GE JCBP40 User manual

Safety Instructions . . . . . . . . . . . . . .2–5
Operating Instructions
Clock, Timer and
Convenience Outlet . . . . . . . . . . . . . .11
Convection Oven . . . . . . . . . . . . .12–14
Timed Features . . . . . . . . . . . . . . . .14
Cookware . . . . . . . . . . . . . . . . . . . . . . . .6
Oven . . . . . . . . . . . . . . . . . . . . . . . . . .8–9
Broiling Guide . . . . . . . . . . . . . . . . . .9
Oven Controls . . . . . . . . . . . . . . . . . . . .7
Proofing Feature . . . . . . . . . . . . . . . . .16
Sabbath Feature . . . . . . . . . . . . . .21, 22
Self-Cleaning . . . . . . . . . . . . . . . . .17, 18
Special Features . . . . . . . . . . . . . .19, 20
Surface Units . . . . . . . . . . . . . . . . . . . . 6
Temperature Conversions . . . . . . . . . 7
Thermostat Adjustment—
Do It Yourself . . . . . . . . . . . . . . . . . . . .15
Timed Baking and
Roasting Features . . . . . . . . . . . . . . . .10
Care and Cleaning . . . . . . . . . . 23–27
Troubleshooting Tips . . . . . . . . 28–31
Accessories . . . . . . . . . . . . . . . . . . . . . 32
Consumer Support
Consumer Support . . . . . . . . . . . . . . 36
Product Registration . . . . . . . . . . 33, 34
Warranty . . . . . . . . . . . . . . . . . . . . . . . 35
www.GEAppliances.ca
JCBP40
183D6379P052 29-5652 10-08 JR
Write the model and serial
numbers here:
Model # ______________
Serial # ______________
You can find them on a label
behind the storage drawer
on the range frame.
Ranges
Self-Cleaning Convection
Owner’s Manual
Printed in Mexico

IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!
For your safety, the information in this manual must be followed to minimize the risk of fire, electric
shock, or to prevent property damage, personal injury, or loss of life.
When using electrical appliances, basic safety precautions should be followed, including the following:
■Use this appliance only for its intended
purpose as described in this Owner’s Manual.
■Be sure your appliance is properly installed and
grounded by a qualified installer in accordance
with the provided installation instructions.
■Have the installer show you the location of
the circuit breaker or fuse. Mark it for easy
reference.
■Do not attempt to repair or replace any
part of your range unless it is specifically
recommended in this manual. All other
servicing should be referred to a qualified
technician.
■Before performing any service, disconnect
the range power supply at the household
distribution panel by removing the fuse or
switching off the circuit breaker.
■Do not leave children alone—children should
not be left alone or unattended in an area
where an appliance is in use. They should
never be allowed to sit or stand on any part
of the appliance.
■Do not allow anyone to climb, stand or hang
on the door, storage drawer or cooktop. They
could damage the range and even tip it over,
causing severe personal injury.
SAFETY PRECAUTIONS
2
Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions
To reduce the risk of tipping the range, the range must be
secured by a properly installed anti-tip bracket. See
installation instructions shipped with the bracket for complete
details before attempting to install.
To check if the bracket is installed and engaged properly,
remove the storage drawer or kick panel and look underneath
the range to see that the leveling leg is engaged in the bracket.
On models without a storage drawer or kick panel, carefully tip
the range forward. The bracket should stop the range within
4 inches. If it does not, the bracket must be reinstalled. If the
range is pulled from the wall for any reason, always repeat
this procedure to verify the range is properly secured by the
anti-tip bracket.
Never completely remove the leveling legs or the range will
not be secured to the anti-tip device properly.
If you did not receive an anti-tip bracket with your
purchase, call 1.800.561.3344 to receive one at no
cost. For installation instructions of the bracket, visit
GEAppliances.ca.
ANTI-TIP DEVICE

www.GEAppliances.ca
Cook meat and poultry thoroughly—meat to at least an INTERNAL temperature of 70°C (160°F) and poultry
to at least an INTERNAL temperature of 80°C (180°F). Cooking to these temperatures usually protects against
foodborne illness.
COOK MEAT AND POULTRY THOROUGHLY…
Safety Instructions Operating InstructionsSafety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support
3
Do not operate the oven or cooktop controls if the glass is broken. Food splatter or cleaning solution
may penetrate a broken control panel and create a risk of electrical shock. Contact a qualified
technician immediately should your glass control panel become broken.
■Do not store flammable materials in an oven
or near the cooktop.
CAUTION: Items of interest to children
should not be stored in cabinets above a range or on
the back of a range—children climbing on the range
to reach items could be seriously injured.
■Never wear loose-fitting or hanging garments
while using the appliance. Be careful when
reaching for items stored over the range.
Flammable material could be ignited if
brought in contact with hot surface units or
heating elements and may cause severe burns.
■Use only dry pot holders—moist or damp
pot holders on hot surfaces may result in
burns from steam. Do not let pot holders
touch hot surface units or heating elements.
Do not use a towel or other bulky cloth in
place of pot holders.
■Do not use water on grease fires. Never pick
up a flaming pan. Turn the controls off.
Smother a flaming pan on a surface unit
by covering the pan completely with
a well-fitting lid, cookie sheet or flat tray.
Use a multi-purpose dry chemical or
foam-type fire extinguisher.
Flaming grease outside a pan can be put
out by covering it with baking soda or, if
available, by using a multi-purpose dry
chemical or foam-type fire extinguisher.
Flame in the oven can be smothered
completely by closing the oven door and
turning the oven off or by using a multi-
purpose dry chemical or foam-type fire
extinguisher.
■For your safety, never use your appliance
for warming or heating the room.
■Do not let cooking grease or other flammable
materials accumulate in or near the range.
■Do not touch the surface units, the heating
elements or the interior surface of the oven.
These surfaces may be hot enough to burn
even though they are dark in color. During and
after use, do not touch, or let clothing or other
flammable materials contact the surface units,
areas nearby the surface units or any interior
area of the oven; allow sufficient time for
cooling first.
Potentially hot surfaces include the cooktop,
areas facing the cooktop, oven vent opening,
surfaces near the opening, crevices around the
oven door.
REMEMBER: The inside surface of the oven may be
hot when the door is opened.
■Do not store or use combustible materials,
gasoline or other flammable vapors and liquids
in the vicinity of this or any other appliance.
■Keep the hood and grease filters clean
to maintain good venting and to avoid
grease fires.
■Teach children not to play with the controls
or any other part of the range.
■Always keep dish towels, dish cloths, pot
holders and other linens a safe distance
from your range.
■Always keep wooden and plastic utensils and
canned food a safe distance from your range.
■Always keep combustible wall coverings,
curtains or drapes a safe distance from
your range.
■Large scratches or impacts to glass doors can
lead to broken or shattered glass.
SAFETY PRECAUTIONS

