GE Profile Advantium PSB2200 User manual

Installation
Instructions
Advantium®240V
Built-In SpeedCook
Ovens
PSB2200
PSB2201
ZSC2200
ZSC2201
ZSC2202
49-40574-1
MFL06213302
02-08 JR

Safety Information
2
CO TE TS
Design Information
Models Availa le......................................................................2
Product Dimensions and Clearances ............................3
Tools and Parts Required ....................................................3
Parts Supplied ..........................................................................3
Electrical Tools and Parts Required ................................3
Advance Planning ..................................................................3
Installation Preparation
Electrical Requirements........................................................4
Install Junction Box ................................................................4
Preparing the Opening (Installation without
an accessory storage drawer)..................................5-6
Preparing the Opening (Installation with
an accessory storage drawer)..................................7-8
Installation Instructions
Step 1, Remove Packaging and Parts ..........................9
Step 2, Route Conduit ........................................................10
Step 3, Install Bottom Trim ..............................................11
Step 4, Install Mounting Screws ....................................11
Step 5, Finalize Installation ..............................................11
BEFORE YOU BEGI
Read these instructions completely and carefully.
IMPORTA T —Save these instructions for
local inspector’s use.
IMPORTA T —O serve all governing codes
and ordinances.
•ote to Installer —Be sure to leave these
instructions with the Consumer.
•ote to Consumer —Keep these instructions
with your Owner’s Manual for future reference.
•Skill Level —Installation of this appliance
requires asic mechanical and electrical skills.
•Completion Time —1 Hour.
• Proper installation is the responsi ility of the
installer. Product failure due to improper
installation is not covered under the warranty.
See Owner’s Manual for warranty information.
IMPORTA T —Use this oven only for
its intended purpose. Never use the oven for
warming or heating a room. Prolonged use of the
oven without proper ventilation can e hazardous.
CAUTIO :
For personal safety, remove house fuse or oven
circuit reaker efore eginning installation to
avoid severe or fatal shock injury.
CAUTIO :
For personal safety, the mounting surface must
e capa le of supporting the ca inet load, in
addition to the added weight of the 80-pound oven
and 30-pound drawer, plus additional oven loads of
up to 50 pounds or a total weight of up to 160
pounds.
CAUTIO :
For personal safety, this product cannot e
installed in ca inet arrangements such as an
island, a peninsula or elow a countertop.
MODELS AVAILABLE
Profile Models:
PSB2200NWW–White
PSB2200NBB–Black
PSB2201NSS–Stainless Steel
Monogram Models:
ZSC2200NWW–White
ZSC2200NBB–Black
ZSC2201NSS–Stainless Steel
Monogram Pro Range Models:
ZSC2202NSS–Stainless Steel
OTE: This unit cannot be installed with an
accessory storage drawer.

Design Information
3
PRODUCT DIME SIO S A D CLEARA CES OTE: Appearance will vary y model.
13”
13/16”
21 1/2”
19 1/32”
29 3/4”
TOOLS A D PARTS REQUIRED
( OT SUPPLIED)
#2 Phillips screwdriver
Hand held drill
High speed drill it, 3/32″diameter
3/8″slot head screwdriver
Level
Saw
2x4 or 2x2 lum er for installing runners
or 3/8″plywood for floor (if required)
Wood screws or other hardware for installing
runner or shelf to support oven (if required)
Safety glasses or goggles
PARTS SUPPLIED
6 rass screws (3 required, 3 extra)
5 color matched screws (4 required, 1 extra)
Bottom trim
ELECTRICAL TOOLS A D PARTS
REQUIRED ( OT SUPPLIED)
Junction ox
Electrical ca le (3-conductor or 4-conductor wire
as required y local codes)
UL-listed conduit connectors
Wire cutters and wire strippers
ADVA CE PLA I G
•These ovens may e installed directly into a 30” wide
oven ca inet.
•Cutout dimensions are NOT the same for installation
with or without an accessory storage drawer. Make
sure to use the correct cutout when preparing the
opening.
OTE: Model ZSC2202 CANNOT e installed with an
accessory storage drawer. See Installation
Preparation Without an Accessory Storage Drawer
for this model.
IMPORTA T —This oven is not approved for
use a ove another uilt-in Advantium Speedcook
oven, a side y side installation or elow a
countertop.
• For personal safety, this oven cannot e installed
in a ca inet arrangement such as an island or
peninsula.
• The oven must e installed at least 36-3/4" a ove
the floor.
• Allow for clearance to adjacent corners, walls,
drawers, etc.
• Ca inets installed adjacent to wall ovens must
have an adhesion spec of at least 194ºF
temperature rating.
The oven must e securely installed in a ca inet
that is firmly attached to the house structure.
Weight on the oven door could cause the oven
to tip and result in injury. Never allow anyone to
clim , sit, stand or hang on the oven door.
If installing the drawer accessory, the drawer must
e assem led to the oven prior to installation into
the ca inet. See the Accessory Storage Drawer
Assembly Instructions.
21-1/2”
1”
13”
19”
29-3/4”

