GE JCSP31 User manual

Use and Care Guide
Electric Range
Camco Inc.
Model: JCSP31
350A4502P100
229C4020P161
29-5013
7-98 CG
Safety Instructions....................3–5
Anti-Tip Device ........................................3, 36
Operating Instructions, Tips
Aluminum Foil ..............4, 5, 19, 23–25, 27
Features........................................................6, 7
Oven ........................................................17–30
Baking..................................................18–21
Broiling, Broiling Guide....................25, 26
Control, Clock and Timer................12–16
Fan........................................................17, 18
Oven Vent..............................................4, 32
Roasting, Roasting Guide ...............23, 24
Self-Cleaning Instructions ..............27–30
Special Features of Your Control.....14–16
Timed Baking.....................................20, 21
Surface Cooking......................................8–11
Control Settings ..........................................9
Cooktop Comparison.................................8
Cookware Tips ..........................................10
Home Canning Tips .................................11
Problem Solver.......................37, 38
Thermostat Adjustment–
Do It Yourself ............................................22
More questions ?…call
Camco Inc.—1-800-361-3400
Care and Cleaning....................31–35
Control Panel and Knobs .................................31
Cooktop ..........................................................33, 35
Lift-Off Oven Door...............................................34
Oven Light Bulb ...................................................35
Self-Cleaning Instructions..................27–30
Shelves ...................................................................32
Surface Units and Drip Pans...........................33
Consumer Services...................39
Appliance Registration..................................2
Important Phone Numbers .......................39
Model and Serial Number Location...........2
Removal of Packaging Tape........................2
Warranty ........................................................40

HELP US HELPYOU…
Before using your range, read this
guide carefully.
It is intended to help you operate and maintain your
new range properly.
Keep it handy for answers to your questions.
If you don’t understand something or need more help, call:
If you don’t understand something or need more help,
write (include your phone number):
Consumer Relations Manager
Camco Inc.
1 Factory Lane
Suite 310
Moncton, N.B. E1C 9M3
How to Remove Packaging Tape
To assure no damage is done to the finish of the
product, the safest way to remove the adhesive left
from packaging tape on new appliances is an
application of a household liquid dishwashing
detergent, mineral oil or cooking oil. Apply with a
soft cloth and allow to soak. Wipe dry and then apply
an appliance polish to thoroughly clean and protect
the surface.
NOTE: The plastic tape must be removed from the
chrome trim on range parts. It cannot be removed if
it is baked on.
Write down the model and serial
numbers.
You’ll find them on a label behind the storage drawer.
These numbers are also on the Consumer Product
Ownership Registration Card that came with your
range. Before sending in this card, please write these
numbers here:
Model Number
Serial Number
Use these numbers in any correspondence or service
calls concerning your range.
If you received a damaged range…
Immediately contact the dealer (or builder) that sold
you the range.
Save time and money.
Before you request service…
Check the Problem Solver in the back of this guide.
It lists causes of minor operating problems that you
can correct yourself.
IFYOU NEED SERVICE…
To obtain service, see the Consumer Services page in
the back of this guide.
We’re proud of our service and want you to be
pleased. If for some reason you are not happy with
the service you receive, here are two steps to follow
for further help.
FIRST, contact the people who serviced your
appliance. Explain why you are not pleased. In most
cases, this will solve the problem.
NEXT, if you are still not pleased, write all the
details—including your phone number—to:
Consumer Relations Manager
Camco Inc.
1 Factory Lane
Suite 310
Moncton, N.B. E1C 9M3
2

Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS
Read all instructions before using this appliance.
IMPORTANT SAFETY NOTICE
• The California Safe Drinking Water and
Toxic Enforcement Act requires the Governor
of California to publish a list of substances
known to the state to cause cancer, birth defects
or other reproductive harm, and requires
businesses to warn customers of potential
exposure to such substances.
• The fiberglass insulation in self-cleaning ovens
gives off a very small amount of carbon
monoxide during the cleaning cycle. Exposure
can be minimized by venting with an open
window or using a ventilation fan or hood.
When using electrical appliances, basic safety
precautions should be followed, including the
following:
• Use this appliance only for its intended use
as described in this guide.
• Be sure your appliance is properly installed
and grounded by a qualified technician in
accordance with the provided installation
instructions.
• Do not attempt to repair or replace any
part of your range unless it is specifically
recommended in this guide. All other servicing
should be referred to a qualified technician.
WARNING —
All ranges can tip and injury could
result. To prevent accidental tipping
of the range, attach it to the wall or
floor by installing the Anti-Tip device
supplied. Make sure the chain fits
securely into the slot in the bracket.
If you pull the range out from the wall
for any reason, make sure the device is
properly engaged when you push the range back
against the wall. If it is not, there is a possible risk
of the range tipping over and causing injury if you
or a child stand, sit or lean on an open door.
Please refer to the Anti-Tip device information in
this guide. Failure to take this precaution could
result in tipping of the range and injury.
• Have the installer show you the location of the
circuit breaker or fuse. Mark it for easy
reference.
• Before performing any service, DISCONNECT
THE RANGE POWER SUPPLY AT THE
HOUSEHOLD DISTRIBUTION PANEL
BY REMOVING THE FUSE OR SWITCHING
OFF THE CIRCUIT BREAKER.
• Do not leave children alone—children should not
be left alone or unattended in an area where an
appliance is in use. They should never be allowed
to sit or stand on any part of the appliance.
• Do not allow anyone to climb, stand or hang
on the door, storage drawer or cooktop. They
could damage the range and even tip it over,
causing severe personal injury.
• Teach children not to play with the controls
or any other part of the range.
• Never leave the oven door open when you are
not watching the range.
• Always keep combustible wall coverings, curtains
or drapes a safe distance from your range.
• Always keep dish towels, dish cloths, pot holders
and other linens a safe distance from your range.
• Always keep wooden and plastic utensils and
canned food a safe distance away from your
range.
• CAUTION: ITEMS OF INTEREST TO
CHILDREN SHOULD NOT BE STORED IN
CABINETS ABOVE A RANGE OR ON THE
BACKSPLASH OFA RANGE—CHILDREN
CLIMBING ON THE RANGE TO REACH
ITEMS COULD BE SERIOUSLY INJURED.
• Never wear loose-fitting or hanging garments
while using the appliance. Be careful when
reaching for items stored over the range.
Flammable material could be ignited if brought in
contact with hot surface units or heating elements
and may cause severe burns.
• Use only dry pot holders—moist
or damp pot holders on hot surfaces
may result in burns from steam.
Do not let pot holders touch hot surface units or
heating elements. Do not use a towel or other
bulky cloth. Such cloths can catch fire on a hot
surface unit or heating element.
• Do not store flammable materials in an oven
or near the cooktop.
(continued next page)
3

IMPORTANT SAFETY INSTRUCTIONS
(continued)
• For your safety, never use your appliance for
warming or heating the room.
• DO NOT STORE OR USE COMBUSTIBLE
MATERIALS, GASOLINE OR OTHER
FLAMMABLE VAPORS AND LIQUIDS IN
THE VICINITY OF THIS OR ANY OTHER
APPLIANCE.
• Do not let cooking grease or other flammable
materials accumulate in or near the range.
• Do not use water on grease fires.
Never pick up a flaming pan.
Turn the controls off. Smother a flaming
pan on a surface unit by covering the
pan completely with a well-fitting lid, cookie
sheet or flat tray. Use a multi-purpose dry
chemical or foam-type fire extinguisher.
Flaming grease outside a pan can be put out
by covering it with baking soda or, if available,
by using a multi-purpose dry chemical or foam-
type fire extinguisher.
Flame in the oven can be smothered completely
by closing the oven door and turning the oven off
or by using a multi-purpose dry chemical or
foam-type fire extinguisher.
• Do not touch the surface units, the heating
elements or the interior surface of the oven.
These surfaces may be hot enough to burn even
though they are dark in color. During and after
use, do not touch, or let clothing or other
flammable materials contact, the surface units, the
areas nearby the surface units or any interior area
of the oven; allow sufficient time for cooling first.
Potentially hot surfaces include the cooktop, areas
facing the cooktop, oven vent opening, surfaces
near the opening, crevices around the oven door,
the edges of the door window and metal trim
parts above the door.
Remember: The inside surface of the oven may
be hot when the door is opened.
• When cooking pork, follow the directions
exactly and always cook the meat to an internal
temperature of at least 170°F. This assures that, in
the remote possibility that trichina may be present
in the meat, it will be killed and the meat will be
safe to eat.
• Keep the hood and grease filters clean to
maintain good venting and to avoid grease fires.
Oven
• Stand away from the range when opening the
oven door. The hot air or steam which escapes
can cause burns to hands, face and/or eyes.
• Do not heat unopened food containers.
Pressure could build up and the container
could burst, causing an injury.
• Keep the oven vent duct unobstructed.
• Keep the oven free from grease buildup.
• Place the oven shelf in the desired position
while the oven is cool. If the shelves must be
handled when hot, do not let a pot holder contact
the heating elements in the oven.
• Pulling out the shelf to the stop-lock is a
convenience in lifting heavy foods. It is also
a precaution against burns from touching hot
surfaces of the door or oven walls.
• After broiling, always take the broiler pan out
of the range and clean it. Leftover grease in the
broiler pan can catch fire next time you use the pan.
• When using cooking or roasting bags in the
oven, follow the manufacturer’s directions.
• Do not use your oven to dry newspapers.
If overheated, they can catch fire.
• Do not leave paper products, cooking utensils
or food in the oven when not in use. Do not
store flammable materials in an oven or near the
surface units.
• Clean only parts listed in this Use and
Care Guide.
• Do not use aluminum foil to line oven bottoms,
except as suggested in this guide. Improper
installation of aluminum foil may result in a risk
of electric shock or fire.
4

