GE Spacemaker JVM1950DR Manual

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
geappliances.com or call GE Answer Center®
service, 800.626.2000.
340157
Specification Revised 10/11
Listed by
Underwriters
Laboratories
JVM1950DR
GE Spacemaker® Over-the-Range Microwave Oven
Note: Requires 120V grounded outlet. Electrical receptacle
must be located in cabinet above Spacemaker microwave oven.
No additional wiring, venting or cabinet rebuilding necessary
in many cases. Complete detailed, easy-to-follow installation
instructions and convenient full-size templates are packed with
the Spacemaker microwave oven.
Important Information: When installing the Spacemaker
microwave oven over a range, allow minimum of 2" from bottom
of Spacemaker microwave oven to top of range backguard to
allow for removal of light covers.
Ventilation Options: The Spacemaker microwave ovens
are designed for adaptation to the following three types of
ventilation:
• Outside exhaust (vertical – as shown)
• Outside exhaust (horizontal)
• Recirculating (non-vented ductless – see Filter Kit drawing)
Installation Information: This information is not intended to
be used for installing unit described. Before installing, consult
installation instructions packed with product/kit for current
dimensional data.
Dimensions and Installation Information (in inches)

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
geappliances.com or call GE Answer Center®
service, 800.626.2000.
340157
Specification Revised 10/11
Listed by
Underwriters
Laboratories
JVM1950DR
GE Spacemaker® Over-the-Range Microwave Oven
Hood Exhaust Duct: Outside ventilation requires a HOOD EXHAUST DUCT. Read the
following carefully.
Exhaust Connection: The hood exhaust has been designed to mate with a standard
3-1/4" x 10" rectangular duct. If a round duct is required, a rectangular-to-round transition
adaptor must be used. Do not use less than a 6" diameter duct
Rear Exhaust: If a rear or horizontal exhaust is to be used, care should be taken to
align exhaust with space between studs, or wall should be prepared at the time it is
constructed by leaving enough space between the wall studs to accommodate exhaust.
Maximum Duct Length: For satisfactory air movement, the total duct length of
3-1/4" x 10" rectangular or 6" diameter round duct should not exceed 120 equivalent feet.
Elbows, Transitions, Wall and Roof Caps, etc., present additional resistance to airflow
and are equivalent to a section of straight duct which is longer than their actual physical
size. When calculating the total duct length, add the equivalent length of all transitions
and adaptors plus the lengths of all straight duct sections. The chart below shows the
approximate feet of equivalent length of some typical ducts.
Duct Equivalent Feet
A. Rectangular-To-round
Transition Adaptor 5 ft.
B. Wall Cap 40 ft.
C. 90° Elbow 10 ft.
D. 45° Elbow 5 ft.
E. 90° Elbow 25 ft.
F. 45° Elbow 5 ft.
G. Roof Cap 24 ft.
Optional Accessories (Available at additional cost)
12" Filler Panel Kit
JX52
When replacing a 36" range hood,
this kit fills in the additional width to
provide a custom built-in
appearance. For installation
between cabinets only; not
for end-of-cabinet installation.
Each kit contains two 3"-wide
filler panels.
Filter KitsJX81H–
Recirculating Charcoal
Filter Kit To be used
when the Spacemaker
microwave oven
cannot be vented to
the outside.
Dimensions and Installation Information (in inches)

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
geappliances.com or call GE Answer Center®
service, 800.626.2000.
340157
Specification Revised 10/11
Listed by
Underwriters
Laboratories
JVM1950DR
GE Spacemaker® Over-the-Range Microwave Oven
Features and Benefits
• 1.9 cu. ft. capacity - 1000 Watts (IEC-705 test procedure)
• Circuwave™1000 cooking system - Cooking system provides more power
for fast, more even cooking results
• Sensor cooking controls - Automatically adjusts time and power for
delicious cooking results
• Easy clean interior - Makes it easy to wipe up spills, splatters and
dried-on foods
• Power Saver mode - Reduces standby power while the unit is not in use
• USDA MyPlate.gov menu - Pre-programmed foods and recipes assist in
preparation of healthy meal choices
• Steam cook button - Perfectly prepare your steamed favorites for
maximum nutrition retention
• Two-piece design with hidden vent - Creates a streamlined look for a
smooth finish
• Four-speed, 400-CFM venting system - Quickly removes smoke, steam
and odors from the cooktop for fresh, cleaner kitchen air
• Recessed turntable with on/off - Offers the flexibility to use different sizes
of dishes. An on/off button controls turntable operation
• Model JVM1950DRBB – Black
• Model JVM1950DRCC – Bisque
• Model JVM1950DRWW - White
