For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
geappliances.com or call GE Answer Center®
service, 800.626.2000.
Dimension Information (in inches)
Important: Please read carefully. For personal safety,
this appliance must be properly grounded to avoid
severe or fatal shock.
Do not, under any circumstances, cut, deform, or
remove any of the prongs from the power cord.
Do not use with an extension cord.
Installation Information: This information is not
intended to be used for installing unit described.
Before installing, consult installation instructions
packed with product/kit for current dimensional data.
Listed by
Underwriters
Laboratories
Above-the-cooktop Advantium oven
Dimensions (in inches)
66" MIN.
Mounting
height
from floor
30" MIN.
width required
Exhaust outlet
connects to
3-1/4" X 10" duct
16-3/8 max
(Rear)
16 max
25-1/2
16 max
30 max
Minimum distance from
door hinge side to adjacent
wall should equal 1/2-inch.
13"
MAX.
12"
MIN.
(without
obstruction)
100˚
Door open
Cabinet Front
SIDE VIEW A-A
Cabinet Bottom Shelf
Filler Block
Self-Aligning Screw
Oven Top
Equivalent
to Depth of
Cabinet Recess
This distance can
NOT exceed 2” to
ensure proper
installation with
the provided
screws.
240V and 120V outlets
need to be spaced on
the side if the desire is
to setup with top
exhaust.
A
A
Note: Outside venting is optional. Vent (duct) can be horizontal or vertical.
Specification Created 5/10 240451
CSA1201RSS
GE Café Advantium®120 Above-the-Cooktop Oven

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
geappliances.com or call GE Answer Center®
service, 800.626.2000.
Dimension Information (in inches)
Hood Exhaust Duct
Outside ventilation requires a HOOD EXHAUST DUCT. Read the following carefully.
EXHAUST CONNECTION:
The hood exhaust has been designed to mate with a standard 3-1/4” x 10”
rectangular duct.
If a round duct is required, a rectangular-to-round transition adaptor must be used.
Do not use less than a 6” diameter duct.
REAR EXHAUST:
If a rear or horizontal exhaust is to be used, care should be taken to align exhaust
with the space between studs, or wall should be prepared at the time it is constructed
by leaving enough space between the wall studs to accommodate exhaust.
MAXIMUM DUCT LENGTH:
For satisfactory air movement, the total duct length of
3-1/4” x 10” rectangular or 6” diameter round duct should
not exceed 140 equivalent feet.
ELBOWS, TRANSITIONS, WALL AND ROOF CAPS, etc.,
present additional resistance to airflow and are equivalent
to a section of straight duct which is longer than their
actual physical size. When calculating the total duct length,
add the equivalent length of all transitions and adaptors plus
the length of all straight duct sections. The chart below
shows the approximate feet of equivalent length of some
typical ducts.
Listed by
Underwriters
Laboratories
Grille
Filter Kit Accessory
Filter Kit
JX81D–Recirculating
Charcoal Filter Kit
To be used when
the Advantium oven
cannot be vented
to the outside.
Duct Equivalent
A. Rectangular-To-Round 5 Ft.
Transition Adaptor
B. Wall Cap 40 Ft.
C. 90° Round Elbow 10 Ft.
D. 45° Round Elbow 5 Ft.
E. 90° Rectangular Elbow 25 Ft.
F. 45° Rectangular Elbow 5 Ft.
G. Roof Cap 24 Ft.
Specification Created 5/10 240451
CSA1201RSS
GE Café Advantium®120 Above-the-Cooktop Oven

Features and Benefits
• SpeedcookTechnology-Cooksupto4timesfasterthana
conventional oven
• 4OvensIn1ToMeetYourCookingNeeds-Speedcook,True
European Convection, Warming/Proofing, Sensor Microwave
• Optimizescooktimeforconsistentresults
• Savesvaluabletimebyeliminatingpreheating
• Over175preprogrammedrecipes
• 2full-widthovenracksformulti-levelcooking
• Model PSA1200RWW – White on white
• Model PSA1200RBB – Black on black
• Model PSA1201RSS – Stainless steel
CSA1201RSS
T
U
R
N
T
O
S
E
L
E
C
T
P
R
E
S
S
T
O
E
N
T
E
R
BACK
HELP
SPEED
COOK
CONV
BAKE
COOKING
OPTIONS
SURFACE
LIGHT
TIMER
ON/OFF
MICRO
WAVE
CLEAR
OFF
START
PAUSE
MICRO
30 SECS
SETTINGS
VENT
CONTROLL OCK
HOLD3 SECS
PRESST O TURN
TIMEROF
6:30PM
Specification Created 5/10 240451
