryness.
This dryer will adjust the initial estimated
drying time of the sensor dry cycles as it
“learns” its installation and usage profile.
Please allow several weeks for the dryer to
customize itself to “you”.
Stainless Steel Drum
Drum Light
The stainless steel used to make the dryer drum
provides the highest reliability available in a GE
dryer. If the dryer drum should be scratched
or dented during normal use, the drum will not
rust or corrode. These surface blemishes will not
affect the function or durability of the drum.
The drum light is an LED light. Replacement must
be done by a qualified technician.
About the dryer features.
More Options
Drum Light
The drum light will go on if the Drum Light button is pushed or the door is opened. It will stay on until the door is shut or the Drum
Light or Power button is pushed.
Variable Signal
Use the Variable Signal button to change the volume of the end of cycle and control signals. Press the button until you reach the
desired volume (low-med-high) or off. The clothes should be removed when the beeper goes off so wrinkles do not set in.
NOTE:
 Remove garments promptly at the sound of signal. Place clothes on hangers so wrinkles will not set in.
 Use the Variable Signal especially when drying fabrics like polyester, knits and permanent press. These fabrics should be removed
so wrinkles will not set in.
Control Lock
You can lock the controls to prevent any selections from being made. Or you can lock the controls after you have started a
cycle. Children cannot accidentally start the dryer by touching buttons with this option selected.
7RORFNWKHGU\HUFRQWUROV press and hold the Drum Light and Variable Signal buttons at the same time for 3 seconds. The control
lock icon will light up when locked. 7RXQORFNWKHGU\HUFRQWUROV press and hold the Drum Light and Variable Signal buttons at
the same time for 3 seconds.
My Settings
As the cycle selector knob is turned, the Time (Timed Dry), Level (Dryness Level), and Temp (Temperature) settings change to
automatic pre-set default settings. If you desire a different setting, press the appropriate button(s). Then press and hold the My
Settings button for 3 seconds. The status heart and button lights will turn on and the dryer will save these settings for that knob
selection. In the future, when you turn the selector knob to that cycle, your settings will be automatically recalled.
To temporarily (for this load) return to the pre-set default settings, depress the My Settings button for 1/2 second. The status heart
and button lights will turn off and the options will change back to these defaults. To make these default settings permanent, hold the
My Settings button again for 3 seconds to make them your preferred settings (the lights will turn back on).
NOTE: Variable Signal volume cannot be set for My Settings.
G
GEAppliances.com

8
Machine
wash
cycle Normal Permanent Press/
wrinkle resistant
Gentle/
delicate Hand wash Do not wash Do not wring
Water
temperature Hot
(50C/120F)
Warm
(40C/105F)
Cold/cool
(30C/85F)
WASH LABELS
Tumble
dry
Dry Normal Permanent Press/
wrinkle resistant
Gentle/
delicate Do not tumble dry
Do not dry
(used with
do not wash)
Heat
setting
High Medium Low No heat/air
Special
instructions Line dry/
hang to dry Drip dry Dry flat In the shade
DRY LABELS
Bleach
symbols Any bleach
(when needed) Only non-chlorine bleach
(when needed)
Do not bleach
BLEACH LABELS
About loading and using the dryer.
Always follow the fabric manufacturer’s care label when laundering.
Sorting and Loading Hints
As a general rule, if clothes are sorted properly for
the washer, they are sorted properly for the dryer.
Do not add fabric softener sheets once the load
has become warm. They may cause fabric softener
stains. Bounce®Fabric Conditioner Dryer Sheets
have been approved for use in all GE Dryers when
used in accordance with the manufacturer’s
instructions.
Do not overload. This wastes energy and causes
wrinkling.
Do not dry the following items: fiberglass items,
woolens, rubber-coated items, plastics, items with
plastic trim and foam-filled items.
Care and Cleaning of the Dryer
The Exterior: Wipe or dust any spills or washing
compounds with a damp cloth. Dryer control panel
and finishes may be damaged by some laundry
pretreatment soil and stain remover products. Apply
these products away from the dryer. The fabric may
then be washed and dried normally. Damage to your
dryer caused by these products is not covered by
your warranty.
The Lint Filter: Clean the lint filter before each use.
Remove by pulling straight up. Run your fingers
across the filter. A waxy buildup may form on the lint
filter from using dryer added fabric softener sheets.
To remove this buildup, wash the lint screen in
warm, soapy water. Dry thoroughly and replace. Do
not operate the dryer without the lint filter in place.
Vacuum the lint from the dryer lint filter area if you
notice a change in dryer performance.
Stainless Steel: To clean stainless steel surfaces,
use a damp cloth with a mild, non-abrasive cleaner
suitable for stainless steel surfaces. Remove the
cleaner residue, and then dry with a clean cloth.
The Exhaust Duct: Inspect and clean the exhaust
ducting at least once a year to prevent clogging. A
partially clogged exhaust can lengthen the drying
time.
To clean the duct, follow these steps:
1Turn off electrical supply by disconnecting the
plug from the wall socket.
2Disconnect the duct from the dryer.
3Vacuum the duct with the hose attachment and
reconnect the duct.
The Exhaust Hood: Check from the outside that the
flaps of the hood move freely when operating. Make
sure that there is not wildlife (birds, insects, etc.)
nesting inside the duct or hood.
Fabric Care Labels
Below are fabric care label “symbols” that affect the clothing you will be laundering.