Installation Preparation
4
ELECTRICAL REQUIREME TS
Single Speedcook Installation
Product rating is 120/208 or 120/240 volt, 60 Hz,
30 amps. This product must e connected to a supply
circuit of the proper voltage and frequency and
protected y a time delay fuse or circuit reaker.
Power should e supplied from a separate, dedicated
30-ampere ranch circuit. Wire size must conform to
the requirements of the National Electrical Code or the
prevailing local code.
Combined Speedcook and Wall Oven Installation
When installed in com ination with a GE/Monogram
single wall oven, use separate electrical junction oxes.
Refer to single oven installation instructions for
electrical requirements of that product.
These connections must e made y a qualified
electrician. All electrical connections must meet
National Electrical Code or prevailing local codes.
Combined Speedcook and Warming Drawer
Installation
When installing the Speedcook oven over a GE or
Monogram electric warming drawer, a separate 120V,
60Hz, properly grounded receptacle must e installed.
See instructions packed with the warming drawer.
WAR I G
• The electrical power to the oven ranch circuit
must e shut off while line connections are eing
made.
• Use copper wiring only.
• Electrical ground is required on this appliance.
The free end of the green wire (ground wire)
must e connected to a suita le ground.
This wire must remain grounded to the oven.
• If cold water pipe is interrupted y plastic,
non-metallic gaskets, union connections or other
insulating materials, DO NOT use for grounding.
• DO NOT ground to a gas pipe.
• DO NOT have a fuse in the NEUTRAL or
GROUNDING circuit. A fuse in the NEUTRAL or
GROUNDING circuit could result in an electrical
shock.
• Check with a qualified electrician if you are in
dou t as to whether the appliance is properly
grounded.
Failure to follow these instructions could result in
serious injury or death.
I STALL JU CTIO BOX
The conduit is located at the top right on the ack of
the oven.
Locate and install the junction ox within reach of the
oven conduit.
•Through the left or right sides of the ca inet wall
and into adjacent ca inet.
•Or, through the cutout floor.
•Or, in the upper ca inet.
Cutout
Height

5
Installation Preparation
Preparation WITHOUT an Accessory Storage Drawer
PREPARE THE OPE I G (CO T.)
Installation over a GE/Monogram
Warming Drawer:
OTE: Additional clearances etween the cutouts
may e required. Check to e sure the oven supports
a ove the Warming Drawer location do not o struct
the required interior depth and height. See Warming
Drawer installation instructions for details.
30” 23-1/2”
25-1/4”
17-1/2”
36-3/4”
Min.
2” Min.
(3” recommended)
Per warming
drawer
requirement
Construct
Solid Bottom
Min. 3/8”
Plywood
Supported
by 2x4 or 2x2
Runners all
Four Sides
PREPARE THE OPE I G
The Advantium 240V can e installed in
com ination with other GE/Monogram appliances.
Always follow each product’s Installation
Instructions to complete the installation.
Single Advantium 240V Installation:
Order a 30” wide single oven ca inet or cut the
opening in a wall to the dimensions shown.
• Always maintain 36-3/4” minimum height from
the floor to the cutout in any single or com ined
installation.
• Allow 2-1/8” case trim overlap on the sides and
7/8” overlap on the ottom of the opening for all
models. Allow 1-1/4” case trim overlap on the top
for models PSB2200 and PSB2201 and 3/4”
overlap on the top for models ZSC2200, ZSC2201
and ZSC2202.
• Oven overlaps will conceal cut edges on all sides
of the opening.
When installed over a single oven or a warming
drawer, allow at least 2” etween the two openings.
This separation will provide clearance for ottom
overlap of the Advantium 240V and the other
appliance overlaps.
Construct a solid oven floor of 3/8” min. thick plywood
supported y 2 x 4 or 2 x 2 runners on all sides.
• The support must e level and rigidly mounted,
flush with the ottom edge of the cutout.
30” 23-1/2”
25-1/4”
17-1/2”
Construct
Base
Min. 3/8”
Plywood
Supported
by 2x4 or 2x2
Runners all
Four Sides
36-3/4”
Min.

