GE Monogram ZET938SMSS User manual

Listed by
Underwriters
Laboratories
KW Rating
240V 4.0
208V 3.0
Breaker Size
240V 20 Amps
208V 20 Amps
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Installation Flexibility
These ovens may be installed below a countertop and beneath
approved cooktops. They may also be installed in combination
with an Advantium oven and a warming drawer. They may also
be installed side by side. This oven is not approved for stackable,
one over another installations.
Note: Cabinets installed adjacent to wall ovens must have an
adhesion spec of at least a 194°F temperature rating.
Installation Information: Before installing, consult installation
instructions packed with product for current dimensional data.
Dimensions and Installation Information (in inches)
ZET938SM/BM/WM
GE Monogram®30” Built-In Single Oven
28-1/2" Min.
28-5/8" Max.
27-1/4" Min.
27-5/16" Max.
23-1/2"
Min.
Locate Junction Box 22"
Above Cutout Floor, Within 5"
of Right Rear Wall
30"
28-1/4"
23-1/4"
Recessed
Depth
29-3/4"
32-1/2"
28-1/2" Min.
28-5/8" Max.
27-1/4" Min.
27-5/16" Max.
23-1/2"
Min.
Locate Junction Box 22"
Above Cutout Floor, Within 5"
of Right Rear Wall
30"
28-1/4"
23-1/4"
Recessed
Depth
29-3/4"
32-1/2"
130184
Specification Revised 5/07
Side by Side Installations
Install two wall ovens in separate cutouts.
Allow 2" (5.1 cm) min. between cutouts.
Note: Install the
oven only with
specific models
listed on the label
located on top of
the oven.
2 (5.1 cm) Min.
2 (5.1 cm) Min.
Per Advantium or
Microwave Oven
Requirement
Per Warming Drawer
Requirement
The solid bottom or runners must be level with the bottom of the
cutout, or the bottom trim may not install correctly and could
interfere with the door opening. If the cabinet does not have a
solid bottom, two braces or runners must be installed level with
the bottom of the cutout to support the weight of the oven. The
runners and braces must support 150 lbs. (68 kg).

Features and Benefits
• Electronic Glass Touch Controls - A gentle touch
allows you to easily select the desired cooking
function: convection bake or roast, variable or
closed-door broiling, 24-hour delay bake, warm
mode or proof mode
• Halogen Light Columns - On the oven walls
provide brilliant task lighting for each
rack position
• Self-Cleaning Oven Racks - Porcelain-coated
racks are designed to be left in the oven during
the self-clean cycle for effortless cleaning
• 4.4 Cu. Ft. Capacity – Easily accommodates even
the largest meals
• True Hidden Bake Element – Concealed beneath
the oven floor, allowing additional capacity and
improved cleanability
• Reverse-Air Convection System - Uses an
innovative fan that reverses direction for optimal
air and heat circulation, providing even cooking
and multi-rack baking capability
• Certified Sabbath Mode - Allows you to keep cooked
foods warm on the Jewish Sabbath and Jewish holidays
• Signature Tubular Handles - Are smooth, sleek and
easy to grasp
• Hand-Finished Edges – Reflect the meticulous quality
and craftsmanship for which Monogram products
are renowned
• Large Viewing Window – Allows you to view your
culinary work in progress
• Standard GE Dimensions – Match the industry’s preferred
cutout sizes for remarkably simple installation
• Model ZET938SMSS – Stainless steel
• Model ZET938BMBB – Black
• Model ZET938WMWW – White
ZET938SMSS
OVEN
CONV
BAKE
MULT
CONV
BAKE
1RACK
CONV
ROASTSTART
BAKE
BROILWARM
PROOF
CLEAR
OFF
OPTIONS
HIGH
LOW
PROBE
SELF
CLEAN
STD
LOW
TIMER
ON
OFF
LOCK
DELA
Y
START
COOK
TIME
1 2 34 5 6 7 890
ZET938SM/BM/WM
GE Monogram®30” Built-In Single Oven
130184
Specification Revised 5/07