9
Correct
Venting
Incorrect
Venting
For the best drying performance, the dryer needs to be properly vented. The dryer will use more
energy and run longer if it is not vented to the below specifications. Carefully follow the
details on Exhausting in the Installation Instructions.
Use only rigid metal 4” diameter ductwork inside the dryer cabinet. Use only rigid metal or
UL listed flexible metal 4” diameter ductwork for exhausting to the outside. Minimize flexible
ductwork sections to increase dryer efficiency.
Do not use plastic or other combustible ductwork.
Use the shortest length possible.
Do not crush or collapse.
Avoid resting the duct on sharp objects.
Venting must conform to local building codes.
About venting the dryer. GEAppliances.com

About Appliance Communication.
CleanSpeakTM
This dryer can communicate with a compatible
washer (one whose Owner’s Manual contains a
CleanSpeak description) via a cable between these
appliances. This cable comes with CleanSpeak
dryer models or may be purchased separately.
At the end of the wash cycle, the washer sends a
signal to the dryer to indicated a preferred dry cycle.
When the dryer becomes idle (“End” display times
out - or- the door is opened) “CYCLE” will scroll
across its cycle time display, its current cycle knob
setting LED will be lit, and (if different) a second
recommended cycle LED will blink. If “CYCLE” times
out, pressing Power will refresh it and the LEDs. If
the dryer cycle knob is turned , the solid LED will
move accordingly. Pressing the dryer Start will
initiate the cycle knob setting (solid LED) and turn off
the recommended (blinking LED) if a different cycle
is started.
Dryer
Washer
10
Brillion Enabled Communication
This dryer (and/or compatible washer) can
communicate with your Home Computer and/or
iPhone®. By using the GE Nucleus™Home Energy
Manager and Appliance Communication Module
(ACM) you will be able to see the following:
On your home computer or iPhone®:
:KLFKF\FOHLVUXQQLQJDQGZKDWLWVFXUUHQWF\FOH
segment is (example, “Cool Down”).
7KHHVWLPDWHGWLPHUHPDLQLQJRIWKHF\FOHWKDW
has been selected.
 When a cycle has completed or if it requires
maintenance or servicing.
$OHUWVQRWLI\LQJ\RXLIWKHZDVKHUQHHGV
maintenance or servicing.
What your software allows you to do:
NOTE: Messages are displayed in English. See
www.gebrillion.com or call 1-800-220-6899 for
possible language options.
Cycle display will provide the current status of the
wash cycle:
'U\LQJ'DPS&RRO'RZQRU&RPSOHWH
Alerts will notify you of problems. Some examples:
,QOHW7KHUPRVWDWSUREOHP
2XWOHW7KHUPRVWDWSUREOHP
What you will need for two-way communication:
1XFOHXVKRPHHQHUJ\PDQDJHUPRGHO
$SSOLDQFHFRPPXQLFDWLRQ0RGXOHPRGHO
%URDGEDQGFRQQHFWLRQZLWKURXWHU:L)LIRU
iPhone®connection)
&RPSXWHU0DF®or PC) and/or Internet capable
iPhone®.
NOTE: If you also have a compatible Energy Smart
washer, see Installation Instructions for additional
parts.
Installation
Step 1: Install your Nucleus Home Energy Manger/
Cable - near your internet router.
Refer to the Quick Start Guide/Installation
Instructions included with this device for
information needed to download software to
a desktop and/or iPhone®.
Step 2: Install your Appliance Communication
Module (ACM) in your Laundry area. Determine
the most convenient location for your ACM. Install
the ACM according to the Quick Start/Installation
Instructions included with the device.
Step 3: Connect your ACM to your dryer or dryer-
washer.
The ACM comes with a splitter, two 6’ cables, and a
1’ cable (see Parts and Accessories section). If you
also have an Energy Smart washer, use the splitter
to connect both appliances. NOTE: If this dryer
did not come with a 6 foot cable, you may need
to purchase a second 6 foot cable (see Parts and
Accessories section).
For more information or questions, please visit:
www.gebrillion.com or call 1-800-220-6899.
Dryer
ACM
Dryer
Washer
Spliter
ACM
- OR -