Important Safety Instructions
Self-Cleaning Oven
• Do not clean the oven door gasket. The door
gasket is essential for a good seal. Care should be
taken not to rub, damage or move the gasket.
• Do not use oven cleaners. No commercial oven
cleaner or oven liner protective coating of any
kind should be used in or around any part of the
oven. Residue from oven cleaners will damage
the inside of the oven when the self-clean cycle is
used.
• Be sure to wipe up excess spillage before
starting the self-cleaning operation.
• Before self-cleaning the oven, remove the
broiler pan, grid and other cookware.
• If the self-cleaning mode malfunctions, turn
the oven off and disconnect the power supply.
Have it serviced by a qualified technician.
Surface Cooking Units
• Use proper pan size—Select cookware having
flat bottoms large enough to cover the surface unit
heating element. The use of undersized cookware
will expose a portion of the surface unit to direct
contact and may result in ignition of clothing.
Proper relationship of the cookware to the surface
unit will also improve efficiency.
• Never leave the surface units unattended at
high heat settings. Boilovers cause smoking and
greasy spillovers that may catch on fire.
• Be sure the drip pans and vent ducts are not
covered and are in place. Their absence during
cooking could damage range parts and wiring.
• Do not use aluminum foil to line the drip pans
or anywhere in the oven except as described in
this guide. Misuse could result in a shock, fire
hazard or damage to the range.
• Never clean the cooktop surface when it
is hot. Some cleaners produce noxious fumes
and wet cloths could cause steam burns if used
on a hot surface.
• Never leave jars or cans of fat drippings
on or near your range.
• Only certain types of glass, glass/ceramic,
earthenware or other glazed containers are
suitable for cooktop cooking; others may break
because of the sudden change in temperature.
• To minimize the possibility of burns, ignition
of flammable materials and spillage, the handle
of a container should be turned toward the center
of the range without extending over nearby
surface units.
• Always turn the surface unit controls off before
removing cookware.
• Carefully watch for spillovers or overheating
of foods when frying at high or medium high
temperatures.
• To avoid the possibility of a burn or electric
shock, always be certain that the controls for all
surface units are at the off position and
all coils are cool before attempting to lift or
remove a unit.
• Do not immerse or soak the removable surface
units. Do not put them in a dishwasher. Do not
clean the surface units in the oven.
• Never try to move a pan of hot fat, especially
a deep fat fryer. Wait until the fat is cool.
• When flaming foods are under the hood, turn
the fan off. The fan, if operating, may spread
the flame.
• Foods for frying should be as dry as possible.
Frost on frozen foods or moisture on fresh
foods can cause hot fat to bubble up and over the
sides of the pan.
• Use little fat for effective shallow or deep-fat
frying. Filling the pan too full of fat can cause
spillovers when food is added.
• If a combination of oils or fats will be used
in frying, stir together before heating, or as fats
melt slowly.
• Always heat fat slowly, and watch as it heats.
• Use a deep fat thermometer whenever
possible to prevent overheating fat beyond
the smoking point.
SAVE THESE
INSTRUCTIONS 5

6
FEATURES OFYOUR RANGE
1
5
7 8 912 1310 11 14
17
16
15
18
19
20
21
Model
JCSP31
3
2
6
4

7
Features of Your Range
Explained
Feature Index on page
1Storage Drawer 3, 32
2Model and Serial Numbers 2
3Bake Element 31
4Broil Element 25, 31
5Oven Interior Light 27, 35
6Surface Unit Controls 5, 8, 31
7Lift-Up Cooktop 33
Support rod holds it up to simplify
cleaning underneath.
8Drip Pans 5, 33
9Plug-In Surface Units 3–5, 8–11, 33
10 Oven Light Switch —
Lets you turn interior oven light on and off.
11 Oven Vent (located under right rear surface unit) 4, 32
12 Anti-Tip Device 3, 36
13 Oven Control, Clock and Timer 12–16
14 Surface Unit “ON” Indicator Light 9
15 Automatic Oven Light Switch —
16 Automatic Oven Door Latch 28–30
17 Oven Shelf Supports 4, 17, 18
Shelf positions for cooking are suggested in the 23, 25–27,
Baking, Roasting and Broiling sections. 30, 32
18 Oven Shelves with Stop-Locks 4, 17, 18,
23, 25–27,
30, 32
19 Lift-Off Oven Door with Broil Stop Position 3, 4, 25, 34
20 Oven Door Gasket 4, 27, 34
21 Broiler Pan and Grid 4, 5, 23,
Do not clean in the self-cleaning oven. 25–27, 35

