GE JBP81TM Manual

†Note: Check local codes for required breaker size.
Effective January 1, 1996, the National Electrical Code requires
that new construction (not existing) utilize a 4-conductor
connection to an electric range.
Receptacle Locations: Locally approved flexible service cord
or conduit must be used because terminals are not accessible
after range installation. See shaded area in drawing for location
of electrical outlet box. Recommended outlet locations allow
range to be installed directly against wall.
Note: 30" ranges conform to U.L. requirements for 0" spacing
from adjacent walls below countertops. To reduce possibility
of scorching walls, engineering recommends a minimum of
1-1/2" spacing to allow for possible extended, high-heat,
no-load heating element operation.
Installation Information: Before installing, consult installation
instructions packed with product for current dimensional data.
Dimensions and Installation Information (in inches)
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Listed by
Underwriters
Laboratories
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
Specification Revised 6/07 321593
KW Rating
240V 13.8
208V 10.4
Breaker Size
40 Amps†
30
25
29-7/8
A*
2-1/2
7-1/2
25-3/8
47-5/8
2-1/2
Acceptable electrical
outlet area
30_install_fse_drawer.eps
7
14-1/2
On models with baking or warming
drawers, electrical outlet must not
be in this area.
Dimension from wall to front of closed
oven door handle is 27-3/8 on models
JB988/968/910/900 and 27-3/4 on models
JBP89/84/81.
*A is 46-7/8 on models JBP89/84/81 and
46-1/2 on models JB988/968/910/900
JBP81TM
GE®30" Free-Standing CleanDesign™Electric Range

Specification Revised 6/07 321593
Features and Benefits
• Self-Clean Oven - Conveniently cleans the oven cavity without the need
for scrubbing
• Super-Large 5.3 Cu. Ft. Oven Capacity - Provides an impressively large oven
interior to cook more dishes and large meals at once
• Hidden Bake Oven Interior - Hides previously exposed bottom element to deliver
a clean interior appearance
• TrueTemp™System - Delivers even heat distribution and maximum oven control
• Warming Drawer - Convenient drawer keeps breads, desserts or just-cooked
foods warm and ready-to-serve
• 6"/9" PowerBoil™Element - Accommodates various-size pots or pans and 3,000
watts of power speeds the boiling process
• Dual Size Ribbon Element - Offers a convenient choice of using a 9" or 12" heating
element, depending on the size of the pan
• Warming Zone - Provides low heat capability for foods, making meal
coordination simple
• 6-Pass Broil Element - Provides better and more even coverage of the food
• Self-Clean Heavy-Duty Oven Racks - Double coated porcelain-enameled racks
no longer require hand cleaning
• Model JBP81TMWW – True white (white door and true white cooktop)
• Model JBP81TMCC – True bisque (bisque door and true bisque cooktop)
JBP81TM/DM
WARMING ZONE
MED
SMALL
BURNER
LARGE
BURNER
FRONT
BURNER
BRIDGE
BURNER
BROIL SELF
CLEAN
OVEN
LIGHT
CLOCK
OVENCONTROLSTrueTemp
ON
TEMP
NORMAL
HILOOFF
KITCHEN
TIMER
ONOFF
BAKESTART
ON
CLEAR
OFF
TIMECONTROLS
COOKING
TIME
ONOFF
AUTOMATICOVEN
START
TIME
ONOFF
JBP81TM
GE®30" Free-Standing CleanDesign™Electric Range
