GE Profile DPVH890GJ Manual

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Specification Revised 5/09 270199
Dimensions and Installation Information (in inches)
Exhaust Options: 3-way via rear, right, and bottom.
Circuit Requirements: An individual, properly grounded
branch circuit, protected by a 30-amp circuit breaker or
a time-delay fuse, is required.
LP Conversion Kit: WE25M46
Note: Dryer wall outlet must be located within 36”
of service cord entry and accessible when dryer is
mounted in position.
Installation Information: For complete information, see
installation instructions packed with your dryer.
S D
T D A F
W U
P
SENSORDRY
TIMEDRY
S
D
L
D
T
D
Harmony
27”
32.34”
39-3/4”
32.34
39-3/4”
4-1/8”
3”
DPVH880
Gas Dryer Rating
120V 60Hz, 6A
DPVH890GJ
GE Profile™7.5 Cu. Ft. Colossal Capacity Gas Dryer With Steam

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Special Installation Requirements:
Stacked Installation:
•Bracketsforstackingdryeroverwasherareavailableatanadditionalcost.
Custom built-in white installation template:
•OrderPub.No.14-A025.
Alcove or Closet Installation:
•Ifyourdryerisapprovedforinstallationinanalcoveorcloset,itwillbe
stated on a label on the dryer back.
•ThedryerMUSTbeexhaustedtotheoutside.
•Minimumclearancesbetweendryercabinetandadjacentwallsorother
surfaces are: 0" either side, 3" front and rear
•Minimumverticalspacefromfloortooverheadcabinets,ceilings,etc.is52".
•Closetdoorsmustbelouveredorotherwiseventilatedandmustcontaina
minimumof60sq.in.ofopenareaequallydistributed.Ifthisclosetcontains
both a washer and a dryer, doors must contain a minimum of 120 sq. in. of
open area equally distributed.
•Nootherfuel-burningapplianceshallbeinstalledinthesameclosetwithagasdryer.
Bathroom or Bedroom Installation:
•ThedryerMUSTbeexhaustedtotheoutdoors.
•Theinstallationmustconformwiththelocalcodes,orintheabsenceof
localcodes,withtheNationalElectricCodeandNationalFuelGasCode,ANSIZ223
for gas dryers.
Minimum Clearance other than Alcove or Closet Installations:
•Minimumclearancestocombustiblesurfaces0"bothsides,3"rear.
For more information on venting kits and accessories,
please call 1-800-GE-CARES.
Stacked Dimensions (in inches)
79"
Harmony
27
1 5
29-1/2
Storage Pedestal Dimensions
(in inches)
SPSD157JMG - Champagne
SPSD157JMV - Vermillion Red
SPSD157JWW - White
Thisoptional15"pedestalraises
the door opening and height of
the washer or dryer. Feet on 15"
pedestalallowittoadjustto15-
3/8" height.
Specification Revised 5/09 270199
DPVH890GJ
GE Profile™7.5 Cu. Ft. Colossal Capacity Gas Dryer With Steam

Dryer Exhausting Information – Metal Duct Only
For complete information, see installation instructions packed with your dryer.
Ducting Materials: For best performance, this dryer should be vented with 4” diameter
allrigidmetalexhaustduct.Ifrigidmetalductcannotbeused,thenUL-listedflexible
metal(semi-rigid)ductingcanbeused(KitWX08X10077).Inspecialinstallations,itmay
benecessarytoconnectthedryertothehouseventusingaflexiblemetal(foil-type)duct.
AUL-listedflexiblemetal(foil-type)ductmaybeusedONLYininstallationswhererigid
metalorflexiblemetal(semi-rigid)ductingcannotbeusedANDwherea4”diametercan
be maintained throughout the entire length of the transition duct. Please see installation
instructionpackedwithyourdryerforcompleteinstructionswhenusingflexiblemetal
(foil type) ducting.
Exhaust Length Calculation:
1. Determinethenumberof90°turnsneededforyourinstallation.Ifyouexhausttothe
side or bottom of dryer, add one turn.
2. Themaximumlengthof4’rigid(aluminumorgalvanized)ductwhichcanbetoleratedis
shown in the table.
 Aturnof45°orlessmaybeignored.Two45°turnswithintheductlengthshouldbe
treated as a 90° elbow.
A turn over 45° should be treated as a 90° elbow.
Dryers mustbeexhaustedtotheoutside.
Caution: Forpersonalsafetydonotterminateexhaustintoachimney,underanyenclosed
house floor (crawl space), or into an attic, since the accumulated lint could create a fire
hazardormoisturecouldcausedamage.Neverterminatetheexhaustintoacommonduct
orplenumwithakitchenexhaust,sincethecombinationoflintandgreasecouldcreatea
fire hazard.
Exhaustductsshouldbeterminatedinadamperedwallcaptopreventbackdrafts,bird
nesting,etc.Thewallcapmustalsobelocatedatleast12"abovethegroundoranyother
obstruction with the opening pointed down.
For more information on venting kits and accessories, please call 1-800-GE-CARES.
Specification Revised 5/09 270199
DPVH890GJ
GE Profile™7.5 Cu. Ft. Colossal Capacity Gas Dryer With Steam
Best performance
Domestic
dryer models
Maximum length of 4"
dia. rigid metal duct
Number
of
90°
turns
Exhaust hood type
A
4"
opening
B
2-1/2"
opening
7.5 and 7.3 cu. ft.
capacity electric
and gas dryers
0
1
2
3
4
150 ft.
140 ft.
130 ft.
120 ft.
110 ft.
127 ft.
117 ft.
107 ft.
97 ft.
87 ft.
A
4
B
2-1/2
A

M
IXED
L
OADS
W
RINKLE
F
REE
A
CTIVE
W
EAR
S
PEED
D
RY
T
IMED
D
RY
A
IR
F
LUFF
W
ARM
U
P
D
ELICATES
P
OWER
SENSOR DRY
TIME DRY
C
OTTONS
S
ENSOR
D
RY
L
EVEL
D
RY
T
EMP
BACK
MY
CYCLE DAMP
ALERT EXTEND
TUMBLE DRUM
LIGHT
LOCK
D
EWRINKLE
Harmony
DPVH580EH/GH
Features and Benefits
• 7.5Cu.Ft.ColossalCapacity-Thiscolossalsizedryerwillbereadyandable
to take on everything the washer sends its way
• SteamRefresh-Helpsreducewrinkles,odorsandrejuvenatesclothes
• SteamDewrinkle-Removewrinklesandrefreshescleanclothes
• ReverseTumble-Byreversingtherotationofthedrum,youcanexpectgentle,
fast even drying
• DuoDry™System - Quickly and consistently dries all types of clothes
• SpecialtyDryCycles-Providejusttherightlevelsofdryingforbetter
fabric care
• BaffleDry-Built-indryingrackandhanger-clipdesignmultipliesthedrying
options for hard-to-dry items or delicates
• CleanSpeak™CommunicationSystem-Thewashercommunicates
electronically with the dryer, which then presets dry cycles for better clothes
care, increased time savings and greater convenience
• StainlessSteelDrum-Resistsrustandwon'tchip,peelorsnagclothes
• DelayStart-Letsyoudothelaundryonyourterms
• OptionalStackingBracket(GEFLSTACK)-Availableatanadditionalcost
• ModelDPVH890GJMG–Champagne
• ModelDPVH890GJMV–VermillionRed
• ModelDPVH890GJWW–White
Specification Revised 5/09 270199
DPVH890GJ
GE Profile™7.5 Cu. Ft. Colossal Capacity Gas Dryer With Steam
