†Note: Check local codes for required breaker size.
Effective January 1, 1996, the National Electrical Code requires
that new construction (not existing) utilize a 4-conductor
connection to an electric range.
Receptacle Locations: Locally approved flexible service cord
or conduit must be used because terminals are not accessible
after range installation. See shaded area in drawing for location
of electrical outlet box. Recommended outlet locations allow
range to be installed directly against wall.
Note: 30" ranges conform to U.L. requirements for 0" spacing
from adjacent walls below countertops. To reduce possibility
of scorching walls, engineering recommends a minimum of
1-1/2" spacing to allow for possible extended, high-heat,
no-load heating element operation.
Installation information: Before installing, consult installation
instructions packed with product for current dimensional data.
Dimensions and Installation Information (in inches)
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Listed by
Underwriters
Laboratories
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
Specification Created 4/07 321577
*Dimension from wall to front of closed door handle is 27-3/4".
KW Rating
240V 13.7
208V 10.3
Breaker Size
40 Amps†
30
25
29-7/8
A*
2-1/2
7-1/2
25-3/8*
47-5/8
2-1/2
Acceptable electrical
outlet area
30_install_fse_drawer.eps
7
14-1/2
On models with baking or warming
drawers, electrical outlet must not
be in this area.
*Dimension from wall to front of closed
oven door handle is 27-3/8 on models
JB988/968/910/900 and 27-3/4 on models
JBP89/84/81.
*A is 46-7/8 on models JBP89/84/81 and
46-1/2 on models JB988/968/910/900
JBP84DM
GE®30" Free-Standing Electric Convection Range

Features and Benefits
• PreciseAir™ Convection System - Delivers even air and heat circulation
for superior baking and roasting results
• Self-Clean Oven - Conveniently cleans the oven cavity without
the need for scrubbing
• Super-Large 5.3 Cu. Ft. Oven Capacity - Provides an impressively large
oven interior to cook more dishes and large meals at once
• Hidden Bake Oven Interior - Hides previously exposed bottom element
to deliver a clean interior appearance
• Self-Clean Heavy-Duty Oven Racks - Double coated porcelain-enameled
racks no longer require hand cleaning
• 12"/9"/6" Tri-Ring Element - Accommodates various-sized pots or pans
for the ultimate in cooking versatility
• Bridge Element - Combines three cooktop elements into one large cooking
area, it is ideal for oversized cooking pans
• Warming Zone - Provides low heat capability for foods, making meal
coordination simple
• QuickSet V Oven Controls - Feature an easy to use design that allows
you to set precise cooking temperatures
• Model JBP84DMBB – Black on black (black glass door and black patterned cooktop)
JBP84TM/DM
WARMINGZONE
MED
SMALL
BURNER
LARGE
BURNER
FRONT
BURNER
BRIDGE
BURNER
Specification Created 4/07 321577
JBP84DM
GE®30" Free-Standing Electric Convection Range