4
Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions
■Never leave the surface units unattended
at high heat settings. Boilovers cause smoking
and greasy spillovers that may catch on fire.
■Do not use aluminum foil to line the drip pans
or anywhere in the oven except as described in
this manual. Misuse could result in a shock, fire
hazard or damage to the range.
■Be sure the drip pans and the vent duct are not
covered and are in place. Their absence during
cooking could damage range parts and wiring.
■Only certain types of glass, glass ⁄ceramic,
earthenware or other glazed containers are
suitable for cooktop service; others may break
because of the sudden change in temperature.
■To minimize the possibility of burns, ignition of
flammable materials and spillage, the handle of
a container should be turned toward the center
of the range without extending over nearby
surface units.
■Always turn the surface units off before
removing cookware.
■Do not immerse or soak the removable surface
units. Do not put them in a dishwasher. Do not
self-clean the surface units in the oven.
■Do not flame foods on the cooktop. If you do
flame foods under the hood, turn the fan on.
■To avoid the possibility of a burn or electric
shock, always be certain that the controls for all
surface units are at the
OFF position and all
coils are cool before attempting to lift or
remove a unit.
■Clean the cooktop with caution. If a wet sponge
is used to wipe spills on a hot cooktop, be
careful to avoid steam burns.
■Keep an eye on foods being fried at high or
medium high heat settings.
■Foods for frying should be as dry as possible.
Frost on frozen foods or moisture on fresh
foods can cause hot fat to bubble up and
over the sides of the pan.
■Use little fat for effective shallow or deep fat
frying. Filling the pan too full of fat can cause
spillovers when food is added.
■If a combination of oils or fats will be used in
frying, stir together before heating, or as fats
melt slowly.
■Always heat fat slowly, and watch as it heats.
■Use a deep fat thermometer whenever possible
to prevent overheating fat beyond the smoking
point.
■The surface units are automatically disabled
during the self-clean cycle. Make sure that all
surface unit controls are turned off at all times
during the self-clean cycle. Any surface unit
that is set to an on position, while the self-clean
cycle is operating, will automatically come on
after the self-clean cycle is finished, and could
result in an on, unattended surface unit. Wait
until the self-clean cycle is finished to set and
use the surface units.
Use proper pan size—select cookware having flat bottoms large enough to cover the surface unit heating
element. The use of undersized cookware will expose a portion of the surface unit to direct contact and may
result in ignition of clothing. Proper relationship of cookware to surface unit will also improve efficiency.
SURFACE COOKING UNITS
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!

SAVE THESE INSTRUCTIONS
Safety Instructions Operating InstructionsSafety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support
5
www.GEAppliances.ca
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.
Do not use oven cleaners. No commercial oven cleaner or oven liner protective coating of any kind
should be used in or around any part of the oven. Residue from oven cleaners will damage the inside
of the oven when the self-clean cycle is used.
CAUTION: DO NOT LEAVE FOOD OR
COOKING UTENSILS, ETC. IN THE OVEN OR ON
THE COOKTOP DURING SELF-CLEANING MODE
OF OPERATION.
■Do not clean the door gasket. The door gasket
is essential for a good seal. Care should be
taken not to rub, damage or move the gasket.
■Before self-cleaning the oven, remove shiny,
silver-colored oven racks (on some models)
and all other cookware.
■Be sure to wipe up excess spillage before
starting the self-cleaning operation.
■If the self-cleaning mode malfunctions, turn
the oven off and disconnect the power supply.
Have it serviced by a qualified technician.
■Clean only parts listed in this Owner’s Manual.
■The surface units are automatically disabled
during the self-clean cycle. Make sure that all
surface unit controls are turned off at all times
during the self-clean cycle. Any surface unit
that is set to an on position, while the self-clean
cycle is operating, will automatically come on
after the self-clean cycle is finished, and could
result in an on, unattended surface unit. Wait
until the self-clean cycle is finished to set and
use the surface units.
■Gray porcelain-coated oven racks may be
cleaned in the oven during the self-clean cycle.
SELF-CLEANING OVEN
Stand away from the range when opening the oven door. Hot air or steam which escapes can cause
burns to hands, face and/or eyes.
■Do not heat unopened food containers.
Pressure could build up and the container
could burst, causing an injury.
■Keep the oven vent unobstructed.
■Keep the oven free from grease buildup.
■Place the oven rack in the desired position
while the oven is cool. If racks must be handled
when hot, do not let pot holder contact the
heating elements.
■When using cooking or roasting bags in the
oven, follow the manufacturer’s directions.
■Pulling out the rack to the stop-lock is a
convenience in lifting heavy foods. It is also
a precaution against burns from touching
hot surfaces of the door or oven walls.
■Do not use the oven to dry newspapers.
If overheated, they can catch on fire.
■Do not use the oven for a storage area. Items
stored in an oven can ignite.
■Do not leave paper products, cooking utensils
or food in the oven when not in use.
■Do not use aluminum foil to line oven
bottoms. Improper installation of aluminum
foil may result in a risk of electric shock or fire.
OVEN