Energy SmartTM
Energy Smart enables your dryer to reduce energy
consumption during periods of high energy costs.
If you live in an area where your power provider
charges different rates at various times of the day,
your dryer will inform you of those times when you
are paying the highest rate. The Energy Smart icon
will illuminate on the dryer control panel, the cycle
time will display “ES”, and the operation will be in
a delay mode. The dryer will delay start (up to 4
hours) until the rate goes down. You can override
this feature by holding the Delay Dry button for 3
seconds to cancel and run it at your convenience
(immediately or delayed 1-9 hours).
What you will need:
6PDUW0HWHUWRFRPPXQLFDWHZLWK\RXUZDVKHU
(call your power provider)
$QEnergy Smart dryer (like this one)
$Q$SSOLDQFH&RPPXQLFDWLRQ0RGXOH$&0
Installation:
Step 1: Power provider installs a Smart Meter
Steps 2 & 3: Install an ACM. See the Brillion Enabled
Communication section.
GEAppliances.com
11

12
About reversing the door.
3Loosen the bottom 2 right side hinge screws. Remove the
door and place it on a protected flat surface to avoid any
damage. Remove both the Blind Plate and the Strike
Plate and install them in opposite positions.
4Remove the 4 door hinge screws, 4 edge screws, and 8
inside screws. Lift the inner door upwards using a flat
blade screwdriver.
Reversing the Door
Tools needed:
Standard #2 Phillips screwdriver
Tape-tipped putty knife
Small flat blade screwdriver
Before you Start
Unplug the dryer from its electrical outlet.
1Open the door approximately 170 degrees. With a putty
knife, remove the 4 plastic covers located along the left
side of the front panel and set them aside.
2Remove the bottom screw from each hinge (right side)
and partially insert them into the top left side hinge
holes.
NOTE: All 4 front panel hinge screws will now be in the top
hinge holes - 2 on the left and 2 on the right.
Plastic Cover (4)
Left side of
front panel
Blind plate
Inner door
Strike plate
Door hinge
screws
Inner door
Outer door
Inside screws
Inside screws
Edge
screws

13
5Remove and swap the 2 cover caps and door handle
from the outer door:
A. Squeeze the tabs on the inside of the door handle
clips. Push clips through the outer door.
B. Squeeze the tabs on the inside of the cover caps. Push
caps through the outer door.
C. Push the door handle clips into the openings on the
opposite side of the outer door making sure you flip
the handle so it curves to the inside.
D. Push the cover caps into the openings on the outer
door where the handle was removed.
6With the cover caps and door handle in place, mount the
inner door back into the outer door with the screws
removed in step 4. Make sure you mount the hinges on
the side opposite the handle.
7Mount the assembled door on the 2 upper left side hinge
screws installed in step 2. Move the hinge screws
loosened in step 3 into the lower left side screw holes
and firmly tighten all 4 screws.
8Install the 4 plastic caps removed in step 1 into the 4
right side front panel holes.
NOTE: To return the door to the original setup, follow these
instructions, swapping “left” and “right”.
When you finish
Plug the dryer back into its electrical outlet.
Door handle
Door handle clip
Cover cap
Inside of door
Door handle
Door
handle
clip
Inside of door
Cover caps
GEAppliances.com
Edge
screws
Door
hinge
screws
Inside screws
Inside screws
Handle
Door
Hang door and
tighten screws