Installation Preparation
6
Preparation WITHOUT an Accessory Storage Drawer
PREPARE THE OPE I G (CO T.)
Installation over a GE/Monogram Oven and
Warming Drawer:
OTE: Additional clearances etween the cutouts
may e required. Check to e sure the oven
supports a ove the Warming Drawer location do
not o struct the required interior depth and height.
See Warming Drawer installation instructions for
details.
CAUTIO : For personal safety, the mounting
surface must e capa le of supporting the
ca inet load, in addition to the added weight of
this approximate 80-pound oven, plus additional
oven loads of up to 50 pounds or a total weight
of 130 pounds.
Construct Solid
Bottom Min.
3/8” Plywood
Supported by
2x4 or 2x2
Runners all
Four Sides
30” 23-1/2”
25-1/4”
17-1/2”
2” Min.
Per Oven
Requirement
45-1/4”
Min. Per warming drawer requirement
2” Min.
(3” recommended)
PREPARE THE OPE I G (CO T.)
Installation over a GE/Monogram Oven:
• If you are replacing a GE/Monogram electric
dou le oven with the com ined installation of
an Advantium 240V and a single oven, use the
dimensions shown. The middle rail separating
the two openings may need to e larger than
the 2” minimum shown.
30” 23-1/2”
25-1/4”
17-1/2” 2” Min.
(3” recommended)
45-1/4”
Min.
Construct Solid
Bottom Min.
3/8” Plywood
Supported by
2x4 or 2x2
Runners all
Four Sides
Per Oven
Requirement

7
Installation Preparation
Preparation WITH an Accessory Storage Drawer
OTE: MODEL ZSC2202 CA OT BE I STALLED WITH A ACCESSORY STORAGE DRAWER. SEE I STALLATIO PREPARATIO
WITHOUT A ACCESSORY STORAGE DRAWER FOR THIS MODEL.
Installation over a GE/Monogram
Warming Drawer:
* For existing cutouts, a maximum width of 28-1/2”
is accepta le. If the opening is slightly wider,
secure a furring strip on each side of the cutout
for securing the oven.
OTE: Additional clearances etween the cutouts
may e required. Check to e sure the oven
supports a ove the Warming Drawer location do
not o struct the required interior depth and height.
See Warming Drawer installation instructions for
details.
30” 23-1/2”
25-1/4”
Min.*
21”
36-3/4”
Min.
2” Min.
(3” recommended)
Per warming
drawer
requirement
Construct
Solid Bottom
Min. 3/8”
Plywood
Supported
by 2x4 or 2x2
Runners all
Four Sides
PREPARE THE OPE I G
The Advantium 240V can e installed in
com ination with other GE/Monogram appliances.
Always follow each product’s Installation
Instructions to complete the installation.
Single Advantium 240V Installation:
Order a 30” wide single oven ca inet or cut the
opening in a wall to the dimensions shown.
* For existing cutouts, a maximum width of 28-1/2”
is accepta le. If the opening is slightly wider,
secure a furring strip on each side of the cutout
for securing the oven.
• Always maintain 36-3/4” minimum height from
the floor to the cutout in any single or com ined
installation.
• Allow 3/4” to 2-1/8” case trim overlap on the sides
and 7/8” overlap on the ottom of the opening for
all models. The amount of overlap on the sides
depends on the actual cutout width. Allow 1-1/4”
case trim overlap on the top for models PSB2200
and PSB2201 and 3/4” overlap on the top for
models ZSC2200, ZSC2201 and ZSC2202.
• Oven overlaps will conceal cut edges on all sides
of the opening.
30” 23-1/2”
25-1/4”
Min.*
21”
Construct
Base
Min. 3/8”
Plywood
Supported
by 2x4 or 2x2
Runners all
Four Sides
36-3/4”
Min.
PREPARE THE OPE I G (CO T.)
Single Advantium 240V Installation (cont.)
When installed over a single oven or a warming
drawer, allow at least 2” etween the two openings.
This separation will provide clearance for ottom
overlap of the Advantium 240V and the other
appliance overlaps.
Construct a solid oven floor of 3/8” min. thick plywood
supported y 2 x 4 or 2 x 2 runners on all sides.
• The support must e level and rigidly mounted,
flush with the ottom edge of the cutout.

