GE Monogram ZET1PHSS User guide

OVERALL DIMENSIONS
Dimensions in parentheses
are in centimeters unless
otherwise noted. Actual
product dimensions may
vary due to manufacturing
tolerances.
* Additional space will be needed for flush installation.
Product Specification Revised 1/15
GE Monogram®30" Built-In Single Oven
SPECIFICATIONS
Overall Width 29 3/4" (75.6 cm)
Overall Height 28 1/2" (72.4 cm)
Overall Depth
Including Handle 27 1/2" (69.9 cm)
Oven Door Clearance 20 9/16" (52.3 cm)
Overall Oven
Interior Capacity 5.0 cu. ft. (141.6 liters)
Oven Interior Dimensions
(W x H x D)
25" x 17 3/8" x 20 1/4"
(63.5 x 44.1 x 51.4 cm)
Minimum Cabinet Width* 30" (76.2 cm)
Minimum Cabinet Depth* 24" (61.0 cm)
Minimum Base Support 200 lbs. (90 kg)
Cutout Width* 28 1/2" (72.4 cm) Min
28 5/8" (72.7 cm) Max
Cutout Height* 27 1/4" (69.2 cm) Min
27 5/16" (69.4 cm) Max
Cutout Depth* 23 1/2" (59.7 cm) Min
Volts/Hertz/Amps 240/208 V AC, 60 Hz, 20A
Conduit Length 40" (72" available special
order: WB18T10398)
Electrical Rating 3.4 kW at 208V
4.5 kW at 240V
Shipping Weight 208 lbs. (95 kg)
ZET1PHSS
ATTENTION ELECTRICIAN:
A 240/208V, 60Hz, 20 Amp circuit is required.
An individual properly grounded branch circuit
or circuit breaker is required. Hard wired
junction box is required for built-in product.
28 5/8"
(72.8)
28 1/2" (72.4)
min cutout width
29 3/4" (75.6)
22 1/2" (57.2)
7/16"
(1.1)
15/16"
(2.5)
27 1/4"
(69.2) min
cutout height
23 1/16"
(58.7)
5 3/16"
(13.2)
7 1/16"
(18.0 )
12"
(30.5)
24 3/4" (62.9)
8 3/8"
(21.4)
14 7/8"
(37.8)
1 3/8" (3.5)
2 5/8" (6.8)
7 15/16"
(20.1)
3 1/2"
(8.9)
1 7/8"
(4.7)
5/8"
(1.6) 10 1/2"
(26.6)
28 7/16" (72.2)
2 3/4"
(7.0)
27 1/2"
(69.9)
8 7/16"
(21.4)
20 9/16"
(52.3) min
ZET1PHSS
FRONT VIEW (SHOWING CUTOUT OVERLAP)
SIDE VIEW
TOP VIEW
OPEN OVEN DOOR
SHOWING DOOR CLEARANCE
ZET1PHSS

NOTES
30 1/4" (76.8) flush inset width
with 1/4" (0.6) reveals
1 3/8"
(3.5)
27 1/4"
(69.2)
32 1/2"
(82.6)
Recommended
cutout
location
from floor
Side cleat
Top cleat
Bottom cleat
5 5/16"
(13.5)
9 1/2"
(24.1)
29 3/4" (75.5)
cutout width
9/16" (1.4) Bottom cleat
(Extends full depth of cabinet)
15/16"
(2.4)
Side cleats
3/4"
(1.9)
Top cleat
29 1/16"
(73.8)
Flush inset
height
9/16"
(1.4)
5 5/16"
(13.5)
9 1/2"
(24.1)
28 1/2" (72.4)
min cutout width
23 1/2"
(59.7) min cutout depth
27 1/4"
(69.2)
24 15/16"
(63.4)
cutout depth
24 15/16" (63.4)
cutout depth
23 1/2" (59.7)
min cutout depth
2 1/2"
(6.4)
Side cleats
depth
Dimension varies
3"
(7.6)
30 1/4" (76.8)
ZET1PHSS
TOP VIEW
STANDARD
INSTALLATION
FLUSH INSET
INSTALLATION
FLUSH INSET INSTALLATION
FRONT VIEW
STANDARD INSTALLATION
FRONT VIEW
STANDARD
INSTALLATION
FLUSH INSET
INSTALLATION
ELEC.
ELEC.
30 1/4" (76.8) flush inset width
with 1/4" (0.6) reveals
1 3/8"
(3.5)
27 1/4"
(69.2)
32 1/2"
(82.6)
Recommended
cutout
location
from floor
Side cleat
Top cleat
Bottom cleat
5 5/16"
(13.5)
9 1/2"
(24.1)
29 3/4" (75.5)
cutout width
9/16" (1.4) Bottom cleat
(Extends full depth of cabinet)
15/16"
(2.4)
Side cleats
3/4"
(1.9)
Top cleat
29 1/16"
(73.8)
Flush inset
height
9/16"
(1.4)
5 5/16"
(13.5)
9 1/2"
(24.1)
28 1/2" (72.4)
min cutout width
23 1/2"
(59.7) min cutout depth
27 1/4"
(69.2)
24 15/16"
(63.4)
cutout depth
24 15/16" (63.4)
cutout depth
23 1/2" (59.7)
min cutout depth
2 1/2"
(6.4)
Side cleats
depth
Dimension varies
3"
(7.6)
30 1/4" (76.8)
ZET1PHSS
TOP VIEW
STANDARD
INSTALLATION
FLUSH INSET
INSTALLATION
FLUSH INSET INSTALLATION
FRONT VIEW
STANDARD INSTALLATION
FRONT VIEW
STANDARD
INSTALLATION
FLUSH INSET
INSTALLATION
ELEC.
ELEC.
WALL INSTALLATION
ABased on a user height
of 5' 6" to 5' 10"
BJunction box location
(May also be located
in adjacent cabinet.)
CPlatform must be
able to support 200 lbs
(90 kg)
DCabinet surfaces must
be an appearance
finished surface for
flush installation.
ECleats may be visible
and should be finished
to match cabinetry.
FMaximum toe kick
height of 4" when
installed beneath a
certified cooktop.
GE Monogram®30" Built-In Single Oven
UNDERCOUNTER INSTALLATION
For more details, refer to the installation instructions for this product on Monogram.com.
Dimensions in parentheses are in centimeters unless otherwise noted.
Allow 1/4" (0.64) clearances
from side edges of oven door.
CC
C
E
B
B
D
A
F
ZET1PHSS
Product Specification Revised 1/15