6
Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions
Be sure you turn the control knob to
OFF when you finish cooking.
Using the surface units.
How to Set
Push the knob in and turn in either
direction to the setting you want.
At both OFF and MAX the control clicks
into position. You may hear slight clicking
sounds during cooking, indicating the
control is keeping the power level you set.
A surface unit ON indicator light will glow
when any surface unit is on,
WARNING: The surface
units are automatically disabled during
the self-clean cycle. Make sure that all
surface unit controls are turned off at all
times during the self-clean cycle. Any
surface unit that is set to an on position,
while the self-clean cycle is operating, will
automatically come on after the self-clean
cycle is finished, and could result in an
on, unattended surface unit. Wait until
the self-clean cycle is finished to set and
use the surface units.
Surface Cookware Tips
Use medium- or heavy-weight cookware.
Aluminum cookware conducts heat faster
than other metals. Cast-iron and coated
cast-iron cookware are slow to absorb
heat, but generally cook evenly at low to
medium heat settings. Steel pans may
cook unevenly if not combined with
other metals.
For best cooking results, pans should be
flat on the bottom. Match the size of the
saucepan to the size of the surface unit.
The pan should not extend over the
edge of the surface unit more than 1″.
Not over 1 inch.
1″
Home Canning Tips
Be sure the canner is centered over the
surface unit.
Make sure the canner is flat on the
bottom.
Use recipes and procedures from
reputable sources. These are available
from manufacturers such as Ball®and
Kerr®and the Department of Agriculture
Extension Service.
To prevent burns from steam or heat, use
caution when canning.
Use only flat-bottomed woks.
Wok Cooking
We recommend that you use only a flat-bottomed
wok. They are available at your local retail store.
Do not use woks that have support rings.
Placing the ring over the surface unit will
cause a buildup of heat that will damage
the porcelain cooktop.
Do not use round bottom woks. You
could be seriously burned if the wok
tipped over.
The WARM setting (on some models)
in the right REAR surface unit keeps
already heated food warm until
ready to serve.

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support
Using the oven controls.
NOTE: Throughout this manual, features and appearance may vary from your model. www.GEAppliances.ca
7
Fahrenheit° 140 150 170 200 250 275 300 325 350 375 400 425 450 475 500 525 550
Celsius° 60 65 75 95 120 135 150 160 175 190 205 220 230 245 260 275 290
Temperature Conversions
BAKE Pad
Touch to select the bake function.
BROIL Pad
Touch to select the broil function.
CONVECTION BAKE Pad
Touch to select baking with the convection
function.
CONVECTION ROAST Pad
Touch to select roasting with the
convection function.
START Pad
Must be touched to start any cooking or
cleaning function.
Display
Shows the time of day, oven temperature,
whether the oven is in the bake, broil or
self-cleaning mode and the times set for
the timer or automatic oven operations.
If “F– and a number or letter” flash in the display and
the oven control signals, this indicates a function
error code. Touch the OFF pad. Allow the oven to cool for
one hour. Put the oven back into operation. If the function
error code repeats, disconnect the power to the oven and
call for service.
If your oven was set for a timed oven operation
and a power outage occurred, the clock and all
programmed functions must be reset.
The time of day will flash in the display when there
has been a power outage.
CLEAN Pad
Touch to select self-cleaning function.
See the Using the self-cleaning oven section.
LIGHT Pad
Touch to turn the oven light on or off.
START TIME Pad
Use along with COOK TIME or CLEAN
pads to set the oven to start and stop
automatically at a time you set.
COOK TIME Pad
Touch and then touch the number pads to
set the amount of time you want your food
to cook. The oven will shut off when the
cooking time has run out.
OFF Pad
Touch to cancel ALL oven operations
except the clock and timer.
CLOCK Pad
Touch before setting the clock.
Number Pads
Use to set any function requiring numbers
such as the time of day on the clock, the
timer, the oven temperature, the internal
food temperature, the start time and
length of operation for timed baking
and self-cleaning.
TIMER Pad
Touch to select the timer feature.
PROOF Pad
Touch to select a warm environment useful
for rising yeast-leavened products.
Oven Control, Clock and Timer Features and Settings
Features and appearance
may vary.
1234 5
6 7 8 9 0
OVEN LOCKOUT
VERROUILLAGE FOUR
CONVECTION
BAKE
CUIRE
ROAST
RÔTIR
BAKE
CUIRE
BROIL
GRIL
CLEAN
NETTOYAGE
TIMER
MINUTERIE
CLOCK
HORLOGE
START TIME
HEURE DE
DÉPART
COOK TIME
TEMPS DE
CUISSON
START
DÉPART
START
DÉPART
PROOF
FERMENTATION
OFF
ARRÊT