8
COOKTOP COMPARISON
Type of Cooktop Description How It Works
Electric Coil Flattened metal Heats by direct contact with the pan and by heating the air under the pan. For best
tubing containing cooking results, use good quality pans. Electric coils are more forgiving of
electric resistance warped pans than radiant or solid disks. Heats up quickly but does not change
wire suspended heat settings as quickly as gas or induction. Electric coils stay hot enough to
over a drip pan. continue cooking for a short time after they are turned off.
Radiant Electric coils Heat travels to the glass surface and then to the cookware, so pans must be flat on
(Glass Ceramic) under a glass- the bottom for good cooking results. The glass cooktop stays hot enough to
Cooktop ceramic cooktop. continue cooking after it is turned off. Remove the pan from the surface unit if
you want cooking to stop.
Induction High frequency Pans must be made of ferrous metals (metal that attracts a magnet). Heat is
induction coils produced by a magnetic circuit between the coil and the pan. Heats up right away
under a glass and changes heat settings right away, like a gas cooktop. After turning the control
surface. off, the glass cooktop is hot from the heat of the pan, but cooking stops right away.
Solid Disk Solid cast iron Heats by direct contact with the pan, so pans must be flat on the bottom for good
disk sealed to the cooking results. Heats up and cools down more slowly than electric coils. The
cooktop surface. disk stays hot enough to continue cooking after it is turned off. Remove the pan
from the solid disk if you want the cooking to stop.
Gas Burners Regular or sealed Flames heat the pans directly. Pan flatness is not critical to cooking results, but
gas burners use pans should be well balanced. Gas burners heat the pan right away and change
either LP gas heat settings right away. When you turn the control off, cooking stops right away.
or natural gas.
Your new cooktop has electric coil surface units.
If you are used to cooking with gas burners or other
types of electric cooktops, you will notice some
differences when you use electric coils.
The best types of cookware to use, plus heat-up and
cool-down times, depend upon the type of burner or
surface unit you have.
The following chart will help you to understand the
differences between electric coil surface units and any
other type of cooktop you may have used in the past.

9
SURFACE COOKING
Your surface units and controls are designed to give
you an infinite choice of heat settings for surface unit
cooking. At both OFF and HI the control “clicks”
into position.
When cooking in a quiet kitchen, you may hear slight
“clicking” sounds—an indication that the heat
settings you selected are being maintained.
Switching to higher heat settings always results in a
quicker heat change than switching to lower settings.
Cooktop Comparison Surface Cooking
How to Set the Controls
1. Grasp the control
knob and push it in.
2. Turn the knob either
clockwise or counterclockwise
to the desired heat setting.
The control must be pushed in to set only from
the OFF position. When the control is in any
position other than OFF, it may be turned without
pushing it in.
Be sure you turn the control knob to OFF when you
finish cooking.
The surface unit “ON” indicator light will glow
when ANY heat on any surface unit is on.
Cooking Guide for Using Heat Settings
HI—Quick start for cooking; brings water to boil.
Medium High—(Setting halfway between HI and
MED) Fast fry, pan broil; maintains a fast boil on
large amounts of food.
MED—Sauté and brown; maintains a slow boil on
large amounts of food.
Medium Low—(Setting halfway between MED and
LO) Cook after starting at HI; cooks with little water
in covered pan.
LO—Steam rice, cereal; maintain serving temperature
of most foods. At LO settings, melt chocolate, butter
on a small unit.
NOTE: At HI and Medium High, never leave food
unattended. Boilovers cause smoking; greasy
spillovers may catch fire.
Medium
High Medium
Low

10
SURFACE COOKWARE TIPS
Wok Cooking
We recommend that you
use only a flat-bottomed
wok. They are available
at your local retail store.
Do not use woks that
have support rings.
Use of these types of woks,
without the support ring in
place, is dangerous because
the wok is unstable. With the
ring in place, heat will be trapped inside the ring
and may cause damage to the porcelain cooktop.
Do not try to use such woks without the ring. You
could be seriously burned if the wok tipped over.
Cookware
Use medium- or heavy-weight cookware. Aluminum
cookware conducts heat faster than other metals.
Cast-iron and coated cast-iron cookware are slow to
absorb heat, but generally cook evenly at low to
medium heat settings. Steel pans may cook unevenly
if not combined with other metals.
For best cooking results pans should be flat on the
bottom. Match the size of the saucepan to the size of
the surface unit. The pan should not extend over the
edge of the surface unit more than 1 inch.
Right Wrong
Not over 1″Over 1″
Deep Fat Frying
Do not overfill cookware with fat that may spill over when adding food.
Frosty foods bubble vigorously. Watch food frying at high temperatures.
Keep the range and hood clean from grease.

