GE JB650EDES Manual

All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
Dimensions and Installation Information (in inches)
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
geappliances.com or call GE Answer Center®
service, 800.626.2000.
JB650ED
GE®30" Free-Standing Electric Range
Listed by
Underwriters
Laboratories
Specification Revised 6/12 321545
KW Rating
240V 13.0
208V 10.8
Breaker Size
40 Amps†
30
25
29-7/8
46-7/8
2-1/2
7-1/2
25-3/8
47-5/8
2-1/2
Acceptable electrical
outlet area
30_install_fse_ge.eps
Dimension from wall to front of
closed oven door handle is 27-3/4.
30
25
29-7/8
46-7/8
2-1/2
7-1/2
25-3/8
47-5/8
2-1/2
Acceptable electrical
outlet area
30_install_fse_ge.eps
Dimension from wall to front of
closed oven door handle is 27-3/4.
†Note: Check local codes for required breaker size.
Effective January 1, 1996, the National Electrical
Code requires that new construction (not existing)
utilize a 4-conductor connection to an electric range.
Receptacle Locations: Locally approved flexible
service cord or conduit must be used because
terminals are not accessible after range installation.
See shaded area in drawing for location of electrical
outlet box. Recommended outlet locations allow
range to be installed directly against wall.
Installation information: Before installing, consult
installation instructions packed with product for
current dimensional data.
All 30" GE gas and electric range backguards
are 30-7/8" wide.*
Note: 30" ranges conform to U.L. requirements
for 0" spacing from adjacent walls below
countertops. To reduce possible scorching of
walls, engineering recommends a minimum of
1-1/2" spacing to allow for possible extended,
high heat, no-load heating element operation.
*Fits most countertop backsplash applications.
Consult Use & Care Manual for detailed
installation instructions.
30-7/8"

JB650ED
GE®30" Free-Standing Electric Range
Features and Benefits
• Self-cleanwithsteamcleanoption-Givestheoptionofself-cleaningorsteamcleaning
• 5.3cu.ft.ovencapacity-Enoughroomtocookanentiremealatonce
• 9"/12"dualelement-Choosea9"or12"heatingelement
• 6"/9"PowerBoil™element-Producesrapid,powerfulheat
• Fifthelementwarmingzone-Provideslow-heatcapabilityforfoodsonthecooktop
• Hiddenbakeoveninterior-Concealsthelowerovenelementtoslimplifycleaning
•  T r u e T e m p ™oven system - Even heat distribution and maximum oven control
• ModelJB650EDES-Slate
Specification Revised 6/12 321545