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions
8
The oven has 6 rack positions.
Using the oven.
To avoid possible burns, place the racks in the desired position before you turn the oven on.
Before you begin…
The racks have stops, so that when placed
correctly on the supports, they will stop
before coming completely out, and will
not tilt.
When placing and removing cookware,
pull the rack out until it stops.
On some models, the bake heating
element is under the oven floor. Do not
place foods on the oven bottom for
cooking.
To remove a rack, pull it toward you,
tilt the front end up and pull it out.
To replace, place the end of the rack
(stop-locks) on the support, tilt up the
front and push the rack in.
CAUTION: When you are using a
rack in the lowest position (A), you will need to
use caution when pulling the rack out. We
recommend that you pull the rack out several
inches and then, using two pot holders, pull the
rack out by holding the sides of it. The rack is low
and you could be burned if you place your hand in
the middle of the rack and pull all the way out. Be
very careful not to burn your hand on the door
when using the rack in the lowest position (A).
How to Set the Oven for Baking or Roasting
Touch the BAKE pad.
Touch the number pads to set
the desired temperature.
Touch the START pad.
Check food for doneness at
minimum time on recipe. Cook
longer if necessary.
Touch the OFF pad when cooking is
complete.
Preheating and Pan Placement
Preheat the oven if the recipe calls for it.
Preheating is necessary for good results
when baking cakes, cookies, pastry and
breads.
To preheat, set the oven at the correct
temperature. The control will beep when
the oven is preheated and the display will
show your set temperature.
Baking results will be better if baking
pans are centered in the oven as much
as possible. If baking with more than one
pan, place the pans so each has at least
2.5 cm to 3.8 cm (1″ to 11⁄2″) of air space
around it.
If baking four cake layers at the same time,
place two layers on rack B and two layers on
rack D. Stagger pans on the rack so one is
not directly above the other.
Type of Food Rack Position
Frozen pies (on cookie sheet) D
Angel food cake A
Bundt or pound cakes B or C
Biscuits, muffins, brownies, C or D
cookies, cupcakes,
layer cakes, pies
Casseroles C or D
Turkey A
Do not place foods directly on the oven floor.
Aluminum Foil
Do not use aluminum foil on the bottom
of the oven.
Never entirely cover a rack with
aluminum foil. This will disturb the heat
circulation and result in poor baking.
A smaller sheet of foil may be used to
catch a spillover by placing it on a lower
rack several inches below the food.

If your range is connected to 208 volts,
rare steaks may be broiled by preheating
the broiler and positioning the oven rack
one position higher.
Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support
9
www.GEAppliances.ca
How to Set the Oven for Broiling
Leave the door open to the broil stop position.
The door stays open by itself, yet the proper
temperature is maintained in the oven.
Place the meat or fish on a broiler
grid in a broiler pan designed
for broiling.
Follow suggested rack positions in
the Broiling Guide.
Touch the BROIL pad once for
HI Broil.
To change to LO Broil, touch the
BROIL pad again.
Use LO Broil to cook foods such as
poultry or thick cuts of meat thoroughly
without over-browning them.
Touch the
START pad.
When broiling is finished, touch the
OFF pad.
The size, weight, thickness,
starting temperature
and your preference
of doneness will affect
broiling times. This guide
is based on meats at
refrigerator temperature.
†The U.S. Department of Agriculture
says “Rare beef is popular, but you
should know that cooking it to only
60°C (140°F) means some food
poisoning organisms may survive.”
(Source: Safe Food Book. Your Kitchen
Guide. USDA Rev. June 1985.)
The oven has 6 rack positions.
Quantity and/ Rack* First Side Second Side
Food or Thickness Position Time (min.) Time (min.) Comments
Ground Beef 454 g (1 lb.) (4 patties) C 10 7–10 Space evenly.
1.25 to 1.9 cm (1⁄2to 3⁄4″) thick
1.8 kg (4 lbs.) (16 patties) C 15 11
Beef Steaks
Rare† 1.9 to 2.5 cm (3⁄4to 1″) thick E 6 4 Steaks less than 1.9 cm
Medium 454 to 680 g (1 to 1 1⁄2lbs.) D 8 6 3⁄4″ thick are difficult
Well Done D 10 7–10 to cook rare.
Slash fat.
Rare† 3.8 cm (1 1⁄2″) thick C 10 8
Medium 900 g to 1.14 kg (2 to 2 1⁄2lbs.) C 15 10–12
Well Done D 20 20
Chicken 1 whole cut up B 25 25 Brush each side with
900 g to 1.14 kg (2 to 2 1⁄2lbs.), melted butter.
split lengthwise Broil skin-side-down
Breast B 25 15 first.
Bakery Product
Bread (toast) 2 to 4 slices D 3 1 Space evenly. Place
English Muffin 2 (split) E 3-4 English muffins cut-
side-up and brush
with butter if desired.
Lobster Tails 2–4 B 18–20 Do not Cut through back of
turn shell. Spread open.
over. Brush with melted
butter before broiling
and after half of
broiling time.
Fish Fillets 454 g (1 lb.) (0.6 to 1.25 cm D 5 5 Handle and turn very
[1⁄4to 1⁄2″] thick) carefully. Brush with
lemon butter before
and during cooking,
if desired.
Salmon
Steaks 2 (2.5 cm [1″] thick) D 10 5 Turn carefully. Do not
Fillets 2 (1.25 to 1.9 cm [1⁄2to 3⁄4″] thick) D 10 turn skin side down.
Ham Slices 1.25 cm (1⁄2″) thick C 6 6
(precooked) 2.5 cm (1″) thick C 8 8
Pork Chops 2 (1.25 cm [1⁄2″] thick) C 10 10 Slash fat.
Well Done 2 (2.5 cm [1″] thick) about 454 g (1 lb.) C15 15
Lamb Chops
Medium 2 (2.5 cm [1″] thick) D 7 4 Slash fat.
Well Done about 312 to 375 g (10 to 12 oz). D10 9
Medium 2 (3.8 cm [11⁄2″] thick) D 9 6
Well Done about 454 g (1 lb.) D 14 10
Broiling Guide
*See illustration for description of rack positions.