HOME CANNING TIPS
Canning should be done on surface units only.
In surface cooking, the use of pots extending more
than one inch beyond the edge of the surface unit’s
drip pan is not recommended. However, when canning
with a water-bath or pressure canner, large-diameter
pots may be used. This is because boiling water
temperatures (even under pressure) are not harmful to
the cooktop surfaces surrounding the surface units.
HOWEVER, DO NOT USE LARGE-DIAMETER
CANNERS OR OTHER LARGE-DIAMETER POTS
FOR FRYING OR BOILING FOODS OTHER THAN
WATER. Most syrup or sauce mixtures—and all types
of frying—cook at temperatures much higher than
boiling water. Such temperatures could eventually harm
the cooktop surfaces surrounding the surface units.
Observe Following Points in Canning
1. Be sure the canner fits over the center of the
surface unit. If your range or its location does not
allow the canner to be centered on the surface unit,
use smaller-diameter pots for good canning results.
2. Flat-bottomed canners must be used. Do not use
canners with flanged or rippled bottoms (often
found in enamelware) because they don’t make
enough contact with the surface unit and take too
long to boil water.
RIGHT WRONG
Flat-bottomed canners are recommended.
3. When canning, use recipes and procedures from
reputable sources. Reliable recipes and procedures
are available from the manufacturer of your canner,
manufacturers of glass jars for canning, such as
Ball and Kerr, and the United States Department of
Agriculture Extension Service.
4. Remember that canning is a process that generates
large amounts of steam. To avoid burns from steam
or heat, be careful when canning.
NOTE: If your house has low voltage, canning may
take longer than expected, even though directions
have been carefully followed.
The process time will be shortened by:
(1) using a pressure canner, and
(2) starting with HOT tap water for fastest heating
of large quantities of water.
Surface Cookware Tips Home Canning Tips
11

12
FEATURES OFYOUR OVEN CONTROL
1. BAKE. Press to select the bake function.
2. BROIL HI/LO. Press to select the broil function.
3. DISPLAY. Shows the operations you have
selected, the time of day and the cooking or
cleaning status.
4. COOKING TIME. Press for Timed Baking
operations.
5. START TIME. Use along with COOKING TIME
or SELF CLEAN to set the oven to start and stop
automatically at a time you select.
6. CLOCK. Press to enter the time of day.
7. KITCHEN TIMER ON/OFF. Press to select the
timer function. The timer does not control oven
operations. The timer can time up to 9 hours
and 59 minutes.
8. START. Must be pressed to start any cooking or
cleaning function.
09. DECREASE. Short taps to this pad decrease
the time or temperature by small amounts.
Press and hold the pad to decrease the time or
temperature by larger amounts.
10. INCREASE. Short taps to this pad increase the
time or temperature by small amounts. Press and
hold the pad to increase the time or temperature
by larger amounts.
11. CLEAR/OFF. Press to cancel any timed oven
operation except the clock and timer.
12. SELF CLEAN. Press to select the self-cleaning
function. See the Operating the Self-Cleaning
Oven section.
If “F– and a number or letter” flash in the
display and the oven control signals, this
indicates function error code. Press CLEAR/OFF.
Allow the oven to cool for one hour. Put the oven
back into operation. If the function error code
repeats, disconnect the power to the range and
call for service.
ON OFF
TIME CONTROLS
COOKING
TIME
START
TIME
CLOCK
KITCHEN
TIMER
START
BROIL
HI/LO
CLEAR
OFF
OVEN
BAKE
SELF
CLEAN
3 41 2 5
1112 10 9 8 7 6

13
OVEN CONTROL, CLOCK AND TIMER
Clock To Set the Clock
The clock must be set for the
automatic oven timing functions
to work properly.
The time of day clock cannot
be changed during Delay Start.
(It can be changed during a
regular bake or broil operation.)
1. Press CLOCK.
2. Press the
INCREASE or
DECREASE pad
to set the time of
day.
If the INCREASE or DECREASE
pad is not pressed within one minute
after you press CLOCK, the display
reverts to the original setting. If this
happens, press CLOCK and reenter
the time of day.
3. Press START. This
enters the time and starts
the clock.
To check the time of day when
the display is showing other
information, simply press
CLOCK. The time of day shows
until another pad is pressed.
START
CLOCK
How to Set the Timer
1. Press KITCHEN TIMER
ON/OFF.
2. Press the INCREASE or
DECREASE pad to set the amount
of time on the timer.
If you make a mistake, press
KITCHEN TIMER ON/OFF
and begin again.
3. Press START.
After pressing START, “SET” disappears;
this tells you the time is counting down,
although the display does not change until
one minute has passed.
4. When time is up, the oven control
signals until you press KITCHEN TIMER
ON/OFF. Display then shows the time
of day.
NOTE: The minute timer is independent of all the
other functions and it does not control the oven.
The CLEAR/OFF pad does not affect the timer.
ON OFF
KITCHEN
TIMER
START
ON OFF
KITCHEN
TIMER
Power Failure
If a flashing time of day is in the display, you have
had a power failure. Reset the clock. To reset the clock, press CLOCK. Enter the correct time of day by pressing the INCREASE or
DECREASE pad. Press START.
(continued next page)
Features of Your Oven Control Oven Control, Clock and Timer
Timer
You may program the timer to time cooking or other
household activities for up to 9 hours and 59 minutes.
The timer counts down in minutes, 1 minute at a time,
until the last 60 seconds are reached, then the control
will beep one time. The seconds will not be displayed
until the last minute is reached.
When the timer reaches “ :00,” the control will beep
3 times followed by one beep every 6 seconds until
KITCHEN TIMER ON/OFF is pressed.
The 6 second tone can be canceled by following the
steps in the Special Features of Your Oven Control
section under Tones at the End of a Timed Cycle.