Troubleshooting Tips
Save time and money! Review the charts on the following pages,
or visit GEAppliances.com. You may not need to call for service.
Before you call for service…
Problem Possible Causes What To Do
Dryer doesn’t start Dryer is unplugged  0DNHVXUHWKHGU\HUSOXJLVSXVKHGFRPSOHWHO\LQWRWKHRXWOHW
House Fuse is blown/circuit   &KHFNWKHKRXVHIXVHFLUFXLWEUHDNHUER[DQGUHSODFHIXVHRU
breaker is tripped r eset breaker. NOTE: Most electric dryers use two fuses/breakers.
Dryer fuse blown   7KHVLQJOH*DVRURQHRIWKHWZR(OHFWULFIXVHVLQWKHUHDURI
the backsplash blew because the house circuit protection didn’t
work. Have a qualified technician check for power at outlet.
Dryer doesn’t heat House Fuse is blown/circuit   &KHFNWKHKRXVHIXVHFLUFXLWEUHDNHUER[DQGUHSODFH
EUHDNHULVWULSSHGWKHGU\HU both fuses or reset both breakers. Your dryer may tumble
may tumble but not heat if only one fuse is blown or one breaker is tripped.
Gas service is off  0DNHVXUHJDVVKXWRIIDWGU\HUDQGPDLQVKXWRIIDUHIXOO\RSHQ
Dryer shakes or Some shaking/noise is normal.   0RYHGU\HUWRDQHYHQIORRUVSDFHRUDGMXVWOHYHOLQJOHJV
makes noise Dryer may be sitting unevenly as necessary until even.
Greasy spots on clothes Improper use of fabric softener  )ROORZGLUHFWLRQVRQIDEULFVRIWHQHUSDFNDJH
Drying dirty items   8VH\RXUGU\HUWRGU\RQO\FOHDQLWHPV'LUW\LWHPVFDQ
with clean ones stain clean items and the dryer.
Clothes were not   6RPHWLPHVVWDLQVZKLFKFDQQRWEHVHHQZKHQWKHFORWKHV
completely clean are wet appear after drying. Use proper washing procedures
before drying.
Lint on clothes Lint filter is full  &OHDQOLQWVFUHHQEHIRUHHDFKORDG
Improper sorting  6RUWOLQWSURGXFHUVOLNHFKHQLOOHIURPOLQWFROOHFWRUV
(like corduroy).
Static electricity can attract lint  6HHVXJJHVWLRQVLQWKLVVHFWLRQXQGHUStatic occurs.
Overloading  6HSDUDWHODUJHORDGVLQWRVPDOOHURQHV
3DSHUWLVVXHHWFOHIWLQSRFNHWV  (PSW\DOOSRFNHWVEHIRUHODXQGHULQJFORWKHV
Static occurs No fabric softener was used  7U\DIDEULFVRIWHQHU
   %RXQFH®Fabric Conditioner Dryer Sheets have been
approved for use in all GE Dryers when used in accordance
with the manufacturer’s instructions.
Over-drying  7U\DIDEULFVRIWHQHU
   $GMXVWVHWWLQJWRLess Dry or Damp.
6\QWKHWLFVSHUPDQHQWSUHVV  7U\DIDEULFVRIWHQHU
and blends can cause static
Inconsistent Type of heat  $XWRPDWLFGU\LQJWLPHVZLOOYDU\DFFRUGLQJWRWKHW\SHRIKHDW
drying times used (electric, natural or LP gas), size of load, types of fabrics,
wetness of clothes and condition of exhaust ducts.
The Dry dryness level Load consists of a mixture  :KHQFRPELQLQJKHDY\DQGOLJKWIDEULFVLQDORDG
was chosen but load is of heavy and light fabrics choose More Dry or Extra Dry if you are using a sensor cycle.
still damp
Exhaust system is blocked  ,QVSHFWDQGFOHDQH[KDXVWV\VWHP
14