10
Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions
Using the timed baking and roasting features.
NOTE: Foods that spoil easily—such as milk, eggs, fish, stuffings, poultry and pork—should not be allowed to sit for
more than 1 hour before or after cooking. Room temperature promotes the growth of harmful bacteria. Be sure that
the oven light is off because heat from the bulb will speed harmful bacteria growth.
How to Set an Immediate Start and Automatic Stop
The oven will turn on immediately and cook for
a selected length of time. At the end of the
cooking time the oven will turn off automatically.
Touch the BAKE pad.
Touch the number pads to set the
desired oven temperature.
Touch the COOK TIME pad.
NOTE: If your recipe requires preheating, you may
need to add additional time to the length of the
cooking time.
Touch the number pads to set the
desired length of cooking time. The
minimum cooking time you can set
is 1 minute.
The oven temperature that you set
and the cooking time that you
entered will be in the display.
Touch the START pad.
NOTE: An attention tone will sound if you are using
timed baking and do not touch the START pad.
The oven will turn ON , and the display will
show the cooking time countdown and the
changing temperature starting at 37.8°C
(100°F). (The temperature display will
start to change once the oven temperature
reaches 37.8°C [100°F].) When the oven
reaches the temperature you set, 3 beeps
will sound.
The oven will continue to cook for
the set amount of time, then turn off
automatically.
Touch the
OFF pad to clear the
display if necessary. Remove the
food from the oven. Remember,
even though the oven turns off
automatically, food left in the oven
will continue cooking after the
oven turns off.
How to Set a Delayed Start and Automatic Stop
The oven will turn on at the time of day you set,
cook for a specific length of time and then turn off
automatically.
Make sure the clock shows the correct
time of day.
Touch the BAKE pad.
Touch the number pads to set the
desired oven temperature.
Touch the
COOK TIME pad.
NOTE: If your recipe requires preheating, you may
need to add additional time to the length of the
cooking time.
Touch the number pads to set the
desired length of cooking time. The
minimum cooking time you can set
is 1 minute.
The oven temperature that you set
and the cooking time that you
entered will be in the display.
Touch the START TIME pad.
Touch the number pads to set the
time of day you want the oven to
turn on and start cooking.
Touch the
START pad.
NOTE: An attention tone will sound if you are using
timed baking and do not touch the START pad.
NOTE: If you would like to check the times you
have set, touch the START TIME pad to check
the start time you have set or touch the COOK
TIME pad to check the length of cooking time
you have set.
When the oven turns ON at the time
of day you set, the display will show
the cooking time countdown and the
changing temperature starting at 37.8°C
(100°F). (The temperature display will
start to change once the oven
temperature reaches 37.8°C [100°F].)
When the oven reaches the temperature
you set, beeps will sound.
The oven will continue to cook for
the set amount of time, then turn off
automatically.
Touch the OFF pad to clear the
display if necessary. Remove the
food from the oven. Remember,
even though the oven turns off
automatically, food left in the oven
will continue cooking after the
oven turns off.

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support
11
Make sure the clock is set to the
correct time of day.
The Timer is a minute timer only.
The Timer does not control oven
operations. The maximum setting on
the Timer is 9 hours and 59 minutes.
Using the clock, timer and convenience outlet. www.GEAppliances.ca
To Set the Clock
The clock must be set to the correct time
of day for the automatic oven timing
functions to work properly. The time of
day cannot be changed during a timed
baking or self-cleaning cycle.
Touch the
CLOCK pad.
Touch the number pads.
Touch the
START pad.
To Set the Timer
Touch the TIMER pad.
Touch the number pads until the
amount of time you want shows
in the display. For example, to set
2 hours and 45 minutes, touch
2,4
and 5 in that order. If you make a
mistake touch the
TIMER pad and
begin again.
Touch the START pad.
After touching the START pad, SET disappears;
this tells you the time is counting down, although
the display does not change until one minute has
passed. Seconds will not be shown in the display
until the last minute is counting down.
When the Timer reaches :00 , the
control will beep 3 times followed
by one beep every 6 seconds until
the TIMER pad is touched.
The 6-second tone can be canceled by following
the steps in the Special features of your oven
control section under Tones at the End of a
Timed Cycle.
To Reset the Timer
If the display is still showing the time
remaining, you may change it by
touching the TIMER pad, then touch
the number pads until the time you
want appears in the display.
If the remaining time is not in the display
(clock, delay start or cooking time are in
the display), recall the remaining time
by touching the TIMER pad and then
touching the number pads to enter
the new time you want.
To Cancel the Timer
Touch the TIMER pad twice.
Convenience Outlet (on some models)
The 120V convenience outlet located on
the top of the backguard may be used to
plug in small electrical appliances.
When using the outlet, be sure that the
electrical cord does not rest on or near a
surface unit. If the surface unit is turned
on, the cord will be damaged.
To reset the circuit breaker, press the
switch located near the outlet on top of
the backguard.