14
OVEN CONTROL, CLOCK AND TIMER
(continued)
The control has a series of tones that will sound at different times. These
tones may sound while you set the control for an oven function or at the
end of the oven function. They will also alert you when an incorrect time
or temperature has been entered or if there is a problem with the oven.
Tones While Setting the Control Preheat Notification Tone
When you press a touch pad you will hear a beep.
This beep will let you know you have placed enough
pressure on the pad to activate it.
When you set an oven temperature the oven
automatically starts to heat. When the temperature
inside the oven reaches your set temperature a tone will
sound to let you know to place the food in the oven.
Attention Tone
This tone will sound if you set an invalid function or try to set an additional
function. The tone can be quickly identified by watching the display messages.
Tones at the End of a Timed Cycle
At the end of a timed cycle, 3 short beeps will
sound followed by one beep every 6 seconds, until
CLEAR/OFF is pressed. This continuous 6 second
beep may be canceled.
To cancel the 6 second beep:
1. Press BAKE and BROIL HI/LO
at the same time for 2 seconds until
the display shows “SF.”
2. Press KITCHEN TIMER ON/OFF.
The display shows “CON BEEP”
(continuous beep). Press KITCHEN
TIMER ON/OFF again. The display shows
“BEEP.” (This cancels the one beep every
6 seconds.)
3. Press START.
START
ON OFF
KITCHEN
TIMER
BROIL
HI/LO
BAKE
SPECIAL FEATURES OFYOUR OVEN CONTROL
Your new touch pad control has additional features that you may choose
to use. The following are the features and how you may activate them.
The special feature modes can only be activated while the display is
showing the time of day clock.
They remain in the control’s memory until the steps are repeated. When the
display shows your choice press START. The special features will remain
in memory after a power failure.

15
12 Hour Shut-Off Cook and Hold
With this feature, should you forget and leave the
oven on, the control will automatically turn off the
oven after 12 hours during baking functions or after
3 hours during a broil function. If you wish to turn
off this feature, follow the steps below.
1. Press BAKE and BROIL
HI/LO at the same time for
2 seconds until the display
shows “SF.”
2. Press START TIME. The
display will show “12 shdn”
(12 hour shut-off). Press START
TIME again and the display will
show “no shdn” (no shut-off).
3. Press START to activate the no
shut-off and leave the control set
in this special features mode.
Your new control has a cook and hold feature that
keeps cooked foods warm for up to 3 hours after the
cooking function is finished. To activate this feature,
follow the steps below.
1. Press BAKE and BROIL
HI/LO at the same time for
2 seconds until the display
shows “SF.”
2. Press COOKING TIME. The
display will show “Hld OFF.”
—Press COOKING TIME again
to activate the feature. The
display will show “Hld ON.”
3. Press START to activate the
cook and hold feature and leave
the control set in this special
features mode.
START
COOKING
TIME
BROIL
HI/LO
BAKE
START
START
TIME
BROIL
HI/LO
BAKE
15
12 Hour, 24 Hour or Clock Black-Out
Your control is set to use a 12 hour clock. If you would prefer to have
a 24 hour military time clock or black-out the clock display, follow the
steps below. 1. Press BAKE and BROIL HI/LO at the same time for
2 seconds until the display shows “SF.”
2. Press CLOCK once. The display will show “12 hr.”
—Press CLOCK again to change to the 24 hour
military time clock. The display will show “24 hr.”
—Press CLOCK again to black-out the clock display.
The display will show “OFF.”
3. Press START to activate your choice and leave the
control set in this special features mode.
NOTE: If the clock is in the black-out mode you will not be able to use
the Delay Start function.
(continued next page)
START
CLOCK
BROIL
HI/LO
BAKE
Oven Control, Clock and Timer Special Features of Your Oven Control