15
Problem Possible Causes What To Do
Clothes take too long Improper sorting 6HSDUDWHKHDY\LWHPVIURPOLJKWZHLJKWLWHPVJHQHUDOO\
to dry a well-sorted washer load is a well-sorted dryer load).
Large loads of heavy fabrics  /DUJHKHDY\IDEULFVFRQWDLQPRUHPRLVWXUHDQGWDNH
(like beach towels) longer to dry. Separate large, heavy fabrics into smaller
loads to speed drying time.
Controls improperly set 0DWFKFRQWUROVHWWLQJVWRWKHORDG\RXDUHGU\LQJ
Lint filter is full &OHDQOLQWILOWHUEHIRUHHYHU\ORDG
Improper or obstructed  &KHFNLQVWDOODWLRQLQVWUXFWLRQVIRUSURSHUGXFWLQJYHQWLQJ
ducting 0DNHVXUHGXFWLQJLVFOHDQIUHHRINLQNVDQGXQREVWUXFWHG
  &KHFNWRVHHLIRXWVLGHZDOOGDPSHURSHUDWHVHDVLO\
  &KHFNWKH,QVWDOODWLRQ,QVWUXFWLRQVWRPDNHVXUHWKH
dryer venting is correct.
Blown fuses or tripped  5HSODFHIXVHVRUUHVHWFLUFXLWEUHDNHUV(OHFWULFGU\HUV
circuit breaker use 2 fuses/breakers, make sure both are operating.
Overloading/combining loads 'RQRWSXWPRUHWKDQRQHZDVKHUORDGLQWKHGU\HUDW
a time.
Under-loading ,I\RXDUHGU\LQJRQO\RQHRUWZRLWHPVDGGDIHZLWHPV
to ensure proper tumbling.
Clothes are wrinkled Over-drying 6HOHFWDVKRUWHUGU\LQJWLPH
  5HPRYHLWHPVZKLOHWKH\VWLOOKROGDVOLJKWDPRXQWRI
moisture. Select a Less Dry or Damp Dry setting.
Letting items sit in dryer  5HPRYHLWHPVZKHQF\FOHHQGVDQGIROGRUKDQJ
after cycle ends immediately.
Overloading 6HSDUDWHODUJHORDGVLQWRVPDOOHURQHV
Clothes shrink Some fabrics will naturally shrink 7RDYRLGVKULQNDJHIROORZJDUPHQWFDUHODEHOVH[DFWO\
when washed. Others can be
VDIHO\ZDVKHGEXWZLOOVKULQN 6RPHLWHPVPD\EHSUHVVHGEDFNLQWRVKDSHDIWHUGU\LQJ
in the dryer ,I\RXDUHFRQFHUQHGDERXWVKULQNDJHLQDSDUWLFXODU
item, do not machine wash or tumble dry it
Collars and waistbands The dryness monitor senses &KRRVHSpeed Dry or Timed Dry to dry damp collars
still wet at end of cycle that the body of the clothes and waistbands. In the future, when drying a load with
is dry collars and waistbands, choose More Dry.
Slight variation This is normal 'XHWRWKHPHWDOOLFSURSHUWLHVRISDLQWXVHGIRUWKLVXQLTXH
in metallic color product, slight variations of color may occur due to viewing
angles and lighting conditions.
GEAppliances.com