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions
12
The convection oven fan shuts off when the oven door is opened. DO NOT leave the door open for long periods of
time while using convection cooking or you may shorten the life of the convection heating element.
Adapting Recipes…
You can use your favorite recipes in
the convection oven.
When baking, reduce baking
temperature by 14°C (25°F), or use
the Convection Conversion feature.
No need to preheat when cooking
longer than 15 minutes.
■
Use pan size recommended.
■ Some package instructions for frozen
casseroles or main dishes have been
developed using commercial convection ovens.
For best results in this oven, preheat the oven
and use the temperature on the package.
To help you understand the difference
between convection bake and roast and
traditional bake and roast, here are some
general guidelines.
Convection Bake
■ Ideal for evenly browned baked foods cooked
on multiple racks.
■ Good for large quantities of baked foods.
■ Good results with cookies, biscuits, brownies,
cupcakes, cream puffs, sweet rolls, angel food
cake and bread.
Heat comes from the heating element in
the rear of the oven. The convection fan
circulates the heated air evenly over and
around the food. Preheating is not
necessary with foods having a bake time
of over 15 minutes.
Convection Roast
■ Good for large tender cuts of meat, uncovered.
Heat comes from the top heating
element. The convection fan circulates
the heated air evenly over and around
the food. Meat and poultry are browned
on all sides as if they were cooked on a
rotisserie. The heated air seals in juices
quickly for a moist and tender product
while, at the same time, creating a rich
golden brown exterior.
When you are convection roasting, it is
important that you use a broiler pan and
grid designed for broiling for best
convection roasting results. The pan is
used to catch grease spills and the grid is
used to prevent grease spatters.
In a convection oven, a fan
circulates hot air over, under and
around the food. This circulating
hot air is evenly distributed
throughout the oven cavity. As a
result, foods are evenly cooked and
browned–often in less time than
with regular heat.
Using the convection oven.

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support
13
Cookware for Convection Cooking
Before using your convection oven, check
to see if your cookware leaves room for air
circulation in the oven. If you are baking
with several pans, leave space between
them. Also, be sure the pans do not touch
each other or the walls of the oven.
Paper and Plastic
Heat-resistant paper and plastic
containers that are recommended
for use in regular ovens can be used in
convection ovens. Plastic cookware that
is heat-resistant to temperatures of
205°C (400°F). can also be used, when
oven is below 205°C (400°F).
Metal and Glass
Any type of cookware will work in your
convection oven. However, metal pans
heat the fastest and are recommended
for convection baking.
■
Darkened or matte-finished pans will bake
faster than shiny pans.
■ Glass or ceramic pans cook more slowly.
When baking cookies, you will get the
best results if you use a flat cookie sheet
instead of a pan with low sides.
For recipes like oven-baked chicken,
use a pan with low sides. Hot air cannot
circulate well around food in a pan with
high sides.
How to Set the Oven for Convection Baking or Roasting
OR
Multi-Rack Baking
Because heated air is circulated evenly
throughout the oven, foods can be
baked with excellent results using
multiple racks.
Multi-rack baking may increase cook
times slightly for some foods but the
overall result is time saved. Cookies,
muffins, biscuits and other quick
breads give very good results with
multi-rack baking.
When baking on 3 racks, place one
rack in the 2nd (B) position, one on the
4th (D) position and one rack in the 6th
(F) position.
When convection baking with only
1 rack, follow the rack positions
recommended in the Using the
oven section.
Touch the CONVECTION BAKE or
CONVECTION ROAST pad.
Touch the number pads to set the
desired oven temperature.
Touch the START pad.
To change the oven temperature, touch
the CONVECTION BAKE or CONVECTION
ROAST pad and then the number pads
to set the new temperature.
When the oven starts to heat, the
changing temperature, starting at 37.8°C
(100°F), will be displayed. When the
oven reaches the temperature you set,
3 beeps will sound.
Touch the
OFF pad when finished.
NOTE: You will hear a fan while cooking with
convection. The fan will stop when the door is
opened but the heat will not turn off.
www.GEAppliances.ca

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions
Using the timed features for convection baking.
You will hear a fan while cooking with this feature. The fan will stop when the door is opened but the heat will
not turn off.
NOTE: Foods that spoil easily—such as milk, eggs, fish, stuffings, poultry and pork—should not be allowed to sit for
more than 1 hour before or after cooking. Room temperature promotes the growth of harmful bacteria. Be sure that
the oven light is off because heat from the bulb will speed harmful bacteria growth.
How to Set an Immediate Start and Automatic Stop
The oven will turn on immediately and cook for a
selected length of time. At the end of the cooking
time the oven will turn off automatically.
Touch the CONVECTION BAKE or
CONVECTION ROAST pad.
Touch the number pads to set the
desired oven temperature.
Touch the COOK TIME pad.
NOTE: If your recipe requires preheating, you
may need to add additional time to the length
of the cooking time.
Touch the number pads to set the
desired length of cooking time. The
minimum cooking time you can set
is 1 minute.
The oven temperature that you set and
the cooking time that you entered will be
in the display.
Touch the
START pad.
The display shows the oven temperature
that you set and the cooking time
countdown. The display starts changing
once the temperature reaches 37.8°C
(100°F).
At the end of timed convection bake
the oven will turn off. The end of
cycle tone will sound. Touch the OFF
pad to clear the display if necessary.
Remove the food from the oven.
Remember, foods that are left in
the oven continue cooking after
the controls are off.
OR
OR
How to Set a Delayed Start and Automatic Stop
You can set the oven control to delay-start the
oven, cook for a specific length of time and then
turn off automatically.
Make sure the clock shows the correct
time of day.
Touch the CONVECTION BAKE or
CONVECTION ROAST pad once
( CONV BAKE is displayed).
Touch the number pads to set the
desired oven temperature.
Touch the COOK TIME pad.
NOTE: If your recipe requires preheating, you
may need to add additional time to the length of
the cooking time.
Touch the number pads to set the
desired cooking time.
Touch the START TIME pad.
Touch the number pads to set the
time of day you want the oven to
turn on and start cooking.
Touch the
START pad.
NOTE: An attention tone will sound if you are
using timed baking and do not touch the START
pad after entering the baking temperature.
When the oven turns on at the time of
day you have set, the display will show the
changing temperature (starting at 37.8°C
[100°F]) and the cooking time
countdown.
At the end of timed convection bake, the
oven will turn off. The end of cycle tone
will sound.
Touch the
OFF pad to clear the
display if necessary. When baking is
finished, remove the food from the
oven. Remember, even though the
oven shuts off automatically, foods
continue cooking after the controls
are off.
14