8
Installation Preparation
Preparation WITH an Accessory Storage Drawer
OTE: MODEL ZSC2202 CA OT BE I STALLED WITH A ACCESSORY STORAGE DRAWER. SEE I STALLATIO PREPARATIO
WITHOUT A ACCESSORY STORAGE DRAWER FOR THIS MODEL.
PREPARE THE OPE I G (CO T.)
Installation over a GE/Monogram Oven and
Warming Drawer:
* For existing cutouts, a maximum width of 28-1/2”
is accepta le. If the opening is slightly wider,
secure a furring strip on each side of the cutout
for securing the oven.
OTE: Additional clearances etween the cutouts
may e required. Check to e sure the oven
supports a ove the Warming Drawer location do
not o struct the required interior depth and height.
See Warming Drawer installation instructions for
details.
CAUTIO : For personal safety, the mounting
surface must e capa le of supporting the ca inet
load, in addition to the added weight of this
approximate 80-pound oven and 30-pound
drawer, plus additional oven loads of up to 50
pounds or a total weight of 160 pounds.
Construct Solid
Bottom Min.
3/8” Plywood
Supported by
2x4 or 2x2
Runners all
Four Sides
30” 23-1/2”
21”
2” Min.
Per Oven
Requirement
45-1/4”
Min. Per warming drawer requirement
2” Min.
(3” recommended)
PREPARE THE OPE I G (CO T.)
Installation over a GE/Monogram Oven:
* For existing cutouts, a maximum width of 28-1/2”
is accepta le. If the opening is slightly wider,
secure a furring strip on each side of the cutout
for securing the oven.
• If you are replacing a GE/Monogram electric
dou le oven with the com ined installation of
an Advantium 240V and a single oven, use the
dimensions shown. The middle rail separating
the two openings may need to e larger than
the 2” minimum shown.
30” 23-1/2”
25-1/4”
Min.*
21” 2” Min.
(3” recommended)
45-1/4”
Min.
Construct Solid
Bottom Min.
3/8” Plywood
Supported by
2x4 or 2x2
Runners all
Four Sides
Per Oven
Requirement
25-1/4”
Min.*

9
Installation Instructions
• Remove all packing material and tape.
• Locate parts package containing mounting screws.
• Remove the oven from the carton. Do not lift unit y
handle or conduit. Two people are required to lift
this oven.
• Open the door and remove any packaging in oven.
REMOVE THE PACKAGI G A D PARTS1
Owner’s
Manual
Owner’s Manual Installation
Instructions
Glass Tray
Metal Grill Tray
Metal Trays (2)
Turnta le Ring
Bottom Trim
Rack
6 Brass Screws
(3 required, 3 extra)
IMPORTA T: If installing the Advantium 240V Oven
with an accessory storage drawer, read the storage
drawer assem ly instructions to assem le the
products together efore proceeding to Step 2.
Cook Book
5 Color Matched Screws
(4 required, 1 extra)
Cooking Guide
Cooking
Guide

Installation Instructions
10
ROUTE CO DUIT THROUGH
CUTOUT (CO T.)
When connecting to a 3-conductor branch
circuit:
•Connect oven red lead to ranch circuit red lead.
•Connect oven lack lead to ranch circuit lack
lead.
•Connect oven green ground lead and white lead
to ranch circuit neutral (white or gray).
When connecting to a 4-conductor branch
circuit:
•Connect oven red lead to ranch circuit red lead.
•Connect oven lack lead to ranch circuit lack
lead.
•Break connection etween oven white lead and
oven green ground lead.
•Connect oven white lead to ranch circuit neutral
lead (white or gray).
•Connect oven green ground lead to ranch circuit
ground lead (green or are copper).
2
ROUTE CO DUIT THROUGH
CUTOUT
CAUTIO : Two people are required to lift
the oven into the opening. Grasp the ottom at
front and rear. Discard foam ase. DO NOT USE
HANDLE OR CONDUIT TO LIFT THE OVEN. DAMAGE
WILL OCCUR.
With oven in front of the ca inet opening:
•Insert conduit into ca inet opening. Connect oven
wiring and ranch circuit.
•Lift the oven into the opening while continuing to feed
the conduit in the direction of the installed junction
ox. Be sure the conduit does not get pinched
etween the ack of the oven and the ca inet wall.
•Leave oven a few inches forward of the ca inet
front frame. Do not push the unit all of the way
into the cutout.
WAR I G
•Disconnect power to the junction ox efore
making the electrical connection.
•Electrical ground is required on this appliance.
•Do not connect the electrical supply until
appliance is permanently grounded.
GROU DI G I STRUCTIO S
This appliance must e connected to a grounded,
metallic, permanent wiring system, or an equipment
grounding connector should e run with the circuit
conductors and connected to the equipment
grounding terminal or lead on the appliance.
Failure to follow these instructions could result
in fire, personal injury or electrical shock.
2
(Oven shown without
accessory storage drawer.)

