JBS27SH – GE® 30" Free-Standing Electric Range
Dimensions (in inches) For all 30" Free-Standing Range
models with coil heating elements
26-1/4*
46-1/4
29-7/8
46-7/8
CENTER LINE
2-1/4
7-1/2
7-1/2
7
5
2-1/4
3-1/2
REAR
WALL
1/4†
†Note: Check local codes for required breaker size.
Effective January 1, 1996, the National Electrical Code requires that new
construction (not existing) utilize a 4-conductor connection to an electric range.
Receptacle Locations
Locally approved flexible service cord or conduit must be used because
terminals are not accessible after range installation. See shaded area in
drawing for location of electrical outlet box. Recommended outlet locations
allow range to be installed directly against wall.
Note: 30" Ranges conform to U.L. requirements for 0" spacing for adjacent
walls below countertops. Allow 1-1/2" spacing from the side of the range
to adjacent vertical walls above the cooktop surface.
Installation Information: Before installing, consult installation instructions
packed with product for current dimensional data.
26-1/4*
46-1/4
29-7/8
46-1/2
CENTER LINE
2-1/4
7-1/2
7-1/2
7
5
2-1/4
3-1/2
REAR
WALL
1/4†
R
Listed by
Underwriters
Laboratories
* Dimension from wall to front of closed oven door
without handle.
† The range may be placed with a 0" clearance (flush) at
the back wall and side walls if the range side trims
extend beyond the cabinet fronts at least 1/4".
Self Clean models only. All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
For answers to your Monogram,
® GE Profile™ or
GE® appliance questions, visit our website at
GEAppliance.com or call
GE Answer Center® service, 800.626.2000.
Specification Revised 11/05
321685
KW Rating
240V 12.6
208V 9.9
Breaker Size
40 Amps†

Specification Revised 11/05
321685
GE Appliances
JBS27SH – GE® 30" Free-Standing Electric Range
JBS27SHSS.EPS
CLOCK
SET
TIMER
ON
OFF
Features and Benefits
• Super-Large Oven Capacity – Provides an impressively large oven interior for cooking
more dishes and large meals at one time.
• Coil Heating Elements – Provides consistent and even heat on the cooktop with a plug-in
element that is removable for easy cleaning.
• ClearView™ Window – Features a convenient viewing area to check the progress of food.
• Dual Element Bake – Alternates the upper broiling element and the lower baking element
for even heating and optimal baking results.
• Electronic Clock and Timer – Features a convenient digital clock and easy-to-use timer
with an audible signal to help coordinate cooking times in the kitchen.
• Frameless Glass Oven Door – Offers an easy-to-clean and stylish design that blends
seamlessly into existing cabinetry.
• Drip Bowls – Contains minor spills and are removable for easy cleaning.
• Model JBS27WHWW – White on white (white door and white cooktop)
• Model JBS27CHCC – Bisque on bisque (bisque door and bisque cooktop)
• Model JBS27BHBB – Black on black (black door and black cooktop)
• Model JBS27SHSS – Stainless steel (stainless steel door and control panel/
black cooktop)