16
Control Lockout
Your control will allow you to lock down the touch
pads so they cannot be activated when pressed.
1. Press BAKE and BROIL HI/LO
at the same time for 2 seconds
until the display shows “SF.”
2. Press SELF CLEAN. The
display will show “LOC OFF.”
—Press SELF CLEAN again.
The display will show “LOC.”
3. Press START to activate the control
lockout feature and leave the control set in
this special features mode.
When this feature is on and the touch pads are
pressed the control will beep and the display will show
“LOC.”
NOTE: The control lockout mode will not affect the
clock or timer touch pads.
START
SELF
CLEAN
BROIL
HI/LO
BAKE
Fahrenheit or Centigrade Temperature Selection
Your oven control is set to use the Fahrenheit
temperature selections but you may change this
to use the Centigrade selections.
1. Press BAKE and BROIL HI/LO
at the same time for 2 seconds
until the display shows “SF.”
2. Press BROIL HI/LO. The
display will show “F”
(Fahrenheit).
3. Press BROIL HI/LO again. The display
will show “C” (Centigrade).
4. Press START.
START
BROIL
HI/LO
BROIL
HI/LO
BROIL
HI/LO
BAKE
Changing the Speed of the + or – Pads
As you use the + or – pads when setting a time or
temperature, you may notice the display changes
slowly. This special feature allows you to change the
speed. To set the speed you prefer, follow the steps
below. 1. Press BAKE and BROIL HI/LO
at the same time for 2 seconds
until the display shows “SF.”
2. Press the + pad. The display
will show you a set speed
between 1 and 5.
3. Press the + pad to increase the speed up
to the number 5.
—Press the – pad to decrease the speed down
to the number 1.
4. Press START to activate the setting
and leave the control set in this special
features mode.
START
BROIL
HI/LO
BAKE
SPECIAL FEATURES
OFYOUR OVEN CONTROL
(continued)

17
USING YOUR OVEN
Before Using Your Oven
1. Look at the controls. Be sure you understand
how to set them properly.
2. Check the oven interior. Look at the shelves.
Take a practice run at removing and replacing them
properly to give sure, sturdy support.
3. Read over the information and tips that follow.
4.
Keep this guide handy so you can refer to it, especially
during the first weeks of using your new range.
NOTE:
• You may notice a “burning” or “oily” smell the first
few times you turn your oven on. This is normal in
a new oven and will disappear in a short time. To
speed the process, set a self-clean cycle for 4 hours.
See the Operating the Self-Cleaning Oven section.
• A cooling fan may automatically turn on and off to
cool internal parts. This is normal, and the fan may
continue to run even after the oven is turned off.
Special Features of Your Oven Control Using Your Oven
Shelf Positions
The oven has four shelf supports identified in this
illustration as A (bottom), B, C and D (top).
Shelf positions for cooking are suggested in the
Baking, Roasting, and Broiling sections. D
C
B
A
Oven Shelves
The shelves are designed with stop-locks so that,
when placed correctly on the shelf supports, they
will stop before coming completely out of the oven
and will not tilt when you are removing food from
them or placing food on them.
When placing cookware on a shelf, pull the shelf out
to the bump on the shelf support. Place the cookware
on the shelf, then slide the shelf back into the oven.
This will eliminate reaching into the hot oven.
To remove the shelf
from the oven, pull the
shelf toward you, tilt
the front end upward,
and pull the shelf out.
To replace, place the
shelf on the shelf
support with the stop-
locks (curved
extension of shelf)
facing up and toward
the rear of the oven. Tilt up the front and push the shelf
toward the back of the oven until it goes past the bump
on the shelf support. Then lower the front of the shelf,
and push it all the way back.
Bump

BAKING
Your oven temperature is controlled very accurately
using an oven control system. It is recommended that
you operate the range for a number of weeks using
the time given on recipes as a guide to become
familiar with your new oven’s performance.
If you think an adjustment is necessary, see the
Adjust the Oven Thermostat section. It lists easy
Do It Yourself instructions on how to adjust the
thermostat.
How to Set Your Oven for Baking
To avoid possible burns, place shelves in the correct
position before you turn the oven on.
1. Press BAKE.
2. Press the INCREASE or DECREASE pad to set
the oven temperature.
3. Press START. When the oven starts to heat,
the changing temperature will be in the display.
(The display starts changing once the temperature
reaches 100°F.)
4. Press CLEAR/OFF when baking is finished.
NOTE:
• A cooling fan may automatically turn on and off to
cool internal parts. This is normal, and the fan may
continue to run even after the oven is turned off.
To change the oven temperature during the
Bake cycle, press BAKE and set the new
temperature.
Oven Shelves
Arrange the oven
shelf or shelves in
the desired locations
while the oven is
cool. The correct
shelf position
depends on the kind
of food and the
browning desired.
As a general rule,
place most foods in
the middle of the oven, on either shelf position B or
C. See the chart for suggested shelf positions.
Type of Food Shelf Position
Angel food cake A
Biscuits or muffins B or C
Cookies or cupcakes B or C
Brownies B or C
Layer cakes B or C
Bundt or pound cakes A or B
Pies or pie shells B or C
Frozen pies A (on cookie sheet)
Casseroles B or C
Roasting A or B
D
C
B
A
Preheating
Preheat the oven if the recipe calls for it. Preheat
means bringing the oven up to the specified
temperature before putting the food in the oven.
To preheat, set the oven at the correct temperature—
selecting a higher temperature does not shorten
preheat time.
Preheating is necessary for good results when baking
cakes, cookies, pastry and breads. For most casseroles
and roasts, preheating is not necessary. For ovens without
a preheat indicator light or tone, preheat 10 minutes.
After the oven is preheated, place the food in the oven as
quickly as possible to prevent heat from escaping.
18

