Dimensions and Installation Information (in inches)
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
JKP35SM
GE®27" Built-In Double Wall Oven
KW Rating
240V 6.8
208V 5.1
Breaker Size
240V 30 Amps
208V 30 Amps
Listed by
Underwriters
Laboratories
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
Specification Created 1/07 320378
Note: Cabinets installed adjacent to wall ovens
must have an adhesion spec of at least a 194°F
temperature rating. For 27” built-in single
ovens, if marks, blemishes or the cutout opening
is visible above the installed oven, it may be
necessary to add wood shims under the runners
and front trim until the marks or openings
are covered.
Note: Door handle protrudes 3" from door face.
Cabinets and drawers on adjacent 45° and 90°
walls should be placed to avoid interference with
the handle.
Electric wall ovens are not approved for
installation with a plug and receptacle.
They must be hard wired in accordance with
installation instructions.
Installation Information: Before installing,
consult installation instructions packed with
product for current dimensional data.
Cabinet 27"
A – Cabinet width required 27" min.
B – Minimum cabinet depth 23-5/8"
C – Opening width 25" min. - 25-1/4" max
D – Opening height 50-1/8" max
E – Recommended minimum cutout location from floor 13-1/4"
Oven
F – Overall depth* 23-5/8"
G – Overall height with trim 51-7/8" - 52-3/4"
Overall height without trim 51"
H – Overall width 26-5/8"
*Depth including door handle is approximately 26-7/10" min. to 26-8/10" max.
C
L
Suitable
bracing
to support
runners 18"
Over centerline
of cabinet
(must support 300 lbs.)
2" x 4" or
equivalent
runners
10
Locate
j
unction box
for 27"models
either 5" MIN.
below cutout
floor or 44"
MIN. above
cutout floor
Access
from
adjacent
cabinet
required
Allow 3/4"
for overlap
over all edges
of cutout
A
Minimum
cutout location
from floor
D
E
2" X 4" or
equiv. runners
(cutout floor) 21" MIN.
door opening
allowance
B
C
H
F
G
Locate
junction box
for 24"models
56" MIN. above
cutout floor
Conduit
(48-1/2" Long)
21
Cabinet 27"
A – Cabinet width required 27" min.
B – Minimum cabinet depth 23-5/8"
C – Opening width 25" min. - 25-1/4" max
D – Opening height 50-1/8" max
E – Recommended minimum cutout location from floor 13-1/4"
Oven
F – Overall depth* 23-5/8"
G – Overall height with trim 51-7/8" - 52-3/4"
Overall height without trim 51"
H – Overall width 26-5/8"
*Depth including door handle is approximately 26-7/10" min. to 26-8/10" max.
C
L
Suitable
bracing
to support
runners 18"
Over centerline
of cabinet
(must support 300 lbs.)
2" x 4" or
equivalent
runners
10
Locate
j
unction box
for 27"models
either 5" MIN.
below cutout
floor or 44"
MIN. above
cutout floor
Access
from
adjacent
cabinet
required
Allow 3/4"
for overlap
over all edges
of cutout
A
Minimum
cutout location
from floor
D
E
2" X 4" or
equiv. runners
(cutout floor) 21" MIN.
door opening
allowance
B
C
H
F
G
Locate
junction box
for 24"models
56" MIN. above
cutout floor
Conduit
(48-1/2" Long)
21

JKP35SM
GE®27" Built-In Double Wall Oven
Specification Created 1/07 320378
Features and Benefits
• Self Clean Oven (upper oven only) - Conveniently cleans the upper oven cavity without
need of scrubbing
• Extra-Large Oven Capacity - Provides a large oven interior ideal for cooking more
items at once
• Electronic Oven Controls - One-touch electronic pads are easy-to-use and allow for
simple oven operation
• TrueTemp™System - Delivers even heat distribution and maximum oven control
• Interior Oven Light - Supplies light to make viewing the progress of cooking easy
and convenient
• Eight-Pass Bake Element - A powerful, continuous heating element loops throughout
the oven, delivering evenly cooked foods
• Six-Pass Broil Element - Provides a more even coverage of the food on the broiler pan
• Hidden Bake Oven Interior - Hides previously exposed bottom element to deliver
a clean interior appearance
• Two Oven Racks - Feature a durable construction to help accommodate any size
or type of cookware
• Heavy-Duty Oven Racks - Provides extra support
• Model JKP35SMSS - Stainless steel