Before you call for service…
16
Problem Possible Causes What To Do
Small amount of water Inadequate load size for steam  ,IXVLQJWKHSteam Dewrinkle cycle, manually reduce
on floor in front of dryer F\FOHVHOHFWHGH[FHVVVWHDP time. If using the Steam Refresh cycle, add more
condenses inside cabinet and garments to the load.
leaks out
Water on floor in back Loose water hose connection to  7LJKWHQFRQQHFWLRQ 
of dryer valve
Hose missing rubber washer at   ,QVWDOOUXEEHUZDVKHUSURYLGHGZLWKKRVH  
connection with valve
Water drips from door Steam condenses on inner door  7KLVLVQRUPDO 
when opened after
a Steam Cycle
Cannot see steam at Steam released at different   7KLVLVQRUPDO 
beginning of cycle time in cycle
Cannot see steam at any The steam nozzle might be   &DOO800.GE.CARES to order nozzle replacement kit WE25M71
time during the cycle clogged with debris from your or to request a service technician to replace this for you.
water supply
Garments still wrinkled Too many garments  /RDGIHZHUJDUPHQWVPDQXDOO\LQFUHDVHWLPH  
after steam cycle
Garments are wet after Lint filter not clean  &OHDQOLQWILOWHU 
Steam cycle
Load is children/infant garments  8VHWKHSteam Refresh cycle.
No numbers displayed Dryer is continuously  7KLVLVQRUPDO:KHQWKHGU\HUVHQVHVDORZOHYHORI
during cycle, only lights monitoring the amount of moisture in the load, the dryer will display the dry time
moisture in the clothes remaining.
Time Remaining The estimated time may change  7KLVLVQRUPDO
jumped to a when a smaller load than usual
lower number is drying
Dryer is running but The Extended Tumble option/  7KLVLVQRUPDO'XULQJExtended Tumble option/Steam Refresh
00 is displayed in Steam Refresh cycle was chosen cycle, the time remaining is not displayed. The extended
Time Remaining tumble option lasts approximately 60 minutes.
Clothes are still wet The door was opened mid-cycle.   $GU\F\FOHPXVWEHUHVHOHFWHGHDFKWLPHDQHZORDG
and dryer shuts off The load was then removed from is put in.
after a short time the dryer and a new load put in
without selecting a new cycle
Small load  :KHQGU\LQJLWHPVRUOHVVFKRRVHSpeed Dry or Timed Dry.
Load was already dry except   &KRRVHSpeed Dry or Timed Dry to dry damp collars
for collars and waistbands and waistbands. In the future, when drying a load with
collars and waistbands, choose More Dry.
Dryer is not level  0RYHGU\HUWRDQHYHQIORRUVSDFHRUDGMXVWOHYHOLQJOHJV
as necessary until even.
Dryer turns off Very small load (such as one item)  8VHWKHTimed Dry cycle option, select the desired dry time.
is not activating the dry sensor

GE Dryer Warranty. GEAppliances.com
17
What GE Will Not Cover:
Service trips to your home to teach you how to use
the product.
 ,PSURSHULQVWDOODWLRQGHOLYHU\RUPDLQWHQDQFH
 )DLOXUHRIWKHSURGXFWLILWLVDEXVHGPLVXVHGRUXVHGIRU
other than the intended purpose or used commercially.
Replacement of house fuses or resetting of circuit
breakers.
'DPDJHWRWKHSURGXFWFDXVHGE\DFFLGHQWILUHIORRGVRU
acts of God.
Incidental or consequential damage caused by possible
defects with this appliance.
Damage caused after delivery.
Product not accessible to provide required service.
Defects or damage due to operation in freezing
temperatures.
3URGXFWVZKLFKDUHQRWGHIHFWLYHRUEURNHQRUZKLFKDUH
ZRUNLQJDVGHVFULEHGLQWKH2ZQHU·V0DQXDO
This warranty is extended to the original purchaser and any succeeding owner for products purchased for home use within the USA. If
the product is located in an area where service by a GE Authorized Servicer is not available, you may be responsible for a trip charge or
you may be required to bring the product to an Authorized GE Service location for service. In Alaska, the warranty excludes the cost of
shipping or service calls to your home.
Some states do not allow the exclusion or limitation of incidental or consequential damages. This warranty gives you specific legal
rights, and you may also have other rights which vary from state to state. To know what your legal rights are, consult your local or
state consumer affairs office or your state’s Attorney General.
Warrantor: General Electric Company. Louisville, KY 40225
All warranty support provided by our Factory Service Centers,
or an authorized Customer Care®technician. To schedule service,
on-line, 24 hours a day, visit us at GEAppliances.com or call 800.
GE.CARES (800.432.2737). Please have serial number and model
number available when calling for service.
Staple your receipt here.
Proof of the original purchase
date is needed to obtain
support under the warranty.
(;&/86,212),03/,(':$55$17,(6³<RXUVROHDQGH[FOXVLYHUHPHG\LVSURGXFWUHSDLUDVSURYLGHGLQWKLV/LPLWHG
Warranty. Any implied warranties, including the implied warranties of merchantability or fitness for a particular purpose,
are limited to one year or the shortest period allowed by law.
For The Period Of: GE Will Replace:
One Year Any part of the dryer which fails due to a defect in materials or workmanship. During this
From the date of the limited one-year warranty, GE will also provide, free of charge, all labor and related service costs
original purchase to replace the defective part.
Second Year Any part of the dryer which fails due to a defect in materials or workmanship. During this
From the date of the additional one-year limited warranty, you will be responsible for any labor or related service costs.
original purchase
Second through The extra large or super capacity dryer drum and main electronic control board, if any of these
Fifth Year parts should fail due to a defect in materials or workmanship. During this additional four-year
From the date of the limited warranty, you will be responsible for any labor or related service costs.
original purchase