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support
15
+
Adjust the oven thermostat—Do it yourself! www.GEAppliances.ca
You may find that your new oven cooks differently than the one it replaced. Use your new oven for a few weeks to
become more familiar with it. If you still think your new oven is too hot or too cold, you can adjust the thermostat
yourself.
Do not use thermometers, such as those found in grocery stores, to check the temperature setting of your oven.
These thermometers may vary 6–11 degrees Celsius (20–40 degrees Fahrenheit).
NOTE: This adjustment will only affect baking and roasting temperatures; it will not affect broiling or
self-cleaning temperatures. The adjustment will be retained in memory after a power failure.
To Adjust the Thermostat
Touch the BROIL and BAKE pads at
the same time for 3 seconds until
the display shows SF.
Touch the BAKE pad. A two digit
number shows in the display.
Touch BAKE again to alternate
between increasing and decreasing
the oven temperature.
The oven temperature can be
adjusted up to (+) 19°C (35ºF)
hotter or (-) 19°C (35ºF) cooler.
Touch the number pads the same
way you read them. For example, to
change the oven temperature 12°C
(15ºF), touch
1 and 5 .
When you have made the
adjustment, touch the START pad to
go back to the time of day display.
Use your oven as you would normally.
The type of margarine will affect baking performance!
Most recipes for baking have been developed using high fat products such as butter or margarine (80% fat).
If you decrease the fat, the recipe may not give the same results as with a higher fat product.
Recipe failure can result if cakes, pies, pastries, cookies or candies are made with low fat spreads. The lower the
fat content of a spread product, the more noticeable these differences become.
Federal standards require products labeled “margarine” to contain at least 80% fat by weight. Low fat spreads, on the
other hand, contain less fat and more water. The high moisture content of these spreads affects the texture and flavor
of baked goods. For best results with your old favorite recipes, use margarine, butter or stick spreads containing at least
70% vegetable oil.

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions
16
START
DÉPART
START
DÉPART
TIMER
MINUTERIE
PROOF
FERMENTATION
OFF
ARRÊT
Using the proofing feature.
The proofing feature maintains a warm environment useful for rising yeast-leavened products.
How to Set the Oven For Proofing (on some models)
Place the covered dough in a dish
in the oven on rack B or C.
NOTE: For best results, cover the dough with a
cloth or with greased plastic wrap (the plastic
may need to be anchored underneath the
container so the oven fan will not blow it off).
Touch the PROOF pad and then
the START pad.
The display will read PrF (proof).
The oven interior light turns on and
remains on during proofing.
The proofing feature automatically
provides the optimum temperature for
the proofing process, and therefore
does not have a temperature adjustment.
Set the
TIMER for the minimum
proof time.
When proofing is finished, touch
the OFF pad.
■
To avoid lowering the oven temperature and
lengthening proofing time, do not open the
oven door unnecessarily.
■ Check bread products early to avoid
over-proofing.
NOTE:
■ Do not use the proofing mode for warming
food or keeping food hot. The proofing oven
temperature is not hot enough to hold foods
at safe temperatures.
■ Proofing will not operate when oven is above
52°C (125°F). “HOT” will show in the display.

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support
17
Wipe up heavy soil on the oven
bottom.
Using the self-cleaning oven. www.GEAppliances.ca
The oven door must be closed and all controls set correctly for the cycle to work properly.
Before a Clean Cycle
We recommend venting your kitchen
with an open window or using a
ventilation fan or hood during the
first self-clean cycle.
Remove broiler pan, broiler grid, all
cookware and any aluminum foil from
the oven.
NOTE: If your oven is equipped with gray
porcelain-coated oven racks, they may be
left in the oven during the self-clean
cycle.
Soil on the front frame of the range and
outside the gasket on the door will need
to be cleaned by hand. Clean these areas
with hot water, soap-filled steel-wool pads
or cleansers such as Soft Scrub® . Rinse
well with clean water and dry.
Do not clean the gasket. The fiberglass
material of the oven door gasket cannot
withstand abrasion. It is essential for the
gasket to remain intact. If you notice it
becoming worn or frayed, replace it.
Wipe up any heavy spillovers on the
oven bottom.
Make sure the oven light bulb cover is
in place and the oven light is off.
IMPORTANT: The health of some birds is
extremely sensitive to the fumes given off during
the self-cleaning cycle of any range. Move birds
to another well- ventilated room.
How to Set the Oven for Cleaning
WARNING: The surface
units are automatically disabled during
the self-clean cycle. Make sure that all
surface unit controls are turned off at all
times during the self-clean cycle. Any
surface unit that is set to an on position,
while the self-clean cycle is operating, will
automatically come on after the self-clean
cycle is finished, and could result in an
on, unattended surface unit. Wait until
the self-clean cycle is finished to set and
use the surface units.
Touch the CLEAN pad.
Using the number pads, enter the
desired clean time, if a time other
than 4 hours, 20 minutes is needed.
Clean cycle time is normally 4 hours, 30
minutes. You can change the clean time
to any time between 3 hours and 5 hours,
depending on how dirty your oven is.
Touch the
START pad.
The door locks automatically. The display
will show the clean time remaining. It will
not be possible to open the oven door
until the temperature drops below the
lock temperature and the LOCKED light
goes off.
When the LOCKED light goes off, you will
be able to open the door.
■The words LOCK DOOR will flash if you
set the clean cycle and forget to close
the oven door.
■To stop a clean cycle, touch the OFF
pad. When the LOCKED light goes off
indicating the oven has cooled below
the locking temperature, you will be
able to open the door.

