GE JB870SRSS Manual

Dimensions and Installation Information (in inches)
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Listed by
Underwriters
Laboratories
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
Specification Revised 8/10 321561
KW Rating
240V 14.2
208V 10.7
Breaker Size
40 Amps†
30
24
3
7-1/2
29-7/8
25-3/4*
45
47
3
Acceptable electrical
outlet area
Orient the electrical
receptacle so the length
is parallel to the floor.
*Dimension from wall to front of
closed oven door handle is 28-7/8.
fse_dual_cavity_install.eps
JB870SR
GE® 30" Free-Standing Electric Double Oven Convection Range
†Note: Check local codes for required breaker size.
Effective January 1, 1996, the National Electrical
Code requires that new construction (not existing)
utilize a 4-conductor connection to an electric range.
Receptacle Locations: Locally approved flexible
service cord or conduit must be used because
terminals are not accessible after range installation.
See shaded area in drawing for location of electrical
outlet box. Recommended outlet locations allow
range to be installed directly against wall.
Note: 30" ranges conform to U.L. requirements for
0" spacing from adjacent walls below countertops.
To reduce possibility of scorching walls, engineering
recommends a minimum of 1-1/2" spacing to allow
for possible extended, high-heat, no-load heating
element operation.
Installation information: Before installing, consult
installation instructions packed with product for
current dimensional data.
All 30" GE gas and electric range backguards
are 30-7/8" wide.*
Note: 30" ranges conform to U.L. requirements
for 0" spacing from adjacent walls below
countertops. To reduce possible scorching of
walls, engineering recommends a minimum of
1-1/2" spacing to allow for possible extended,
high heat, no-load heating element operation.
*Except these models: JGBS07, JGBS04, all GE
Profile free-standing electric and gas ranges
Fits most countertop backsplash applications.
Consult Use & Care Manual for detailed
installation instructions.
30-7/8"

321561
Features and Benefits
• 6.6cu.ft.totalovencapacity-Largecapacityisidealforbigmeals
• Self-cleanoven-Self-cleanallowsyoutospareyourselffromthetroubleandeffortit
takes to scrub the oven interior
• ConvectionBake-Thissettingisoptimalforbakingcasserolesorlasagnas,yeast
breads, pies and pizzas with no need to turn the pan
• 9"/12"Dualelement-Twoheatingelementsinoneallowsyoutochooseeithera9"or
12" element for your cookware
• Warmingzone(Fifthelementwarmingzone)-Simplifymealsbykeepingfoodsfresh
from the oven warm and ready to serve
• Heavy-dutyrollerrack-Racksprovideeasyaccesstoitemsinsidetheovenby
simplifying loading and unloading
• Hiddenbakeoveninterior-Concealsthelowerovenbakeelementtoeliminatehard-
to-reach areas that collect food and spills for easy cleaning
•  T r u e T e m p ™oven system - This feature helps ensure the temperature you set is
the temperature you get, with less variance, to give you the baking and broiling
performance you desire
• Dualelementbake-Thistop-and-bottomheatingproducesuniformbrowningand
fast oven preheating
• QuickSetVOvenControls-Featureaneasytousedesignthatallowsyoutoset
precise cooking temperatures
• ModelJB870SRSS-StainlessSteel
JB870SR
BROIL
STEAM
CLEAN TIME START
TIME
OVEN
LIGHT
CLOCK
BAKE START
ON
CLEAR
OFF
12345
67890
Specification Revised 8/10
JB870SR
GE® 30" Free-Standing Electric Double Oven Convection Range
