GE JSP46SNSS Manual

Dimension and installation information are shown in inches.
JSP46SN
GE®30" Slide-In CleanDesign Electric Range
Dimensions and Installation Information (in inches)
Specification Revised 7/09
320648
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
Listed by
Underwriters
Laboratories
KW Rating
240V 12.4
208V 9.3
If you are NOT using the
optional Filler or Backguard:
23-3/16
30
If you are using the optional
Filler or Backguard:
25
30
If you are NOT using the
optional Filler or Backguard:
23-3/16
30
If you are using the optional
Filler or Backguard:
25
30
Acceptable
Electrical
Outlet Area
30" Min.
30" Min.
Shave Raised Edge To Clear
31-1/8" Wide Control Panel
Excluding Models JSS28 and JSP39
2-7/8"
To Front
Surface Of
Countertop
20-5/8" Door
Clearance
From Front
Surface of
Countertop
31-1/4
30
25-3/4**
Recommended
6" Min.
From Walls
23-3/16
15" Min.
A/B*
13" Max.
2-1/2
30
25
9/16
7-1/2
2-1/2
Accessory
Backguard
24
36-1/4
*JXS37 is 5-1/4" and JXS32 is 4"
(excluding handle)
**Total depth from wall to
front of closed oven door
including handle is 27-13/16.
35-7/8"–38"
from floor to
countertop
If the countertop area is not flat, excess tension may be applied to the glass cooktop causing breakage
and voiding the warranty. Make sure the wall covering, countertop, flooring and cabinets around the range
can withstand the heat (up to 200˚F) generated by the range.
A. Allow 30
" minimum clearance between surface units and bottom of unprotected wood or metal cabinet,
or allow a 24
" minimum when bottom of wood or metal cabinet is protected by no less then 1/4 " thick
flame retardant millboard covered with no less than No. 28 MSG sheet metal (.015
" thick), .015 " thick
stainless steel, .025
" aluminum or .020 " copper.
B. This appliance has been approved for 0
" spacing to adjacent surfaces above the cooktop. However,
a minimum 6
" spacing to surfaces less than 15 " above the cooktop and adjacent cabinetry
is recommended to reduce exposure to steam, grease splatter and heat. Allow 1/4
" minimum clearance
at the back wall.
To reduce the risk of burns or fire when reaching over hot surface elements, cabinet storage space above
the cooktop should be avoided. If cabinet storage space is to be provided above the cooktop, the risk can
be reduced by installing a range hood that projects at least 5
" beyond the front of the cabinets. Cabinets
installed above the cooktop must be no deeper than 13
" .
Acceptable
Electrical
Outlet Area
30" Min.
30" Min.
Shave Raised Edge To Clear
31-1/8" Wide Control Panel
Excluding Models JSS28 and JSP39
2-7/8"
To Front
Surface Of
Countertop
20-5/8" Door
Clearance
From Front
Surface of
Countertop
31-1/4
30
25-3/4**
Recommended
6" Min.
From Walls
23-3/16
15" Min.
A/B*
13" Max.
2-1/2
30
25
9/16
7-1/2
2-1/2
Accessory
Backguard
24
36-1/4
*JXS37 is 5-1/4" and JXS32 is 4"
(excluding handle)
**Total depth from wall to
front of closed oven door
including handle is 27-13/16.
35-7/8"–38"
from floor to
countertop
If the countertop area is not flat, excess tension may be applied to the glass cooktop causing breakage
and voiding the warranty. Make sure the wall covering, countertop, flooring and cabinets around the range
can withstand the heat (up to 200˚F) generated by the range.
A. Allow 30
" minimum clearance between surface units and bottom of unprotected wood or metal cabinet,
or allow a 24
" minimum when bottom of wood or metal cabinet is protected by no less then 1/4 " thick
flame retardant millboard covered with no less than No. 28 MSG sheet metal (.015
" thick), .015 " thick
stainless steel, .025
" aluminum or .020 " copper.
B. This appliance has been approved for 0
" spacing to adjacent surfaces above the cooktop. However,
a minimum 6
" spacing to surfaces less than 15 " above the cooktop and adjacent cabinetry
is recommended to reduce exposure to steam, grease splatter and heat. Allow 1/4
" minimum clearance
at the back wall.
To reduce the risk of burns or fire when reaching over hot surface elements, cabinet storage space above
the cooktop should be avoided. If cabinet storage space is to be provided above the cooktop, the risk can
be reduced by installing a range hood that projects at least 5
" beyond the front of the cabinets. Cabinets
installed above the cooktop must be no deeper than 13
" .
Note: Cabinets installed adjacent to slide-in ranges must have an adhesion spec
of at least 194° temperature rating.
Note: To reduce the possibility of scorching the side walls above the countertop
when no load is present on burners, it is recommended that a minimum 6"
spacing from adjacent side wall be allowed for possible extended high-heat
element operation.
Receptacle Locations: For all 30" Slide-In Ranges locally approved flexible service cord or conduit
must be used because terminals are not accessible after range installation.
See shaded area
in drawing for location of electrical outlet box. Recommended
outlet locations allow range to be
installed directly against rear wall.
Optional Kits For Slide-In
Electric Ranges
(Available At Additional Cost)
Accessory Backguards
(Attaches to the back of range
as a backguard when unit is
installed in 30" free-standing
cutout)
JXS32SS (Stainless) - 4" High
JXS32BB (Black) - 4" High
JXS37BB (Black) - 5-1/4" High
Body Sides
(Slide-in ranges are sold
without sides installed. Can
be installed on either left
or right when unit has one
exposed side [no cabinet
adjacent]. Kit contains
1 body side)
JXS77BB (Black)
Rear Filler Strip
WB07T10680 - Black Filler Strip Assembly
Optional Lower Trim Kits
(If counter height is greater
than 36.5", a lower trim kit
is recommended to extend
the useful height to 38"
maximum)
JXS56BB – Black

JSP46SN
GE®30" Slide-In CleanDesign Electric Range
Specification Revised 7/09
320648
Features and Benefits
• Self-CleanOven-Convenientlycleanstheovencavitywithoutneedofscrubbing
•PreciseAir™Convection System - Delivers even air and heat circulation for superior
baking and roasting results
•TrueEuropeanConvection-Athirddual-loopheatingelementsurroundsthefanto
deliver uniform and savory cooking results
•ElectronicOvenControls-One-touchelectronicpadsareeasy-to-useandallowfor
simple oven operation
•PowerBoil™Element - Accommodates various-size pots or pans and 3,000 watts of
power speeds the boiling process
•BridgeElement-Combinesthreecooktopelementsintoonelargecookingarea,
ideal for oversized cooking pans
•Super-LargeOvenCapacity-Providesanimpressivelylargeoveninteriorforcooking
more dishes and large meals at one time
•TwoOvenRacks-Featureadurableconstructiontohelpaccommodateanysizeor
type of cookware
•RibbonHeatingElements-Providepowerfulheatbeneathasmoothglasssurface
to ensure even heat and fast warm-up times
•BigHearthWindow-Featuresanenhancedshapetoaddanelegantappearance
and make viewing trouble-free
• ModelJSP46SNSS-Stainlesssteel