19
Baking
Baking Pans Pan Placement
Use the proper baking pan. The type of finish on the
pan determines the amount of browning that will occur.
• Dark, rough or dull pans absorb heat resulting in a
browner, crisper crust. Use this type for pies.
• Shiny, bright and smooth pans reflect heat, resulting
in a lighter, more delicate browning. Cakes and
cookies require this type of pan.
• Glass baking dishes absorb heat. When baking in
glass baking dishes, the temperature may need to be
reduced by 25°F.
• If you are using dark non-stick pans, you may find
that you need to reduce the oven temperature 25°F.
to prevent over-browning.
For even cooking and proper browning, there must be
enough room for air circulation in the oven. Baking
results will be better if baking pans are centered as
much as possible rather than being placed to the front
or to the back of the oven.
Pans should not touch each other or the walls of the
oven. Allow 1- to 11⁄2-inch space between pans as well
as from the back of the oven, the door and the sides.
If you need to use two shelves, stagger the pans so one
is not directly above the other.
Cookies Aluminum Foil
When baking cookies,
flat cookie sheets
(without sides) produce
better-looking cookies.
Cookies baked in a
jelly roll pan (short
sides all around) may
have darker edges and
pale or light browning
may occur.
Do not use a cookie sheet so large that it touches the
walls or the door of the oven. Never entirely cover
a shelf with a large cookie sheet.
For best results during baking, use only one cookie
sheet in the oven at a time.
Never entirely cover a
shelf with aluminum
foil. This will disturb
the heat circulation and
result in poor baking.
A smaller sheet of foil
may be used to catch a
spillover by placing it
on a lower shelf several
inches below the food.
Pies Cakes
For best results, bake pies in dark, rough or dull pans
to produce a browner, crisper crust. Frozen pies in foil
pans should be placed on an aluminum cookie sheet
for baking since the shiny foil pan reflects heat away
from the pie crust; the cookie sheet helps retain it.
When baking cakes, warped or bent pans will cause
uneven baking results and poorly shaped products.
A cake baked in a pan larger than the recipe
recommends will usually be crisper, thinner and drier
than it should be. If baked in a pan smaller than
recommended, it may be undercooked and batter may
overflow. Check the recipe to make sure the pan size
used is the one recommended.
Don’t Peek
Set the timer for the estimated cooking time and do
not open the door to look at your food. Most recipes
provide minimum and maximum baking times such
as “bake 30-40 minutes.”
DO NOT open the door to check until the minimum
time. Opening the oven door frequently during
cooking allows heat to escape and makes baking times
longer. Your baking results may also be affected.

20
TIMED BAKING
How to Set Your Oven for Time Bake
The oven control allows you to turn the oven on or
off automatically at specific times that you set.
Examples of Immediate Start (oven turns on now and
you set it to turn off automatically at the end of
cooking time) and Delay Start and Stop (setting the
oven to turn on automatically at a later time and turn
off after a preset cooking time) will be described.
NOTE: Before beginning make sure the clock shows
the correct time of day.
To set the clock, first press CLOCK.
Press the INCREASE or DECREASE pad
to set the time of day. Press START.
NOTE: An attention tone will sound if you are using
Timed Baking and do not press START after entering
the baking temperature.
CLOCK
How to Set Immediate Start and Automatic Stop
To avoid possible burns, place the shelves in the
correct position before you turn the oven on.
The oven will turn on immediately and cook for a
selected length of time. At the end of cooking time,
the oven will turn off automatically.
1. Press BAKE.
2. Press the INCREASE or
DECREASE pad to set the
oven temperature.
3. Press COOKING TIME.
NOTE: If your recipe requires
preheating, you may need to add
additional time to the length of the
cooking time.
4. Press the INCREASE or
DECREASE pad to set the
baking time.
The oven temperature and the
cooking time that you entered will
be displayed.
5. Press START. The display shows the
oven temperature that you set and the
cooking time countdown. (The display
starts changing once the temperature reaches
100°F.)
The oven will continue to cook for the
programmed amount of time, then shut off
automatically.
6. Press CLEAR/OFF to clear the end
of cycle tone if necessary.
NOTE:
• The low temperature zone of this range (between
170°F. and 200°F.) is available to keep hot cooked
foods warm. Food kept in the oven longer than two
hours at these low temperatures may spoil.
• Foods that spoil easily, such as milk, eggs, fish,
stuffings, poultry and pork, should not be allowed to
sit for more than one hour before or after cooking.
Room temperature promotes the growth of harmful
bacteria. Be sure that the oven light is off because
heat from the bulb will speed harmful bacteria
growth.
CLEAR
OFF
START
COOKING
TIME
BAKE