18
Consumer Support.
GE Appliances Website GEAppliances.com
Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a day,
any day of the year! For greater convenience and faster service, you can now download Owner’s Manuals,
order parts or even schedule service on-line.
Schedule Service GEAppliances.com
Expert GE repair service is only one step away from your door. Get on-line and schedule your service at your
convenience 24 hours any day of the year! Or call 800.GE.CARES (800.432.2737) during normal business
hours.
Real Life Design Studio GEAppliances.com
*(VXSSRUWVWKH8QLYHUVDO'HVLJQFRQFHSW³SURGXFWVVHUYLFHVDQGHQYLURQPHQWVWKDWFDQEHXVHGE\
people of all ages, sizes and capabilities. We recognize the need to design for a wide range of physical and
mental abilities and impairments. For details of GE’s Universal Design applications, including kitchen design
ideas for people with disabilities, check out our Website today. For the hearing impaired, please call 800.TDD.
GEAC (800.833.4322).
Extended Warranties GEAppliances.com
Purchase a GE extended warranty and learn about special discounts that are available while your warranty
is still in effect. You can purchase it on-line anytime, or call 800.626.2224 during normal business hours.
GE Consumer Home Services will still be there after your warranty expires.
Parts and Accessories GEApplianceparts.com
Individuals qualified to service their own appliances can have parts or accessories sent directly to their homes
(VISA, MasterCard and Discover cards are accepted). Order on-line today, 24 hours every day or by phone
at 800.626.2002 during normal business hours.
Instructions contained in this manual cover procedures to be performed by any user. Other servicing
generally should be referred to qualified service personnel. Caution must be exercised, since improper
servicing may cause unsafe operation.
Contact Us GEAppliances.com
If you are not satisfied with the service you receive from GE, contact us on our Website with all the details
including your phone number, or write to: General Manager, Customer Relations
GE Appliances, Appliance Park
Louisville, KY 40225
Register Your Appliance GEAppliances.com
5HJLVWHU\RXUQHZDSSOLDQFHRQOLQH³DW\RXUFRQYHQLHQFH Timely product registration will allow for
enhanced communication and prompt service under the terms of your warranty, should the need arise.
You may also mail in the pre-printed registration card included in the packing material.

Manual del
propietario
Secadoras
Instrucciones
de seguridad............... 2,3
Instrucciones de operación
Comunicación del
Electrodoméstico ........... 10,11
Cómo cambiar el sentido
deaperturadelapuerta .....12,13
Cómo cargar y usar la secadora . . 8
Funciones de la secadora ........7
Instrucciones de uso ...........4-7
Ventilación de la secadora........9
Consejos para la solución
de problemas ............ 14-16
Soporte al consumidor
Garantía ...................... 17
Piezas y accesorios............ 3,18
Soportealconsumidor..........18
Escriba el número de modelo
y de serie aquí:
No. de modelo _____________
No. de serie _______________
Estos números se encuentran
en una etiqueta en la parte
delantera de la secadora,
detrás de la puerta.
Impreso en Mexico 234D1754P002 49-90462-3 11-12 GE
GEAppliances.com