11
Installation Instructions
I STALL BOTTOM TRIM
OTE: If installing the Advantium 240 Oven with an
accessory storage drawer, the ottom trim is not
required. Proceed to Step 4.
•Align ottom trim ta s to slots in the ottom of the
oven.
•Secure the ottom trim to the ottom of the oven
using 3 rass screws provided.
3I STALL MOU TI G SCREWS
•Slide the oven the remaining way into the opening
so that the side flanges and control panel are
against the ca inet frame. Make sure that the oven
is centered in the opening.
•Open the door, place a turnta le tray in the oven
and make sure that the tray in the unit is level.
•Drill pilot holes through the side flanges.
•Drive the color matched screws into the side
flanges. It is recommended that the screws
e hand tightened.
If installing oven with an accessory storage
drawer:
•Open the drawer.
•Drill pilot holes through the side flanges.
•Drive color match screws into the side flanges.
It is recommended that the screws e hand
tightened.
4
FI ALIZE I STALLATIO
•Turn power on at the source. The interior light
should come on when the door is opened.
•Refer to Owner’s Manual for operating instructions.
5

OTE: Appearance will vary y model.
Assembly Instructions
Advantium®240V Built-In Accessory Storage Drawer
JX2200, JX2201, ZX2201
BEFORE YOU BEGI
Read these instructions completely and carefully. Read
the Installation Instructions for the Advantium 240V oven
completely and carefully for cutout dimensions and
step- y-step instructions.
IMPORTA T —Save these instructions for
local inspector’s use.
IMPORTA T —O serve all governing codes
and ordinances.
• OTE TO I STALLER: Be sure to leave these
instructions with the Consumer.
• OTE TO CO SUMER: Keep these instructions with
your Advantium 240V Oven Owner’s Manual for
future reference.
• SKILL LEVEL: Installation of this appliance requires
asic mechanical skills.
• COMPLETIO TIME: One hour with the installation
of an Advantium 240V oven.
• Proper installation is the responsi ility of the installer.
• Product failure due to improper installation is not
covered under the Warranty. See the Advantium
240V Oven Owner’s Manual for warranty information.
TOOLS REQUIRED
• #2 Phillips screwdriver
PARTS SUPPLIED
• 2 Side Supports
• Screws
• Screws (color matched)
MODELS AVAILABLE
Profile Models:
JX2200BB–Black
JX2201SS–Stainless Steel
Monogram Models:
ZX2201SS–Stainless Steel
OTE: Advantium 240V Built-In SpeedCook Oven
model ZSC2202SS CA OT be installed with an
accessory storage drawer. See Installation
Preparation Without an Accessory Storage Drawer in
the Advantium 240V Built-In SpeedCook Oven
Installation Instructions for this model.
PRODUCT DIME SIO S A D CLEARA CES
Allow 15” clearance
when fully open
5”
12

REMOVE PACKAGI G A D PARTS
• Remove the drawer from the carton.
• Remove all packing material and tape.
• Open the drawer and remove any parts inside.
• Locate parts.
1
ASSEMBLY TO ADVA TIUM 240V BUILT-I SPEEDCOOK OVE
Assem ly
Instructions
Side Supports (2)
Screws (2 Sets)
ASSEMBLI G THE OVE TO DRAWER
(CO T.)
Remove the front two ottom screws on each
side of the oven and the top center screw on
each side of the storage drawer.
Place the side supports into the ta s on the
drawer and secure using the screws supplied
and the screws removed in Step C.
The oven and storage drawer assem ly is now
ready to e installed. Return to the Advantium
240V Built-In SpeedCook Oven Installation
Instructions to complete the installation.
E
D
C
ASSEMBLI G THE OVE TO DRAWER
Place storage drawer on a surface with the
front of drawer hanging over the edge of the
surface. Not placing the front edge of drawer
over the edge of the surface may result in
damage to the drawer since the front edge of
drawer hangs elow the ottom of drawer.
Place the oven on top of the storage drawer.
Make sure that the ack and sides of the oven
align with the ack and sides of drawer.
OTE: The ottom of the oven side flanges will
sit directly in front of the top of the storage
drawer side flanges.
B
A
2
13

14

15

Printed in Korea
OTE: While performing installations descri ed in this ook,
safety glasses or goggles should e worn.
OTE: Product improvement is a continuing endeavor at
General Electric. Therefore, materials, appearance and
specifications are su ject to change without notice.
GE Consumer & Industrial
Appliances
General Electric Company
Louisville, KY 40225
ge.com