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions
18
Using the self-cleaning oven.
The oven door must be closed and all controls set correctly for the cycle to work properly.
How to Delay the Start of Cleaning
Touch the CLEAN pad.
Using the number pads, enter the
desired clean time, if a time other
than 4 hours, 20 minutes is needed.
You can change the clean time to any
time between 3 hours and 5 hours,
depending on how dirty your oven is.
Touch the START TIME pad.
Using the number pads, enter the
time of day you want the clean cycle
to start.
Touch the START pad.
The door locks automatically. The display
will show the start time. It will not be
possible to open the oven door until
the temperature drops below the lock
temperature and the LOCKED light
goes off.
When the LOCKED light goes off, you
will be able to open the door.
After a Clean Cycle
You may notice some white ash in the
oven. Wipe it up with a damp cloth after
the oven cools.
If white spots remain, remove them with
a soap-filled steel wool pad and rinse
thoroughly with a vinegar and water
mixture.
These deposits are usually a salt residue
that cannot be removed by the clean
cycle.
If the oven is not clean after one clean
cycle, repeat the cycle.
■
You cannot set the oven for cooking or another
self-clean cycle until the oven is cool enough
for the door to unlock.
■ While the oven is self-cleaning, you can touch
the CLOCK pad to display the time of day.
To return to the clean countdown, touch the
COOK TIME pad.
■ If the racks become hard to slide, apply a small
amount of cooking oil to a paper towel and
wipe the edges of the oven racks with the
paper towel.

19
Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support
Special features of your oven control. www.GEAppliances.ca
Your new touch pad control has additional features that you may choose to use. The following are the features and
how you may activate them.
The special feature modes can only be activated while the display is showing the time of day. They remain in the
control’s memory until the steps are repeated.
When the display shows your choice, touch the START pad. The special features will remain in memory after
a power failure, except for the Sabbath feature, which will have to be reset.
START
DÉPART
START
DÉPART
BROIL
GRIL
BAKE
CUIRE
START TIME
HEURE DE
DÉPART
BROIL
GRIL
START
DÉPART
START
DÉPART
BAKE
CUIRE
TIMER
MINUTERIE
12-Hour Shutdown
With this feature, should you forget and leave the
oven on, the control will automatically turn off
the oven after 12 hours during baking functions
or after 3 hours during a broil function.
If you wish to turn OFF this feature,
follow the steps below.
Touch the BROIL and BAKE pads
at the same time for 3 seconds until
the display shows SF.
Touch the START TME pad until
no shdn (no shut-off) appears in the
display.
Touch the START pad to activate the
no shut-off and leave the control
set in this special features mode.
Tones at the End of a Timed Cycle
At the end of a timed cycle, 3 short beeps will
sound followed by one beep every 6 seconds
until the OFF pad is touched. This continual
6-second beep may be canceled.
To cancel the 6-second beep:
Touch the BROIL and BAKE pads
at the same time for 3 seconds until
the display shows SF.
Touch the TIMER pad. The display
shows CON BEEP (continuous beep).
Touch the TIMER pad again. The
display shows BEEP. (This cancels the
one beep every 6 seconds.)
Touch the START pad.
9 0
OVEN LOCKOUT
VERROUILLAGE FOUR
Oven Lockout
Your control will allow you to lock out the touch
pads so they cannot be activated when touched.
To activate this feature:
Touch the 9 and 0 pads at the same
time for 5 seconds until the control
beeps twice. The display will show
LOC continuously and the time of
day, if not blacked out.
NOTE: All cooking and timing functions will be
cancelled when locking out the control.
To unlock the control, touch the
9 and 0 pads at the same time for
5 seconds until the control beeps
twice and LOC is removed from
the display.
Fahrenheit or Celsius Temperature Selection
Your oven control is set to use the Fahrenheit
temperature selections but you may change this
to use the Celsius selections.
Touch the BROIL and BAKE pads
at the same time for 3 seconds until
the display shows SF.
Touch the BROIL and COOK TIME
pads. The display will show
F (Fahrenheit).
Touch the BROIL and COOK TIME
pads again. The display will show
C (Celsius).
Touch the START pad.

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions
+
20
Special features of your oven control.
12-Hour, 24-Hour or Clock Blackout
Your control is set to use a 12-hour clock.
If you would prefer to have a 24-hour
military time clock or black out the clock
display, follow the steps below.
Touch the BROIL and BAKE pads at
the same time for 3 seconds until
the display shows SF.
Touch the CLOCK pad once. The
display will show 12 hr. If this is
the choice you want, touch the
START pad.
Touch the CLOCK pad again to
change to the 24 hour military time
clock. The display will show 24 hr.
If this is the choice you want, touch
the START pad.
Touch the CLOCK pad again to black
out the clock display. The display will
show OFF. If this is the choice you
want, touch the START pad.
NOTE: If the clock is in the black-out mode you
will not be able to use the START TIME function.
Using Convection Conversion
By using the Convection Conversion feature, you
can automatically convert the oven temperature
from regular baking to Convection Bake
temperatures.
To convert the oven temperature for
convection baking, follow the steps below.
Touch and hold the CONVECTION
BAKE pad for 4 to 5 seconds.
Using the number pads, enter
the temperature recommended
in the recipe.
Touch the
START pad.
The display shows the converted
(reduced) temperature. For
example, if you entered a recipe
temperature of 177°C (350°F), the
display will show
163°C (325°F) when
it is converted.
Touch the OFF pad when baking is
finished.
NOTE: Conversion must be set each time
you want to use it. It is not held in memory.
Conversion is used on Convection Bake only.