2" (5.1) min
2 1/2"
(6.4)
min
2" (5.1)
min
3/4" thick platform
required
2 7/8"
(7.4) max
Junction box
can protrude
from back wall
of installation
(Not cabinet wall)
5"
(12.7)
To centerline
of gas pipe
C
L
GAS
4 3/4"
(12.1) max
21"
(53.3)
9 1/4"
(23.5)
ZET1PHSS
SIDE BY SIDE INSTALLATION
FRONT VIEW OF CUTOUTS
STANDARD INSTALLATION
SIDE VIEW
STANDARD INSTALLATION
SIDE VIEW
FRONT VIEW
ELEC. ELEC.
ELEC.
wall oven ELEC.
cooktop
GAS ELEC.
Wall oven
2" (5.1) min
2 1/2"
(6.4)
min
2" (5.1)
min
3/4" thick platform
required
2 7/8"
(7.4) max
Junction box
can protrude
from back wall
of installation
(Not cabinet wall)
5"
(12.7)
To centerline
of gas pipe
C
L
GAS
4 3/4"
(12.1) max
21"
(53.3)
9 1/4"
(23.5)
ZET1PHSS
SIDE BY SIDE INSTALLATION
FRONT VIEW OF CUTOUTS
STANDARD INSTALLATION
SIDE VIEW
STANDARD INSTALLATION
SIDE VIEW
FRONT VIEW
ELEC. ELEC.
ELEC.
wall oven ELEC.
cooktop
GAS ELEC.
Wall oven
NOTES
GE Monogram®30" Built-In Single Oven
INSTALLATION WITH ADVANTIUM
AND WARMING DRAWER
SIDE BY SIDE INSTALLATION
ADimensions per
Advantium or
Microwave Oven
requirement
BDimension per Warming
Drawer requirement
CNote this oven is only
approved to be installed
under specific models as
labeled on this unit.
DSupport platform made
of 3/4" (1.9 cm) wood
is required. Must be
capable of supporting
200 lbs (90 kg). Support
Platform base to be
same height as toe kick.
EJunction box location
for wall oven. (May
also be located in
adjacent cabinet).
FGas regulator and
electric connections
for cooktops must be
located in an adjacent
accessible location to
the right
GTop and/or side fillers
may be necessary if unit
is positioned between
existing cabinets. Be
sure they are attached
securely, since they will
anchor the oven in the
cabinet.
HFor flush oven
installations, the
cooktop cutout must be
set back 2 1/2" (6.4) plus
the cleat setback.
IDimension varies based
on model.
example:
ZGU385 5 1/2" (14.0)
(from wall)
ZGU384 4 5/16" (11.0)
(from wall)
JDimension varies based
on model.
example:
ZGU385 0"
(centerline)
ZGU384 12 1/16" (30.6)
(centerline)
For more details, refer to the installation instructions for this product on Monogram.com.
Dimensions in parentheses are in centimeters unless otherwise noted.
UNDER COOKTOP INSTALLATION
ZET1PHSS
A
B
J
I
HC
D
E
F
G
Product Specification Revised 1/15

FEATURES AND BENEFITS
True European Convection with Direct Air -
Channels heated air from the top of the oven and
circulates it around food on all sides for perfectly
uniform baking and roasting
5.0 Cu. Ft. Capacity - Accommodates even the
largest meals
Ten-Pass Bake Element - Covers more surface area
for more even baking results
All-Glass Interior Door Panel – Offers a visually
striking look that's easy to clean
Theatre-Style LED Oven Lighting - Located on both
sides of the oven to enhance visibility and provide a
clear view of food, regardless of rack position
Stainless steel back-lit digital control knobs -
Rotate with smooth precision. An indicator light
in each knob makes it easy to view and select
heat settings
Notification Lighting - Allows you to check cooking
status with a quick glance
Self-Cleaning, Full-Extension Oven Racks - Glide
in and out smoothly on stainless steel ball bearings,
and are designed to be left in the oven during the
self-clean cycle
Self-Clean with Steam Clean Option - Gives you
flexible options for thorough oven cleaning
Ten-Pass, Dual Broil Element - Evenly browns
dishes of all types and sizes
WiFi Connect - Allows you to control oven functions
from anywhere inside or even outside your home,
using your smartphone or other web-enabled
mobile device
Black Interior – Offers a stylish complement to the
sophisticated exterior design
GE Monogram®30" Built-In Single Oven ZET1PHSS
R
Product Specification Revised 1/15