INFORMACIÓN DE SEGURIDAD IMPORTANTE.
LEA TODAS LAS INSTRUCCIONES ANTES DE USAR.
2
Éste es el símbolo de alerta de seguridad. El mismo alerta sobre potenciales riesgos que le pueden producir la muerte o
lesiones tanto a usted como a otras personas. Todos los mensajes de seguridad estarán a continuación del símbolo de
alerta de seguridad y con la palabra “PELIGRO”, “ADVERTENCIA” o “PRECAUCIÓN”. Estas palabras se definen como:
Indica una situación de riesgo que, si no se evita, producirá la muerte o lesiones graves.
Indica una situación de riesgo que, si no se evita, podría producir la muerte o lesiones graves.
Indica una situación de riesgo que, si no se evita, podría resultar en lesiones menores o moderadas.
PELIGRO
ADVERTENCIA
PRECAUCIÓN
INSTRUCCIONES IMPORTANTES DE SEGURIDAD
Para reducir el riesgo de incendio, explosión, descargas eléctricas o lesiones sobre las personas al usar su
electrodoméstico, siga las precauciones básicas, incluyendo lo siguiente:
 Lea todas las instrucciones antes de usar este electrodoméstico.
 NO seque prendas que en forma previa hayan sido secadas, lavadas, penetradas o manchadas con gasolina, solventes de
limpieza en seco, u otras sustancias inflamables o explosivas, ya que despiden vapores que se podrían encender o explotar .
 NO permita que los niños jueguen sobre o dentro de este electrodoméstico. Cuando el electrodoméstico se use cerca de
niños, será necesario supervisarlos de cerca .
 Antes de que este electrodoméstico quede fuera de uso o se descarte, retire la puerta del compartimiento de secado .
 NO introduzca las manos en la secadora cuando el tambor se encuentre en movimiento .
 NO instale ni guarde este electrodoméstico donde quede expuesto a los factores climáticos .
 NO manipule indebidamente los controles .
 No intente reparar ni reemplazar cualquier parte del electrodoméstico o realizar cualquier otro trabajo técnico, a menos
que esto sea específicamente recomendado en las instrucciones de mantenimiento del usuario o en instrucciones
publicadas sobre reparaciones del usuario, que entienda y para las cuales posea las destrezas necesarias.
 NO utilice suavizantes de tela ni productos para eliminar la estática, a menos que esto sea recomendado por el fabricante del
suavizante de tela u otro producto .
 NO seque artículos que contengan goma, plástico, espuma o materiales similares tales como sostenes (brasieres) con relleno,
zapatos deportivos, ganchos de goma, alfombras de baño, baberos de niño, pantalones de niño, bolsas plásticas y almohadas
que se puedan derretir o quemar. Algunos materiales gomosos, cuando se calientan, bajo ciertas circunstancias podrían
incendiarse por combustión espontánea.
 Limpie la rejilla para pelusas antes o después de cada carga .
 NO UTILICE LA SECADORA SI EL FILTRO DE PELUSAS NO SE ENCUENTRA COLOCADO .
 Evite la acumulación de pelusa, polvo o tierra alrededor del área de la apertura de ventilación y áreas adyacentes.
 La parte interior del electrodoméstico y el conducto de ventilación se deberán limpiar periódicamente por personal calificado
del servicio técnico
.
 NO coloque prendas expuestas a aceites de cocción en su secadora. Las prendas contaminadas con aceites de cocción
podrán contribuir a una reacción química que podría hacer que una carga de ropa se prenda fuego .

Coloque todos los materiales de lavandería (tales como detergentes, blanqueadores, etc.) fuera del alcance de los niños,
preferentemente en un gabinete cerrado. Siga todas las advertencias de las etiquetas de los envases a fin de evitar lesiones .
 Mantenga el piso alrededor de sus electrodomésticos limpio y seco .
 El proceso de lavandería puede reducir los retardantes de las llamas sobre las telas. A fin de evitar dicho resultado, siga
cuidadosamente las instrucciones del fabricante sobre el cuidado de las prendas .

Desenchufe el electrodoméstico o apague el disyuntor antes de realizar el servicio técnico. Presionar el botón Power
(Encendido) o Start/Pause (Inicio/Pausa) NO desconecta el encendido .
 NO intente usar este electrodoméstico si se encuentra dañado, funcionando mal, parcialmente desensamblado, o si tiene
partes faltantes o rotas, incluyendo un cable o enchufe dañado .

NO utilice aerosoles en o cerca de la secadora .

NO utilice este electrodoméstico si se encuentra dañado, funcionando mal, parcialmente desensamblado, o si tiene partes
faltantes o rotas, incluyendo un cable o enchufe dañado .
 Para acceder a las instrucciones de conexión a tierra, lea los “Requisitos Eléctricos” ubicados en las Instrucciones de Instalación .
GUARDE ESTAS INSTRUCCIONES
ADVERTENCIA
